在Oracle中，执行计划里的access和filter有什么区别？
如下所示：
1Predicate Information (identified by operation id):
2---------------------------------------------------
3 4 - access("A"."EMPNO"="B"."MGR")
4 filter("A"."EMPNO"="B"."MGR")
5 5 - filter("B"."MGR" IS NOT NULL)
一般而言，access表示这个谓词条件的值将会影响数据的访问路径（表还是索引）；filter表示谓词条件的值不会影响数据的访问路劲，只起到过滤的作用。NOT IN或MIN函数等容易产生filter操作。
对于filter而言如果只有一个子节点，那么就是简单过滤操作（独立操作）。如果有两个或更多子节点，那么就是类似Nested Loops操作，只不过与Nested Loops差别在于，filter内部会构建HASH表，对于重复匹配的，不会再次进行循环查找，而是利用已有结果，提高效率。但是一旦重复匹配的较少，循环次数多，那么，filter操作将是严重影响性能的操作，可能会导致目标SQL几天都执行不完。
下面看看各种情况下的FILTER操作：
（一）单子节点：
1LHR@orclasm > set autot on
2LHR@orclasm > SELECT T.JOB, COUNT(1) FROM SCOTT.EMP T GROUP BY T.JOB HAVING COUNT(1)>3;
3
4JOB COUNT(1)
5--------- ----------
6CLERK 4
7SALESMAN 4
8
9
10Execution Plan
11----------------------------------------------------------
12Plan hash value: 2138686577
13
14----------------------------------------------------------------------------
15| Id | Operation | Name | Rows | Bytes | Cost (%CPU)| Time |
16----------------------------------------------------------------------------
17| 0 | SELECT STATEMENT | | 1 | 8 | 4 (25)| 00:00:01 |
18|* 1 | FILTER | | | | | |
19| 2 | HASH GROUP BY | | 1 | 8 | 4 (25)| 00:00:01 |
20| 3 | TABLE ACCESS FULL| EMP | 14 | 112 | 3 (0)| 00:00:01 |
21----------------------------------------------------------------------------
22
23Predicate Information (identified by operation id):
24---------------------------------------------------
25
26 1 - filter(COUNT(*)>3)
27
28
29Statistics
30----------------------------------------------------------
31 25 recursive calls
32 4 db block gets
33 6 consistent gets
34 0 physical reads
35 1544 redo size
36 660 bytes sent via SQL*Net to client
37 519 bytes received via SQL*Net from client
38 2 SQL*Net roundtrips to/from client
39 0 sorts (memory)
40 0 sorts (disk)
41 2 rows processed
很显然ID1的filter操作只有一个子节点ID2，在这种情况下的filter操作也就是单纯的过滤操作。
（二）多子节点：
filter多子节点往往就是性能杀手，主要出现在子查询无法UNNEST查询转换，经常遇到的情况就是NOT IN子查询、子查询和OR连用、复杂子查询等情况。
1DROP TABLE T_20170703_LHR_01 PURGE;
2DROP TABLE T_20170703_LHR_02 PURGE;
3DROP TABLE T_20170703_LHR_03 PURGE;
4CREATE TABLE T_20170703_LHR_01 AS SELECT OBJECT_ID,OBJECT_NAME,OBJECT_TYPE FROM DBA_OBJECTS;
5CREATE TABLE T_20170703_LHR_02 AS SELECT OBJECT_ID,OBJECT_NAME FROM USER_OBJECTS;
6CREATE TABLE T_20170703_LHR_03 AS SELECT OBJECT_ID,OBJECT_NAME FROM USER_OBJECTS WHERE ROWNUM <=1000;
7CREATE INDEX IND_T1_OBJ_ID_1 ON T_20170703_LHR_01(OBJECT_ID);
8CREATE INDEX IND_T2_OBJ_ID_1 ON T_20170703_LHR_02(OBJECT_ID);
9CREATE INDEX IND_T3_OBJ_ID_1 ON T_20170703_LHR_03(OBJECT_ID);
10EXEC DBMS_STATS.GATHER_TABLE_STATS(USER,'t_20170703_LHR_01');
11EXEC DBMS_STATS.GATHER_TABLE_STATS(USER,'t_20170703_LHR_02');
12EXEC DBMS_STATS.GATHER_TABLE_STATS(USER,'t_20170703_LHR_03');
13
14ALTER SESSION SET STATISTICS_LEVEL=ALL;
15SELECT COUNT(1)
16 FROM T_20170703_LHR_01 T1
17 WHERE T1.OBJECT_TYPE = 'TABLE'
18 OR EXISTS (SELECT 1 FROM T_20170703_LHR_02 T2 WHERE T1.OBJECT_ID = T2.OBJECT_ID)
19 OR EXISTS (SELECT 1 FROM T_20170703_LHR_03 T3 WHERE T1.OBJECT_ID = T3.OBJECT_ID);
