【我和openGauss的故事】记录在openEuler-22.03中安装openGauss_5.0.0企业版

环境准备

VMware 17.0.2
openEuler-22.03-LTS-SP2
openGauss-5.0.0
MobaXterm 22.1
服务器名称：node0，IP地址：192.168.192.129

查看、设置主机名

## 查看主机名
[root@192 ~]# hostname
192.168.192.129

## 设置主机名
[root@192 ~]# hostnamectl set-hostname node0
[root@192 ~]#

## 重启
[root@192 ~]# reboot

## 重启后
[root@node0 ~]# hostname
node0


获取openGauss安装包

openGauss是一款开源关系型数据库管理系统，采用木兰宽松许可证v2发行。openGauss内核深度融合华为在数据库领域多年的经验，结合企业级场景需求，持续构建竞争力特性。

安装依赖包

[root@node0 ~]# yum install -y gcc-c++ pcre pcre-devel zlib zlib-devel openssl openssl-devel
OS                                                                                                                                                                            4.5 MB/s | 3.4 MB     00:00
everything                                                                                                                                                                    2.1 MB/s |  17 MB     00:07
EPOL                                                                                                                                                                          9.9 MB/s | 4.5 MB     00:00
debuginfo                                                                                                                                                                     4.6 MB/s | 4.0 MB     00:00
source                                                                                                                                                                        1.9 MB/s | 1.8 MB     00:00
update                                                                                                                                                                        2.1 MB/s | 1.8 MB     00:00
update-source                                                                                                                                                                  66 kB/s |  22 kB     00:00
Package pcre-8.45-5.oe2203sp2.x86_64 is already installed.
Package zlib-1.2.11-22.oe2203sp2.x86_64 is already installed.
Package zlib-devel-1.2.11-22.oe2203sp2.x86_64 is already installed.
Package openssl-1:1.1.1m-20.oe2203sp2.x86_64 is already installed.
Package openssl-devel-1:1.1.1m-20.oe2203sp2.x86_64 is already installed.
Dependencies resolved.
===============================================================================================================......

Installed:
  gcc-c++-10.3.1-37.oe2203sp2.x86_64                               libstdc++-devel-10.3.1-37.oe2203sp2.x86_64                               pcre-devel-8.45-5.oe2203sp2.x86_64

Complete!

修改操作系统配置

关闭操作系统防火墙

目前仅支持在防火墙关闭的状态下进行安装。

# 查看防火墙状态
[root@node0 ~]# systemctl status firewalld.service
● firewalld.service - firewalld - dynamic firewall daemon
     Loaded: loaded (/usr/lib/systemd/system/firewalld.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2023-07-20 21:38:54 CST; 6min ago
       Docs: man:firewalld(1)
   Main PID: 932 (firewalld)
      Tasks: 2 (limit: 21384)
     Memory: 34.1M
     CGroup: /system.slice/firewalld.service
             └─ 932 /usr/bin/python3 -s /usr/sbin/firewalld --nofork --nopid

7月 20 21:38:53 node0 systemd[1]: Starting firewalld - dynamic firewall daemon...
7月 20 21:38:54 node0 systemd[1]: Started firewalld - dynamic firewall daemon.
[root@node0 ~]#

# 关闭防火墙并禁止开机重启
[root@node0 ~]# systemctl stop firewalld.service
[root@node0 ~]#
[root@node0 ~]# systemctl disable firewalld.service
Removed /etc/systemd/system/dbus-org.fedoraproject.FirewallD1.service.
Removed /etc/systemd/system/multi-user.target.wants/firewalld.service.
[root@node0 ~]#

# 查看防火墙状态
[root@node0 ~]# systemctl status firewalld
○ firewalld.service - firewalld - dynamic firewall daemon
     Loaded: loaded (/usr/lib/systemd/system/firewalld.service; disabled; vendor preset: enabled)
     Active: inactive (dead)
       Docs: man:firewalld(1)

7月 20 21:38:53 node0 systemd[1]: Starting firewalld - dynamic firewall daemon...
7月 20 21:38:54 node0 systemd[1]: Started firewalld - dynamic firewall daemon.
7月 20 21:46:24 node0 systemd[1]: Stopping firewalld - dynamic firewall daemon...
7月 20 21:46:25 node0 systemd[1]: firewalld.service: Deactivated successfully.
7月 20 21:46:25 node0 systemd[1]: Stopped firewalld - dynamic firewall daemon.

