深入理解SpringBoot中的自动装配

马士兵 2020-04-23
147

今天跟大家分享常用的深入理解SpringBoot中的自动装配知识。

1 深入理解SpringBoot中的自动装配

SpringBoot的自动装配是拆箱即用的基础,也是微服务化的前提。其实它并不那么神秘,我在这之前已经写过最基本的实现了,大家可以参考这篇文章。这次主要的议题是,来看看它是怎么样实现的,我们透过源代码来把握自动装配的来龙去脉。

一、自动装配过程分析

1.1、关于@SpringBootApplication

我们在编写SpringBoot项目时,@SpringBootApplication是最常见的注解了,我们可以看一下源代码:

    /*
    * Copyright 2012-2017 the original author or authors.
    *
    * Licensed under the Apache License, Version 2.0 (the "License");
    * you may not use this file except in compliance with the License.
    * You may obtain a copy of the License at
    *
    * http://www.apache.org/licenses/LICENSE-2.0
    *
    * Unless required by applicable law or agreed to in writing, software
    * distributed under the License is distributed on an "AS IS" BASIS,
    * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
    * See the License for the specific language governing permissions and
    * limitations under the License.
    */


    package org.springframework.boot.autoconfigure;


    import java.lang.annotation.Documented;
    import java.lang.annotation.ElementType;
    import java.lang.annotation.Inherited;
    import java.lang.annotation.Retention;
    import java.lang.annotation.RetentionPolicy;
    import java.lang.annotation.Target;


    import org.springframework.boot.SpringBootConfiguration;
    import org.springframework.boot.context.TypeExcludeFilter;
    import org.springframework.context.annotation.Bean;
    import org.springframework.context.annotation.ComponentScan;
    import org.springframework.context.annotation.ComponentScan.Filter;
    import org.springframework.context.annotation.Configuration;
    import org.springframework.context.annotation.FilterType;
    import org.springframework.core.annotation.AliasFor;


    /**
    * Indicates a {@link Configuration configuration} class that declares one or more
    * {@link Bean @Bean} methods and also triggers {@link EnableAutoConfiguration
    * auto-configuration} and {@link ComponentScan component scanning}. This is a convenience
    * annotation that is equivalent to declaring {@code @Configuration},
    * {@code @EnableAutoConfiguration} and {@code @ComponentScan}.
    *
    * @author Phillip Webb
    * @author Stephane Nicoll
    * @since 1.2.0
    */
    @Target(ElementType.TYPE)
    @Retention(RetentionPolicy.RUNTIME)
    @Documented
    @Inherited
    @SpringBootConfiguration
    @EnableAutoConfiguration
    @ComponentScan(excludeFilters = {
    @Filter(type = FilterType.CUSTOM, classes = TypeExcludeFilter.class),
    @Filter(type = FilterType.CUSTOM, classes = AutoConfigurationExcludeFilter.class) })
    public @interface SpringBootApplication {


    /**
    * Exclude specific auto-configuration classes such that they will never be applied.
    * @return the classes to exclude
    */
    @AliasFor(annotation = EnableAutoConfiguration.class, attribute = "exclude")
    Class<?>[] exclude() default {};


    /**
    * Exclude specific auto-configuration class names such that they will never be
    * applied.
    * @return the class names to exclude
    * @since 1.3.0
    */
    @AliasFor(annotation = EnableAutoConfiguration.class, attribute = "excludeName")
    String[] excludeName() default {};


    /**
    * Base packages to scan for annotated components. Use {@link #scanBasePackageClasses}
    * for a type-safe alternative to String-based package names.
    * @return base packages to scan
    * @since 1.3.0
    */
    @AliasFor(annotation = ComponentScan.class, attribute = "basePackages")
    String[] scanBasePackages() default {};


    /**
    * Type-safe alternative to {@link #scanBasePackages} for specifying the packages to
    * scan for annotated components. The package of each class specified will be scanned.
    * <p>
    * Consider creating a special no-op marker class or interface in each package that
    * serves no purpose other than being referenced by this attribute.
    * @return base packages to scan
    * @since 1.3.0
    */
    @AliasFor(annotation = ComponentScan.class, attribute = "basePackageClasses")
    Class<?>[] scanBasePackageClasses() default {};


    }

    这里面包含了@SpringBootConfiguration,@EnableAutoConfiguration,@ComponentScan,此处@ComponentScan由于没有指定扫描包,因此它默认扫描的是与该类同级的类或者同级包下的所有类,另外@SpringBootConfiguration,通过源码得知它是一个@Configuration:

      /*
      * Copyright 2012-2016 the original author or authors.
      *
      * Licensed under the Apache License, Version 2.0 (the "License");
      * you may not use this file except in compliance with the License.
      * You may obtain a copy of the License at
      *
      * http://www.apache.org/licenses/LICENSE-2.0
      *
      * Unless required by applicable law or agreed to in writing, software
      * distributed under the License is distributed on an "AS IS" BASIS,
      * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
      * See the License for the specific language governing permissions and
      * limitations under the License.
      */


      package org.springframework.boot;


      import java.lang.annotation.Documented;
      import java.lang.annotation.ElementType;
      import java.lang.annotation.Retention;
      import java.lang.annotation.RetentionPolicy;
      import java.lang.annotation.Target;


      import org.springframework.context.annotation.Configuration;


