这就是ansible系列之三（adhoc模式入门实践)

埋头过坎 2020-11-20

748

前面ansible系列的内容介绍了基础信息，而番外篇则介绍了定位准备ansible环境过程中如何定位SSH带来的问题的全过程，本文开始笔者将从实践的角度介绍ansible。

如图所示， ansible有两种常用的使用方式，分别是ad-hoc和palybook，其中playbook又包含基本的playbook及复杂的使用roles组织的形式。本文先介绍ad-hoc模式，其它的放到后续的文章介绍。

ad-hoc模式（http://ansible.com.cn/docs/intro_adhoc.html），顾名思义，ad-hoc有单次的意思，就是说通过命令行方式单次执行单个命令的一种使用模式。它适用于用来快速地验证环境或者做一些比较简单的模式等场景。

我们先来看下ansible支持的命令行，采用的ansible版本信息如下：（约定，主机/用户名等敏感信息约定进行脱敏，采用<host-xx>、<user-xx>等形式来替代)

(base) bash-4.1$ ansible --version
ansible 2.9.6
  config file = /home/<user-xx>/.ansible.cfg
  configured module search path = ['/home/<user-xx>/.ansible/plugins/modules', '/usr/share/ansible/plugins/modules']
  ansible python module location = home/<user-xx>/anaconda3/lib/python3.7/site-packages/ansible
  executable location = home/<user-xx>/anaconda3/bin/ansible
  python version = 3.7.4 (default, Aug 13 2019, 20:35:49) [GCC 7.3.0]

ansible提供的命令如下：

(base) bash-4.1$ ansible -h
usage: ansible
  [-h] # 帮助信息
  [--version] # 版本信息
  [-v] # 同--version
  [-b] #以提权后的用户执行命令
  [--become-method BECOME_METHOD] # 提权方法，通常是sudo
  [--become-user BECOME_USER] # 切换帐户
  [-K] # 请求sudo时密码
  [-i INVENTORY] # 指定主机文件路径
  [--list-hosts] # 列出主机清单
  [-l SUBSET] # 指定一种模式， 用于过滤出有效主机
  [-P POLL_INTERVAL] # 定期POLL_INTERVAL秒返回后台任务进度
  [-B SECONDS] # 超过SECONDS秒后杀死后台执行命令
  [-o] # 标准输出到一行
  [-t TREE] # 输出信息到TREE目录下
  [-k] # 请求ssh密码
  [--private-key PRIVATE_KEY_FILE] # 私有密钥路径
  [-u REMOTE_USER] # 登录远程被管节点的帐户
  [-c CONNECTION] # 指定连接方式， 包括ssh、 pramiko等
  [-T TIMEOUT] # SSH连接超时
  [--ssh-common-args SSH_COMMON_ARGS] # ssh通用参数
  [--sftp-extra-args SFTP_EXTRA_ARGS] # sftp额外参数
  [--scp-extra-args SCP_EXTRA_ARGS] # scp额外参数
  [--ssh-extra-args SSH_EXTRA_ARGS] # ssh额外参数
  [-C] # 模拟执行但不会真正执行
  [--syntax-check] # 语法检查，通用是playbook
  [-D] # 比较文件、模板的区别
  [-e EXTRA_VARS]  # 额外变量
  [--vault-id VAULT_IDS] # 用于加密的保险库ID?
  [--ask-vault-pass | --vault-password-file VAULT_PASSWORD_FILES] 用于加密的保险库密码？
  [-f FORKS] # 进程并发数量
  [-M MODULE_PATH] # 使用的模块的路径
  [--playbook-dir BASEDIR] # playbook的根路径
  [-a MODULE_ARGS] # 模块参数
  [-m MODULE_NAME] # 选用模块
  pattern #与哪台主机进行交互

先来看一下用于确认基础环境是否OK的常用的ping和command模块，如下：

(base) bash-4.1$ ansible host_02 -m ping
<host-xx> | SUCCESS => {
    "ansible_facts": {
        "discovered_interpreter_python": "/usr/bin/python"
    },
    "changed": false,
    "ping": "pong"
}
(base) bash-4.1$ ansible host_02 -m command -a uptime
<host-xx> | CHANGED | rc=0 >>
 22:38:09 up 11 days,  6:25,  1 user,  load average: 1.79, 1.88, 1.75
(base) bash-4.1$