关闭SELINUX

修改/etc/selinux/config文件中的“SELINUX”值为“disabled”

使用vi打开config文件

vi /etc/selinux/config

修改“SELINUX”的值“disabled”，执行:wq保存并退出修改

重新启动操作系统

[root@192 openEuler]# reboot

设置操作系统字符集

# 设置字符集
[root@node0 ~]# cat>> /etc/profile<<EOF
> export LANG=en_US.UTF-8
> EOF
[root@node0 ~]#

# 使参数生效
[root@node0 ~]# source /etc/profile


Welcome to 5.10.0-153.12.0.92.oe2203sp2.x86_64

System information as of time:  2023年 07月 20日 星期四 21:51:32 CST

System load:    0.00
Processes:      158
Memory used:    6.1%
Swap used:      0%
Usage On:       4%
IP address:     192.168.192.129
Users online:   1

# 检查字符集
[root@node0 ~]# env |grep -i lang
LANG=en_US.UTF-8

设置时区和时间

# 安装ntp服务
[root@node0 ~]# yum install -y ntp
Last metadata expiration check: 0:11:18 ago on Thu 20 Jul 2023 09:43:18 PM CST.
Dependencies resolved.
......

Installed:
  ntp-4.2.8p15-11.oe2203sp2.x86_64                                   ntp-help-4.2.8p15-11.oe2203sp2.noarch                                   ntpstat-0.6-4.oe2203sp2.noarch

Complete!

# 开机启动ntp服务
[root@node0 ~]# systemctl enable ntpd
Created symlink /etc/systemd/system/multi-user.target.wants/ntpd.service → /usr/lib/systemd/system/ntpd.service.

# 启动ntp服务
[root@node0 ~]# systemctl start ntpd

# 设置时区Asia/Shanghai
[root@node0 ~]# timedatectl set-timezone Asia/Shanghai

# 检查时区
[root@node0 ~]# timedatectl |grep -i zone
                Time zone: Asia/Shanghai (CST, +0800)

# 启用ntp服务
[root@node0 ~]# timedatectl set-ntp yes

# 编辑定时任务列表
[root@node0 ~]# crontab -e
no crontab for root - using an empty one
crontab: installing new crontab

# 查看时间及时区
[root@node0 ~]# timedatectl status
               Local time: Thu 2023-07-20 22:00:27 CST
           Universal time: Thu 2023-07-20 14:00:27 UTC
                 RTC time: Thu 2023-07-20 14:00:27
                Time zone: Asia/Shanghai (CST, +0800)
System clock synchronized: yes
              NTP service: active
          RTC in local TZ: no

修改硬件时钟

# 将当前系统时间写入硬件时钟
[root@node0 ~]# hwclock --systohc
[root@node0 ~]#

# 查看硬件时钟
[root@node0 ~]# hwclock
2023-07-20 22:02:58.916124+08:00

关闭swap交换内存

关闭swap交换内存是为了保障数据库的访问性能，避免把数据库的缓冲区内存淘汰到磁盘上。如果服务器内存比较小，内存过载时，可打开swap交换内存保障正常运行。

[root@node0 ~]# swapoff -a

设置网卡MTU值

# 设置网卡MTU，MTU值推荐8192
[root@node0 ~]# ifconfig ens33 mtu 8192

# 查看网卡MTU
[root@node0 ~]# ifconfig -a |grep -i mtu
ens33: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 8192
lo: flags=73<UP,LOOPBACK,RUNNING>  mtu 65536