      /**
      * Indicates that a class provides Spring Boot application
      * {@link Configuration @Configuration}. Can be used as an alternative to the Spring's
      * standard {@code @Configuration} annotation so that configuration can be found
      * automatically (for example in tests).
      * <p>
      * Application should only ever include <em>one</em> {@code @SpringBootConfiguration} and
      * most idiomatic Spring Boot applications will inherit it from
      * {@code @SpringBootApplication}.
      *
      * @author Phillip Webb
      * @since 1.4.0
      */
      @Target(ElementType.TYPE)
      @Retention(RetentionPolicy.RUNTIME)
      @Documented
      @Configuration
      public @interface SpringBootConfiguration {


      }

      由此我们可以推断出@SpringBootApplication等同于@Configuration @ComponentScan @EnableAutoConfiguration。更多相关内容:SpringBoot内容聚合

      1.2、@EnableAutoConfiguration

      一旦加上此注解,那么将会开启自动装配功能,简单点讲,Spring会试图在你的classpath下找到所有配置的Bean然后进行装配。当然装配Bean时,会根据若干个(Conditional)定制规则来进行初始化。我们看一下它的源码:

        /*
        * Copyright 2012-2017 the original author or authors.
        *
        * Licensed under the Apache License, Version 2.0 (the "License");
        * you may not use this file except in compliance with the License.
        * You may obtain a copy of the License at
        *
        * http://www.apache.org/licenses/LICENSE-2.0
        *
        * Unless required by applicable law or agreed to in writing, software
        * distributed under the License is distributed on an "AS IS" BASIS,
        * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
        * See the License for the specific language governing permissions and
        * limitations under the License.
        */


        package org.springframework.boot.autoconfigure;


        import java.lang.annotation.Documented;
        import java.lang.annotation.ElementType;
        import java.lang.annotation.Inherited;
        import java.lang.annotation.Retention;
        import java.lang.annotation.RetentionPolicy;
        import java.lang.annotation.Target;


        import org.springframework.boot.autoconfigure.condition.ConditionalOnBean;
        import org.springframework.boot.autoconfigure.condition.ConditionalOnClass;
        import org.springframework.boot.autoconfigure.condition.ConditionalOnMissingBean;
        import org.springframework.boot.context.embedded.EmbeddedServletContainerFactory;
        import org.springframework.boot.context.embedded.tomcat.TomcatEmbeddedServletContainerFactory;
        import org.springframework.context.annotation.Conditional;
        import org.springframework.context.annotation.Configuration;
        import org.springframework.context.annotation.Import;
        import org.springframework.core.io.support.SpringFactoriesLoader;


        /**
        * Enable auto-configuration of the Spring Application Context, attempting to guess and
        * configure beans that you are likely to need. Auto-configuration classes are usually
        * applied based on your classpath and what beans you have defined. For example, If you
        * have {@code tomcat-embedded.jar} on your classpath you are likely to want a
        * {@link TomcatEmbeddedServletContainerFactory} (unless you have defined your own
        * {@link EmbeddedServletContainerFactory} bean).
        * <p>
        * When using {@link SpringBootApplication}, the auto-configuration of the context is
        * automatically enabled and adding this annotation has therefore no additional effect.
        * <p>
        * Auto-configuration tries to be as intelligent as possible and will back-away as you
        * define more of your own configuration. You can always manually {@link #exclude()} any
        * configuration that you never want to apply (use {@link #excludeName()} if you don't
        * have access to them). You can also exclude them via the
        * {@code spring.autoconfigure.exclude} property. Auto-configuration is always applied
        * after user-defined beans have been registered.
        * <p>
        * The package of the class that is annotated with {@code @EnableAutoConfiguration},
        * usually via {@code @SpringBootApplication}, has specific significance and is often used
        * as a 'default'. For example, it will be used when scanning for {@code @Entity} classes.
        * It is generally recommended that you place {@code @EnableAutoConfiguration} (if you're
        * not using {@code @SpringBootApplication}) in a root package so that all sub-packages
        * and classes can be searched.
        * <p>
        * Auto-configuration classes are regular Spring {@link Configuration} beans. They are
        * located using the {@link SpringFactoriesLoader} mechanism (keyed against this class).
        * Generally auto-configuration beans are {@link Conditional @Conditional} beans (most
        * often using {@link ConditionalOnClass @ConditionalOnClass} and
        * {@link ConditionalOnMissingBean @ConditionalOnMissingBean} annotations).
        *
        * @author Phillip Webb
        * @author Stephane Nicoll
        * @see ConditionalOnBean
        * @see ConditionalOnMissingBean
        * @see ConditionalOnClass
        * @see AutoConfigureAfter
        * @see SpringBootApplication
        */
        @SuppressWarnings("deprecation")
        @Target(ElementType.TYPE)
        @Retention(RetentionPolicy.RUNTIME)
        @Documented
        @Inherited
        @AutoConfigurationPackage
        @Import(EnableAutoConfigurationImportSelector.class)
        public @interface EnableAutoConfiguration {


