Disruptor源码分析之提供端

徘徊笔记 2019-05-17

909

来源：https://github.com/LMAX-Exchange/disruptor

提供端发布消息

public void publishEvent(final EventTranslator<T> eventTranslator)
{
    ringBuffer.publishEvent(eventTranslator);
}


public void publishEvent(EventTranslator<E> translator)
{
    final long sequence = sequencer.next();
    translateAndPublish(translator, sequence);
}

获取提供者定序器的下一个可用下标，

public long next()
{
    return next(1);
}

获取当前下标以及下一个下标，wrapPoint大于等于0代表已经设置一圈数据了，获取gatingSequenceCache下标，初始值为-1，刚开始时设置成功cursor.compareAndSet(current, next)返回next下标，第二圈时，wrapPoint为0，cachedGatingSequence为-1，这个时候就会进入if语句判断是否会需要等待消费，当current溢出时也会进入，获取消费端已经消费的下标和当前提供者的下标的最小下标gatingSequence，当wrapPoint大于gatingSequence时，代表消费者还没有消费当前下标，所以不能覆盖当前位置的对象，所以就需要等待LockSupport.parkNanos(1);如果小于的话，就把那个最小位置设置到gatingSequenceCache保存下来，下一次当提供者放入了之前两次gatingSequenceCache之间的差值数量的数据时又会进入下面的if语句，不一定是是每bufferSize进入一次，如果消费速度慢的话会小于bufferSize进入一次if语句。

public long next(int n)
{
    if (n < 1 || n > bufferSize)
    {
        throw new IllegalArgumentException("n must be > 0 and < bufferSize");
    }


    long current;
    long next;


    do
    {
        current = cursor.get();
        next = current + n;


        long wrapPoint = next - bufferSize;
        long cachedGatingSequence = gatingSequenceCache.get();


        if (wrapPoint > cachedGatingSequence || cachedGatingSequence > current)
        {
            long gatingSequence = Util.getMinimumSequence(gatingSequences, current);


            if (wrapPoint > gatingSequence)
            {
                LockSupport.parkNanos(1); // TODO, should we spin based on the wait strategy?
                continue;
            }


            gatingSequenceCache.set(gatingSequence);
        }
        else if (cursor.compareAndSet(current, next))
        {
            break;
        }
    }
    while (true);


    return next;
}

获取消费者和提供者的下标中最小的下标

public static long getMinimumSequence(final Sequence[] sequences, long minimum)
{
    for (int i = 0, n = sequences.length; i < n; i++)
    {
        long value = sequences[i].get();
        minimum = Math.min(minimum, value);
    }


    return minimum;
}

转化需要设置的对象并发布，获取对应位置的值，EventTranslator是用来设置对应数组entries下标的值。

private void translateAndPublish(EventTranslator<E> translator, long sequence)
{
    try
    {
        translator.translateTo(get(sequence), sequence);
    }
    finally
    {
        sequencer.publish(sequence);
    }
}

设置完后发布对应的下标，设置该下标的可用标志

public void publish(final long sequence)
{
    setAvailable(sequence);
    waitStrategy.signalAllWhenBlocking();
}


private void setAvailable(final long sequence)
{
    setAvailableBufferValue(calculateIndex(sequence), calculateAvailabilityFlag(sequence));
}

计算对应的数组下标

private int calculateIndex(final long sequence)
{
    return ((int) sequence) & indexMask;
}

计算可用flag

private int calculateAvailabilityFlag(final long sequence)
{
    return (int) (sequence >>> indexShift);
}

给对应的可用标志数组的地址设置可用flag

private void setAvailableBufferValue(int index, int flag)
{
    long bufferAddress = (index * SCALE) + BASE;
    UNSAFE.putOrderedInt(availableBuffer, bufferAddress, flag);
}

唤醒所有等待的消费线程有数据到达

public void signalAllWhenBlocking()
{
    synchronized (mutex)
    {
        mutex.notifyAll();
    }
}