关闭RemoveIPC

修改logind.conf文件

# 使用vi打开logind.conf文件
[root@node0 ~]# vi  /etc/systemd/logind.conf

# 修改“RemoveIPC”值为“no”

修改systemd-logind.service文件

# 使用vi打开systemd-logind.service文件
[root@node0 ~]# vi /usr/lib/systemd/system/systemd-logind.service

# 修改“RemoveIPC”值为“no”
# 文件中没有配置参数，追加到文件的末尾即可

重新加载配置参数

[root@node0 ~]# systemctl daemon-reload
[root@node0 ~]# systemctl restart systemd-logind

检查修改是否生效

[root@node0 ~]# loginctl show-session | grep RemoveIPC
RemoveIPC=no
[root@node0 ~]# systemctl show systemd-logind | grep RemoveIPC
RemoveIPC=no

关闭HISTORY记录

为避免指令历史记录安全隐患，需关闭各主机的history指令。

[root@node0 ~]# vi /etc/profile

设置HISTSIZE值为0

系统中HISTSIZE默认值为1000，将其修改为0。
保存/etc/profile。 :wq

设置/etc/profile生效

[root@node0 ~]# source /etc/profile


Welcome to 5.10.0-153.12.0.92.oe2203sp2.x86_64

System information as of time:  Thu Jul 20 10:23:28 PM CST 2023

System load:    0.00
Processes:      158
Memory used:    6.0%
Swap used:      0.0%
Usage On:       4%
IP address:     192.168.192.129
Users online:   1

设置root用户远程登录

在openGauss安装时需要root帐户远程登录访问权限
数据库需要root互信时才开启远程连接。在各主机操作完成并且验证完毕后请及时注销root用户，避免误操作。

修改PermitRootLogin配置，允许用户远程登录

打开sshd_config文件

[root@node0 ~]# vi /etc/ssh/sshd_config

修改权限配置

# 方式1：注释掉“PermitRootLogin no”
#PermitRootLogin no

# 方式2：将“PermitRootLogin”改为“yes”
PermitRootLogin=yes

执行 :wq 保存并退出编辑页面

修改Banner配置，去掉连接到系统时，系统提示的欢迎信息。欢迎信息会干扰安装时远程操作的返回结果，影响安装正常执行。

编辑sshd_config文件

vi /etc/ssh/sshd_config

修改Banner配置，注释掉“Banner”所在的行

执行 :wq 保存并退出编辑页面

使设置生效

[root@node0 ~]# systemctl restart sshd.service

以root用户身份重新登录

[root@node0 ~]# ssh 192.168.192.129
The authenticity of host '192.168.192.129 (192.168.192.129)' can't be established.
ED25519 key fingerprint is SHA256:YIx66zD1ELsXkT4D82ZpOk7Pbity1evlwbtM9kc3wcI.
This key is not known by any other names
Are you sure you want to continue connecting (yes/no/[fingerprint])? yes
Warning: Permanently added '192.168.192.129' (ED25519) to the list of known hosts.
root@192.168.192.129's password:

Authorized users only. All activities may be monitored and reported.
Activate the web console with: systemctl enable --now cockpit.socket

Last login: Thu Jul 20 21:39:19 2023 from 192.168.192.1


Welcome to 5.10.0-153.12.0.92.oe2203sp2.x86_64

System information as of time:  Thu Jul 20 10:34:04 PM CST 2023

System load:    0.00
Processes:      165
Memory used:    6.3%
Swap used:      0.0%
Usage On:       4%
IP address:     192.168.192.129
Users online:   2

创建用户和用户组

为了实现安装过程中安装帐户权限最小化，及安装后openGauss的系统运行安全性，安装脚本在安装过程中会自动按照用户指定内容创建安装用户，并将此用户作为后续运行和维护openGauss的管理员帐户。

用户组：dbgrp

[root@node0 ~]# groupadd dbgrp

用户：omm

[root@node0 ~]# useradd -g dbgrp omm
[root@node0 ~]#
[root@node0 ~]# echo 'omm!666' | passwd --stdin omm
Changing password for user omm.
passwd: all authentication tokens updated successfully.
[root@node0 ~]#
[root@node0 ~]# id omm
uid=1001(omm) gid=1001(dbgrp) groups=1001(dbgrp)

