10 - 教你如何动态注册Spark UDF和UDAF

MLSQL之道 2021-09-23

2069

今天笔者解密MLSQL是如何动态注册UDF和UDAF的（Scala版本），笔者从分析解决问题思路展开讨论。一步一步实现，学习解决问题的思路。培养解决问题的思维很重要，不断受益。

Spark注册UDF和UDAF都是通过以下接口：

spark.sessionState.udfRegistration

下面先分析如何实现UDF，进入udfRegistration：

  def register(name: String, udf: UserDefinedFunction): UserDefinedFunction = {
    def builder(children: Seq[Expression]) = udf.apply(children.map(Column.apply) : _*).expr
    functionRegistry.createOrReplaceTempFunction(name, builder)
    udf
  }


----------------------------------------
UserDefinedFunction的apply方法：
    def apply(exprs: Column*): Column = {
    // TODO: make sure this class is only instantiated through `SparkUserDefinedFunction.create()`
    / and `nullableTypes` is always set.
    if (nullableTypes.isEmpty) {
      nullableTypes = Some(ScalaReflection.getParameterTypeNullability(f))
    }
    if (inputTypes.isDefined) {
      assert(inputTypes.get.length == nullableTypes.get.length)
    }


    Column(ScalaUDF(
      f,
      dataType,
      exprs.map(_.expr),
      nullableTypes.get,
      inputTypes.getOrElse(Nil),
      udfName = _nameOption,
      nullable = _nullable,
      udfDeterministic = _deterministic))
  }

只需要构造UserDefinedFunction，然后看到它的apply中有ScalaUDF，查看一下构造的具体描述：

/**
 * User-defined function.
 * @param function  The user defined scala function to run.
 *                  Note that if you use primitive parameters, you are not able to check if it is
 *                  null or not, and the UDF will return null for you if the primitive input is
 *                  null. Use boxed type or [[Option]] if you wanna do the null-handling yourself.
 * @param dataType  Return type of function.
 * @param children  The input expressions of this UDF.
 */
case class ScalaUDF(
    function: AnyRef,
    dataType: DataType,
    children: Seq[Expression],
    inputsNullSafe: Seq[Boolean],
    inputTypes: Seq[DataType] = Nil,
    udfName: Option[String] = None,
    nullable: Boolean = true,
    udfDeterministic: Boolean = true)
  extends Expression with ImplicitCastInputTypes with NonSQLExpression with UserDefinedExpression {

这里面有三个比较重要的参数，function为处理数据的函数，dataType是函数的返回类型，children是UDF接收的表达式（比如udf(max(age)) ,max(age)为接收的表达式）

用户输入的是脚本，如何编译Scala脚本呢？Google可以找到用mkToolBox动态编译Scala，或者去https://docs.scala-lang.org/overviews/reflection下面找找，可以看到symbols-trees-types.html。

从网上找的一个示例：

import scala.reflect.runtime.universe
import scala.tools.reflect.ToolBox


private object RuntimeCompilationTest{
  val tb = universe.runtimeMirror(getClass.getClassLoader).mkToolBox()


  val classDef = tb.parse {
    """
      |private class MyParser extends Function[String,String]{
      |  override def apply(v1: String): String = v1 + "123"
      |}
      |
      |scala.reflect.classTag[MyParser].runtimeClass
    """.stripMargin
  }




  val clazz = tb.compile(classDef).apply().asInstanceOf[Class[Function[String,String]]]


  val instance = clazz.getConstructor().newInstance()
  println(instance.apply("asdf"))
}

根据这个示例来构造一个工具类：

object ScriptCodeCompiler extends Logging {


  def newInstance(clazz: Class[_]): Any = {
    val constructor = clazz.getDeclaredConstructors.head
    constructor.setAccessible(true)
    constructor.newInstance()
  }


  def getMethod(clazz: Class[_], method: String) = {
    val candidate = clazz.getDeclaredMethods.filter(_.getName == method).filterNot(_.isBridge)
    if (candidate.isEmpty) {
      throw new Exception(s"No method $method found in class ${clazz.getCanonicalName}")
    } else if (candidate.length > 1) {
      throw new Exception(s"Multiple method $method found in class ${clazz.getCanonicalName}")
    } else {
      candidate.head
    }
  }


  def compileScala(src: String): Class[_] = {
    import scala.reflect.runtime.universe
    import scala.tools.reflect.ToolBox
    val classLoader = scala.reflect.runtime.universe.getClass.getClassLoader
    val tb = universe.runtimeMirror(classLoader).mkToolBox()
    val tree = tb.parse(src)
    val clazz = tb.compile(tree).apply().asInstanceOf[Class[_]]
    clazz
  }


  def prepareScala(src: String, className: String): String = {
    src + "\n" + s"scala.reflect.classTag[$className].runtimeClass"
  }
}

