18 - MLSQL on k8s（5） - JuiceFS加速Spark Shuffle

MLSQL之道 2021-09-24

1913

上一篇（17 - MLSQL on k8s（4） - JuiceFS共享配置）通过静态方式挂载MLSQL的配置，这篇笔者用JuiceFS动态挂载方式，来加速Spark Shuffle。

Spark在Shuffle阶段临时文件及RDD持久化存储会放到spark.local.dir/SPARK_LOCAL_DIRS下，使用逗号分隔可以配置多个不同磁盘的路径。在Spark on Yarn下，这个路径会被Yarn集群的配置LOCAL_DIRS所取代。在Spark on k8s下，这个路径默认是emptyDir Volume所取代，可以简单的理解为java.io.tmpDir对应的/tmp目录。

Spark有4种方式可以把K8S Volumn挂载到Executor/Driver Pod中。

hostPath: mounts a file or directory from the host node’s filesystem into a pod.
emptyDir: an initially empty volume created when a pod is assigned to a node.
nfs: mounts an existing NFS(Network File System) into a pod.
persistentVolumeClaim: mounts a PersistentVolume
into a pod.

为了加速Shuffle，可以通过增加本地磁盘的方式，挂载到多个本地磁盘（磁盘数量是有上限的），也就是hostPath方式；也可以挂载多个persistentVolumeClaim，下面笔者将用JuiceFS来实现。

构建JuiceFS动态persistentVolumeClaim，名为jtext-pvc：

$ mkdir dynamic-provisioning
$ cd dynamic-provisioning


$ cat > juicefs-sc-secret.sh << EOF
$ kubectl -n kube-system create secret generic juicefs-sc-secret \
  --from-literal=name=mhdfs \
  --from-literal=metaurl=redis://:123456@172.16.2.120:16379/2 \
  --from-literal=storage=hdfs \
  --from-literal=bucket=172.16.2.119:8020 \
  --from-literal=access-key=hdfs
EOF


$ cat > storageClass.yaml << EOF
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: juicefs-sc
provisioner: csi.juicefs.com
parameters:
  csi.storage.k8s.io/node-publish-secret-name: juicefs-sc-secret
  csi.storage.k8s.io/node-publish-secret-namespace: kube-system
  csi.storage.k8s.io/provisioner-secret-name: juicefs-sc-secret
  csi.storage.k8s.io/provisioner-secret-namespace: kube-system
reclaimPolicy: Delete
volumeBindingMode: Immediate
EOF


$ cat > persistentVolumeClaim.yaml << EOF
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: jtext-pvc
spec:
  accessModes:
  - ReadWriteMany
  resources:
    requests:
      storage: 1Gi
  storageClassName: juicefs-sc
EOF


$ sh juicefs-sc-secret.sh
secret/juicefs-sc-secret created


$ kubectl apply -f storageClass.yaml
storageclass.storage.k8s.io/juicefs-sc created


$ kubectl  apply -f persistentVolumeClaim.yaml
persistentvolumeclaim/jtext-pvc created

构建deployment文件：

cat > testp.yaml << EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: spark-hello
  namespace: default
spec:
  selector:
    matchLabels:
      app: spark-hello
  strategy:
    rollingUpdate:
      maxUnavailable: 0
    type: RollingUpdate
  template:
    metadata:
      labels:
        app: spark-hello
    spec:
      serviceAccountName: spark
      containers:
      - name: spark-hello
        args: [ "while true; do sleep 10000; done;" ]
        command:
          - /bin/sh
          - '-c'
        image: '172.16.2.66:5000/mlsql:3.0-j14-mlsql'
        imagePullPolicy: Always
        securityContext:
          runAsUser: 0
        volumeMounts:
          - name: juicefs-pv
            mountPath: /opt/mlsql/jar
            subPath: mlsql/mlsqljar
          - name: juicefs-pv
            mountPath: /opt/spark/conf
            subPath: mlsql/sparkconf
          - name: juicefs-pv
            mountPath: /opt/mlsql/script
            subPath: mlsql/script
      volumes:
        - name: juicefs-pv
          persistentVolumeClaim:
            claimName: one-gb-fs
EOF