创建目录

以root用户登录待安装openGauss的主机，并按规划创建存放安装包的目录。
不建议把安装包的存放目录规划到openGauss用户的根目录或其子目录下，可能导致权限问题。
openGauss用户须具有/opt/software/openGauss目录的读写权限。

[root@node0 ~]# mkdir -p /opt/software/openGauss
[root@node0 ~]# chmod 755 -R /opt/software

上传安装包

将安装包openGauss-5.0.0-openEuler-64bit-all.tar.gz上传至所创建的/opt/software/openGauss目录中

[root@node0 openGauss]# pwd
/opt/software/openGauss
[root@node0 openGauss]# ll
total 129824
-rw-r--r-- 1 root root 132936681 Jul 20 22:56 openGauss-5.0.0-openEuler-64bit-all.tar.gz
[root@node0 openGauss]#

解压安装包

[root@node0 openGauss]# tar -zxvf openGauss-5.0.0-openEuler-64bit-all.tar.gz
openGauss-5.0.0-openEuler-64bit-cm.tar.gz
openGauss-5.0.0-openEuler-64bit-om.tar.gz
openGauss-5.0.0-openEuler-64bit.tar.bz2
openGauss-5.0.0-openEuler-64bit-cm.sha256
openGauss-5.0.0-openEuler-64bit-om.sha256
openGauss-5.0.0-openEuler-64bit.sha256
upgrade_sql.tar.gz
upgrade_sql.sha256
[root@node0 openGauss]#
[root@node0 openGauss]# tar -zxvf openGauss-5.0.0-openEuler-64bit-om.tar.gz
./lib/
./lib/_cffi_backend.so
./lib/six.py
./lib/paramiko/
./lib/paramiko/proxy.py
./lib/paramiko/pipe.py
......

创建xml文件

单节点配置文件

<?xml version="1.0" encoding="UTF-8"?>
<ROOT>
    <!-- openGauss整体信息 -->
    <CLUSTER>
        <!-- 数据库名称 -->
        <PARAM name="clusterName" value="dbCluster" />
        <!-- 数据库节点名称(hostname) -->
        <PARAM name="nodeNames" value="node0" />
        <!-- 数据库安装目录-->
        <PARAM name="gaussdbAppPath" value="/opt/huawei/install/app" />
        <!-- 日志目录-->
        <PARAM name="gaussdbLogPath" value="/var/log/omm" />
        <!-- 临时文件目录-->
        <PARAM name="tmpMppdbPath" value="/opt/huawei/tmp" />
        <!-- 数据库工具目录-->
        <PARAM name="gaussdbToolPath" value="/opt/huawei/install/om" />
        <!-- 数据库core文件目录-->
        <PARAM name="corePath" value="/opt/huawei/corefile" />
        <!-- 节点IP，与数据库节点名称列表一一对应 -->
        <PARAM name="backIp1s" value="192.168.192.129"/>
    </CLUSTER>
    <!-- 每台服务器上的节点部署信息 -->
    <DEVICELIST>
        <!-- 节点1上的部署信息 -->
        <DEVICE sn="node1_hostname">
            <!-- 节点1的主机名称 -->
            <PARAM name="name" value="node0"/>
            <!-- 节点1所在的AZ及AZ优先级 -->
            <PARAM name="azName" value="AZ1"/>
            <PARAM name="azPriority" value="1"/>
            <!-- 节点1的IP，如果服务器只有一个网卡可用，将backIP1和sshIP1配置成同一个IP -->
            <PARAM name="backIp1" value="192.168.192.129"/>
            <PARAM name="sshIp1" value="192.168.192.129"/>

            <!--dbnode-->
            <PARAM name="dataNum" value="1"/>
            <PARAM name="dataPortBase" value="15400"/>
            <PARAM name="dataNode1" value="/opt/huawei/install/data/dn"/>
            <PARAM name="dataNode1_syncNum" value="0"/>
        </DEVICE>
    </DEVICELIST>
</ROOT>