接下来实现ScalaUDF的两个主要参数的构造：

object ScalaSourceUDF {


//因为输入是脚本，比如
//def apply(a:Double,b:Double)={
//   a + b
//}
//因此要把它包裹成一个类。
   def wrapClass(function: String) = {
     val className = s"WowUDF_${UUID.randomUUID().toString.replaceAll("-", "")}"
     val newfun = s"""
         |class  ${className}{
         |
         |${function}
         |
         |}
            """.stripMargin
    (className, newfun)
  }


  def apply(src: String, className: String, methodName: Option[String]): (AnyRef, DataType) = {
    val (argumentNum, returnType) = getFunctionReturnType(src, className, methodName)
    (generateFunction(src, className, methodName, argumentNum), returnType)
  }


//需要根据反射获取函数返回的类型和参数的个数，参数的个数用于new函数
  private def getFunctionReturnType(src: String, className: String, methodName: Option[String]): (Int, DataType) = {
  val clazz = SourceCodeCompiler.compileScala(SourceCodeCompiler.prepareScala(src, className))
  val method = SourceCodeCompiler.getMethod(clazz, methodName.getOrElse("apply"))
  val dataType: (DataType, Boolean) = JavaTypeInference.inferDataType(method.getReturnType)
      (method.getParameterCount, dataType._1)
  }


//构造函数，根据反射调用真实的函数，case class最大支持参数是22个，因此要实现22个new Function，也限制了UDF参数的个数不能超过22个
  def generateFunction(src: String, className: String, methodName: Option[String], argumentNum: Int): AnyRef = {
      lazy val clazz = SourceCodeCompiler.compileScala(SourceCodeCompiler.prepareScala(src, className))
      lazy val instance = SourceCodeCompiler.newInstance(clazz)
      lazy val method = SourceCodeCompiler.getMethod(clazz, methodName.getOrElse("apply"))
    argumentNum match {
      case 0 => new Function0[Any] with Serializable {
    override def apply(): Any = {
          method.invoke(instance)
        }
      }
      case 1 => new Function1[Object, Any] with Serializable {
    override def apply(v1: Object): Any = {
          method.invoke(instance, v1)
        }
      }
     ...


}

下面来写测试程序：

    val scalaScript =
      """
        |def apply(a:Double,b:Double)={
        |   a + b
        |}
      """.stripMargin


    val (className, src) = ScalaSourceUDF.wrapClass(scalaScript)
    val clazz = ScriptCodeCompiler.compileScala(ScriptCodeCompiler.prepareScala(src, className))


    val (func, returnType) = ScalaSourceUDF(src, className, Some("apply"))


    spark.sessionState.udfRegistration.register("wowPlus" ,UserDefinedFunction(func ,returnType ,None))


    import spark.implicits._


    val testDf = Seq(1 ,2 ,3).toDF("a").createOrReplaceTempView("test")


    spark.sql("select wowPlus(a ,1) a from test").show(false)


---------------结果---------------


+---+
|a  |
+---+
|2.0|
|3.0|
|4.0|
+---+

第二部分，如何实现UDAF：

  def register(name: String, udaf: UserDefinedAggregateFunction): UserDefinedAggregateFunction = {
  def builder(children: Seq[Expression]) = ScalaUDAF(children, udaf)
    functionRegistry.createOrReplaceTempFunction(name, builder)
    udaf
  }

UserDefinedAggregateFunction是一个抽象类，比case class简单些，只需要实现这个类，通过反射机制获取方法信息，并调用相应方法：

object ScalaSourceUDAF {
    def apply(src: String, className: String): UserDefinedAggregateFunction = {
        generateAggregateFunction(src, className)
    }


    private def generateAggregateFunction(src: String, className: String): UserDefinedAggregateFunction = {
        new UserDefinedAggregateFunction with Serializable {


