HBase2.x源码剖析：HMaster启动过程

大数据开发运维架构 2020-04-03

1779

一、概述

本文基于HBase-2.2.1分析HMaster的启动流程。由于HMaster启动代码比较多，这里只是将主要函数拿出来说一下，其实主要做了以下几件事：

1).获取配置文件，对HBasemaster进行了实例化，由于HMaster继承自HRregionServer，先调用HRegionServer的构造函数进行初始化；

2).HRegionServer构造函数主要是对做了一些校验，如果启用了Kerberos先进行进行了登录，启动zookeper对于hbase znode的监听，获取master对应znode节点变化，同时启动对于集群状态变化的监听；

3).HMasterr构造函数启动balaner，实例化MetricsMaster统计Master数据供webUI接口调用；

4).最后调用run函数，循环向zk中注册成为active Master，一直阻塞循环直到写入成功为止，成功后进入finishInitialization()函数并初始化master。

二、源码剖析

1.一般我们单独启动HMaster的启动命令是：

/data/app/hbase-2.2.1/bin/hbase-daemon.sh start master

2.hbase-daemon.sh脚本做了以下工作：

1).设置master进程文件目录，默认是/tmp，进程文件名为：hbase-${USER}-master.pid

2).master日志路径，默认为$HBASE_HOME/logs

3).获取JAVA_HOME，所以环境变量或者hbase-env.sh一定配置JAVA_HOME

4).最后调用以下函数进行启动

(start)
    check_before_start
    hbase_rotate_log $HBASE_LOGOUT
    hbase_rotate_log $HBASE_LOGGC
    echo running $command, logging to $HBASE_LOGOUT
    $thiscmd --config "${HBASE_CONF_DIR}" \
        foreground_start $command $args < dev/null > ${HBASE_LOGOUT} 2>&1  &
    disown -h -r
    sleep 1; head "${HBASE_LOGOUT}"
  ;;

3.入口函数是是HMaster类的main函数,代码如下：

  /**
   * @see org.apache.hadoop.hbase.master.HMasterCommandLine
   */
  public static void main(String [] args) {
    LOG.info("STARTING service " + HMaster.class.getSimpleName());
    //这里没啥东西  就是打印版本信息
    VersionInfo.logVersion();
    //实例化一个HMasterCommandLine对象，执行该对象的doMain(args)方法
    new HMasterCommandLine(HMaster.class).doMain(args);
  }

4.下面看HMasterCommandLine的doMain()，这个函数在其父类ServerCommandLine中，代码如下：

  public void doMain(String args[]) {
    try {
    //通过ToolRunner机制执行启动/停止等命令
      int ret = ToolRunner.run(HBaseConfiguration.create(), this, args);
      if (ret != 0) {
        System.exit(ret);
      }
    } catch (Exception e) {
      LOG.error("Failed to run", e);
      System.exit(-1);
    }
  }

5.调用ToolRunner.run()，将conf,args封装到了GenericOptionsParser，然后返回到HMasterCommandLine的run()方法中去执行，封装代码：

public static int run(Configuration conf, Tool tool, String[] args)
    throws Exception{
    if(conf == null) {
      conf = new Configuration();
    }
    //封装成了GenericOptionsParser 对象，然后调用HMasterCommandLine的run函数启动master
    GenericOptionsParser parser = new GenericOptionsParser(conf, args);
    //set the configuration back, so that Tool can configure itself
    tool.setConf(conf);
    //get the args w/o generic hadoop args
    String[] toolArgs = parser.getRemainingArgs();
    return tool.run(toolArgs);
  }

6.后面直接看HMasterCommandLine的run()函数，代码如下：

@Override
  public int run(String args[]) throws Exception {
    Options opt = new Options();
    opt.addOption("localRegionServers", true,
      "RegionServers to start in master process when running standalone");
    opt.addOption("masters", true, "Masters to start in this process");
    opt.addOption("minRegionServers", true, "Minimum RegionServers needed to host user tables");
    opt.addOption("backup", false, "Do not try to become HMaster until the primary fails");

