RocketMQ源码分析之拉取消息（4）

徘徊笔记 2019-04-30

322

来源：https://github.com/apache/rocketmq

构建拉取请求PullRequest

public void dispatchPullRequest(List<PullRequest> pullRequestList) {
    for (PullRequest pullRequest : pullRequestList) {
        this.defaultMQPushConsumerImpl.executePullRequestImmediately(pullRequest);
        log.info("doRebalance, {}, add a new pull request {}", consumerGroup, pullRequest);
    }
}

立即拉取

public void executePullRequestImmediately(final PullRequest pullRequest) {
    this.mQClientFactory.getPullMessageService().executePullRequestImmediately(pullRequest);
}

也就是把请求放入拉取线程的阻塞队列中。

public void executePullRequestImmediately(final PullRequest pullRequest) {
    try {
        this.pullRequestQueue.put(pullRequest);
    } catch (InterruptedException e) {
        log.error("executePullRequestImmediately pullRequestQueue.put", e);
    }
}

拉取线程为PullMessageService，一直从队列中获取拉取请求。

public void run() {
    log.info(this.getServiceName() + " service started");


    while (!this.isStopped()) {
        try {
            PullRequest pullRequest = this.pullRequestQueue.take();
            this.pullMessage(pullRequest);
        } catch (InterruptedException ignored) {
        } catch (Exception e) {
            log.error("Pull Message Service Run Method exception", e);
        }
    }


    log.info(this.getServiceName() + " service end");
}

查询消费组对应的实例信息。

private void pullMessage(final PullRequest pullRequest) {
    final MQConsumerInner consumer = this.mQClientFactory.selectConsumer(pullRequest.getConsumerGroup());
    if (consumer != null) {
        DefaultMQPushConsumerImpl impl = (DefaultMQPushConsumerImpl) consumer;
        impl.pullMessage(pullRequest);
    } else {
        log.warn("No matched consumer for the PullRequest {}, drop it", pullRequest);
    }
}

判断处理队列的状态是否正确，更新它的最新拉取时间，判断消费实例状态，判断当前处理队列缓存的消息数量以及大小是否超过限制，这些消息在同一个队列的偏移量间隔是否超过限制，本机是否有该topic的订阅信息，如果是上面这些情况的话就稍候再拉取消息。

final ProcessQueue processQueue = pullRequest.getProcessQueue();
if (processQueue.isDropped()) {
    log.info("the pull request[{}] is dropped.", pullRequest.toString());
    return;
}


pullRequest.getProcessQueue().setLastPullTimestamp(System.currentTimeMillis());


try {
    this.makeSureStateOK();
} catch (MQClientException e) {
    log.warn("pullMessage exception, consumer state not ok", e);
    this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_EXCEPTION);
    return;
}


if (this.isPause()) {
    log.warn("consumer was paused, execute pull request later. instanceName={}, group={}", this.defaultMQPushConsumer.getInstanceName(), this.defaultMQPushConsumer.getConsumerGroup());
    this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_SUSPEND);
    return;
}


long cachedMessageCount = processQueue.getMsgCount().get();
long cachedMessageSizeInMiB = processQueue.getMsgSize().get()  (1024 * 1024);


if (cachedMessageCount > this.defaultMQPushConsumer.getPullThresholdForQueue()) {
    this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_FLOW_CONTROL);
    if ((queueFlowControlTimes++ % 1000) == 0) {
        log.warn(
            "the cached message count exceeds the threshold {}, so do flow control, minOffset={}, maxOffset={}, count={}, size={} MiB, pullRequest={}, flowControlTimes={}",
            this.defaultMQPushConsumer.getPullThresholdForQueue(), processQueue.getMsgTreeMap().firstKey(), processQueue.getMsgTreeMap().lastKey(), cachedMessageCount, cachedMessageSizeInMiB, pullRequest, queueFlowControlTimes);
    }
    return;
}


if (cachedMessageSizeInMiB > this.defaultMQPushConsumer.getPullThresholdSizeForQueue()) {
    this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_FLOW_CONTROL);
    if ((queueFlowControlTimes++ % 1000) == 0) {
        log.warn(
            "the cached message size exceeds the threshold {} MiB, so do flow control, minOffset={}, maxOffset={}, count={}, size={} MiB, pullRequest={}, flowControlTimes={}",
            this.defaultMQPushConsumer.getPullThresholdSizeForQueue(), processQueue.getMsgTreeMap().firstKey(), processQueue.getMsgTreeMap().lastKey(), cachedMessageCount, cachedMessageSizeInMiB, pullRequest, queueFlowControlTimes);
    }
    return;
}


