这就是k8s系列之六（cert-manager升级）

埋头过坎 2020-12-02

2746

前面k8s系列之一介绍ingress-nginx，提到了采用kubespary安装的datalab k8s集群的ingress-nginx版本有些低，在研究cert-manager时发现了同样的问题，最新的cert-manager是稳定版本的(GA、mature)，官方介绍这是过去3年来的大成就，新版本主要有下面几大特性：

API版本升级，之前是v1alpha2，现在是v1
提供了kubectl插件 cert-manager，提供了丰富的辅助功能
日志方面的改善
ACME方面的改善

看官方的介绍，后续v1.x是主要的趋势，就把当前的集群v0.16.1版本的cert-manager进行升级了，下面介绍具体过程。

根据官方文档介绍， v0.16到v1.0没有直接的升级方式，需要先删除原来的安装，再安装新的。之前相关的cert-manager服务如下：

[root@host01 ~]# kubectl get all -n cert-manager
NAME                                          READY   STATUS    RESTARTS   AGE
pod/cert-manager-cainjector-fc6c787db-cjtgx   1/1     Running   0          47h
pod/cert-manager-d994d94d7-ptqvj              1/1     Running   0          47h
pod/cert-manager-webhook-845d9df8bf-fls2v     1/1     Running   0          47h


NAME                           TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)    AGE
service/cert-manager           ClusterIP   ip01   <none>        9402/TCP   47h
service/cert-manager-webhook   ClusterIP   ip02  <none>        443/TCP    47h


NAME                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/cert-manager              1/1     1            1           47h
deployment.apps/cert-manager-cainjector   1/1     1            1           47h
deployment.apps/cert-manager-webhook      1/1     1            1           47h


NAME                                                DESIRED   CURRENT   READY   AGE
replicaset.apps/cert-manager-cainjector-fc6c787db   1         1         1       47h
replicaset.apps/cert-manager-d994d94d7              1         1         1       47h
replicaset.apps/cert-manager-webhook-845d9df8bf     1         1         1       47h

通过kubectl describe pod cert-manager-xx ，确认当前安装的版本为v0.16.1, 这次删除安装不再采用上一篇文章删除namespace及其它资源的方式，而是直接通过delete -f 资源定义文件（即apply的相反过程）来完成，如下：



[root@host01 ~]# kubectl delete -f https://github.com/jetstack/cert-manager/releases/download/v0.16.1/cert-manager.yaml
Warning: apiextensions.k8s.io/v1beta1 CustomResourceDefinition is deprecated in v1.16+, unavailable in v1.22+; use apiextensions.k8s.io/v1 CustomResourceDefinition
customresourcedefinition.apiextensions.k8s.io "certificaterequests.cert-manager.io" deleted
customresourcedefinition.apiextensions.k8s.io "certificates.cert-manager.io" deleted
customresourcedefinition.apiextensions.k8s.io "challenges.acme.cert-manager.io" deleted
customresourcedefinition.apiextensions.k8s.io "clusterissuers.cert-manager.io" deleted
customresourcedefinition.apiextensions.k8s.io "issuers.cert-manager.io" deleted
customresourcedefinition.apiextensions.k8s.io "orders.acme.cert-manager.io" deleted
namespace "cert-manager" deleted
serviceaccount "cert-manager-cainjector" deleted
serviceaccount "cert-manager" deleted
serviceaccount "cert-manager-webhook" deleted
Warning: rbac.authorization.k8s.io/v1beta1 ClusterRole is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 ClusterRole
clusterrole.rbac.authorization.k8s.io "cert-manager-cainjector" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-issuers" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-clusterissuers" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-certificates" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-orders" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-challenges" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-controller-ingress-shim" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-view" deleted
clusterrole.rbac.authorization.k8s.io "cert-manager-edit" deleted
Warning: rbac.authorization.k8s.io/v1beta1 ClusterRoleBinding is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 ClusterRoleBinding
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-cainjector" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-issuers" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-clusterissuers" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-certificates" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-orders" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-challenges" deleted
clusterrolebinding.rbac.authorization.k8s.io "cert-manager-controller-ingress-shim" deleted
Warning: rbac.authorization.k8s.io/v1beta1 Role is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 Role
role.rbac.authorization.k8s.io "cert-manager-cainjector:leaderelection" deleted
role.rbac.authorization.k8s.io "cert-manager:leaderelection" deleted
role.rbac.authorization.k8s.io "cert-manager-webhook:dynamic-serving" deleted
Warning: rbac.authorization.k8s.io/v1beta1 RoleBinding is deprecated in v1.17+, unavailable in v1.22+; use rbac.authorization.k8s.io/v1 RoleBinding
rolebinding.rbac.authorization.k8s.io "cert-manager-cainjector:leaderelection" deleted
rolebinding.rbac.authorization.k8s.io "cert-manager:leaderelection" deleted
rolebinding.rbac.authorization.k8s.io "cert-manager-webhook:dynamic-serving" deleted
service "cert-manager" deleted
service "cert-manager-webhook" deleted
deployment.apps "cert-manager-cainjector" deleted
deployment.apps "cert-manager" deleted
deployment.apps "cert-manager-webhook" deleted
Warning: admissionregistration.k8s.io/v1beta1 MutatingWebhookConfiguration is deprecated in v1.16+, unavailable in v1.22+; use admissionregistration.k8s.io/v1 MutatingWebhookConfiguration
mutatingwebhookconfiguration.admissionregistration.k8s.io "cert-manager-webhook" deleted
Warning: admissionregistration.k8s.io/v1beta1 ValidatingWebhookConfiguration is deprecated in v1.16+, unavailable in v1.22+; use admissionregistration.k8s.io/v1 ValidatingWebhookConfiguration
validatingwebhookconfiguration.admissionregistration.k8s.io "cert-manager-webhook" deleted