命令的基本格式是 ansible <主机信息> -m 模块信息 -a 模块参数

第一条命令是使用ping模块测试连通性，第二个命令是使用command模块（缺省模块，可以不显示指出来）执行uptime命令获取开机时间。

ad-hoc模式的使用方式就是类似上面这样简单方便，在特定的场景下起着重要的作用。

之前定位SSH问题时，曾经加上了-vvv (3个v就够了， 4个更详细）来调试具体的交互过程，同样地我们可以来看一下ad-hoc模式下，整个过程大概都做了哪些事情，还是以上面ping命令为例子，如下：

(base) bash-4.1$ ansible host_02 -m ping -vvv
#获取并显示当前ansible版本、模块等基础信息
ansible 2.9.6
  config file = home/<user-xx>/.ansible.cfg
  configured module search path = ['/home/<user-xx>/.ansible/plugins/modules', '/usr/share/ansible/plugins/modules']
  ansible python module location = home/<user-xx>/anaconda3/lib/python3.7/site-packages/ansible
  executable location = home/<user-xx>/anaconda3/bin/ansible
  python version = 3.7.4 (default, Aug 13 2019, 20:35:49) [GCC 7.3.0]
# 读取配置文件
Using home/<user-xx>/.ansible.cfg as config file
host_list declined parsing home/<user-xx>/.ansible/hosts as it did not pass its verify_file() method
script declined parsing home/<user-xx>/.ansible/hosts as it did not pass its verify_file() method
auto declined parsing home/<user-xx>/.ansible/hosts as it did not pass its verify_file() method
Parsed /home/<user-xx>/.ansible/hosts inventory source with ini plugin
META: ran handlers
# 与被管节点建立连接， 获取使用的帐户的home目录
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
## 具体执行命令
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx> '/bin/sh -c '"'"'echo ~ && sleep 0'"'"''
## 返回的结果
<host-xx> (0, b'/home/<user-xx>\n', b'')
# 在被管节点的home目录下建立tmp目录并创建本次会话需要的临时文件
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx> '/bin/sh -c '"'"'( umask 77 && mkdir -p "` echo /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425 `" && echo ansible-tmp-1605883636.6817505-49446542390425="` echo /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425 `" ) && sleep 0'"'"''
<host-xx> (0, b'ansible-tmp-1605883636.6817505-49446542390425=/home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425\n', b'')
<host-xx> Attempting python interpreter discovery
# 查找被管节点的python执行环境信息
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx> '/bin/sh -c '"'"'echo PLATFORM; uname; echo FOUND; command -v '"'"'"'"'"'"'"'"'/usr/bin/python'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python3.7'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python3.6'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python3.5'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python2.7'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python2.6'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'/usr/libexec/platform-python'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'/usr/bin/python3'"'"'"'"'"'"'"'"'; command -v '"'"'"'"'"'"'"'"'python'"'"'"'"'"'"'"'"'; echo ENDFOUND && sleep 0'"'"''
<host-xx> (0, b'PLATFORM\nLinux\nFOUND\n/usr/bin/python\n/usr/bin/python2.7\n/usr/bin/python\nENDFOUND\n', b'')
#  查询被管节点的系统信息
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx>  '/bin/sh -c '"'"'/usr/bin/python && sleep 0'"'"''
