Spark2.x精通：ShuffleReader过程源码深度剖析

override def runTask(context: TaskContext): U = {

    val threadMXBean = ManagementFactory.getThreadMXBean
    val deserializeStartTime = System.currentTimeMillis()
    val deserializeStartCpuTime = if (threadMXBean.isCurrentThreadCpuTimeSupported) {
      threadMXBean.getCurrentThreadCpuTime
    } else 0L
    val ser = SparkEnv.get.closureSerializer.newInstance()
    //从广播变量获取rdd和func并进行反序列化ResultTask，结果为rdd,和func函数
    //taskBinary的值是在DAGScheduler.submitMissingTasks()方法中进行序列化的
    val (rdd, func) = ser.deserialize[(RDD[T], (TaskContext, Iterator[T]) => U)](
      ByteBuffer.wrap(taskBinary.value), Thread.currentThread.getContextClassLoader)
    _executorDeserializeTime = System.currentTimeMillis() - deserializeStartTime
    _executorDeserializeCpuTime = if (threadMXBean.isCurrentThreadCpuTimeSupported) {
      threadMXBean.getCurrentThreadCpuTime - deserializeStartCpuTime
    } else 0L
    // 对rdd中每个parition迭代执行，这里的RDD为ShuffleRDD，会调用ShuffleRDD中
    // 的compute()函数，然后从各个ShuffleMapTask的输出结果中拉取数据处理
    func(context, rdd.iterator(partition, context))
  }

  override def compute(split: Partition, context: TaskContext): Iterator[(K, C)] = {
    val dep = dependencies.head.asInstanceOf[ShuffleDependency[K, V, C]]
    SparkEnv.get.shuffleManager.getReader(dep.shuffleHandle, split.index, split.index + 1, context)
      .read()
      .asInstanceOf[Iterator[(K, C)]]
  }

  override def getReader[K, C](
      handle: ShuffleHandle,
      startPartition: Int,
      endPartition: Int,
      context: TaskContext): ShuffleReader[K, C] = {
    new BlockStoreShuffleReader(
      handle.asInstanceOf[BaseShuffleHandle[K, _, C]], startPartition, endPartition, context)
  }

 override def read(): Iterator[Product2[K, C]] = {
   //实例化手，后面用于拉取多种block数据。对于local block，它将从本地block manager获取block数据；
   // 对于remote block，它通过使用BlockTransferService拉取remote block

   // 里面有几个重要的参数

   //1.spark.reducer.maxSizeInFlight 默认48MB，该参数用于设置shuffle read task的buffer缓冲大小，决定每次拉取多少数据  非常重要 重要 重要！！！

   //2.spark.reducer.maxReqsInFlight 远程机器拉取本机器文件块的请求数，随着集群增大，需要对此做出限制。否则可能会使本机负载过大而挂掉,一般不需要修改

   //3.REDUCER_MAX_BLOCKS_IN_FLIGHT_PER_ADDRESS 每个reduce任务从给定主机端口获取的远程块的数量。当在一次获取或同时从给定地址请求大量块时，这可能会导致服务执行程序或节点管理器崩溃。
   // 这对于在启用外部shuffle时减少节点管理器上的负载特别有用。您可以通过将其设置为较低的值来减轻这个问题

   //4.spark.maxRemoteBlockSizeFetchToMem ,默认值Int.MaxValue - 512 当块的大小超过此阈值时，远程块将被提取到磁盘.一般都降低spill阈值,增加spill频率减少内存压力
   //Reduce 获取数据时，由于数据倾斜，有可能造成单个 Block 的数据非常的大，默认情况下是需要有足够的内存来保存单个 Block 的数据。因此，此时极有可能因为数据倾斜造成 OOM

   //spark.shuffle.detectCorrupt  获取数据后是否对数据进行校验，默认为true 一般不需要调整
    val wrappedStreams = new ShuffleBlockFetcherIterator(
      context,
      blockManager.shuffleClient,
      blockManager,
      //根据shuffleId和开始结束分区 通过mapOutputTracker获取的需要拉取数据块列表
      mapOutputTracker.getMapSizesByExecutorId(handle.shuffleId, startPartition, endPartition),
      serializerManager.wrapStream,
      // Note: we use getSizeAsMb when no suffix is provided for backwards compatibility
      SparkEnv.get.conf.getSizeAsMb("spark.reducer.maxSizeInFlight", "48m") * 1024 * 1024,
      SparkEnv.get.conf.getInt("spark.reducer.maxReqsInFlight", Int.MaxValue),
      SparkEnv.get.conf.get(config.REDUCER_MAX_BLOCKS_IN_FLIGHT_PER_ADDRESS),
      SparkEnv.get.conf.get(config.MAX_REMOTE_BLOCK_SIZE_FETCH_TO_MEM),
      SparkEnv.get.conf.getBoolean("spark.shuffle.detectCorrupt", true))

    val serializerInstance = dep.serializer.newInstance()