if (!this.consumeOrderly) {
    if (processQueue.getMaxSpan() > this.defaultMQPushConsumer.getConsumeConcurrentlyMaxSpan()) {
        this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_FLOW_CONTROL);
        if ((queueMaxSpanFlowControlTimes++ % 1000) == 0) {
            log.warn(
                "the queue's messages, span too long, so do flow control, minOffset={}, maxOffset={}, maxSpan={}, pullRequest={}, flowControlTimes={}",
                processQueue.getMsgTreeMap().firstKey(), processQueue.getMsgTreeMap().lastKey(), processQueue.getMaxSpan(),
                pullRequest, queueMaxSpanFlowControlTimes);
        }
        return;
    }
} else {
    if (processQueue.isLocked()) {
        if (!pullRequest.isLockedFirst()) {
            final long offset = this.rebalanceImpl.computePullFromWhere(pullRequest.getMessageQueue());
            boolean brokerBusy = offset < pullRequest.getNextOffset();
            log.info("the first time to pull message, so fix offset from broker. pullRequest: {} NewOffset: {} brokerBusy: {}",
                pullRequest, offset, brokerBusy);
            if (brokerBusy) {
                log.info("[NOTIFYME]the first time to pull message, but pull request offset larger than broker consume offset. pullRequest: {} NewOffset: {}",
                    pullRequest, offset);
            }


            pullRequest.setLockedFirst(true);
            pullRequest.setNextOffset(offset);
        }
    } else {
        this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_EXCEPTION);
        log.info("pull message later because not locked in broker, {}", pullRequest);
        return;
    }
}


final SubscriptionData subscriptionData = this.rebalanceImpl.getSubscriptionInner().get(pullRequest.getMessageQueue().getTopic());
if (null == subscriptionData) {
    this.executePullRequestLater(pullRequest, PULL_TIME_DELAY_MILLS_WHEN_EXCEPTION);
    log.warn("find the consumer's subscription failed, {}", pullRequest);
    return;
}


private void executePullRequestLater(final PullRequest pullRequest, final long timeDelay) {
    this.mQClientFactory.getPullMessageService().executePullRequestLater(pullRequest, timeDelay);
}


public void executePullRequestLater(final PullRequest pullRequest, final long timeDelay) {
    if (!isStopped()) {
        this.scheduledExecutorService.schedule(new Runnable() {
            @Override
            public void run() {
                PullMessageService.this.executePullRequestImmediately(pullRequest);
            }
        }, timeDelay, TimeUnit.MILLISECONDS);
    } else {
        log.warn("PullMessageServiceScheduledThread has shutdown");
    }
}

当是集群模式并且当前消费的偏移量大于0的话就设置提交偏移量标志位

boolean commitOffsetEnable = false;
long commitOffsetValue = 0L;
if (MessageModel.CLUSTERING == this.defaultMQPushConsumer.getMessageModel()) {
    commitOffsetValue = this.offsetStore.readOffset(pullRequest.getMessageQueue(), ReadOffsetType.READ_FROM_MEMORY);
    if (commitOffsetValue > 0) {
        commitOffsetEnable = true;
    }
}


String subExpression = null;
boolean classFilter = false;
SubscriptionData sd = this.rebalanceImpl.getSubscriptionInner().get(pullRequest.getMessageQueue().getTopic());
if (sd != null) {
    if (this.defaultMQPushConsumer.isPostSubscriptionWhenPull() && !sd.isClassFilterMode()) {
        subExpression = sd.getSubString();
    }


    classFilter = sd.isClassFilterMode();
}


int sysFlag = PullSysFlag.buildSysFlag(
    commitOffsetEnable, // commitOffset
    true, // suspend
    subExpression != null, // subscription
    classFilter // class filter
);

组装sysFlag的标志，

private final static int FLAG_COMMIT_OFFSET = 0x1 << 0;
private final static int FLAG_SUSPEND = 0x1 << 1;
private final static int FLAG_SUBSCRIPTION = 0x1 << 2;
private final static int FLAG_CLASS_FILTER = 0x1 << 3;


public static int buildSysFlag(final boolean commitOffset, final boolean suspend,
    final boolean subscription, final boolean classFilter) {
    int flag = 0;


    if (commitOffset) {
        flag |= FLAG_COMMIT_OFFSET;
    }


    if (suspend) {
        flag |= FLAG_SUSPEND;
    }


    if (subscription) {
        flag |= FLAG_SUBSCRIPTION;
    }


    if (classFilter) {
        flag |= FLAG_CLASS_FILTER;
    }


    return flag;
}

组装拉取核心实现，BROKER_SUSPEND_MAX_TIME_MILLIS = 1000 * 15，

消费端拉取消息的超时时间为CONSUMER_TIMEOUT_MILLIS_WHEN_SUSPEND = 1000 * 30，每次拉取消息数量为pullBatchSize = 32