可以看到cert-manager相关的资源非常多。下面安装最新版本的v1.1.0：

[root@host01 ~]# kubectl apply -f https://github.com/jetstack/cert-manager/releases/download/v1.1.0/cert-manager.yaml
customresourcedefinition.apiextensions.k8s.io/certificaterequests.cert-manager.io created
customresourcedefinition.apiextensions.k8s.io/certificates.cert-manager.io created
customresourcedefinition.apiextensions.k8s.io/challenges.acme.cert-manager.io created
customresourcedefinition.apiextensions.k8s.io/clusterissuers.cert-manager.io created
customresourcedefinition.apiextensions.k8s.io/issuers.cert-manager.io created
customresourcedefinition.apiextensions.k8s.io/orders.acme.cert-manager.io created
namespace/cert-manager created
serviceaccount/cert-manager-cainjector created
serviceaccount/cert-manager created
serviceaccount/cert-manager-webhook created
clusterrole.rbac.authorization.k8s.io/cert-manager-cainjector created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-issuers created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-clusterissuers created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-certificates created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-orders created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-challenges created
clusterrole.rbac.authorization.k8s.io/cert-manager-controller-ingress-shim created
clusterrole.rbac.authorization.k8s.io/cert-manager-view created
clusterrole.rbac.authorization.k8s.io/cert-manager-edit created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-cainjector created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-issuers created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-clusterissuers created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-certificates created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-orders created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-challenges created
clusterrolebinding.rbac.authorization.k8s.io/cert-manager-controller-ingress-shim created
role.rbac.authorization.k8s.io/cert-manager-cainjector:leaderelection created
role.rbac.authorization.k8s.io/cert-manager:leaderelection created
role.rbac.authorization.k8s.io/cert-manager-webhook:dynamic-serving created
rolebinding.rbac.authorization.k8s.io/cert-manager-cainjector:leaderelection created
rolebinding.rbac.authorization.k8s.io/cert-manager:leaderelection created
rolebinding.rbac.authorization.k8s.io/cert-manager-webhook:dynamic-serving created
service/cert-manager created
service/cert-manager-webhook created
deployment.apps/cert-manager-cainjector created
deployment.apps/cert-manager created
deployment.apps/cert-manager-webhook created
mutatingwebhookconfiguration.admissionregistration.k8s.io/cert-manager-webhook created
validatingwebhookconfiguration.admissionregistration.k8s.io/cert-manager-webhook created
[root@host01 ~]#
# 查看已经安装的资源
[root@host01 ~]# kubectl get all -n cert-manager
NAME                                          READY   STATUS    RESTARTS   AGE
pod/cert-manager-5597cff495-phdjj             1/1     Running   0          67s
pod/cert-manager-cainjector-bd5f9c764-csvgm   1/1     Running   0          67s
pod/cert-manager-webhook-5f57f59fbc-dqq54     1/1     Running   0          67s


NAME                           TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)    AGE
service/cert-manager           ClusterIP   ip01   <none>        9402/TCP   67s
service/cert-manager-webhook   ClusterIP   ip02   <none>        443/TCP    67s


NAME                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/cert-manager              1/1     1            1           67s
deployment.apps/cert-manager-cainjector   1/1     1            1           67s
deployment.apps/cert-manager-webhook      1/1     1            1           67s


NAME                                                DESIRED   CURRENT   READY   AGE
replicaset.apps/cert-manager-5597cff495             1         1         1       67s
replicaset.apps/cert-manager-cainjector-bd5f9c764   1         1         1       67s
replicaset.apps/cert-manager-webhook-5f57f59fbc     1         1         1       67s
# 查看pod详情
[root@host01 ~]# kubectl describe  -n cert-manager pod cert-manager-5597cff495-phdjj
Name:         cert-manager-5597cff495-phdjj
Namespace:    cert-manager
......
docker://bd819732bd9bb835b70d3954a425a407e38f147e66ed308b697bc80f8da88914
    Image:         quay.io/jetstack/cert-manager-controller:v1.1.0
......