    CommandLine cmd; //获取cmd 其实就一个start  参数
    try {
      cmd = new GnuParser().parse(opt, args);
    } catch (ParseException e) {
      LOG.error("Could not parse: ", e);
      usage(null);
      return 1;
    }
    //下面就是一些判断了，直接跳过 下面代码省略掉一部分判断，各种判断
    if (cmd.hasOption("minRegionServers")) {
    .....................................
    @SuppressWarnings("unchecked")
    List<String> remainingArgs = cmd.getArgList();
    if (remainingArgs.size() != 1) {
      usage(null);
      return 1;
    }

    String command = remainingArgs.get(0);

    if ("start".equals(command)) {
    //  跳了一圈最后执行的是这个startMaster()函数
      return startMaster();
    } else if ("stop".equals(command)) {
      return stopMaster();
    } else if ("clear".equals(command)) {
      return (ZNodeClearer.clear(getConf()) ? 0 : 1);
    } else {
      usage("Invalid command: " + command);
      return 1;
    }
  }

7.下面这个startMaster()函数，才是真正的HMaster启动，代码如下：

private int startMaster() {
    //初始化conf配置
    Configuration conf = getConf();
    TraceUtil.initTracer(conf);
    try {
      // If 'local', defer to LocalHBaseCluster instance.  Starts master
      // and regionserver both in the one JVM.
      //如果是本地默认，这master和regionserver在一个节点上启动，我们是集群模式 直接跳过
      if (LocalHBaseCluster.isLocal(conf)) {
      .............................
      } else {

      //直接看这里，打印配置信息到日志里面
        logProcessInfo(getConf());
        //这里构造一个HMaster线程,由于Hmaster继承自HRegionser类，这里会构造HRegionser，执行初始化
        HMaster master = HMaster.constructMaster(masterClass, conf);
        if (master.isStopped()) {
          LOG.info("Won't bring the Master up as a shutdown is requested");
          return 1;
        }
        //调用start 和join方法
        master.start();
        master.join();
        if(master.isAborted())
          throw new RuntimeException("HMaster Aborted");
      }
    } catch (Throwable t) {
      LOG.error("Master exiting", t);
      return 1;
    }
    return 0;
  }

8.由于Hmaster继承自HRegionser类，这里会构造HRegionser，执行初始化，看下HRegionser的构造函数：

public HRegionServer(Configuration conf) throws IOException {
    super("RegionServer");  // thread name
    TraceUtil.initTracer(conf);
    try {
      this.startcode = System.currentTimeMillis();
      this.conf = conf;
      this.fsOk = true;
      //下面都是一些校验
      this.masterless = conf.getBoolean(MASTERLESS_CONFIG_NAME, false);
      this.eventLoopGroupConfig = setupNetty(this.conf);
      //检查是否有足够的内存分配给Memstore和Block Cache使用
      //memstore 默认分配40%的内存给Memstore 由参数hbase.regionserver.global.memstore.size控制
      //block cache也是默认分配40% 由参数hfile.block.cache.size控制
      //就是说memstore和Block cache 内存不能大于80%  否则报错
      MemorySizeUtil.checkForClusterFreeHeapMemoryLimit(this.conf);
      //文件格式通过hfile.format.version配置。老版本是2  现在是3 只能是2 和3
      HFile.checkHFileVersion(this.conf);
      checkCodecs(this.conf);
      this.userProvider = UserProvider.instantiate(conf);
      //checksum校验 一般设置为flase不校验
      FSUtils.setupShortCircuitRead(this.conf);

