hbase-2.1.0 源码阅读之Hmaster启动

用了这么久的HBase,今天开始着手HBase方面的源码阅读。2.1.0版本刚发布不久，是Hbase 2.x系列的第二次版本。旨在提高 HBase 的稳定性和可靠性，主要更新内容如下：

• 基于 Procedure v2 的复制对等修改

• 串行复制

• 最小 Hadoop 版本已更改为 2.7.1

• 成功完成从 1.4.3 到 2.1.0 的滚动升级，这表明可以从 1.x 滚动升级到 2.x

我们如何启动hbase master （代码块右滑可滚动）

# linxu 系统下：
bin/hbase-daemon.sh start master

我们来分析这里发生了什么，追本溯源，在脚本hbase-daemon.sh中：

case $startStop in
(start)
    check_before_start
    hbase_rotate_log $HBASE_LOGOUT
    hbase_rotate_log $HBASE_LOGGC
    echo running $command, logging to $HBASE_LOGOUT
    $thiscmd --config "${HBASE_CONF_DIR}" \
        foreground_start $command $args < dev/null > ${HBASE_LOGOUT} 2>&1  &
    disown -h -r
    sleep 1; head "${HBASE_LOGOUT}"
  ;;

这里发现通过start的时候,调用了foreground_start 来启动：

(foreground_start)
    trap cleanAfterRun SIGHUP SIGINT SIGTERM EXIT
    if [ "$HBASE_NO_REDIRECT_LOG" != "" ]; then
        # NO REDIRECT
        echo "`date` Starting $command on `hostname`"
        echo "`ulimit -a`"
        # in case the parent shell gets the kill make sure to trap signals.
        # Only one will get called. Either the trap or the flow will go through.
        nice -n $HBASE_NICENESS "$HBASE_HOME"/bin/hbase \
            --config "${HBASE_CONF_DIR}" \
            $command "$@" start &
    else
        echo "`date` Starting $command on `hostname`" >> ${HBASE_LOGLOG}
        echo "`ulimit -a`" >> "$HBASE_LOGLOG" 2>&1
        # in case the parent shell gets the kill make sure to trap signals.
        # Only one will get called. Either the trap or the flow will go through.
        nice -n $HBASE_NICENESS "$HBASE_HOME"/bin/hbase \
            --config "${HBASE_CONF_DIR}" \
            $command "$@" start >> ${HBASE_LOGOUT} 2>&1 &
    fi
    # Add to the command log file vital stats on our environment.
    hbase_pid=$!
    echo $hbase_pid > ${HBASE_PID}
    wait $hbase_pid
  ;;

可以看到最终调用了"$HBASE_HOME"/bin/hbase 脚本来start,我们继续查看hbase脚本：

elif [ "$COMMAND" = "master" ] ; then
  CLASS='org.apache.hadoop.hbase.master.HMaster'
  if [ "$1" != "stop" ] && [ "$1" != "clear" ] ; then
    HBASE_OPTS="$HBASE_OPTS $HBASE_MASTER_OPTS"
  fi

匹配COMMAND为 master 时 CLASS 为 org.apache.hadoop.hbase.master.HMaster，最后通过java 命令启动：

if [ "${HBASE_NOEXEC}" != "" ]; then
  "$JAVA" -Dproc_$COMMAND -XX:OnOutOfMemoryError="kill -9 %p" $HEAP_SETTINGS $HBASE_OPTS $CLASS "$@"
else
  exec "$JAVA" -Dproc_$COMMAND -XX:OnOutOfMemoryError="kill -9 %p" $HEAP_SETTINGS $HBASE_OPTS $CLASS "$@"
fi

我们通过jps -v -m -l |grep HMaster查看对应的启动命令 (这里是HBase 1.2.4)