可以看到安装成功了， cert-manager名字空间下的资源跟v0.16.1版本是一样的，而cert-manager的描述中发现已经升级到了最新的v1.1.0版本。

采用官方提供的例子验证创建issuer、certificate的功能，如下：

[root@host01 ~]#
cat <<EOF > test-resources.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: cert-manager-test
---
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
  name: test-selfsigned
  namespace: cert-manager-test
spec:
  selfSigned: {}
---
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: selfsigned-cert
  namespace: cert-manager-test
spec:
  dnsNames:
    - example.com
  secretName: selfsigned-cert-tls
  issuerRef:
    name: test-selfsigned
EOF
# 创建isuuer及cert
[root@host01 ~]# kubectl apply -f test-resources.yaml
namespace/cert-manager-test created
issuer.cert-manager.io/test-selfsigned created
certificate.cert-manager.io/selfsigned-cert created
[root@host01 ~]#


# 查看证书是否颁发成功
[root@host01 ~]# kubectl describe certificate -n cert-manager-test
Name:         selfsigned-cert
Namespace:    cert-manager-test
... ...
Events:
  Type    Reason     Age                From          Message
  ----    ------     ----               ----          -------
  Normal  Issuing    48s                cert-manager  Issuing certificate as Secret does not exist
  Normal  Generated  47s                cert-manager  Stored new private key in temporary Secret resource "selfsigned-cert-6vzw9"
  Normal  Requested  47s                cert-manager  Created new CertificateRequest resource "selfsigned-cert-kr86d"
  Normal  Generated  46s (x2 over 47s)  cert-manager  Stored new private key in temporary Secret resource "selfsigned-cert-vz2mm"
  Normal  Requested  46s                cert-manager  Created new CertificateRequest resource "selfsigned-cert-pz6mj"
  Normal  Issuing    36s                cert-manager  The certificate has been successfully issued

可以看到用定义的issuer发布certifcation成功了。

下面简单介绍一下kubectl cert-manger的安装过程，直接从官方下载后放置到可执行的路径即可：

[root@host01 cert-manager]# curl -L -o kubectl-cert-manager.tar.gz https://github.com/jetstack/cert-manager/releases/download/v1.1.0/kubectl-cert_manager-linux-amd64.tar.gz


[root@host01 cert-manager]# tar xzf kubectl-cert-manager.tar.gz
[root@host01 cert-manager]# mv kubectl-cert_manager usr/local/bin
[root@host01 cert-manager]# kubectl cert-manager help


kubectl cert-manager is a CLI tool manage and configure cert-manager resources for Kubernetes


Usage:
  kubectl cert-manager [command]


Available Commands:
  convert     Convert cert-manager config files between different API versions
  create      Create cert-manager resources
  help        Help about any command
  renew       Mark a Certificate for manual renewal
  status      Get details on current status of cert-manager resources
  version     Print the kubectl cert-manager version

通过help命令可以看到提供了不少功能，包括跨API版本的配置文件转换、创建相关资源、重新生成证书、查看资源状态等功能。下面是一个将配置文件从v1alpha2置换到v1的示例：

kubectl cert-manager convert -f cluster-issuer-staging.yaml  -o  yaml > cluster-issuer-staging-v1.1.0.yaml


[root@host01 cert-manager]# cat cluster-issuer-staging.yaml
apiVersion: cert-manager.io/v1alpha2
kind: ClusterIssuer
metadata:
  name: letsencrypt-staging
spec:
  acme:
      email: xxx
      server: https://acme-staging-v02.api.letsencrypt.org/directory
      privateKeySecretRef:
        name: letsencrypt-staging
      solvers:
      - http01:
          ingress:
            class: nginx


[root@host01 cert-manager]# cat acme-v1.1.0.yaml
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
  name: letsencrypt-staging
spec:
  acme:
    # You must replace this email address with your own.
    # Let's Encrypt will use this to contact you about expiring
    # certificates, and issues related to your account.
    email: xxx
    server: https://acme-staging-v02.api.letsencrypt.org/directory
    privateKeySecretRef:
      # Secret resource that will be used to store the account's private key.
      name: letsencrypt-staging
    # Add a single challenge solver, HTTP01 using nginx
    solvers:
    - http01:
        ingress:
          class: nginx
[root@host01 cert-manager]#

后面文章将介绍结合letsencrypt自动生成证书的过程。

数据库

文章转载自埋头过坎，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

这就是k8s系列之六（cert-manager升级）

评论