接下来看MLSQL的启动脚本该如何写：

cat > mlsql-start-d.sh << EOF
ip=$(cat etc/hosts | head -n 8 | tail -n 1 | awk '{print $1}')
echo $ip
/opt/spark/bin/spark-submit --master k8s://https://172.16.2.62:6443 \
            --deploy-mode client     \
            --class streaming.core.StreamingApp  \
            --conf spark.kubernetes.container.image=172.16.2.66:5000/mlsql:3.0-j14-mlsql \
            --conf spark.kubernetes.container.image.pullPolicy=Always  \
            --conf spark.kubernetes.namespace=default                            \
            --conf spark.kubernetes.executor.request.cores=0.05  \
            --conf spark.kubernetes.executor.limit.cores=0.3                   \
            --conf spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.options.claimName=jtext-pvc \
            --conf spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.options.sizeLimit=1Gi \
            --conf spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.mount.path=/data \
            --conf spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.mount.subPath=cool \
            --conf spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.mount.readOnly=false\
            --conf spark.dynamicAllocation.enabled=true  \
            --conf spark.dynamicAllocation.shuffleTracking.enabled=true \
            --conf spark.dynamicAllocation.minExecutors=3 \
            --conf spark.dynamicAllocation.maxExecutors=4 \
            --conf spark.dynamicAllocation.executorIdleTimeout=60 \
            --conf spark.jars.ivy=/tmp/.ivy \
            --conf spark.driver.host=$ip \
            --conf spark.sql.cbo.enabled=true  \
            --conf spark.sql.adaptive.enabled=true  \
            --conf spark.sql.cbo.joinReorder.enabled=true  \
            --conf spark.sql.cbo.planStats.enabled=true  \
            --conf spark.sql.cbo.starSchemaDetection=true  \
            --conf spark.driver.maxResultSize=512m  \
            --conf spark.executor.memory=512m \
            --conf spark.driver.memory=512m \
            --conf spark.serializer=org.apache.spark.serializer.KryoSerializer  \
            --conf spark.kryoserializer.buffer.max=100m \
            --conf spark.executor.extraJavaOptions="-XX:+UnlockExperimentalVMOptions -XX:+UseZGC -XX:+UseContainerSupport  -Dio.netty.tryReflectionSetAccessible=true" \
            --conf spark.driver.extraJavaOptions="-XX:+UnlockExperimentalVMOptions -XX:+UseZGC -XX:+UseContainerSupport  -Dio.netty.tryReflectionSetAccessible=true -DREALTIME_LOG_HOME=/tmp/__mlsql__/logs" \
            --jars opt/mlsql/jar/juicefs-hadoop-0.11.0.jar \
            opt/mlsql/jar/streamingpro-mlsql-spark_3.0_2.12-2.1.0-SNAPSHOT.jar \
            -streaming.name mlsql \
            -streaming.rest true  \
            -streaming.thrift false  \
            -streaming.platform spark  \
            -streaming.enableHiveSupport true  \
            -streaming.spark.service true  \
            -streaming.job.cancel true              \
            -streaming.driver.port 9003
EOF


# 注意这个参数：spark.kubernetes.executor.volumes.persistentVolumeClaim.spark-local-dir-1.options.claimName=jtext-pvc
# Spark文档说明：spark.kubernetes.driver.volumes.[VolumeType].[VolumeName].options.[OptionName]=<value>
# VolumnName必须以 spark-local-dir- 开头。可以挂载多个。

启动MLSQL服务并进行测试，根据前文应该都很熟悉流程了，这里笔者就把要执行的命令列一下，就不重复描述了：

kubectl create -f tesp.yaml
kubectl get pods -o wide
docker ps | grep hello
docker exec -it  container_id bin/sh
cd opt/mlsql
nohup sh mlsql-start-d.sh &
curl -XPOST hello.mlsql.com/run/script -d 'sql=select 1 a as t;'

MLSQL服务启动后，在JuiceFS Format的Hdfs上可以看到：

hadoop fs -ls jfs://test/
drwxr-xr-x   - hdfs hdfs       4096 2021-03-06 23:31 jfs://test/mlsql
drwxr-xr-x   - hdfs hdfs       4096 2021-03-06 23:12 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7
[root@t1-27-70 jfsh]# hadoop fs -ls jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool
drwxr-xr-x   - hdfs hdfs       4096 2021-03-07 18:11 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/blockmgr-1d640b9c-a9b9-4158-922a-faf09c7bc94c
drwxr-xr-x   - hdfs hdfs       4096 2021-03-07 18:11 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/blockmgr-9c4ba9b4-f8cc-4b86-9e19-3bf2636bc4eb
drwxr-xr-x   - hdfs hdfs       4096 2021-03-07 18:07 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/blockmgr-c0cb6f2f-0303-4ee5-b0b2-64be3fb5c2ec
drwx------   - hdfs hdfs       4096 2021-03-07 18:07 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/spark-44b33eef-0c64-4626-ba59-c5c18fffca35
drwx------   - hdfs hdfs       4096 2021-03-07 18:11 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/spark-4c13d70a-e5ca-4137-9496-b732a2a36e56
drwx------   - hdfs hdfs       4096 2021-03-07 18:11 jfs://test/pvc-a5ea07cc-8f4f-475f-98ef-fc67d77c0dc7/cool/spark-7ea25290-b70e-4305-9d30-843a8887a7d5