<host-xx> (0, b'{"osrelease_content": "NAME=\\"CentOS Linux\\"\\nVERSION=\\"7 (Core)\\"\\nID=\\"centos\\"\\nID_LIKE=\\"rhel fedora\\"\\nVERSION_ID=\\"7\\"\\nPRETTY_NAME=\\"CentOS Linux 7 (Core)\\"\\nANSI_COLOR=\\"0;31\\"\\nCPE_NAME=\\"cpe:/o:centos:centos:7\\"\\nHOME_URL=\\"https://www.centos.org/\\"\\nBUG_REPORT_URL=\\"https://bugs.centos.org/\\"\\n\\nCENTOS_MANTISBT_PROJECT=\\"CentOS-7\\"\\nCENTOS_MANTISBT_PROJECT_VERSION=\\"7\\"\\nREDHAT_SUPPORT_PRODUCT=\\"centos\\"\\nREDHAT_SUPPORT_PRODUCT_VERSION=\\"7\\"\\n\\n", "platform_dist_result": ["centos", "7.5.1804", "Core"]}\n', b'')
Using module file /home/<user-xx>/anaconda3/lib/python3.7/site-packages/ansible/modules/system/ping.py
# 将要执行的任务放到临时目录， 并通过 sftp上传到被管节点
<host-xx> PUT /home/<user-xx>/.ansible/tmp/ansible-local-32382jry0hz_b/tmp4uuzwwg7 TO /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/AnsiballZ_ping.py
<host-xx> SSH: EXEC sftp -b - -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 '[<host-xx> ]'
<host-xx> (0, b'sftp> put /home/<user-xx>/.ansible/tmp/ansible-local-32382jry0hz_b/tmp4uuzwwg7 /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/AnsiballZ_ping.py\n', b'')
# 给被管节点的任务文件添加执行权限
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx> '/bin/sh -c '"'"'chmod u+x /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/ /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/AnsiballZ_ping.py && sleep 0'"'"''
<host-xx> (0, b'', b'')
# 在被管节点执行任务， 这里是ping
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 -tt <host-xx>  '/bin/sh -c '"'"'/usr/bin/python /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/AnsiballZ_ping.py && sleep 0'"'"''
<host-xx> (0, b'\r\n{"invocation": {"module_args": {"data": "pong"}}, "ping": "pong"}\r\n', b'Shared connection to <host-xx> closed.\r\n')
# 删除被管节点的临时文件
<host-xx> ESTABLISH SSH CONNECTION FOR USER: None
<host-xx> SSH: EXEC ssh -C -o ControlMaster=auto -o ControlPersist=60s -o StrictHostKeyChecking=no -o KbdInteractiveAuthentication=no -o PreferredAuthentications=gssapi-with-mic,gssapi-keyex,hostbased,publickey -o PasswordAuthentication=no -o ConnectTimeout=10 -o ControlPath=/home/disk3/<user-xx>/.ansible/cp/472fc29db8 <host-xx> '/bin/sh -c '"'"'rm -f -r /home/<user-xx>/.ansible/tmp/ansible-tmp-1605883636.6817505-49446542390425/ > /dev/null 2>&1 && sleep 0'"'"''
<host-xx> (0, b'', b'')
<host-xx> | SUCCESS => {
    "ansible_facts": {
        "discovered_interpreter_python": "/usr/bin/python"
    },
    "changed": false,
    "invocation": {
        "module_args": {
            "data": "pong"
        }
    },
    "ping": "pong"
}
META: ran handlers
META: ran handlers
(base) bash-4.1$

经历的步骤大概如下：

a. 获取并显示当前ansible版本、模块等基础信息

b. 读取配置文件

c. 与被管节点建立连接，获取使用的帐户的home目录

d. 在被管节点的home目录下建立tmp目录并创建本次会话需要的临时文件

e. 查询被管节点的python执行环境信息

f. 查询被管节点的系统信息

g. 将要执行的任务放到临时目录，并通过 sftp上传到被管节点

h. 给被管节点的任务文件添加执行权限

i. 在被管节点执行任务，这里是ping

j. 删除被管节点的临时文件

可以看到看起来一个简单的命令，实际上发生了多次交互，同时也看到缺省模式需要多次建立远程的ssh连接，效率会相对比较低。可以通过SSH的长链接属性来减少SSH本身的消耗，另外可以通过pipelining配置来将多条命令压缩在一个SSH去执行。

总的来说， ad-hoc模式对用户来说还是非常方便的，且在一些场景下很管用，值得好好学习一下常用的命令。