this.pullAPIWrapper.pullKernelImpl(
    pullRequest.getMessageQueue(),
    subExpression,
    subscriptionData.getExpressionType(),
    subscriptionData.getSubVersion(),
    pullRequest.getNextOffset(),
    this.defaultMQPushConsumer.getPullBatchSize(),
    sysFlag,
    commitOffsetValue,
    BROKER_SUSPEND_MAX_TIME_MILLIS,
    CONSUMER_TIMEOUT_MILLIS_WHEN_SUSPEND,
    CommunicationMode.ASYNC,
    pullCallback
);


public PullResult pullKernelImpl(
    final MessageQueue mq,
    final String subExpression,
    final String expressionType,
    final long subVersion,
    final long offset,
    final int maxNums,
    final int sysFlag,
    final long commitOffset,
    final long brokerSuspendMaxTimeMillis,
    final long timeoutMillis,
    final CommunicationMode communicationMode,
    final PullCallback pullCallback
) throws MQClientException, RemotingException, MQBrokerException, InterruptedException {
    FindBrokerResult findBrokerResult =
        this.mQClientFactory.findBrokerAddressInSubscribe(mq.getBrokerName(),
            this.recalculatePullFromWhichNode(mq), false);
    if (null == findBrokerResult) {
        this.mQClientFactory.updateTopicRouteInfoFromNameServer(mq.getTopic());
        findBrokerResult =
            this.mQClientFactory.findBrokerAddressInSubscribe(mq.getBrokerName(),
                this.recalculatePullFromWhichNode(mq), false);
    }


    if (findBrokerResult != null) {
        {
            // check version
            if (!ExpressionType.isTagType(expressionType)
                && findBrokerResult.getBrokerVersion() < MQVersion.Version.V4_1_0_SNAPSHOT.ordinal()) {
                throw new MQClientException("The broker[" + mq.getBrokerName() + ", "
                    + findBrokerResult.getBrokerVersion() + "] does not upgrade to support for filter message by " + expressionType, null);
            }
        }
        int sysFlagInner = sysFlag;


        if (findBrokerResult.isSlave()) {
            sysFlagInner = PullSysFlag.clearCommitOffsetFlag(sysFlagInner);
        }


        PullMessageRequestHeader requestHeader = new PullMessageRequestHeader();
        requestHeader.setConsumerGroup(this.consumerGroup);
        requestHeader.setTopic(mq.getTopic());
        requestHeader.setQueueId(mq.getQueueId());
        requestHeader.setQueueOffset(offset);
        requestHeader.setMaxMsgNums(maxNums);
        requestHeader.setSysFlag(sysFlagInner);
        requestHeader.setCommitOffset(commitOffset);
        requestHeader.setSuspendTimeoutMillis(brokerSuspendMaxTimeMillis);
        requestHeader.setSubscription(subExpression);
        requestHeader.setSubVersion(subVersion);
        requestHeader.setExpressionType(expressionType);


        String brokerAddr = findBrokerResult.getBrokerAddr();
        if (PullSysFlag.hasClassFilterFlag(sysFlagInner)) {
            brokerAddr = computPullFromWhichFilterServer(mq.getTopic(), brokerAddr);
        }


        PullResult pullResult = this.mQClientFactory.getMQClientAPIImpl().pullMessage(
            brokerAddr,
            requestHeader,
            timeoutMillis,
            communicationMode,
            pullCallback);


        return pullResult;
    }


    throw new MQClientException("The broker[" + mq.getBrokerName() + "] not exist", null);
}

计算从哪个broker节点拉取消息，默认是主节点。

public long recalculatePullFromWhichNode(final MessageQueue mq) {
    if (this.isConnectBrokerByUser()) {
        return this.defaultBrokerId;
    }


    AtomicLong suggest = this.pullFromWhichNodeTable.get(mq);
    if (suggest != null) {
        return suggest.get();
    }


    return MixAll.MASTER_ID;
}

topic订阅表达式不是tag则要判断系统版本，本次以tag为例。如果选择从从broker拉取消息，则需要去掉提交偏移量的请求标志位。如果有过滤类标志的话就从查询对应地址对应的过滤服务器地址。拉取消息，传递回调函数PullCallback，构造请求头类PullMessageRequestHeader，请求码为PULL_MESSAGE = 11，默认是异步拉取消息

public PullResult pullMessage(
    final String addr,
    final PullMessageRequestHeader requestHeader,
    final long timeoutMillis,
    final CommunicationMode communicationMode,
    final PullCallback pullCallback
) throws RemotingException, MQBrokerException, InterruptedException {
    RemotingCommand request = RemotingCommand.createRequestCommand(RequestCode.PULL_MESSAGE, requestHeader);


    switch (communicationMode) {
        case ONEWAY:
            assert false;
            return null;
        case ASYNC:
            this.pullMessageAsync(addr, request, timeoutMillis, pullCallback);
            return null;
        case SYNC:
            return this.pullMessageSync(addr, request, timeoutMillis);
        default:
            assert false;
            break;
    }


    return null;
}
