「DUBBO系列」JDK动态代理机制

JAVA前线 2020-05-24

931

IT徐胖子原创本文未授权请勿转载

1 文章概述

Dubbo源码里有很多动态代理使用场景，例如源码里JdkProxyFactory正是使用了JDK动态代理。

package org.apache.dubbo.rpc.proxy.jdk;
import java.lang.reflect.Method;
import java.lang.reflect.Proxy;


public class JdkProxyFactory extends AbstractProxyFactory {


    @Override
    public <T> T getProxy(Invoker<T> invoker, Class<?>[] interfaces) {
        return (T) Proxy.newProxyInstance(Thread.currentThread().getContextClassLoader(), interfaces, new InvokerInvocationHandler(invoker));
    }


    @Override
    public <T> Invoker<T> getInvoker(T proxy, Class<T> type, URL url) {
        return new AbstractProxyInvoker<T>(proxy, type, url) {
            @Override
            protected Object doInvoke(T proxy, String methodName,
                                      Class<?>[] parameterTypes,
                                      Object[] arguments) throws Throwable {
                Method method = proxy.getClass().getMethod(methodName, parameterTypes);
                return method.invoke(proxy, arguments);
            }
        };
    }
}

本文我们介绍JDK动态代理实现原理，后续文章再进行Dubbo源码分析。下面我们通过一个实例分析JDK动态代理实现原理。

2 代码实例

2.1 业务接口

public interface StudentJDKService {
    public void addStudent();
    public void updateStudent();
}


public class StudentJDKServiceImpl implements StudentJDKService {
    @Override
    public void addStudent() {
        System.out.println("add student");
    }


    @Override
    public void updateStudent() {
        System.out.println("update student");
    }
}

2.2 InvocationHander

import java.lang.reflect.InvocationHandler;
import java.lang.reflect.Method;
public class TransactionHandler implements InvocationHandler {


    // 被代理对象
    private Object target;


    // 构造函数
    public TransactionHandler(Object target) {
        this.target = target;
    }


    // 代理逻辑
    @Override
    public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
        System.out.println("transaction begin");
        Object result = method.invoke(target, args);
        System.out.println("transaction end");
        return result;
    }
}

2.3 测试用例

public class TestStudentService {
    public static void main(String[] args) throws Exception {
        StudentJDKService target = new StudentJDKServiceImpl();
        TransactionHandler handler = new TransactionHandler(target);
        ClassLoader loader = target.getClass().getClassLoader();
        Class<?>[] interfaces = target.getClass().getInterfaces();
        StudentJDKService proxy = (StudentJDKService) Proxy.newProxyInstance(loader, interfaces, handler);
        System.out.println(proxy.getClass().getName());
        proxy.addStudent();
    }
}


// 输出结果
// com.sun.proxy.$Proxy0
// transaction begin
// add student
// transaction end

3 源码分析

3.1 分析入口

StudentJDKService proxy = (StudentJDKService) Proxy.newProxyInstance(loader, interfaces, handler);

3.2 Proxy

public class Proxy implements java.io.Serializable {
    private static final Class<?>[] constructorParams = { InvocationHandler.class };
    protected InvocationHandler h;


    @CallerSensitive
    public static Object newProxyInstance(ClassLoader loader, Class<?>[] interfaces, InvocationHandler h) throws IllegalArgumentException {


        // InvocationHandler不能为空
        Objects.requireNonNull(h);
        final Class<?>[] intfs = interfaces.clone();
        final SecurityManager sm = System.getSecurityManager();
        if (sm != null) {
            checkProxyAccess(Reflection.getCallerClass(), loader, intfs);
        }
        // 获取指定代理类
        Class<?> cl = getProxyClass0(loader, intfs);


        try {
            // 权限校验
            if (sm != null) {
                checkNewProxyPermission(Reflection.getCallerClass(), cl);
            }
            // 获取代理类的构造器
            final Constructor<?> cons = cl.getConstructor(constructorParams);
            final InvocationHandler ih = h;
            if (!Modifier.isPublic(cl.getModifiers())) {
                AccessController.doPrivileged(new PrivilegedAction<Void>() {
                    public Void run() {
                        cons.setAccessible(true);
                        return null;
                    }
                });
            }
            // 通过代理类构造器实例化为代理对象
            return cons.newInstance(new Object[] {h});
        }
    }
}