        String ENABLED_OVERRIDE_PROPERTY = "spring.boot.enableautoconfiguration";


        /**
        * Exclude specific auto-configuration classes such that they will never be applied.
        * @return the classes to exclude
        */
        Class<?>[] exclude() default {};


        /**
        * Exclude specific auto-configuration class names such that they will never be
        * applied.
        * @return the class names to exclude
        * @since 1.3.0
        */
        String[] excludeName() default {};


        }

        虽然根据文档注释的说明它指点我们去看EnableAutoConfigurationImportSelector。但是该类在SpringBoot1.5.X版本已经过时了,因此我们看一下它的父类AutoConfigurationImportSelector:

          /*
          * Copyright 2012-2017 the original author or authors.
          *
          * Licensed under the Apache License, Version 2.0 (the "License");
          * you may not use this file except in compliance with the License.
          * You may obtain a copy of the License at
          *
          * http://www.apache.org/licenses/LICENSE-2.0
          *
          * Unless required by applicable law or agreed to in writing, software
          * distributed under the License is distributed on an "AS IS" BASIS,
          * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
          * See the License for the specific language governing permissions and
          * limitations under the License.
          */


          package org.springframework.boot.autoconfigure;


          import java.io.IOException;
          import java.util.ArrayList;
          import java.util.Arrays;
          import java.util.Collections;
          import java.util.HashSet;
          import java.util.LinkedHashSet;
          import java.util.List;
          import java.util.Map;
          import java.util.Set;
          import java.util.concurrent.TimeUnit;


          import org.apache.commons.logging.Log;
          import org.apache.commons.logging.LogFactory;


          import org.springframework.beans.BeansException;
          import org.springframework.beans.factory.Aware;
          import org.springframework.beans.factory.BeanClassLoaderAware;
          import org.springframework.beans.factory.BeanFactory;
          import org.springframework.beans.factory.BeanFactoryAware;
          import org.springframework.beans.factory.NoSuchBeanDefinitionException;
          import org.springframework.beans.factory.config.ConfigurableListableBeanFactory;
          import org.springframework.boot.bind.RelaxedPropertyResolver;
          import org.springframework.context.EnvironmentAware;
          import org.springframework.context.ResourceLoaderAware;
          import org.springframework.context.annotation.DeferredImportSelector;
          import org.springframework.core.Ordered;
          import org.springframework.core.annotation.AnnotationAttributes;
          import org.springframework.core.env.ConfigurableEnvironment;
          import org.springframework.core.env.Environment;
          import org.springframework.core.io.ResourceLoader;
          import org.springframework.core.io.support.SpringFactoriesLoader;
          import org.springframework.core.type.AnnotationMetadata;
          import org.springframework.core.type.classreading.CachingMetadataReaderFactory;
          import org.springframework.core.type.classreading.MetadataReaderFactory;
          import org.springframework.util.Assert;
          import org.springframework.util.ClassUtils;
          import org.springframework.util.StringUtils;


          /**
          * {@link DeferredImportSelector} to handle {@link EnableAutoConfiguration
          * auto-configuration}. This class can also be subclassed if a custom variant of
          * {@link EnableAutoConfiguration @EnableAutoConfiguration}. is needed.
          *
          * @author Phillip Webb
          * @author Andy Wilkinson
          * @author Stephane Nicoll
          * @author Madhura Bhave
          * @since 1.3.0
          * @see EnableAutoConfiguration
          */
          public class AutoConfigurationImportSelector
          implements DeferredImportSelector, BeanClassLoaderAware, ResourceLoaderAware,
          BeanFactoryAware, EnvironmentAware, Ordered {


          private static final String[] NO_IMPORTS = {};


          private static final Log logger = LogFactory
          .getLog(AutoConfigurationImportSelector.class);


          private ConfigurableListableBeanFactory beanFactory;


          private Environment environment;


          private ClassLoader beanClassLoader;


          private ResourceLoader resourceLoader;


          @Override
          public String[] selectImports(AnnotationMetadata annotationMetadata) {
          if (!isEnabled(annotationMetadata)) {
          return NO_IMPORTS;
          }
          try {
          AutoConfigurationMetadata autoConfigurationMetadata = AutoConfigurationMetadataLoader
          .loadMetadata(this.beanClassLoader);
          AnnotationAttributes attributes = getAttributes(annotationMetadata);
          List<String> configurations = getCandidateConfigurations(annotationMetadata,
          attributes);
          configurations = removeDuplicates(configurations);
          configurations = sort(configurations, autoConfigurationMetadata);
          Set<String> exclusions = getExclusions(annotationMetadata, attributes);
          checkExcludedClasses(configurations, exclusions);
          configurations.removeAll(exclusions);
          configurations = filter(configurations, autoConfigurationMetadata);
          fireAutoConfigurationImportEvents(configurations, exclusions);
          return configurations.toArray(new String[configurations.size()]);
          }
          catch (IOException ex) {
          throw new IllegalStateException(ex);
          }
          }


          protected boolean isEnabled(AnnotationMetadata metadata) {
          return true;
          }


