# 问题描述

今天在一套测试环境下遇到了如下问题，当数据库执行update后，debezium中止并报错：

```
[FATAL] Replication stream was unexpectedly terminated: ERROR:  no known snapshots
CONTEXT:  slot "myslot", output plugin "debezium", in the change callback, associated LSN 19/B6A4A448
```

（左右滑动查看完整内容）

# 故障处理过程

首先查询数据库运行日志。

```
2021-08-09 11:31:45.370 CST [62063] postgres@mydb app=debezium LOG:  received replication command: IDENTIFY_SYSTEM
2021-08-09 11:31:45.373 CST [62063] postgres@mydb app=debezium LOG:  received replication command: START_REPLICATION SLOT "myslot" LOGICAL 19/B22FE808 ("error_policy" 'exit',"table_list_path" '/home/postgres/app/table_list.conf')
2021-08-09 11:31:45.373 CST [62063] postgres@mydb app=debezium LOG:  starting logical decoding for slot "myslot"
2021-08-09 11:31:45.373 CST [62063] postgres@mydb app=debezium DETAIL:  streaming transactions committing after 19/B3000000, reading WAL from 19/B22FE808
2021-08-09 11:31:45.373 CST [62063] postgres@mydb app=debezium LOG:  logical decoding found consistent point at 19/B22FE808
2021-08-09 11:31:45.373 CST [62063] postgres@mydb app=debezium DETAIL:  There are no running transactions.
Mon Aug  9 11:31:46 CST 2021
2021-08-09 11:31:46.629 CST [62063] postgres@mydb app=debezium ERROR:  no known snapshots
2021-08-09 11:31:46.629 CST [62063] postgres@mydb app=debezium CONTEXT:  slot "myslot", output plugin "debezium", in the change callback, associated LSN 19/B6A4A448
```

（左右滑动查看完整内容）

初步怀疑是复制槽的问题，在主库查询出该复制槽，进行手动删除。让debezium重新生成一个新复制槽，发现不行，报错依旧，包括重启数据库，都不好使。。

再次分析日志，通过上述日志中的报错信息“DETAIL: There are no running transactions.”，定位源码是

snapbuild.c中执行SnapBuildFindSnapshot函数。源码内容如下。

```
  /*
   * a) No transaction were running, we can jump to consistent.
   *
   * This is not affected by races around xl_running_xacts, because we can
   * miss transaction commits, but currently not transactions starting.
   *
   * NB: We might have already started to incrementally assemble a snapshot,
   * so we need to be careful to deal with that.
   */
  if (running->oldestRunningXid == running->nextXid)
  {
    if (builder->start_decoding_at == InvalidXLogRecPtr ||
      builder->start_decoding_at <= lsn)
      /* can decode everything after this */
      builder->start_decoding_at = lsn + 1;

    /* As no transactions were running xmin/xmax can be trivially set. */
    builder->xmin = running->nextXid;  /* < are finished */
    builder->xmax = running->nextXid;  /* >= are running */

    /* so we can safely use the faster comparisons */
    Assert(TransactionIdIsNormal(builder->xmin));
    Assert(TransactionIdIsNormal(builder->xmax));

    builder->state = SNAPBUILD_CONSISTENT;
    SnapBuildStartNextPhaseAt(builder, InvalidTransactionId);

    ereport(LOG,
        (errmsg("logical decoding found consistent point at %X/%X",
            (uint32) (lsn >> 32), (uint32) lsn),
         errdetail("There are no running transactions.")));

    return false;
  }
```

（左右滑动查看完整内容）

执行判断条件running->oldestRunningXid == running->nextXid为true，说明获取的的旧的事务ID和新的事务ID相同，抛出上述日志信息。

继续通过查询源码定位到是tuptoaster.c中执行init_toast_snapshot函数抛出的异常。

```
/* ----------
 * init_toast_snapshot
 *
 *  Initialize an appropriate TOAST snapshot.  We must use an MVCC snapshot
 *  to initialize the TOAST snapshot; since we don't know which one to use,
 *  just use the oldest one.  This is safe: at worst, we will get a "snapshot
 *  too old" error that might have been avoided otherwise.
 */
static void
init_toast_snapshot(Snapshot toast_snapshot)
{
  Snapshot  snapshot = GetOldestSnapshot();

  if (snapshot == NULL)
    elog(ERROR, "no known snapshots");

  InitToastSnapshot(*toast_snapshot, snapshot->lsn, snapshot->whenTaken);
}
```

（左右滑动查看完整内容）

这一块代码就是初始化一个合适的TOAST快照，会获取最老的一个快照，由于没获取到导致snapshot变量为NULL，导致异常被抛出。

目前通过修改表结构，将行外存储改为行内存储。

经验证后问题不再出现。
至此问题初步解决。