8984 org.apache.hadoop.hbase.master.HMaster start -Dproc_master
-XX:OnOutOfMemoryError=kill -9 %p -Xmx2G -Duser.timezone=Asia/Shanghai
-Xss256k -XX:PermSize=128m -XX:MaxPermSize=128m -Xmx24g -Xms24g -Xmn4G
-XX:+DisableExplicitGC -XX:+UseConcMarkSweepGC -XX:ParallelCMSThreads=8
-XX:+CMSClassUnloadingEnabled -XX:+UseCMSCompactAtFullCollection
-XX:CMSInitiatingOccupancyFraction=70 -XX:+HeapDumpOnOutOfMemoryError
-XX:+UseCMSInitiatingOccupancyOnly -XX:MaxTenuringThreshold=4
-XX:SurvivorRatio=4 -verbose:gc -Xloggc:logs/gc_log -XX:+PrintGCDateStamps
-XX:+PrintGCTimeStamps -XX:+PrintGCDetails -XX:+PrintTenuringDistribution
-XX:+PrintCommandLineFlags -XX:+UseGCLogFileRotation -XX:NumberOfGCLogFiles=10
-XX:GCLogFileSize=1024M -XX:PermSize=256m -XX:MaxPermSize=256m
-Dhbase.log.dir=/data/hbase_home/logs
-Dhbase.log.file=hbase-wifi-master-hadoop1.log
-Dhbase.home.dir=/data/hbase_home -Dhbase.id.str=hadoop
-Dhbase.root.logger=INFO,RFA -Djava.library.path=/data/hadoop-2.6.4/lib/native
-Dhbase.security.logger=INFO,RFAS

下来我们打开org.apache.hadoop.hbase.master.HMaster看看。主函数入口:

 public static void main(String [] args) {
    LOG.info("STARTING service " + HMaster.class.getSimpleName());
    VersionInfo.logVersion();
    new HMasterCommandLine(HMaster.class).doMain(args);
  }

可以发现通过调用HMasterCommandLine的doMain方法来启动,解析命令行参数并运行.

/**
   * Parse and run the given command line. This may exit the JVM if
   * a nonzero exit code is returned from <code>run()</code>.
   */
  public void doMain(String args[]) {
    try {
      int ret = ToolRunner.run(HBaseConfiguration.create(), this, args);
      if (ret != 0) {
        System.exit(ret);
      }
    } catch (Exception e) {
      LOG.error("Failed to run", e);
      System.exit(-1);
    }
  }

进入run方法发现，他调用的是org.apache.hadoop.util中的ToolRunner,这里的this将HMasterCommandLine对象实现的run方法传递进去，以达到调用的效果.

public class ToolRunner {
    public ToolRunner() {
    }
    public static int run(Configuration conf, Tool tool, String[] args) throws Exception {
        if (conf == null) {
            conf = new Configuration();
        }
        GenericOptionsParser parser = new GenericOptionsParser(conf, args);
        tool.setConf(conf);
        String[] toolArgs = parser.getRemainingArgs();
        return tool.run(toolArgs);
    }

最后调用了 tool.run,我们发现 doMain方法内会调用ToolRunner的run方法，HMasterCommandLine继承自ServerCommandLine类,ServerCommandLine类实现了Tool接口。所以最后会调用HMasterCommandLine的run方法。下面我们看看HMasterCommandLine的run方法:

public int run(String args[]) throws Exception {
    Options opt = new Options();
    opt.addOption("localRegionServers", true,"RegionServers to start in master process when running standalone");
    opt.addOption("masters", true, "Masters to start in this process");
    opt.addOption("minRegionServers", true, "Minimum RegionServers needed to host user tables");
    opt.addOption("backup", false, "Do not try to become HMaster until the primary fails");
    CommandLine cmd;
    try {
      cmd = new GnuParser().parse(opt, args);
    } catch (ParseException e) {
      LOG.error("Could not parse: ", e);
      usage(null);
      return 1;
    }