          /**
          * Return the appropriate {@link AnnotationAttributes} from the
          * {@link AnnotationMetadata}. By default this method will return attributes for
          * {@link #getAnnotationClass()}.
          * @param metadata the annotation metadata
          * @return annotation attributes
          */
          protected AnnotationAttributes getAttributes(AnnotationMetadata metadata) {
          String name = getAnnotationClass().getName();
          AnnotationAttributes attributes = AnnotationAttributes
          .fromMap(metadata.getAnnotationAttributes(name, true));
          Assert.notNull(attributes,
          "No auto-configuration attributes found. Is " + metadata.getClassName()
          + " annotated with " + ClassUtils.getShortName(name) + "?");
          return attributes;
          }


          /**
          * Return the source annotation class used by the selector.
          * @return the annotation class
          */
          protected Class<?> getAnnotationClass() {
          return EnableAutoConfiguration.class;
          }


          /**
          * Return the auto-configuration class names that should be considered. By default
          * this method will load candidates using {@link SpringFactoriesLoader} with
          * {@link #getSpringFactoriesLoaderFactoryClass()}.
          * @param metadata the source metadata
          * @param attributes the {@link #getAttributes(AnnotationMetadata) annotation
          * attributes}
          * @return a list of candidate configurations
          */
          protected List<String> getCandidateConfigurations(AnnotationMetadata metadata,
          AnnotationAttributes attributes) {
          List<String> configurations = SpringFactoriesLoader.loadFactoryNames(
          getSpringFactoriesLoaderFactoryClass(), getBeanClassLoader());
          Assert.notEmpty(configurations,
          "No auto configuration classes found in META-INF/spring.factories. If you "
          + "are using a custom packaging, make sure that file is correct.");
          return configurations;
          }


          /**
          * Return the class used by {@link SpringFactoriesLoader} to load configuration
          * candidates.
          * @return the factory class
          */
          protected Class<?> getSpringFactoriesLoaderFactoryClass() {
          return EnableAutoConfiguration.class;
          }


          private void checkExcludedClasses(List<String> configurations,
          Set<String> exclusions) {
          List<String> invalidExcludes = new ArrayList<String>(exclusions.size());
          for (String exclusion : exclusions) {
          if (ClassUtils.isPresent(exclusion, getClass().getClassLoader())
          && !configurations.contains(exclusion)) {
          invalidExcludes.add(exclusion);
          }
          }
          if (!invalidExcludes.isEmpty()) {
          handleInvalidExcludes(invalidExcludes);
          }
          }


          /**
          * Handle any invalid excludes that have been specified.
          * @param invalidExcludes the list of invalid excludes (will always have at least one
          * element)
          */
          protected void handleInvalidExcludes(List<String> invalidExcludes) {
          StringBuilder message = new StringBuilder();
          for (String exclude : invalidExcludes) {
          message.append("\t- ").append(exclude).append(String.format("%n"));
          }
          throw new IllegalStateException(String
          .format("The following classes could not be excluded because they are"
          + " not auto-configuration classes:%n%s", message));
          }


          /**
          * Return any exclusions that limit the candidate configurations.
          * @param metadata the source metadata
          * @param attributes the {@link #getAttributes(AnnotationMetadata) annotation
          * attributes}
          * @return exclusions or an empty set
          */
          protected Set<String> getExclusions(AnnotationMetadata metadata,
          AnnotationAttributes attributes) {
          Set<String> excluded = new LinkedHashSet<String>();
          excluded.addAll(asList(attributes, "exclude"));
          excluded.addAll(Arrays.asList(attributes.getStringArray("excludeName")));
          excluded.addAll(getExcludeAutoConfigurationsProperty());
          return excluded;
          }


          private List<String> getExcludeAutoConfigurationsProperty() {
          if (getEnvironment() instanceof ConfigurableEnvironment) {
          RelaxedPropertyResolver resolver = new RelaxedPropertyResolver(
          this.environment, "spring.autoconfigure.");
          Map<String, Object> properties = resolver.getSubProperties("exclude");
          if (properties.isEmpty()) {
          return Collections.emptyList();
          }
          List<String> excludes = new ArrayList<String>();
          for (Map.Entry<String, Object> entry : properties.entrySet()) {
          String name = entry.getKey();
          Object value = entry.getValue();
          if (name.isEmpty() || name.startsWith("[") && value != null) {
          excludes.addAll(new HashSet<String>(Arrays.asList(StringUtils
          .tokenizeToStringArray(String.valueOf(value), ","))));
          }
          }
          return excludes;
          }
          RelaxedPropertyResolver resolver = new RelaxedPropertyResolver(getEnvironment(),
          "spring.autoconfigure.");
          String[] exclude = resolver.getProperty("exclude", String[].class);
          return (Arrays.asList(exclude == null ? new String[0] : exclude));
          }


          private List<String> sort(List<String> configurations,
          AutoConfigurationMetadata autoConfigurationMetadata) throws IOException {
          configurations = new AutoConfigurationSorter(getMetadataReaderFactory(),
          autoConfigurationMetadata).getInPriorityOrder(configurations);
          return configurations;
          }