20SELECT * FROM TABLE(DBMS_XPLAN.DISPLAY_CURSOR(NULL,NULL,'allstats last'));
21
22SELECT COUNT(1)
23 FROM (SELECT T1.*
24 FROM T_20170703_LHR_01 T1
25 WHERE T1.OBJECT_TYPE = 'TABLE'
26 UNION ALL (SELECT T1.*
27 FROM T_20170703_LHR_01 T1, T_20170703_LHR_02 T2
28 WHERE T1.OBJECT_ID = T2.OBJECT_ID
29 AND T1.OBJECT_TYPE <> 'TABLE'
30 UNION
31 SELECT T1.*
32 FROM T_20170703_LHR_01 T1, T_20170703_LHR_03 T3
33 WHERE T1.OBJECT_ID = T3.OBJECT_ID
34 AND T1.OBJECT_TYPE <> 'TABLE'));
35SELECT * FROM TABLE(DBMS_XPLAN.DISPLAY_CURSOR(NULL,NULL,'allstats last'));
36
37
38WITH TMP_T1 AS
39 (SELECT T1.* FROM T_20170703_LHR_01 T1)
40SELECT COUNT(1)
41 FROM (SELECT T1.*
42 FROM TMP_T1 T1
43 WHERE T1.OBJECT_TYPE = 'TABLE'
44 UNION ALL (SELECT T1.*
45 FROM TMP_T1 T1, T_20170703_LHR_02 T2
46 WHERE T1.OBJECT_ID = T2.OBJECT_ID
47 AND T1.OBJECT_TYPE <> 'TABLE'
48 UNION
49 SELECT T1.*
50 FROM TMP_T1 T1, T_20170703_LHR_03 T3
51 WHERE T1.OBJECT_ID = T3.OBJECT_ID
52 AND T1.OBJECT_TYPE <> 'TABLE'));
53SELECT * FROM TABLE(DBMS_XPLAN.DISPLAY_CURSOR(NULL,NULL,'allstats last'));
具体执行计划：
1LHR@orclasm > ALTER SESSION SET STATISTICS_LEVEL=ALL;
2
3Session altered.
4
5LHR@orclasm > SELECT COUNT(1)
6 2 FROM T_20170703_LHR_01 T1
7 3 WHERE T1.OBJECT_TYPE = 'TABLE'
8 4 OR EXISTS (SELECT 1 FROM T_20170703_LHR_02 T2 WHERE T1.OBJECT_ID = T2.OBJECT_ID)
9 5 OR EXISTS (SELECT 1 FROM T_20170703_LHR_03 T3 WHERE T1.OBJECT_ID = T3.OBJECT_ID);
10
11 COUNT(1)
12----------
13 5060
14
15LHR@orclasm > SELECT * FROM TABLE(DBMS_XPLAN.DISPLAY_CURSOR(NULL,NULL,'allstats last'));
16
17PLAN_TABLE_OUTPUT
18------------------------------------------------------------------------------------
19SQL_ID 5894cbw5v4mpj, child number 0
20-------------------------------------
21SELECT COUNT(1) FROM T_20170703_LHR_01 T1 WHERE T1.OBJECT_TYPE =
22'TABLE' OR EXISTS (SELECT 1 FROM T_20170703_LHR_02 T2 WHERE
23T1.OBJECT_ID = T2.OBJECT_ID) OR EXISTS (SELECT 1 FROM
24T_20170703_LHR_03 T3 WHERE T1.OBJECT_ID = T3.OBJECT_ID)
25
26Plan hash value: 1566256780
27
28---------------------------------------------------------------------------------------------------
29| Id | Operation | Name | Starts | E-Rows | A-Rows | A-Time | Buffers |
30---------------------------------------------------------------------------------------------------
31| 0 | SELECT STATEMENT | | 1 | | 1 |00:00:00.17 | 149K|
32| 1 | SORT AGGREGATE | | 1 | 1 | 1 |00:00:00.17 | 149K|
33|* 2 | FILTER | | 1 | | 5060 |00:00:00.17 | 149K|
34| 3 | TABLE ACCESS FULL| T_20170703_LHR_01 | 1 | 78271 | 78271 |00:00:00.01 | 469 |
35|* 4 | INDEX RANGE SCAN | IND_T2_OBJ_ID_1 | 74941 | 1 | 1741 |00:00:00.05 | 75356 |
36|* 5 | INDEX RANGE SCAN | IND_T3_OBJ_ID_1 | 73200 | 1 | 0 |00:00:00.05 | 73308 |
37---------------------------------------------------------------------------------------------------
38
39Predicate Information (identified by operation id):
40---------------------------------------------------
41
42 2 - filter(("T1"."OBJECT_TYPE"='TABLE' OR IS NOT NULL OR IS NOT NULL))
43 4 - access("T2"."OBJECT_ID"=:B1)
44 5 - access("T3"."OBJECT_ID"=:B1)
45
46
4727 rows selected.