    if (cmd.hasOption("minRegionServers")) {
      String val = cmd.getOptionValue("minRegionServers");
      getConf().setInt("hbase.regions.server.count.min",Integer.parseInt(val));
      LOG.debug("minRegionServers set to " + val);
    }
    // minRegionServers used to be minServers.  Support it too.
    if (cmd.hasOption("minServers")) {
      String val = cmd.getOptionValue("minServers");
      getConf().setInt("hbase.regions.server.count.min", Integer.parseInt(val));
      LOG.debug("minServers set to " + val);
    }
    // check if we are the backup master - override the conf if so
    if (cmd.hasOption("backup")) {
      getConf().setBoolean(HConstants.MASTER_TYPE_BACKUP, true);
    }
    // How many regionservers to startup in this process (we run regionservers in same process as
    // master when we are in local/standalone mode. Useful testing)
    if (cmd.hasOption("localRegionServers")) {
      String val = cmd.getOptionValue("localRegionServers");
      getConf().setInt("hbase.regionservers", Integer.parseInt(val));
      LOG.debug("localRegionServers set to " + val);
    }
    // How many masters to startup inside this process; useful testing
    if (cmd.hasOption("masters")) {
      String val = cmd.getOptionValue("masters");
      getConf().setInt("hbase.masters", Integer.parseInt(val));
      LOG.debug("masters set to " + val);
    }
    @SuppressWarnings("unchecked")
    List<String> remainingArgs = cmd.getArgList();
    if (remainingArgs.size() != 1) {
      usage(null);
      return 1;
    }
    String command = remainingArgs.get(0);
    if ("start".equals(command)) {
      return startMaster();
    } else if ("stop".equals(command)) {
      return stopMaster();
    } else if ("clear".equals(command)) {
      return (ZNodeClearer.clear(getConf()) ? 0 : 1);
    } else {
      usage("Invalid command: " + command);
      return 1;
    }
  }

