概述

引入Sentry后的工作流程

Sentry的使用方式

服务端：

1. 提供cloud 版本（https://sentry.io/auth/login），直接注册，即可使用。

2. 提供开源的安装部署版本，可通过helm进行部署。

客户端：支持多种平台接入，以下是比较流行的接入方式，具体参见相应docs文档（https://docs.sentry.io/platforms）

使用helm安装

#fetch sentry，并解压
helm fetch --untar stable/sentry
#进入sentry目录，编辑values.yaml配置文件
...
email:
  from_address: xxxx@example.org //修改为发邮件人的地址
  host: smtp.exmail.qq.com //腾讯企业邮箱
  port: 587//端口需要使用587，非465
  use_tls: true//默认为true
  user: xxxx@example.org //修改为用户email
  password: xxxxx //修改为用户密码
  enable_replies: true
...
service:
  type: NodePort//我这边Type修改为NodePort
  nodePort: 32190//并定义nodePort
...
filestore:
  filesystem:
    persistence:
      storageClass: nfs-client
      accessMode: ReadWriteMany
      size: 50Gi
...
#由于postgres 9.6.2版本下载很慢，这里我选用了本地仓库的版本(先同步到本地仓库)
对charts/postgresql依赖的values.yaml做如下修改：
...
image: "harbor.example.org/library/postgres"//请根据情况确认是不喜要替换
persistence:
  storageClass: "nfs-client"//需提前配置好
  accessMode: ReadWriteMany
  size: 20Gi
  subPath: "postgresql-db"
  mountPath: /var/lib/postgresql/data/pgdata

#执行以下命令进行安装
helm install --wait --name sre-sentry -f ./sentry/values.yaml --namespace sre ./sentry
NAME:   sre-sentry
LAST DEPLOYED: FriOct1122:03:512019
NAMESPACE: sre
STATUS: DEPLOYED

RESOURCES:
==> v1/PersistentVolumeClaim
NAME                   STATUS  VOLUME                                    CAPACITY  ACCESS MODES  STORAGECLASS  AGE
sre-sentry-postgresql  Bound   pvc-f4173484-ec2f-11e9-9ca2-00163e064a2f20Gi      RWX           nfs-client    4m38s
sre-sentry             Bound   pvc-f418245a-ec2f-11e9-9ca2-00163e064a2f50Gi      RWX           nfs-client    4m38s

==> v1/Service
NAME                     TYPE       CLUSTER-IP       EXTERNAL-IP  PORT(S)         AGE
sre-sentry-postgresql    ClusterIP192.168.125.27<none>5432/TCP        4m38s
sre-sentry-redis-master  ClusterIP192.168.134.237<none>6379/TCP        4m38s
sre-sentry-redis-slave   ClusterIP192.168.122.115<none>6379/TCP        4m38s
sre-sentry               NodePort192.168.98.128<none>9000:32190/TCP  4m38s

==> v1beta1/Deployment
NAME                    DESIRED  CURRENT  UP-TO-DATE  AVAILABLE  AGE
sre-sentry-postgresql   11114m38s
sre-sentry-redis-slave  11104m38s
sre-sentry-cron         11114m38s
sre-sentry-web          11114m38s
sre-sentry-worker       22224m38s

==> v1beta2/StatefulSet
NAME                     DESIRED  CURRENT  AGE
sre-sentry-redis-master  114m38s

==> v1/Pod(related)
NAME                                     READY  STATUS             RESTARTS  AGE
sre-sentry-postgresql-5d87c88f49-cxx4x   1/1Running04m38s
sre-sentry-redis-slave-5fc9fffbcf-mftzz  0/1ContainerCreating04m38s
sre-sentry-cron-5b84b84c9d-sgk4w         1/1Running04m38s
sre-sentry-web-5cfc5bb6b6-tz45j          1/1Running14m38s
sre-sentry-worker-79fcfff6c7-j24pc       1/1Running04m37s
sre-sentry-worker-79fcfff6c7-p9s9t       1/1Running14m37s
sre-sentry-redis-master-01/1Running04m38s

==> v1/Secret
NAME                   TYPE    DATA  AGE
sre-sentry-postgresql  Opaque14m38s
sre-sentry-redis       Opaque14m38s
sre-sentry             Opaque34m38s

==> v1/ConfigMap
NAME                   DATA  AGE
sre-sentry-postgresql  04m38s
sre-sentry             24m38s


NOTES:

WARNING:
You have changed the default memory request for the db-init job hook. It may affect your setup.
If you are facing problems, check next links:
- https://github.com/helm/charts/issues/15296
- https://github.com/getsentry/onpremise/blob/master/install.sh
1.Get the application URL by running these commands:
export NODE_PORT=$(kubectl get--namespace sre -o jsonpath="{.spec.ports[0].nodePort}" services sre-sentry)
export NODE_IP=$(kubectl get nodes --namespace sre -o jsonpath="{.items[0].status.addresses[0].address}")
  echo http://$NODE_IP:$NODE_PORT/auth/login/sentry

2.Loginwith

  USER: admin@sentry.local
Get login password with
    kubectl get secret --namespace sre sre-sentry -o jsonpath="{.data.user-password}"| base64 --decode

总结

在安装过程中有几个注意点：

1. 安装sentry时，postgresql初始化时间比较长，我这边出错，很大部分原因就是因为postgresql初始化引起，后来通过修改image为本地仓库镜像才得到解决。

2. email配置这里，一直使用465端口，收不到邮件，改为587后就可以了