          private List<String> filter(List<String> configurations,
          AutoConfigurationMetadata autoConfigurationMetadata) {
          long startTime = System.nanoTime();
          String[] candidates = configurations.toArray(new String[configurations.size()]);
          boolean[] skip = new boolean[candidates.length];
          boolean skipped = false;
          for (AutoConfigurationImportFilter filter : getAutoConfigurationImportFilters()) {
          invokeAwareMethods(filter);
          boolean[] match = filter.match(candidates, autoConfigurationMetadata);
          for (int i = 0; i < match.length; i++) {
          if (!match[i]) {
          skip[i] = true;
          skipped = true;
          }
          }
          }
          if (!skipped) {
          return configurations;
          }
          List<String> result = new ArrayList<String>(candidates.length);
          for (int i = 0; i < candidates.length; i++) {
          if (!skip[i]) {
          result.add(candidates[i]);
          }
          }
          if (logger.isTraceEnabled()) {
          int numberFiltered = configurations.size() - result.size();
          logger.trace("Filtered " + numberFiltered + " auto configuration class in "
          + TimeUnit.NANOSECONDS.toMillis(System.nanoTime() - startTime)
          + " ms");
          }
          return new ArrayList<String>(result);
          }


          protected List<AutoConfigurationImportFilter> getAutoConfigurationImportFilters() {
          return SpringFactoriesLoader.loadFactories(AutoConfigurationImportFilter.class,
          this.beanClassLoader);
          }


          private MetadataReaderFactory getMetadataReaderFactory() {
          try {
          return getBeanFactory().getBean(
          SharedMetadataReaderFactoryContextInitializer.BEAN_NAME,
          MetadataReaderFactory.class);
          }
          catch (NoSuchBeanDefinitionException ex) {
          return new CachingMetadataReaderFactory(this.resourceLoader);
          }
          }


          protected final <T> List<T> removeDuplicates(List<T> list) {
          return new ArrayList<T>(new LinkedHashSet<T>(list));
          }


          protected final List<String> asList(AnnotationAttributes attributes, String name) {
          String[] value = attributes.getStringArray(name);
          return Arrays.asList(value == null ? new String[0] : value);
          }


          private void fireAutoConfigurationImportEvents(List<String> configurations,
          Set<String> exclusions) {
          List<AutoConfigurationImportListener> listeners = getAutoConfigurationImportListeners();
          if (!listeners.isEmpty()) {
          AutoConfigurationImportEvent event = new AutoConfigurationImportEvent(this,
          configurations, exclusions);
          for (AutoConfigurationImportListener listener : listeners) {
          invokeAwareMethods(listener);
          listener.onAutoConfigurationImportEvent(event);
          }
          }
          }


          protected List<AutoConfigurationImportListener> getAutoConfigurationImportListeners() {
          return SpringFactoriesLoader.loadFactories(AutoConfigurationImportListener.class,
          this.beanClassLoader);
          }


          private void invokeAwareMethods(Object instance) {
          if (instance instanceof Aware) {
          if (instance instanceof BeanClassLoaderAware) {
          ((BeanClassLoaderAware) instance)
          .setBeanClassLoader(this.beanClassLoader);
          }
          if (instance instanceof BeanFactoryAware) {
          ((BeanFactoryAware) instance).setBeanFactory(this.beanFactory);
          }
          if (instance instanceof EnvironmentAware) {
          ((EnvironmentAware) instance).setEnvironment(this.environment);
          }
          if (instance instanceof ResourceLoaderAware) {
          ((ResourceLoaderAware) instance).setResourceLoader(this.resourceLoader);
          }
          }
          }


          @Override
          public void setBeanFactory(BeanFactory beanFactory) throws BeansException {
          Assert.isInstanceOf(ConfigurableListableBeanFactory.class, beanFactory);
          this.beanFactory = (ConfigurableListableBeanFactory) beanFactory;
          }


          protected final ConfigurableListableBeanFactory getBeanFactory() {
          return this.beanFactory;
          }


          @Override
          public void setBeanClassLoader(ClassLoader classLoader) {
          this.beanClassLoader = classLoader;
          }


          protected ClassLoader getBeanClassLoader() {
          return this.beanClassLoader;
          }


          @Override
          public void setEnvironment(Environment environment) {
          this.environment = environment;
          }


          protected final Environment getEnvironment() {
          return this.environment;
          }


          @Override
          public void setResourceLoader(ResourceLoader resourceLoader) {
          this.resourceLoader = resourceLoader;
          }


          protected final ResourceLoader getResourceLoader() {
          return this.resourceLoader;
          }


          @Override
          public int getOrder() {
          return Ordered.LOWEST_PRECEDENCE - 1;
          }


          }

          首先该类实现了DeferredImportSelector接口,这个接口继承了ImportSelector:

            /*
            * Copyright 2002-2013 the original author or authors.
            *
            * Licensed under the Apache License, Version 2.0 (the "License");
            * you may not use this file except in compliance with the License.
            * You may obtain a copy of the License at
            *
            * http://www.apache.org/licenses/LICENSE-2.0
            *
            * Unless required by applicable law or agreed to in writing, software
            * distributed under the License is distributed on an "AS IS" BASIS,
            * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
            * See the License for the specific language governing permissions and
            * limitations under the License.
            */


            package org.springframework.context.annotation;


            import org.springframework.core.type.AnnotationMetadata;


