Go-原生包源码看看(container包)

花一个无所 2019-09-27
343

题图:pixabay

container 包

这个包讲了3个数据结构,堆(heap)、链表(list)、环(ring)

heap(堆)

    //要实现这个接口需要写5个方法
    type Interface interface {
    继承 sort.Interface,也就是下面的那个
    sort.Interface
    Push(x interface{}) add x as element Len()
    Pop() interface{} remove and return element Len() - 1.
    }
    //sort.Interface
    type Interface interface {
    Len is the number of elements in the collection.
    Len() int
    Less reports whether the element with
    index i should sort before the element with index j.
    Less(i, j int) bool
    Swap swaps the elements with indexes i and j.
    Swap(i, j int)
    }


    这里的堆使用的数据结构是一个最小二叉树,任意父节点比左右子树节点都要小。也就是最小二叉堆。

    核心方法是这两个:维护着最小二叉堆

      func up(h Interface, j int) {
      for {
      一直找j的父节点
      i := (j - 1) 2 parent
      if i == j || !h.Less(j, i) {
      如果自己就是或者小于父节点就退出
      break
      }
      /否则交换
      h.Swap(i, j)
      j = i
      }
      }


      func down(h Interface, i0, n int) bool {
      //i0代表需要down的元素在数组中的索引
      //n代表长度
      i := i0
      for {
      j1 := 2*i + 1
      if j1 >= n || j1 < 0 { // j1 < 0 after int overflow
      //越界跳出
      break
      }
      //左子节点索引
      j := j1 // left child
      if j2 := j1 + 1; j2 < n && h.Less(j2, j1) {
      //j2 右子节点索引
      j = j2
      }
      //父节点 > 右子节点,则交换位置
      if !h.Less(j, i) {
      break
      }
      h.Swap(i, j)
      i = j
      }
      return i > i0
      }


      下面讲讲添加元素和删除元素怎么保证最小二叉堆

        / Push pushes the element x onto the heap.
        // The complexity is O(log n) where n = h.Len().
        func Push(h Interface, x interface{}) {
        //在最后头添加一个元素
        h.Push(x)
        //然后上升
        up(h, h.Len()-1)
        }


          // Remove removes and returns the element at index i from the heap.
          // The complexity is O(log n) where n = h.Len().
          func Remove(h Interface, i int) interface{} {
          n := h.Len() - 1
          if n != i {
          //把要删除的跟最后一个交换
          h.Swap(i, n)
          //然后下沉或上升到合适的位置
          if !down(h, i, n) {
          up(h, i)
          }
          }
          //把最后一个干掉
          return h.Pop()
          }




          // Pop removes and returns the minimum element (according to Less) from the heap.
          // The complexity is O(log n) where n = h.Len().
          // Pop is equivalent to Remove(h, 0).
          //删除最上面的元素
          func Pop(h Interface) interface{} {
          n := h.Len() - 1
          //把根节点跟最后一个交换
          h.Swap(0, n)
          //然后下沉到合适的位置
          down(h, 0, n)
          //把最后一个干掉
          return h.Pop()
          }

          heap 可以用来构建优先队列 xeample_pq_test.go

          list(链表)

            //元素
            type Element struct {
            // Next and previous pointers in the doubly-linked list of elements.
            // To simplify the implementation, internally a list l is implemented
            // as a ring, such that &l.root is both the next element of the last
            // list element (l.Back()) and the previous element of the first list
            // element (l.Front()).
            //前指针、后指针
            next, prev *Element


            // The list to which this element belongs.
            list *List


            // The value stored with this element.
            Value interface{}
            }




            // List represents a doubly linked list.
            // The zero value for List is an empty list ready to use.
            //双向链表
            //双向是由Element里的next/prev决定的。如果只有一个就是单链表
            type List struct {
            root Element // sentinel list element, only &root, root.prev, and root.next are used
            len int // current list length excluding (this) sentinel element
            }




            开始

              //初始化一个双向链表,前后指针都指向自己
              // Init initializes or clears list l.
              func (l *List) Init() *List {
              l.root.next = &l.root
              l.root.prev = &l.root
              l.len = 0
              return l
              }


              // New returns an initialized list.
              func New() *List { return new(List).Init() }


              几个关键函数

                //在at元素的后面插入一个e元素
                // insert inserts e after at, increments l.len, and returns e.
                func (l *List) insert(e, at *Element) *Element {
                //
                n := at.next
                //修改指针指向,先修改要插入的那个元素的前一个元素后指针,指向e元素
                at.next = e
                //修改要插入的元素的前指针
                e.prev = at
                //把e元素的后指针指向原来at元素的后面一个元素
                e.next = n
                //原本at元素的前指针就指向e元素了
                n.prev = e
                e.list = l
                l.len++
                //返回要插入的元素
                return e
                }


                //移出一个元素
                // remove removes e from its list, decrements l.len, and returns e.
                func (l *List) remove(e *Element) *Element {
                //把e前一个元素的后指针指向e的下一个元素
                e.prev.next = e.next
                //再把e后一个元素的前指针指向e的前一个元素
                e.next.prev = e.prev
                //销毁指针值
                e.next = nil // avoid memory leaks
                e.prev = nil // avoid memory leaks
                //销毁data域
                e.list = nil
                // - len
                l.len--
                return e
                }




                // move moves e to next to at and returns e.
                //移动元素
                //其实就是把插入跟移出结合了
                //把e元素挪到at元素后面
                func (l *List) move(e, at *Element) *Element {
                if e == at {
                return e
                }
                e.prev.next = e.next
                e.next.prev = e.prev


                n := at.next
                at.next = e
                e.prev = at
                e.next = n
                n.prev = e


                return e
                }


                其他还有一些方法可以自己看源码

                ring(环)

                环也是一个链表,是一条收尾相连的链表。

                  type Ring struct {
                  next, prev *Ring
                  Value interface{} // for use by client; untouched by this library
                  }

                  新建一个环



                    // New creates a ring of n elements.
                    func New(n int) *Ring {
                    if n <= 0 {
                    return nil
                    }
                    r := new(Ring)
                    p := r
                    for i := 1; i < n; i++ {
                    //多个元素,首尾相连起来
                    p.next = &Ring{prev: p}
                    p = p.next
                    }
                    //再把最后一个后指针指向第一个元素
                    p.next = r
                    //把第一个元素的前指针指向最后一个元素
                    r.prev = p
                    return r
                    }


                    其他的没啥讲的。

                      //由有一个do方法遍历huan
                      // Do calls function f on each element of the ring, in forward order.
                      // The behavior of Do is undefined if f changes *r.
                      func (r *Ring) Do(f func(interface{})) {
                      if r != nil {
                      f(r.Value)
                      for p := r.Next(); p != r; p = p.next {
                      f(p.Value)
                      }
                      }
                      }
