flume kafka和sparkstreaming整合

数据湖 2020-09-14

235

本文介绍Flume、Kafka和Sparkstreaming的整合。代码流程是，我们通过shell脚本重播测试轨迹数据到指定轨迹文件中，使用Flume监听该轨迹数据文件，实时将轨迹数据发送到Kafka，然后使用SparkStreaming简单统计轨迹数据量。

简单介绍下Flume

flume核心角色是agent，每个Agent相当于数据传递员，agent内部有3大组件

source：源端数据采集，Flume内置多种Source，同时还提供了自定义的Source
Channel：数据传输通道，主要用的是memory channel和File channel
Sink：移动数据到目标端，如HDFS、KAFKA、DB以及自定义的sink

kafka和spark在这里就不做介绍了，之后会有大量文章分析Kafka和Spark。

代码整合流程：

1.将flume包下载到数据节点，解压，进入flume的conf目录，编辑 gps.conf

a1.sources = r1
a1.sinks = k1
a1.channels = c1


# Describe/configure the source
a1.sources.r1.type = exec
#flume监听轨迹文件内容的变化 tuch gps
a1.sources.r1.command = tail -F data/gps/gps
a1.sources.r1.fileHeader = true
#a1.sources.r1.ignorePattern=(^gps_)


# Describe the sink
a1.sinks.k1.type = org.apache.flume.sink.kafka.KafkaSink
#flume监听的文件数据发送到此kafka的主题当中
a1.sinks.k1.topic = gps_topic
a1.sinks.k1.brokerList= cdh1.macro.com:9092,cdh2.macro.com:9092,cdh3.macro.com:9092
a1.sinks.k1.batchSize = 20
a1.sinks.k1.requiredAcks = 1
a1.sinks.k1.producer.linger.ms = 1




# Use a channel which buffers events in memory
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100


# Bind the source and sink to the channel
a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

2.创建回放脚本 play_gps.sh

#!/bin/bash
srcfile=/data/gps/2020-9-13/testGps.log


outputpath=/data/gps/gps


echo "srcfile:"$srcfile
echo "outputpath:"$outputpath


while read line
do
#  sleep 0.01
  sleep 0.5
  echo $line
  `echo $line >>/data/gps/gps`
done <$srcfile


echo "compled!"

3.创建轨迹存放文件，也就是flume agent要监听的文件

创建数据存放路径，然后把准备好的轨迹数据放到此目录下

4.启动flume

[root@cdh3 bin]# nohup flume-ng  agent --name a1 --conf-file ../conf/gps.conf &
[1] 976
[root@cdh3 bin]# nohup: ignoring input and appending output to ‘nohup.out’
[root@cdh3 bin]# tail -f nohup.out
  transactional.id = null
  value.serializer = class org.apache.kafka.common.serialization.ByteArraySerializer


20/09/13 01:36:54 INFO utils.AppInfoParser: Kafka version : 2.0.1
20/09/13 01:36:54 INFO utils.AppInfoParser: Kafka commitId : fa14705e51bd2ce5
20/09/13 01:36:54 INFO instrumentation.MonitoredCounterGroup: Monitored counter group for type: SINK, name: k1: Successfully registered new MBean.
20/09/13 01:36:54 INFO instrumentation.MonitoredCounterGroup: Component type: SINK, name: k1 started
20/09/13 01:36:57 WARN clients.NetworkClient: [Producer clientId=producer-1] Connection to node -2 could not be established. Broker may not be available.
20/09/13 01:36:57 WARN clients.NetworkClient: [Producer clientId=producer-1] Error while fetching metadata with correlation id 2 : {gps_topic=LEADER_NOT_AVAILABLE}
20/09/13 01:36:57 INFO clients.Metadata: Cluster ID: 7Sq6gNsRQtW4c9eosNA6Nw

5.回放轨迹数据

[root@cdh3 ~]# sh play_gps.sh
srcfile:/data/gps/2020-9-13/testGps.log
outputpath:/data/gps/gps
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969147,104.07513,30.72724
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969150,104.07513,30.72702
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969154,104.07504,30.72672
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969156,104.07497,30.72630
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969159,104.07497,30.72582
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969162,104.07496,30.72544
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969168,104.07489,30.72487