            /**
            * Interface to be implemented by types that determine which @{@link Configuration}
            * class(es) should be imported based on a given selection criteria, usually one or more
            * annotation attributes.
            *
            * <p>An {@link ImportSelector} may implement any of the following
            * {@link org.springframework.beans.factory.Aware Aware} interfaces, and their respective
            * methods will be called prior to {@link #selectImports}:
            * <ul>
            * <li>{@link org.springframework.context.EnvironmentAware EnvironmentAware}</li>
            * <li>{@link org.springframework.beans.factory.BeanFactoryAware BeanFactoryAware}</li>
            * <li>{@link org.springframework.beans.factory.BeanClassLoaderAware BeanClassLoaderAware}</li>
            * <li>{@link org.springframework.context.ResourceLoaderAware ResourceLoaderAware}</li>
            * </ul>
            *
            * <p>ImportSelectors are usually processed in the same way as regular {@code @Import}
            * annotations, however, it is also possible to defer selection of imports until all
            * {@code @Configuration} classes have been processed (see {@link DeferredImportSelector}
            * for details).
            *
            * @author Chris Beams
            * @since 3.1
            * @see DeferredImportSelector
            * @see Import
            * @see ImportBeanDefinitionRegistrar
            * @see Configuration
            */
            public interface ImportSelector {


            /**
            * Select and return the names of which class(es) should be imported based on
            * the {@link AnnotationMetadata} of the importing @{@link Configuration} class.
            */
            String[] selectImports(AnnotationMetadata importingClassMetadata);


            }


            该接口主要是为了导入@Configuration的配置项,而DeferredImportSelector是延期导入,当所有的@Configuration都处理过后才会执行。更多相关内容:SpringBoot内容聚合

            回过头来我们看一下AutoConfigurationImportSelector的selectImport方法:

              @Override
              public String[] selectImports(AnnotationMetadata annotationMetadata) {
              if (!isEnabled(annotationMetadata)) {
              return NO_IMPORTS;
              }
              try {
              AutoConfigurationMetadata autoConfigurationMetadata = AutoConfigurationMetadataLoader
              .loadMetadata(this.beanClassLoader);
              AnnotationAttributes attributes = getAttributes(annotationMetadata);
              List<String> configurations = getCandidateConfigurations(annotationMetadata,
              attributes);
              configurations = removeDuplicates(configurations);
              configurations = sort(configurations, autoConfigurationMetadata);
              Set<String> exclusions = getExclusions(annotationMetadata, attributes);
              checkExcludedClasses(configurations, exclusions);
              configurations.removeAll(exclusions);
              configurations = filter(configurations, autoConfigurationMetadata);
              fireAutoConfigurationImportEvents(configurations, exclusions);
              return configurations.toArray(new String[configurations.size()]);
              }
              catch (IOException ex) {
              throw new IllegalStateException(ex);
              }
              }

              该方法刚开始会先判断是否进行自动装配,而后会从META-INF/spring-autoconfigure-metadata.properties读取元数据与元数据的相关属性,紧接着会调用getCandidateConfigurations方法:

                /**
                * Return the auto-configuration class names that should be considered. By default
                * this method will load candidates using {@link SpringFactoriesLoader} with
                * {@link #getSpringFactoriesLoaderFactoryClass()}.
                * @param metadata the source metadata
                * @param attributes the {@link #getAttributes(AnnotationMetadata) annotation
                * attributes}
                * @return a list of candidate configurations
                */
                protected List<String> getCandidateConfigurations(AnnotationMetadata metadata,
                AnnotationAttributes attributes) {
                List<String> configurations = SpringFactoriesLoader.loadFactoryNames(
                getSpringFactoriesLoaderFactoryClass(), getBeanClassLoader());
                Assert.notEmpty(configurations,
                "No auto configuration classes found in META-INF/spring.factories. If you "
                + "are using a custom packaging, make sure that file is correct.");
                return configurations;
                }


                /**
                * Return the class used by {@link SpringFactoriesLoader} to load configuration
                * candidates.
                * @return the factory class
                */
                protected Class<?> getSpringFactoriesLoaderFactoryClass() {
                return EnableAutoConfiguration.class;
                }

                在这里又遇到我们的老熟人了SpringFactoryiesLoader, 它会读取META-INF/spring.factories下的EnableAutoConfiguration的配置,紧接着在进行排除与过滤,进而得到需要装配的类。最后让所有配置在META-INF/spring.factories下的AutoConfigurationImportListener执行AutoConfigurationImportEvent事件,代码如下:

                  private void fireAutoConfigurationImportEvents(List<String> configurations,
                  Set<String> exclusions) {
                  List<AutoConfigurationImportListener> listeners = getAutoConfigurationImportListeners();
                  if (!listeners.isEmpty()) {
                  AutoConfigurationImportEvent event = new AutoConfigurationImportEvent(this,
                  configurations, exclusions);
                  for (AutoConfigurationImportListener listener : listeners) {
                  invokeAwareMethods(listener);
                  listener.onAutoConfigurationImportEvent(event);
                  }
                  }
                  }


                  protected List<AutoConfigurationImportListener> getAutoConfigurationImportListeners() {
                  return SpringFactoriesLoader.loadFactories(AutoConfigurationImportListener.class,
                  this.beanClassLoader);
                  }