      // Disable usage of meta replicas in the regionserver
      this.conf.setBoolean(HConstants.USE_META_REPLICAS, false);
      // Config'ed params
      //重试次数
      this.numRetries = this.conf.getInt(HConstants.HBASE_CLIENT_RETRIES_NUMBER,
          HConstants.DEFAULT_HBASE_CLIENT_RETRIES_NUMBER);
      this.threadWakeFrequency = conf.getInt(HConstants.THREAD_WAKE_FREQUENCY, 10 * 1000);
       //regionserver合并周期
      this.compactionCheckFrequency = conf.getInt(PERIOD_COMPACTION, this.threadWakeFrequency);
      this.flushCheckFrequency = conf.getInt(PERIOD_FLUSH, this.threadWakeFrequency);
      this.msgInterval = conf.getInt("hbase.regionserver.msginterval", 3 * 1000);

      this.sleeper = new Sleeper(this.msgInterval, this);

      boolean isNoncesEnabled = conf.getBoolean(HConstants.HBASE_RS_NONCES_ENABLED, true);
      this.nonceManager = isNoncesEnabled ? new ServerNonceManager(this.conf) : null;

      this.numRegionsToReport = conf.getInt("hbase.regionserver.numregionstoreport", 10);

      this.operationTimeout = conf.getInt(HConstants.HBASE_CLIENT_OPERATION_TIMEOUT,
          HConstants.DEFAULT_HBASE_CLIENT_OPERATION_TIMEOUT);

      this.shortOperationTimeout = conf.getInt(HConstants.HBASE_RPC_SHORTOPERATION_TIMEOUT_KEY,
          HConstants.DEFAULT_HBASE_RPC_SHORTOPERATION_TIMEOUT);

      this.abortRequested = false;
      this.stopped = false;

      //这里比较重要 调用createRpcService生成RSRpcServices对象
      //在构造RpcServer对象的过程中，HMaster和HRegionServer分别创建rpcserver服务
      // 以使HMaster和HRegionServer响应不同的rpc服务
      rpcServices = createRpcServices();
      useThisHostnameInstead = getUseThisHostnameInstead(conf);
      String hostName =
          StringUtils.isBlank(useThisHostnameInstead) ? this.rpcServices.isa.getHostName()
              : this.useThisHostnameInstead;
      //根据主机名 端口和 启动时间确定服务名
      //格式大约是这样的master.hadoop.ljs:16000：时间戳
      serverName = ServerName.valueOf(hostName, this.rpcServices.isa.getPort(), this.startcode);

      rpcControllerFactory = RpcControllerFactory.instantiate(this.conf);
      rpcRetryingCallerFactory = RpcRetryingCallerFactory.instantiate(this.conf);

      // login the zookeeper client principal (if using security)
      //这里只有在开启了kerberos的安全集群才会进行zookeeper的登录
      //非安全集群这里忽略
      ZKUtil.loginClient(this.conf, HConstants.ZK_CLIENT_KEYTAB_FILE,
          HConstants.ZK_CLIENT_KERBEROS_PRINCIPAL, hostName);
      // login the server principal (if using secure Hadoop)
      //这里也一样 非安全集群 可忽略
      login(userProvider, hostName);
      // init superusers and add the server principal (if using security)
      // or process owner as default super user.
      Superusers.initialize(conf);
      //实例化RegionServerAccounting 它用来记录此rs中所有的memstore所占大小的实例
      regionServerAccounting = new RegionServerAccounting(conf);
      //HBase2.0中Master节点可以有表 默认为false
      boolean isMasterNotCarryTable =
          this instanceof HMaster && !LoadBalancer.isTablesOnMaster(conf);

      // isMasterNotCarryTable为false 需要创建block cache缓存和 MOB缓存
      if (!isMasterNotCarryTable) {
        blockCache = BlockCacheFactory.createBlockCache(conf);
        mobFileCache = new MobFileCache(conf);
      }

      uncaughtExceptionHandler = new UncaughtExceptionHandler() {
        @Override
        public void uncaughtException(Thread t, Throwable e) {
          abort("Uncaught exception in executorService thread " + t.getName(), e);
        }
      };
      //获取HBase在hdfs上的各个存储目录 比如WAL预写日志 数据存储路径等
      initializeFileSystem();

      //hbase-site.xml中读取span   RegionServer参数指标
      spanReceiverHost = SpanReceiverHost.getInstance(getConfiguration());

      this.configurationManager = new ConfigurationManager();
      setupWindows(getConfiguration(), getConfigurationManager());