            @transient val clazzUsingInDriver = ScriptCodeCompiler.compileScala(ScriptCodeCompiler.prepareScala(src, className))
            @transient val instanceUsingInDriver = ScriptCodeCompiler.newInstance(clazzUsingInDriver)


            lazy val clazzUsingInExecutor = ScriptCodeCompiler.compileScala(ScriptCodeCompiler.prepareScala(src, className))
            lazy val instanceUsingInExecutor = ScriptCodeCompiler.newInstance(clazzUsingInExecutor)


             def invokeMethod[T: ClassTag](clazz: Class[_], instance: Any, method: String): T = {
                ScriptCodeCompiler.getMethod(clazz, method).invoke(instance).asInstanceOf[T]
            }


            val _inputSchema = invokeMethod[StructType](clazzUsingInDriver, instanceUsingInDriver, "inputSchema")
            val _dataType = invokeMethod[DataType](clazzUsingInDriver, instanceUsingInDriver, "dataType")
            val _bufferSchema = invokeMethod[StructType](clazzUsingInDriver, instanceUsingInDriver, "bufferSchema")
            val _deterministic = invokeMethod[Boolean](clazzUsingInDriver, instanceUsingInDriver, "deterministic")


            override def inputSchema: StructType = {
                _inputSchema
            }


            override def dataType: DataType = {
                _dataType
            }


            override def bufferSchema: StructType = {
                _bufferSchema
            }


            override def deterministic: Boolean = {
                _deterministic
            }


            lazy val _update = ScriptCodeCompiler.getMethod(clazzUsingInExecutor, "update")
            lazy val _merge = ScriptCodeCompiler.getMethod(clazzUsingInExecutor, "merge")
            lazy val _initialize = ScriptCodeCompiler.getMethod(clazzUsingInExecutor, "initialize")
            lazy val _evaluate = ScriptCodeCompiler.getMethod(clazzUsingInExecutor, "evaluate")


            override def update(buffer: MutableAggregationBuffer, input: Row): Unit = {
                _update.invoke(instanceUsingInExecutor, buffer, input)
            }


            override def merge(buffer1: MutableAggregationBuffer, buffer2: Row): Unit = {
                _merge.invoke(instanceUsingInExecutor, buffer1, buffer2)
            }


            override def initialize(buffer: MutableAggregationBuffer): Unit = {
                _initialize.invoke(instanceUsingInExecutor, buffer)
            }


            override def evaluate(buffer: Row): Any = {
                _evaluate.invoke(instanceUsingInExecutor, buffer)
            }




        }
    }
}

下面实现测试程序：

    val scalaScript =
      """
        |import org.apache.spark.sql.expressions.{MutableAggregationBuffer, UserDefinedAggregateFunction}
        |import org.apache.spark.sql.types._
        |import org.apache.spark.sql.Row
        |class SumAggregation extends UserDefinedAggregateFunction with Serializable{
        |    def inputSchema: StructType = new StructType().add("a", LongType)
        |    def bufferSchema: StructType =  new StructType().add("total", LongType)
        |    def dataType: DataType = LongType
        |    def deterministic: Boolean = true
        |    def initialize(buffer: MutableAggregationBuffer): Unit = {
        |      buffer.update(0, 0l)
        |    }
        |    def update(buffer: MutableAggregationBuffer, input: Row): Unit = {
        |      val sum   = buffer.getLong(0)
        |      val newitem = input.getLong(0)
        |      buffer.update(0, sum + newitem)
        |    }
        |    def merge(buffer1: MutableAggregationBuffer, buffer2: Row): Unit = {
        |      buffer1.update(0, buffer1.getLong(0) + buffer2.getLong(0))
        |    }
        |    def evaluate(buffer: Row): Any = {
        |      buffer.getLong(0)
        |    }
        |}
      """.stripMargin


    spark.sessionState.udfRegistration.register("wowSum" ,ScalaSourceUDAF(scalaScript, "SumAggregation"))


    import spark.implicits._


    val testDf = Seq(1 ,2 ,3).toDF("a").createOrReplaceTempView("test")


    spark.sql("select wowSum(a) a from test").show(false)


---------------结果---------------
+---+
|a  |
+---+
|6  |
+---+

本实现参照MLSQL的streaming.udf.ScalaRuntimeCompileUDAF和ScalaRuntimeCompileUDF，做了简化和部分修改。本示例以开发的角度，思考分析解决问题，希望对读者在分析解决问题上有所帮助。Java和Python版本实现请参照MLSQL：https://github.com/allwefantasy/mlsql的streaming.udf包。Python的实现基于jython，python包支持受限于jython的支持。