                  二、何时进行自动装配

                  在前面的环节里只是最终要确定哪些类需要被装配,在SpringBoot时何时处理这些自动装配的类呢?下面我们简要的分析一下:

                  2.1、AbstractApplicationContext的refresh方法:

                  这个方法老生常谈了其中请大家关注一下这个方法:

                    // Invoke factory processors registered as beans in the context.
                    invokeBeanFactoryPostProcessors(beanFactory);

                    在这里是处理BeanFactoryPostProcessor的,那么我们在来看一下这个接口BeanDefinitionRegistryPostProcessor:

                      /*
                      * Copyright 2002-2010 the original author or authors.
                      *
                      * Licensed under the Apache License, Version 2.0 (the "License");
                      * you may not use this file except in compliance with the License.
                      * You may obtain a copy of the License at
                      *
                      * http://www.apache.org/licenses/LICENSE-2.0
                      *
                      * Unless required by applicable law or agreed to in writing, software
                      * distributed under the License is distributed on an "AS IS" BASIS,
                      * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
                      * See the License for the specific language governing permissions and
                      * limitations under the License.
                      */


                      package org.springframework.beans.factory.support;


                      import org.springframework.beans.BeansException;
                      import org.springframework.beans.factory.config.BeanFactoryPostProcessor;


                      /**
                      * Extension to the standard {@link BeanFactoryPostProcessor} SPI, allowing for
                      * the registration of further bean definitions <i>before</i> regular
                      * BeanFactoryPostProcessor detection kicks in. In particular,
                      * BeanDefinitionRegistryPostProcessor may register further bean definitions
                      * which in turn define BeanFactoryPostProcessor instances.
                      *
                      * @author Juergen Hoeller
                      * @since 3.0.1
                      * @see org.springframework.context.annotation.ConfigurationClassPostProcessor
                      */
                      public interface BeanDefinitionRegistryPostProcessor extends BeanFactoryPostProcessor {


                      /**
                      * Modify the application context's internal bean definition registry after its
                      * standard initialization. All regular bean definitions will have been loaded,
                      * but no beans will have been instantiated yet. This allows for adding further
                      * bean definitions before the next post-processing phase kicks in.
                      * @param registry the bean definition registry used by the application context
                      * @throws org.springframework.beans.BeansException in case of errors
                      */
                      void postProcessBeanDefinitionRegistry(BeanDefinitionRegistry registry) throws BeansException;


                      }

                      该接口继承了BeanFactoryPostProcessor。更多相关内容:SpringBoot内容聚合

                      2.2、ConfigurationClassPostProcessor 类

                      该类主要处理@Configuration注解的,它实现了BeanDefinitionRegistryPostProcessor, 那么也间接实现了BeanFactoryPostProcessor,关键代码如下:

                        @Override
                        public void postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory) {
                        int factoryId = System.identityHashCode(beanFactory);
                        if (this.factoriesPostProcessed.contains(factoryId)) {
                        throw new IllegalStateException(
                        "postProcessBeanFactory already called on this post-processor against " + beanFactory);
                        }
                        this.factoriesPostProcessed.add(factoryId);
                        if (!this.registriesPostProcessed.contains(factoryId)) {
                        // BeanDefinitionRegistryPostProcessor hook apparently not supported...
                        // Simply call processConfigurationClasses lazily at this point then.
                        processConfigBeanDefinitions((BeanDefinitionRegistry) beanFactory);
                        }


                        enhanceConfigurationClasses(beanFactory);
                        beanFactory.addBeanPostProcessor(new ImportAwareBeanPostProcessor(beanFactory));
                        }


                        /**
                        * Build and validate a configuration model based on the registry of
                        * {@link Configuration} classes.
                        */
                        public void processConfigBeanDefinitions(BeanDefinitionRegistry registry) {
                        //.....省略部分代码


                        // Parse each @Configuration class
                        ConfigurationClassParser parser = new ConfigurationClassParser(
                        this.metadataReaderFactory, this.problemReporter, this.environment,
                        this.resourceLoader, this.componentScanBeanNameGenerator, registry);


                        Set<BeanDefinitionHolder> candidates = new LinkedHashSet<BeanDefinitionHolder>(configCandidates);
                        Set<ConfigurationClass> alreadyParsed = new HashSet<ConfigurationClass>(configCandidates.size());
                        do {
                        parser.parse(candidates);
                        parser.validate();


                        Set<ConfigurationClass> configClasses = new LinkedHashSet<ConfigurationClass>(parser.getConfigurationClasses());
                        configClasses.removeAll(alreadyParsed);


                        // Read the model and create bean definitions based on its content
                        if (this.reader == null) {
                        this.reader = new ConfigurationClassBeanDefinitionReader(
                        registry, this.sourceExtractor, this.resourceLoader, this.environment,
                        this.importBeanNameGenerator, parser.getImportRegistry());
                        }
                        this.reader.loadBeanDefinitions(configClasses);
                        alreadyParsed.addAll(configClasses);