    // Create a key/value iterator for each stream
    //对每个流建立数据迭代器
    val recordIter = wrappedStreams.flatMap { case (blockId, wrappedStream) =>
      // Note: the asKeyValueIterator below wraps a key/value iterator inside of a
      // NextIterator. The NextIterator makes sure that close() is called on the
      // underlying InputStream when all records have been read.
      serializerInstance.deserializeStream(wrappedStream).asKeyValueIterator
    }

    // Update the context task metrics for each record read.
    val readMetrics = context.taskMetrics.createTempShuffleReadMetrics()
    val metricIter = CompletionIterator[(Any, Any), Iterator[(Any, Any)]](
      recordIter.map { record =>
        readMetrics.incRecordsRead(1)
        record
      },
      context.taskMetrics().mergeShuffleReadMetrics())

    // An interruptible iterator must be used here in order to support task cancellation
    val interruptibleIter = new InterruptibleIterator[(Any, Any)](context, metricIter)
     //下面就是做了一些聚合操作

      //判断会否指定了聚合操作
    //内部使用ExternalAppendOnlyMap进行聚合操作，类似ExternalSort的实现，
    //这里没有排序，只是对key,value进行聚合操作
    val aggregatedIter: Iterator[Product2[K, C]] = if (dep.aggregator.isDefined) {
      if (dep.mapSideCombine) {
        // We are reading values that are already combined
        val combinedKeyValuesIterator = interruptibleIter.asInstanceOf[Iterator[(K, C)]]
        dep.aggregator.get.combineCombinersByKey(combinedKeyValuesIterator, context)
      } else {
        //合并聚合值
        val keyValuesIterator = interruptibleIter.asInstanceOf[Iterator[(K, Nothing)]]
        dep.aggregator.get.combineValuesByKey(keyValuesIterator, context)
      }
    } else {
      //如果没有聚合  这里进行完整聚合操作
      require(!dep.mapSideCombine, "Map-side combine without Aggregator specified!")
      interruptibleIter.asInstanceOf[Iterator[Product2[K, C]]]
    }

    //这里做了一些排序
    dep.keyOrdering match {
     //判断是否需要排序
      case Some(keyOrd: Ordering[K]) =>
        //
        // 对于需要排序的情况，创建一个ExtenrnalSorter实例，使用ExtenrnalSorter进行排序，
        // 这里需要注意，如果spark.shuffle.spill是false的话，数据是不会写入硬盘的。
        val sorter =
          new ExternalSorter[K, C, C](context, ordering = Some(keyOrd), serializer = dep.serializer)
        sorter.insertAll(aggregatedIter)
        context.taskMetrics().incMemoryBytesSpilled(sorter.memoryBytesSpilled)
        context.taskMetrics().incDiskBytesSpilled(sorter.diskBytesSpilled)
        context.taskMetrics().incPeakExecutionMemory(sorter.peakMemoryUsedBytes)
        CompletionIterator[Product2[K, C], Iterator[Product2[K, C]]](sorter.iterator, sorter.stop())
      case None =>
        aggregatedIter
    }
  }

private[this] def initialize(): Unit = {
    // Add a task completion callback (called in both success case and failure case) to cleanup.
    context.addTaskCompletionListener(_ => cleanup())

    //区分local block和remote block,本地数据块和远程数据块拉取肯定是不一样的
    // 这里获取了哪些需要从远程拉取的
    val remoteRequests = splitLocalRemoteBlocks()
    // Add the remote requests into our queue in a random order
    fetchRequests ++= Utils.randomize(remoteRequests)
    assert ((0 == reqsInFlight) == (0 == bytesInFlight),
      "expected reqsInFlight = 0 but found reqsInFlight = " + reqsInFlight +
      ", expected bytesInFlight = 0 but found bytesInFlight = " + bytesInFlight)
     //发送fetch request获取remote block
    fetchUpToMaxBytes()

    val numFetches = remoteRequests.size - fetchRequests.size
    logInfo("Started " + numFetches + " remote fetches in" + Utils.getUsedTimeMs(startTime))

    // 获取本地数据块
    fetchLocalBlocks()
    logDebug("Got local blocks in " + Utils.getUsedTimeMs(startTime))
  }