执行安装

采用交互模式执行预安装脚本

[root@node0 openGauss]# cd /opt/software/openGauss/script

执行初始化安装

[root@node0 script]# ./gs_preinstall -U omm -G dbgrp -X /opt/software/openGauss/cluster_config.xml

打印信息

/opt/software/openGauss/script/domain_utils/sql_handler/../../../lib/ipaddress.py:1106: SyntaxWarning: 'str' object is not callable; perhaps you missed a comma?
  raise TypeError("%s and %s are not of the same version" (a, b))
Parsing the configuration file.
Successfully parsed the configuration file.
Installing the tools on the local node.
Successfully installed the tools on the local node.
Setting host ip env
Successfully set host ip env.
Are you sure you want to create the user[omm] (yes/no)? yes
Preparing SSH service.
Successfully prepared SSH service.
Checking OS software.
Successfully check os software.
Checking OS version.
Successfully checked OS version.
Creating cluster's path.
Successfully created cluster's path.
Set and check OS parameter.
Setting OS parameters.
Successfully set OS parameters.
Warning: Installation environment contains some warning messages.
Please get more details by "/opt/software/openGauss/script/gs_checkos -i A -h node0 --detail".
Set and check OS parameter completed.
Preparing CRON service.
Successfully prepared CRON service.
Setting user environmental variables.
Successfully set user environmental variables.
Setting the dynamic link library.
Successfully set the dynamic link library.
Setting Core file
Successfully set core path.
Setting pssh path
Successfully set pssh path.
Setting Cgroup.
Successfully set Cgroup.
Set ARM Optimization.
No need to set ARM Optimization.
Fixing server package owner.
Setting finish flag.
Successfully set finish flag.
Preinstallation succeeded.

警告信息处理

查看详情

[root@node0 script]# /opt/software/openGauss/script/gs_checkos -i A -h node0 --detail

A6警告信息

A6. [ System control parameters status ] : Warning

# 操作系统参数设置
[root@node0 ~]# echo net.ipv4.tcp_retries1 = 5 >>/etc/sysctl.conf
[root@node0 ~]# echo net.ipv4.tcp_syn_retries = 5 >>/etc/sysctl.conf

# 使参数生效
[root@node0 ~]# sysctl -p
kernel.sysrq = 0
net.ipv4.ip_forward = 0
net.ipv4.conf.all.send_redirects = 0
net.ipv4.conf.default.send_redirects = 0
net.ipv4.conf.all.accept_source_route = 0
net.ipv4.conf.default.accept_source_route = 0
net.ipv4.conf.all.accept_redirects = 0
net.ipv4.conf.default.accept_redirects = 0
net.ipv4.conf.all.secure_redirects = 0
net.ipv4.conf.default.secure_redirects = 0
net.ipv4.icmp_echo_ignore_broadcasts = 1
net.ipv4.icmp_ignore_bogus_error_responses = 1
net.ipv4.conf.all.rp_filter = 1
net.ipv4.conf.default.rp_filter = 1
net.ipv4.tcp_syncookies = 1
kernel.dmesg_restrict = 1
net.ipv6.conf.all.accept_redirects = 0
net.ipv6.conf.default.accept_redirects = 0
net.ipv4.tcp_max_tw_buckets = 10000
net.ipv4.tcp_tw_reuse = 1
net.ipv4.tcp_keepalive_time = 30
net.ipv4.tcp_keepalive_intvl = 30
net.ipv4.tcp_retries2 = 12
net.ipv4.ip_local_reserved_ports = 15400-15407,20050-20057
net.core.wmem_max = 21299200
net.core.rmem_max = 21299200
net.core.wmem_default = 21299200
net.core.rmem_default = 21299200
kernel.sem = 250 6400000 1000 25600
net.ipv4.tcp_rmem = 8192 250000 16777216
net.ipv4.tcp_wmem = 8192 250000 16777216
vm.min_free_kbytes = 172879
net.core.netdev_max_backlog = 65535
net.ipv4.tcp_max_syn_backlog = 65535
net.core.somaxconn = 65535
kernel.shmall = 1152921504606846720
kernel.shmmax = 18446744073709551615
net.ipv4.tcp_retries1 = 5
net.ipv4.tcp_syn_retries = 5