      // Some unit tests don't need a cluster, so no zookeeper at all
      if (!conf.getBoolean("hbase.testing.nocluster", false)) {
        //这里获取zookeeper连接，并启动hbase  znode节点的监听
        zooKeeper = new ZKWatcher(conf, getProcessName() + ":" +
          rpcServices.isa.getPort(), this, canCreateBaseZNode());
        // If no master in cluster, skip trying to track one or look for a cluster status.
        if (!this.masterless) {
          if (conf.getBoolean(HBASE_SPLIT_WAL_COORDINATED_BY_ZK,
            DEFAULT_HBASE_SPLIT_COORDINATED_BY_ZK)) {
            this.csm = new ZkCoordinatedStateManager(this);
          }
          //根据zookeeper相关信息，设置MasterAddressTracker 构造一个Master地址的监听器
          masterAddressTracker = new MasterAddressTracker(getZooKeeper(), this);
         //启动对于Hbase znode对应的监听，
         masterAddressTracker.start();
          //创建一个对集群状态的监听
          clusterStatusTracker = new ClusterStatusTracker(zooKeeper, this);
          //启动监听
          clusterStatusTracker.start();
        } else {
          masterAddressTracker = null;
          clusterStatusTracker = null;
        }
      } else {
        zooKeeper = null;
        masterAddressTracker = null;
        clusterStatusTracker = null;
      }
      //启动rpc  等待regionserver端和客户端的请求
      this.rpcServices.start(zooKeeper);
      // This violates 'no starting stuff in Constructor' but Master depends on the below chore
      // and executor being created and takes a different startup route. Lots of overlap between HRS
      // and M (An M IS A HRS now). Need to refactor so less duplication between M and its super
      // Master expects Constructor to put up web servers. Ugh.
      // class HRS. TODO.
      this.choreService = new ChoreService(getName(), true);
      this.executorService = new ExecutorService(getName());
      putUpWebUI();
    } catch (Throwable t) {
      // Make sure we log the exception. HRegionServer is often started via reflection and the
      // cause of failed startup is lost.
      LOG.error("Failed construction RegionServer", t);
      throw t;
    }
  }

9.HRegionserver父类构造函数执行完成之后，调用HMaster的构造函数，这里看下代码：

public HMaster(final Configuration conf)
      throws IOException, KeeperException {
    super(conf);
    TraceUtil.initTracer(conf);
    try {
      if (conf.getBoolean(MAINTENANCE_MODE, false)) {
        LOG.info("Detected {}=true via configuration.", MAINTENANCE_MODE);
        maintenanceMode = true;
      } else if (Boolean.getBoolean(MAINTENANCE_MODE)) {
        LOG.info("Detected {}=true via environment variables.", MAINTENANCE_MODE);
        maintenanceMode = true;
      } else {
        maintenanceMode = false;
      }
      //存储regionserver异常的内存缓存
      this.rsFatals = new MemoryBoundedLogMessageBuffer(
          conf.getLong("hbase.master.buffer.for.rs.fatals", 1 * 1024 * 1024));
      LOG.info("hbase.rootdir=" + getRootDir() +
          ", hbase.cluster.distributed=" + this.conf.getBoolean(HConstants.CLUSTER_DISTRIBUTED, false));

      // Disable usage of meta replicas in the master
      this.conf.setBoolean(HConstants.USE_META_REPLICAS, false);

      //这里修改conf配置，然后将replication相关特性写入conf中
      decorateMasterConfiguration(this.conf);

      // Hack! Maps DFSClient => Master for logs.  HDFS made this
      // config param for task trackers, but we can piggyback off of it.
      if (this.conf.get("mapreduce.task.attempt.id") == null) {
        this.conf.set("mapreduce.task.attempt.id", "hb_m_" + this.serverName.toString());
      }
      //实例化hbase的监控
      this.metricsMaster = new MetricsMaster(new MetricsMasterWrapperImpl(this));