这里的run干了什么？

一解析参数，二根据参数判断是start还是stop 执行对应的方法，我们来看一些startMaster

private int startMaster() {
    Configuration conf = getConf();
    TraceUtil.initTracer(conf);
    try {
      // If 'local', defer to LocalHBaseCluster instance.  Starts master
      // and regionserver both in the one JVM.
      if (LocalHBaseCluster.isLocal(conf)) {
        DefaultMetricsSystem.setMiniClusterMode(true);
        final MiniZooKeeperCluster zooKeeperCluster = new MiniZooKeeperCluster(conf);
        File zkDataPath = new File(conf.get(HConstants.ZOOKEEPER_DATA_DIR));
        // find out the default client port
        int zkClientPort = 0;
        // If the zookeeper client port is specified in server quorum, use it.
        String zkserver = conf.get(HConstants.ZOOKEEPER_QUORUM);
        if (zkserver != null) {
          String[] zkservers = zkserver.split(",");
          if (zkservers.length > 1) {
            // In local mode deployment, we have the master + a region server and zookeeper server
            // started in the same process. Therefore, we only support one zookeeper server.
            String errorMsg = "Could not start ZK with " + zkservers.length +
                " ZK servers in local mode deployment. Aborting as clients (e.g. shell) will not "
                + "be able to find this ZK quorum.";
              System.err.println(errorMsg);
              throw new IOException(errorMsg);
          }
          String[] parts = zkservers[0].split(":");
          if (parts.length == 2) {
            // the second part is the client port
            zkClientPort = Integer.parseInt(parts [1]);
          }
        }
        // If the client port could not be find in server quorum conf, try another conf
        if (zkClientPort == 0) {
          zkClientPort = conf.getInt(HConstants.ZOOKEEPER_CLIENT_PORT, 0);
          // The client port has to be set by now; if not, throw exception.
          if (zkClientPort == 0) {
            throw new IOException("No config value for " + HConstants.ZOOKEEPER_CLIENT_PORT);
          }
        }
        zooKeeperCluster.setDefaultClientPort(zkClientPort);
        // set the ZK tick time if specified
        int zkTickTime = conf.getInt(HConstants.ZOOKEEPER_TICK_TIME, 0);
        if (zkTickTime > 0) {
          zooKeeperCluster.setTickTime(zkTickTime);
        }
        // login the zookeeper server principal (if using security)
        ZKUtil.loginServer(conf, HConstants.ZK_SERVER_KEYTAB_FILE,
          HConstants.ZK_SERVER_KERBEROS_PRINCIPAL, null);
        int localZKClusterSessionTimeout =
          conf.getInt(HConstants.ZK_SESSION_TIMEOUT + ".localHBaseCluster", 10*1000);
        conf.setInt(HConstants.ZK_SESSION_TIMEOUT, localZKClusterSessionTimeout);
        LOG.info("Starting a zookeeper cluster");
        int clientPort = zooKeeperCluster.startup(zkDataPath);
        if (clientPort != zkClientPort) {
          String errorMsg = "Could not start ZK at requested port of " +
            zkClientPort + ".  ZK was started at port: " + clientPort +
            ".  Aborting as clients (e.g. shell) will not be able to find " +
            "this ZK quorum.";
          System.err.println(errorMsg);
          throw new IOException(errorMsg);
        }
  conf.set(HConstants.ZOOKEEPER_CLIENT_PORT,Integer.toString(clientPort));
        // Need to have the zk cluster shutdown when master is shutdown.
        // Run a subclass that does the zk cluster shutdown on its way out.
        int mastersCount = conf.getInt("hbase.masters", 1);
        int regionServersCount = conf.getInt("hbase.regionservers", 1);
        // Set start timeout to 5 minutes for cmd line start operations
        conf.setIfUnset("hbase.master.start.timeout.localHBaseCluster", "300000");
        LOG.info("Starting up instance of localHBaseCluster; master=" + mastersCount + ", regionserversCount=" + regionServersCount);
        LocalHBaseCluster cluster = new LocalHBaseCluster(conf, mastersCount, regionServersCount,LocalHMaster.class, HRegionServer.class);
        ((LocalHMaster)cluster.getMaster(0)).setZKCluster(zooKeeperCluster);
        cluster.startup();
        waitOnMasterThreads(cluster);
      } else {
        logProcessInfo(getConf());
        HMaster master = HMaster.constructMaster(masterClass, conf);
        if (master.isStopped()) {
          LOG.info("Won't bring the Master up as a shutdown is requested");
          return 1;
        }
        master.start();
        master.join();
        if(master.isAborted())
          throw new RuntimeException("HMaster Aborted");
      }
    } catch (Throwable t) {
      LOG.error("Master exiting", t);
      return 1;
    }
    return 0;
  }

根据配置判断启动那种模式的master,可以看到有两种模式,本地模式和分布式模式。如果是分布式模式，通过反射调用HMaster的构造方法，并调用其start和join方法。如果是本地模式，将会运行一个LocalHBaseCluster，包括：LocalHMaster、HRegionServer、MiniZooKeeperCluster （Starts master and regionserver both in the one JVM）下面看看Hmaster构造：

public static HMaster constructMaster(Class<? extends HMaster> masterClass,final Configuration conf)  {
    try {
      Constructor<? extends HMaster> c = masterClass.getConstructor(Configuration.class);
      return c.newInstance(conf);
    } catch(Exception e) {
      Throwable error = e;
      if (e instanceof InvocationTargetException &&
          ((InvocationTargetException)e).getTargetException() != null) {
        error = ((InvocationTargetException)e).getTargetException();
      }
      throw new RuntimeException("Failed construction of Master: " + masterClass.toString() + ". " , error);
    }
  }

通过反射构造Hmaster,java 反射机制 通过 getConstructor获取有参数构造函数,然后newInstance执行有参数的构造函数 Hmaster 初始化启动。