3.3 getProxyClass0

public class Proxy implements java.io.Serializable {


    // 代理类缓存
    // 如果缓存里不存则通过ProxyClassFactory生成代理类
    private static final WeakCache<ClassLoader, Class<?>[], Class<?>> proxyClassCache = new WeakCache<>(new KeyFactory(), new ProxyClassFactory());


    private static Class<?> getProxyClass0(ClassLoader loader, Class<?>... interfaces) {
        if (interfaces.length > 65535) {
            throw new IllegalArgumentException("interface limit exceeded");
        }
        return proxyClassCache.get(loader, interfaces);
    }
}

3.4 ProxyClassFactory

private static final class ProxyClassFactory implements BiFunction<ClassLoader, Class<?>[], Class<?>> {
    // 类名前缀
    private static final String proxyClassNamePrefix = "$Proxy";
    // 代理类序号
    private static final AtomicLong nextUniqueNumber = new AtomicLong();


    @Override
    public Class<?> apply(ClassLoader loader, Class<?>[] interfaces) {
        Map<Class<?>, Boolean> interfaceSet = new IdentityHashMap<>(interfaces.length);


        // 遍历接口数组
        for (Class<?> intf : interfaces) {
            Class<?> interfaceClass = null;
            try {
                interfaceClass = Class.forName(intf.getName(), false, loader);
            } catch (ClassNotFoundException e) {
            }
            if (interfaceClass != intf) {
                throw new IllegalArgumentException(intf + " is not visible from class loader");
            }
            // 校验是否是接口
            if(!interfaceClass.isInterface()) {
                throw new IllegalArgumentException(interfaceClass.getName() + " is not an interface");
            }
            // 接口去重
            if (interfaceSet.put(interfaceClass, Boolean.TRUE) != null) {
                throw new IllegalArgumentException("repeated interface: " + interfaceClass.getName());
            }
        }
        // 代理类所在的包路径
        String proxyPkg = null;
        // 代理类的访问修饰符
        int accessFlags = Modifier.PUBLIC | Modifier.FINAL;
        for (Class<?> intf : interfaces) {
            int flags = intf.getModifiers();
            if (!Modifier.isPublic(flags)) {
                accessFlags = Modifier.FINAL;
                String name = intf.getName();
                int n = name.lastIndexOf('.');
                String pkg = ((n == -1) ? "" : name.substring(0, n + 1));
                if (proxyPkg == null) {
                    proxyPkg = pkg;
                } else if (!pkg.equals(proxyPkg)) {
                    throw new IllegalArgumentException("non-public interfaces from different packages");
                }
            }
        }
        if (proxyPkg == null) {
            proxyPkg = ReflectUtil.PROXY_PACKAGE + ".";
        }
        // 生成代理类名
        long num = nextUniqueNumber.getAndIncrement();
        String proxyName = proxyPkg + proxyClassNamePrefix + num;


        // 核心方法生成代理类字节码
        byte[] proxyClassFile = ProxyGenerator.generateProxyClass(proxyName, interfaces, accessFlags);
        try {
            // 通过本地方法defineClass0生成代理
            return defineClass0(loader, proxyName, proxyClassFile, 0, proxyClassFile.length);
        } catch (ClassFormatError e) {
            throw new IllegalArgumentException(e.toString());
        }
    }
}