48
49LHR@orclasm >
50LHR@orclasm >
51LHR@orclasm > SELECT COUNT(1)
52 2 FROM (SELECT T1.*
53 3 FROM T_20170703_LHR_01 T1
54 4 WHERE T1.OBJECT_TYPE = 'TABLE'
55 5 UNION ALL (SELECT T1.*
56 6 FROM T_20170703_LHR_01 T1, T_20170703_LHR_02 T2
57 7 WHERE T1.OBJECT_ID = T2.OBJECT_ID
58 8 AND T1.OBJECT_TYPE <> 'TABLE'
59 9 UNION
60 10 SELECT T1.*
61 11 FROM T_20170703_LHR_01 T1, T_20170703_LHR_03 T3
62 12 WHERE T1.OBJECT_ID = T3.OBJECT_ID
63 13 AND T1.OBJECT_TYPE <> 'TABLE'));
64
65 COUNT(1)
66----------
67 5060
68
69LHR@orclasm > SELECT * FROM TABLE(DBMS_XPLAN.DISPLAY_CURSOR(NULL,NULL,'allstats last'));
70
71PLAN_TABLE_OUTPUT
72-----------------------------------------------------------------------------------
73SQL_ID 5n0xpnt0gzb0d, child number 0
74-------------------------------------
75SELECT COUNT(1) FROM (SELECT T1.* FROM T_20170703_LHR_01 T1
76 WHERE T1.OBJECT_TYPE = 'TABLE' UNION ALL (SELECT T1.*
77 FROM T_20170703_LHR_01 T1, T_20170703_LHR_02 T2
78 WHERE T1.OBJECT_ID = T2.OBJECT_ID
79AND T1.OBJECT_TYPE <> 'TABLE' UNION
80SELECT T1.* FROM T_20170703_LHR_01 T1,
81T_20170703_LHR_03 T3 WHERE T1.OBJECT_ID =
82T3.OBJECT_ID AND T1.OBJECT_TYPE <> 'TABLE'))
83
84Plan hash value: 3651740877
85
86-------------------------------------------------------------------------------------------------------------------------------------
87| Id | Operation | Name | Starts | E-Rows | A-Rows | A-Time | Buffers | OMem | 1Mem | Used-Mem |
88-------------------------------------------------------------------------------------------------------------------------------------
89| 0 | SELECT STATEMENT | | 1 | | 1 |00:00:00.05 | 1423 | | | |
90| 1 | SORT AGGREGATE | | 1 | 1 | 1 |00:00:00.05 | 1423 | | | |
91| 2 | VIEW | | 1 | 4641 | 5060 |00:00:00.05 | 1423 | | | |
92| 3 | UNION-ALL | | 1 | | 5060 |00:00:00.05 | 1423 | | | |
93|* 4 | TABLE ACCESS FULL | T_20170703_LHR_01 | 1 | 1631 | 3319 |00:00:00.01 | 469 | | | |
94| 5 | SORT UNIQUE | | 1 | 4641 | 1741 |00:00:00.05 | 954 | 178K| 178K| 158K (0)|
95| 6 | UNION-ALL | | 1 | | 2634 |00:00:00.05 | 954 | | | |
96|* 7 | HASH JOIN | | 1 | 2010 | 1741 |00:00:00.03 | 479 | 1452K| 1452K| 1667K (0)|
97| 8 | INDEX FAST FULL SCAN| IND_T2_OBJ_ID_1 | 1 | 2012 | 2010 |00:00:00.01 | 10 | | | |
98|* 9 | TABLE ACCESS FULL | T_20170703_LHR_01 | 1 | 76640 | 74952 |00:00:00.01 | 469 | | | |
99|* 10 | HASH JOIN | | 1 | 1000 | 893 |00:00:00.02 | 475 | 1452K| 1452K| 1571K (0)|
100| 11 | INDEX FAST FULL SCAN| IND_T3_OBJ_ID_1 | 1 | 1000 | 1000 |00:00:00.01 | 6 | | | |
101|* 12 | TABLE ACCESS FULL | T_20170703_LHR_01 | 1 | 76640 | 74952 |00:00:00.01 | 469 | | | |
102-------------------------------------------------------------------------------------------------------------------------------------
103
104Predicate Information (identified by operation id):
105---------------------------------------------------
106
107 4 - filter("T1"."OBJECT_TYPE"='TABLE')
108 7 - access("T1"."OBJECT_ID"="T2"."OBJECT_ID")
109 9 - filter("T1"."OBJECT_TYPE"<>'TABLE')
110 10 - access("T1"."OBJECT_ID"="T3"."OBJECT_ID")
111 12 - filter("T1"."OBJECT_TYPE"<>'TABLE')
112
113
11440 rows selected.
115