6.数据回放后我们查看下kafka是否已经产生对应的主题

[root@cdh3 ~]# kafka-topics --zookeeper cdh1.macro.com:2181,cdh2.macro.com:2181,cdh3.macro.com:2181/kafka --list
20/09/13 01:39:34 INFO utils.Log4jControllerRegistration$: Registered kafka:type=kafka.Log4jController MBean
20/09/13 01:39:34 INFO zookeeper.ZooKeeperClient: [ZooKeeperClient] Initializing a new session to cdh1.macro.com:2181,cdh2.macro.com:2181,cdh3.macro.com:2181/kafka.
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:zookeeper.version=3.5.5-100-51e233a47ddbcf45f5aa690243bc31b25eded2a2, built on 08/05/2020 09:41 GMT
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:host.name=cdh3.macro.com
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:java.version=1.8.0_171
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:java.vendor=Oracle Corporation
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:java.io.tmpdir=/tmp
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:java.compiler=<NA>
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.name=Linux
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.arch=amd64
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.version=3.10.0-327.el7.x86_64
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:user.name=root
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:user.home=/root
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:user.dir=/root
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.memory.free=231MB
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.memory.max=256MB
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Client environment:os.memory.total=250MB
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Initiating client connection, connectString=cdh1.macro.com:2181,cdh2.macro.com:2181,cdh3.macro.com:2181/kafka sessionTimeout=30000 watcher=kafka.zookeeper.ZooKeeperClient$ZooKeeperClientWatcher$@4efbca5a
20/09/13 01:39:34 INFO common.X509Util: Setting -D jdk.tls.rejectClientInitiatedRenegotiation=true to disable client-initiated TLS renegotiation
20/09/13 01:39:34 INFO zookeeper.ClientCnxnSocket: jute.maxbuffer value is 4194304 Bytes
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: zookeeper.request.timeout value is 0. feature enabled=
20/09/13 01:39:34 INFO zookeeper.ZooKeeperClient: [ZooKeeperClient] Waiting until connected.
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: Opening socket connection to server cdh2.macro.com/192.168.0.207:2181. Will not attempt to authenticate using SASL (unknown error)
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: Socket error occurred: cdh2.macro.com/192.168.0.207:2181: Connection refused
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: Opening socket connection to server cdh3.macro.com/192.168.0.208:2181. Will not attempt to authenticate using SASL (unknown error)
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: Socket connection established, initiating session, client: 192.168.0.208:50761, server: cdh3.macro.com/192.168.0.208:2181
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: Session establishment complete on server cdh3.macro.com/192.168.0.208:2181, sessionid = 0x10014dbded001e2, negotiated timeout = 30000
20/09/13 01:39:34 INFO zookeeper.ZooKeeperClient: [ZooKeeperClient] Connected.
ATLAS_HOOK
ATLAS_SPARK_HOOK
__consumer_offsets
gps_topic
pos
20/09/13 01:39:34 INFO zookeeper.ZooKeeperClient: [ZooKeeperClient] Closing.
20/09/13 01:39:34 INFO zookeeper.ZooKeeper: Session: 0x10014dbded001e2 closed
20/09/13 01:39:34 INFO zookeeper.ClientCnxn: EventThread shut down for session: 0x10014dbded001e2
20/09/13 01:39:34 INFO zookeeper.ZooKeeperClient: [ZooKeeperClient] Closed.