4 代理类字节码分析

通过分析源码我们知道ProxyGenerator生成了代理类字节码，这是动态代理的核心。下面我们直接调用这个方法看看生成字节码的具体内容。

public class TestStudentService {


    public static void main(String[] args) throws Exception {
        createProxyClassFile();
    }


    public static void createProxyClassFile() {
        String name = "Student$Proxy";
        byte[] data = ProxyGenerator.generateProxyClass(name, new Class[] { StudentJDKService.class });
        FileOutputStream out = null;
        try {
            // 字节码文件路径
            String fileName = "c:/test/" + name + ".class";
            File file = new File(fileName);
            out = new FileOutputStream(file);
            out.write(data);
        } catch (Exception e) {
            System.out.println(e.getMessage());
        } finally {
            if (null != out) {
                try {
                    out.close();
                } catch (IOException e) {
                    e.printStackTrace();
                }
            }
        }
        System.out.println();
    }
}

找到代理类文件通过反编译工具打开得到如下代码，通过代码我们就可以看到动态代理实现原理。

import com.itxpz.dubbo.spi.proxy.jdk.StudentJDKService;
import java.lang.reflect.InvocationHandler;
import java.lang.reflect.Method;
import java.lang.reflect.Proxy;
import java.lang.reflect.UndeclaredThrowableException;


public final class Student$Proxy extends Proxy implements StudentJDKService {
    private static Method m1;
    private static Method m4;
    private static Method m3;
    private static Method m2;
    private static Method m0;


    public Student$Proxy(InvocationHandler paramInvocationHandler) {
        super(paramInvocationHandler);
    }


    public final boolean equals(Object paramObject) {
        try {
            return ((Boolean)this.h.invoke(this, m1, new Object[] { paramObject })).booleanValue();
        } catch (Error | RuntimeException error) {
            throw null;
        } catch (Throwable throwable) {
            throw new UndeclaredThrowableException(throwable);
        }
    }


    public final void updateStudent() {
        try {
            // invocationHandler.invoke
            this.h.invoke(this, m4, null);
            return;
        } catch (Error | RuntimeException error) {
            throw null;
        } catch (Throwable throwable) {
            throw new UndeclaredThrowableException(throwable);
        }
    }


    public final void addStudent() {
        try {
            // invocationHandler.invoke
            this.h.invoke(this, m3, null);
            return;
        } catch (Error | RuntimeException error) {
            throw null;
        } catch (Throwable throwable) {
            throw new UndeclaredThrowableException(throwable);
        }
    }


    public final String toString() {
        try {
            return (String)this.h.invoke(this, m2, null);
        } catch (Error | RuntimeException error) {
            throw null;
        } catch (Throwable throwable) {
            throw new UndeclaredThrowableException(throwable);
        }
    }


    public final int hashCode() {
        try {
            return ((Integer)this.h.invoke(this, m0, null)).intValue();
        } catch (Error | RuntimeException error) {
            throw null;
        } catch (Throwable throwable) {
            throw new UndeclaredThrowableException(throwable);
        }
    }


    static {
        try {
            m1 = Class.forName("java.lang.Object").getMethod("equals", new Class[] { Class.forName("java.lang.Object") });
            m4 = Class.forName("com.itxpz.dubbo.proxy.jdk.StudentJDKService").getMethod("updateStudent", new Class[0]);
            m3 = Class.forName("com.itxpz.dubbo.proxy.jdk.StudentJDKService").getMethod("addStudent", new Class[0]);
            m2 = Class.forName("java.lang.Object").getMethod("toString", new Class[0]);
            m0 = Class.forName("java.lang.Object").getMethod("hashCode", new Class[0]);
            return;
        } catch (NoSuchMethodException noSuchMethodException) {
            throw new NoSuchMethodError(noSuchMethodException.getMessage());
        } catch (ClassNotFoundException classNotFoundException) {
            throw new NoClassDefFoundError(classNotFoundException.getMessage());
        }
    }
}

5 文章总结

本文我们介绍了JDK动态代理实现原理，后续文章再进行Dubbo源码分析，到时候会看到大量使用动态代理的场景。