                        candidates.clear();
                        if (registry.getBeanDefinitionCount() > candidateNames.length) {
                        String[] newCandidateNames = registry.getBeanDefinitionNames();
                        Set<String> oldCandidateNames = new HashSet<String>(Arrays.asList(candidateNames));
                        Set<String> alreadyParsedClasses = new HashSet<String>();
                        for (ConfigurationClass configurationClass : alreadyParsed) {
                        alreadyParsedClasses.add(configurationClass.getMetadata().getClassName());
                        }
                        for (String candidateName : newCandidateNames) {
                        if (!oldCandidateNames.contains(candidateName)) {
                        BeanDefinition bd = registry.getBeanDefinition(candidateName);
                        if (ConfigurationClassUtils.checkConfigurationClassCandidate(bd, this.metadataReaderFactory) &&
                        !alreadyParsedClasses.contains(bd.getBeanClassName())) {
                        candidates.add(new BeanDefinitionHolder(bd, candidateName));
                        }
                        }
                        }
                        candidateNames = newCandidateNames;
                        }
                        }
                        while (!candidates.isEmpty());
                            // ....省略部分代码
                        }

                        其实这里注释已经很清楚了,我们可以清楚的看到解析每一个@ConfigurationClass的关键类是:ConfigurationClassParser,那么我们继续看一看这个类的parse方法:

                          public void parse(Set<BeanDefinitionHolder> configCandidates) {
                          this.deferredImportSelectors = new LinkedList<DeferredImportSelectorHolder>();


                          for (BeanDefinitionHolder holder : configCandidates) {
                          BeanDefinition bd = holder.getBeanDefinition();
                          try {
                          if (bd instanceof AnnotatedBeanDefinition) {
                          parse(((AnnotatedBeanDefinition) bd).getMetadata(), holder.getBeanName());
                          }
                          else if (bd instanceof AbstractBeanDefinition && ((AbstractBeanDefinition) bd).hasBeanClass()) {
                          parse(((AbstractBeanDefinition) bd).getBeanClass(), holder.getBeanName());
                          }
                          else {
                          parse(bd.getBeanClassName(), holder.getBeanName());
                          }
                          }
                          catch (BeanDefinitionStoreException ex) {
                          throw ex;
                          }
                          catch (Throwable ex) {
                          throw new BeanDefinitionStoreException(
                          "Failed to parse configuration class [" + bd.getBeanClassName() + "]", ex);
                          }
                          }


                          processDeferredImportSelectors();
                          }

                          在这里大家留意一下最后一句processDeferredImportSelectors方法,在这里将会对DeferredImportSelector进行处理,这样我们就和AutoConfigurationSelectImporter结合到一起了:

                            private void processDeferredImportSelectors() {
                            List<DeferredImportSelectorHolder> deferredImports = this.deferredImportSelectors;
                            this.deferredImportSelectors = null;
                            Collections.sort(deferredImports, DEFERRED_IMPORT_COMPARATOR);


                            for (DeferredImportSelectorHolder deferredImport : deferredImports) {
                            ConfigurationClass configClass = deferredImport.getConfigurationClass();
                            try {
                            String[] imports = deferredImport.getImportSelector().selectImports(configClass.getMetadata());
                            processImports(configClass, asSourceClass(configClass), asSourceClasses(imports), false);
                            }
                            catch (BeanDefinitionStoreException ex) {
                            throw ex;
                            }
                            catch (Throwable ex) {
                            throw new BeanDefinitionStoreException(
                            "Failed to process import candidates for configuration class [" +
                            configClass.getMetadata().getClassName() + "]", ex);
                            }
                            }
                            }

                            请大家关注这句代码:String[] imports = deferredImport.getImportSelector().selectImports(configClass.getMetadata());在这里deferredImport的类型为DeferredImportSelectorHolder:

                              private static class DeferredImportSelectorHolder {


                              private final ConfigurationClass configurationClass;


                              private final DeferredImportSelector importSelector;


                              public DeferredImportSelectorHolder(ConfigurationClass configClass, DeferredImportSelector selector) {
                              this.configurationClass = configClass;
                              this.importSelector = selector;
                              }


                              public ConfigurationClass getConfigurationClass() {
                              return this.configurationClass;
                              }


                              public DeferredImportSelector getImportSelector() {
                              return this.importSelector;
                              }
                              }

                              在这个内部类里持有了一个DeferredImportSelector的引用,至此将会执行自动装配的所有操作

                              三、总结

                              1)自动装配还是利用了SpringFactoriesLoader来加载META-INF/spring.factoires文件里所有配置的EnableAutoConfgruation,它会经过exclude和filter等操作,最终确定要装配的类

                              2) 处理@Configuration的核心还是ConfigurationClassPostProcessor,这个类实现了BeanFactoryPostProcessor, 因此当AbstractApplicationContext执行refresh方法里的invokeBeanFactoryPostProcessors(beanFactory)方法时会执行自动装配

                              如有收获请划至底部

                              点击“在看”支持,谢



                              关注马士兵

                              每天分享技术干货




                              点赞是最大的支持

                              文章转载自马士兵,如果涉嫌侵权,请发送邮件至:contact@modb.pro进行举报,并提供相关证据,一经查实,墨天轮将立刻删除相关内容。

                              评论