7.可以看到kafka已经生成对应的topic，我们消费一下数据

[root@cdh3 ~]# kafka-console-consumer --bootstrap-server cdh1.macro.com:9092,cdh2.macro.com:9092,cdh3.macro.com:9092 --topic gps_topic
20/09/13 01:40:00 INFO utils.Log4jControllerRegistration$: Registered kafka:type=kafka.Log4jController MBean
20/09/13 01:40:00 INFO consumer.ConsumerConfig: ConsumerConfig values:
  allow.auto.create.topics = true
  auto.commit.interval.ms = 5000
  auto.offset.reset = latest
  bootstrap.servers = [cdh1.macro.com:9092, cdh2.macro.com:9092, cdh3.macro.com:9092]
  check.crcs = true
  client.dns.lookup = default
  client.id =
  client.rack =
  connections.max.idle.ms = 540000
  default.api.timeout.ms = 60000
  enable.auto.commit = false
  exclude.internal.topics = true
  fetch.max.bytes = 52428800
  fetch.max.wait.ms = 500
  fetch.min.bytes = 1
  group.id = console-consumer-31005
  group.instance.id = null
  heartbeat.interval.ms = 3000
  interceptor.classes = []
  internal.leave.group.on.close = true
  isolation.level = read_uncommitted
  key.deserializer = class org.apache.kafka.common.serialization.ByteArrayDeserializer
  max.partition.fetch.bytes = 1048576
  max.poll.interval.ms = 300000
  max.poll.records = 500
  metadata.max.age.ms = 300000
  metric.reporters = []
  metrics.num.samples = 2
  metrics.recording.level = INFO
  metrics.sample.window.ms = 30000
  partition.assignment.strategy = [class org.apache.kafka.clients.consumer.RangeAssignor]
  receive.buffer.bytes = 65536
  reconnect.backoff.max.ms = 1000
  reconnect.backoff.ms = 50
  request.timeout.ms = 30000
  retry.backoff.ms = 100
  sasl.client.callback.handler.class = null
  sasl.jaas.config = null
  sasl.kerberos.kinit.cmd = /usr/bin/kinit
  sasl.kerberos.min.time.before.relogin = 60000
  sasl.kerberos.service.name = null
  sasl.kerberos.ticket.renew.jitter = 0.05
  sasl.kerberos.ticket.renew.window.factor = 0.8
  sasl.login.callback.handler.class = null
  sasl.login.class = null
  sasl.login.refresh.buffer.seconds = 300
  sasl.login.refresh.min.period.seconds = 60
  sasl.login.refresh.window.factor = 0.8
  sasl.login.refresh.window.jitter = 0.05
  sasl.mechanism = GSSAPI
  security.protocol = PLAINTEXT
  security.providers = null
  send.buffer.bytes = 131072
  session.timeout.ms = 10000
  ssl.cipher.suites = null
  ssl.enabled.protocols = [TLSv1.2, TLSv1.1, TLSv1]
  ssl.endpoint.identification.algorithm = https
  ssl.key.password = null
  ssl.keymanager.algorithm = SunX509
  ssl.keystore.location = null
  ssl.keystore.password = null
  ssl.keystore.type = JKS
  ssl.protocol = TLS
  ssl.provider = null
  ssl.secure.random.implementation = null
  ssl.trustmanager.algorithm = PKIX
  ssl.truststore.location = null
  ssl.truststore.password = null
  ssl.truststore.type = JKS
  value.deserializer = class org.apache.kafka.common.serialization.ByteArrayDeserializer