      // preload table descriptor at startup
      this.preLoadTableDescriptors = conf.getBoolean("hbase.master.preload.tabledescriptors", true);

      this.maxBlancingTime = getMaxBalancingTime();
      this.maxRitPercent = conf.getDouble(HConstants.HBASE_MASTER_BALANCER_MAX_RIT_PERCENT,
          HConstants.DEFAULT_HBASE_MASTER_BALANCER_MAX_RIT_PERCENT);

      // 集群状态发表。 比如当regionService 死了，要立即告知client ，不要用client等待socket回应了。
      boolean shouldPublish = conf.getBoolean(HConstants.STATUS_PUBLISHED,
          HConstants.STATUS_PUBLISHED_DEFAULT);
      Class<? extends ClusterStatusPublisher.Publisher> publisherClass =
          conf.getClass(ClusterStatusPublisher.STATUS_PUBLISHER_CLASS,
              ClusterStatusPublisher.DEFAULT_STATUS_PUBLISHER_CLASS,
              ClusterStatusPublisher.Publisher.class);

      if (shouldPublish) {
        if (publisherClass == null) {
          LOG.warn(HConstants.STATUS_PUBLISHED + " is true, but " +
              ClusterStatusPublisher.DEFAULT_STATUS_PUBLISHER_CLASS +
              " is not set - not publishing status");
        } else {
          clusterStatusPublisherChore = new ClusterStatusPublisher(this, conf, publisherClass);
          getChoreService().scheduleChore(clusterStatusPublisherChore);
        }
      }

      // Some unit tests don't need a cluster, so no zookeeper at all
      if (!conf.getBoolean("hbase.testing.nocluster", false)) {
        //视图将Master信息写入到zookeeper中，这里构造函数会启动一个zookeeper  对Mater的znode的监听
        //接收zookeeer的事件
        this.activeMasterManager = new ActiveMasterManager(zooKeeper, this.serverName, this);
      } else {
        this.activeMasterManager = null;
      }
    } catch (Throwable t) {
      // Make sure we log the exception. HMaster is often started via reflection and the
      // cause of failed startup is lost.
      LOG.error("Failed construction of Master", t);
      throw t;
    }
  }

10.最后调用HMaster中的run()函数，这里会启动一个循环，在成为活动主服务器后，通过调用regionserver运行循环;在成为主节点之前一直阻塞。

@Override
  public void run() {
    try {
      if (!conf.getBoolean("hbase.testing.nocluster", false)) {
        Threads.setDaemonThreadRunning(new Thread(() -> {
          try {
            int infoPort = putUpJettyServer();
            startActiveMasterManager(infoPort);
          } catch (Throwable t) {
            // Make sure we log the exception.
            String error = "Failed to become Active Master";
            LOG.error(error, t);
            // Abort should have been called already.
            if (!isAborted()) {
              abort(error, t);
            }
          }
        }), getName() + ":becomeActiveMaster");
      }
      // Fall in here even if we have been aborted. Need to run the shutdown services and
      // the super run call will do this for us.
      super.run();
    } finally {
      if (this.clusterSchemaService != null) {
        // If on way out, then we are no longer active master.
        this.clusterSchemaService.stopAsync();
        try {
          this.clusterSchemaService.awaitTerminated(
              getConfiguration().getInt(HBASE_MASTER_WAIT_ON_SERVICE_IN_SECONDS,
              DEFAULT_HBASE_MASTER_WAIT_ON_SERVICE_IN_SECONDS), TimeUnit.SECONDS);
        } catch (TimeoutException te) {
          LOG.warn("Failed shutdown of clusterSchemaService", te);
        }
      }
      this.activeMaster = false;
    }
  }

至此，HMaster启动的大体流程剖析完毕，这里只是分析了主流程，很多细节需要你自己再去看看源码。

如果觉得我的文章能帮到您，请关注微信公众号“大数据开发运维架构”，并转发朋友圈，谢谢支持！！！

数据库

文章转载自大数据开发运维架构，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

HBase2.x源码剖析：HMaster启动过程

评论