20/09/13 01:40:01 INFO utils.AppInfoParser: Kafka version: 2.4.1.7.1.3.0-100
20/09/13 01:40:01 INFO utils.AppInfoParser: Kafka commitId: 0cfbf9b7ef3ca50d
20/09/13 01:40:01 INFO utils.AppInfoParser: Kafka startTimeMs: 1599932401067
20/09/13 01:40:01 INFO consumer.KafkaConsumer: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Subscribed to topic(s): gps_topic
20/09/13 01:40:01 INFO clients.Metadata: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Cluster ID: 7Sq6gNsRQtW4c9eosNA6Nw
20/09/13 01:40:01 INFO internals.AbstractCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Discovered group coordinator cdh3.macro.com:9092 (id: 2147483539 rack: null)
20/09/13 01:40:01 INFO internals.AbstractCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] (Re-)joining group
20/09/13 01:40:01 INFO internals.AbstractCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] (Re-)joining group
20/09/13 01:40:04 INFO internals.ConsumerCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Finished assignment for group at generation 1: {consumer-console-consumer-31005-1-d8761451-a2c6-4b40-a18e-ba4b27ee4315=Assignment(partitions=[gps_topic-0])}
20/09/13 01:40:04 INFO internals.AbstractCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Successfully joined group with generation 1
20/09/13 01:40:04 INFO internals.ConsumerCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Adding newly assigned partitions:gps_topic-0
20/09/13 01:40:04 INFO internals.ConsumerCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Found no committed offset for partition gps_topic-0
20/09/13 01:40:04 INFO internals.SubscriptionState: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Resetting offset for partition gps_topic-0 to offset 185.
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969700,104.10055,30.70650
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969702,104.10064,30.70634
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969706,104.10083,30.70603
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969711,104.10114,30.70549
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969714,104.10130,30.70521
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969717,104.10148,30.70491
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969724,104.10179,30.70438
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969727,104.10195,30.70411
8f20c9188561b796ef8e26196de30be4,39a096b71376b82f35732eff6d95779b,1477969730,104.10205,30.70393
^C20/09/13 01:40:21 INFO internals.ConsumerCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Revoke previously assigned partitions gps_topic-0
20/09/13 01:40:21 INFO internals.AbstractCoordinator: [Consumer clientId=consumer-console-consumer-31005-1, groupId=console-consumer-31005] Member consumer-console-consumer-31005-1-d8761451-a2c6-4b40-a18e-ba4b27ee4315 sending LeaveGroup request to coordinator cdh3.macro.com:9092 (id: 2147483539 rack: null) due to the consumer is being closed
Processed a total of 36 messages

用SparkStreaming代码消费Kafka数据

import org.apache.kafka.common.serialization.StringDeserializer
import org.apache.log4j.{Level, Logger}
import org.apache.spark.streaming.kafka010.ConsumerStrategies.Subscribe
import org.apache.spark.streaming.kafka010.KafkaUtils
import org.apache.spark.streaming.kafka010.LocationStrategies.PreferConsistent


object SparkStreamingAndKafka {
  def main(args: Array[String]): Unit = {
    import org.apache.spark._
    import org.apache.spark.streaming._
    Logger.getLogger("org").setLevel(Level.WARN)
    //表示使用两个线程来模拟spark集群
    val conf = new SparkConf().setAppName("SparkStreamingAndKafka").setMaster("local[2]")
    //初始化Spark Streaming环境
    val streamingContext = new StreamingContext(conf, Seconds(1))
    //设置检查点
    streamingContext.checkpoint("/sparkapp/tmp")


    //"auto.offset.reset" -> "earliest"
    val kafkaParams = Map[String, Object](
      "bootstrap.servers" -> "192.168.0.171:9092,192.168.0.207:9092,192.168.0.208:9092",
      "key.deserializer" -> classOf[StringDeserializer],
      "value.deserializer" -> classOf[StringDeserializer],
      "group.id" -> "test0002",
      "auto.offset.reset" -> "earliest",
      "enable.auto.commit" -> (false: java.lang.Boolean)
    )


    val topics = Array("cheng_du_gps_topic")


    topics.foreach(println(_))
    println("topics:" + topics)


    val stream = KafkaUtils.createDirectStream[String, String](
      streamingContext,
      PreferConsistent,
      Subscribe[String, String](topics, kafkaParams)
    )


    stream.count().print();


    //启动sparkstreaming程序
    streamingContext.start();
    streamingContext.awaitTermination();
    streamingContext.stop()
  }
}

8.输出结果

gps_topic
topics:[Ljava.lang.String;@54a3ab8f
20/09/13 03:25:39 WARN kafka010.KafkaUtils: overriding enable.auto.commit to false for executor
20/09/13 03:25:39 WARN kafka010.KafkaUtils: overriding auto.offset.reset to none for executor
20/09/13 03:25:39 WARN kafka010.KafkaUtils: overriding executor group.id to spark-executor-test0002
20/09/13 03:25:39 WARN kafka010.KafkaUtils: overriding receive.buffer.bytes to 65536 see KAFKA-3135
                                                                                -------------------------------------------
Time: 1599938740000 ms
-------------------------------------------
466


-------------------------------------------
Time: 1599938741000 ms
-------------------------------------------
0

至此flume、Kafka和sparkstreaming的整合完毕。

大数据

文章转载自数据湖，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

flume kafka和sparkstreaming整合

评论