A7警告信息

A7. [ File system configuration status ] : Warning

[root@node0 script]# ulimit -a
real-time non-blocking time  (microseconds, -R) unlimited
core file size              (blocks, -c) unlimited
data seg size               (kbytes, -d) unlimited
scheduling priority                 (-e) 0
file size                   (blocks, -f) unlimited
pending signals                     (-i) 13365
max locked memory           (kbytes, -l) 65536
max memory size             (kbytes, -m) unlimited
open files                          (-n) 1000000
pipe size                (512 bytes, -p) 8
POSIX message queues         (bytes, -q) 819200
real-time priority                  (-r) 0
stack size                  (kbytes, -s) 8192
cpu time                   (seconds, -t) unlimited
max user processes                  (-u) 13365
virtual memory              (kbytes, -v) unlimited
file locks                          (-x) unlimited

[root@node0 script]# echo "* soft nofile 1000000" >>/etc/security/limits.conf
[root@node0 script]# echo "* hard nofile 1000000" >>/etc/security/limits.conf

重新打开一个会话窗口

[root@node0 ~]# ulimit -a
real-time non-blocking time  (microseconds, -R) unlimited
core file size              (blocks, -c) unlimited
data seg size               (kbytes, -d) unlimited
scheduling priority                 (-e) 0
file size                   (blocks, -f) unlimited
pending signals                     (-i) 13365
max locked memory           (kbytes, -l) 65536
max memory size             (kbytes, -m) unlimited
open files                          (-n) 1000000
pipe size                (512 bytes, -p) 8
POSIX message queues         (bytes, -q) 819200
real-time priority                  (-r) 0
stack size                  (kbytes, -s) 8192
cpu time                   (seconds, -t) unlimited
max user processes                  (-u) unlimited
virtual memory              (kbytes, -v) unlimited
file locks                          (-x) unlimited

A11警告信息

A11.[ Network card configuration status ] : Warning

[root@node0 ~]# cd /etc/sysconfig/network-scripts/
[root@node0 network-scripts]# vi ifcfg-ens33

在文末追加 MTU=“8192”，重启生效。

TYPE=Ethernet
PROXY_METHOD=none
BROWSER_ONLY=no
BOOTPROTO=dhcp
DEFROUTE=yes
IPV4_FAILURE_FATAL=no
IPV6INIT=yes
IPV6_AUTOCONF=yes
IPV6_DEFROUTE=yes
IPV6_FAILURE_FATAL=no
NAME=ens33
UUID=3d97d676-8b1d-4639-b5b9-1094c543fc37
DEVICE=ens33
ONBOOT=yes

MTU="8192"

A12警告信息

A12.[ Time consistency status ] : Warning

查看ntp状态，发现ntp没有启动

[root@node0 script]# systemctl status ntpd
○ ntpd.service - Network Time Service
     Loaded: loaded (/usr/lib/systemd/system/ntpd.service; disabled; vendor preset: disabled)
     Active: inactive (dead)

启动ntp服务

[root@node0 script]# systemctl start ntpd
[root@node0 script]#

# 查看ntp状态
[root@node0 script]# systemctl status ntpd
● ntpd.service - Network Time Service
     Loaded: loaded (/usr/lib/systemd/system/ntpd.service; disabled; vendor preset: disabled)
     Active: active (running) since Thu 2023-07-20 23:39:09 CST; 9s ago
    Process: 2269 ExecStart=/usr/sbin/ntpd -u ntp:ntp $OPTIONS (code=exited, status=0/SUCCESS)
   Main PID: 2271 (ntpd)
      Tasks: 2 (limit: 21384)
     Memory: 1.7M
     CGroup: /system.slice/ntpd.service
             └─ 2271 /usr/sbin/ntpd -u ntp:ntp -g

Jul 20 23:39:09 node0 ntpd[2271]: Listen and drop on 0 v6wildcard [::]:123
Jul 20 23:39:09 node0 ntpd[2271]: Listen and drop on 1 v4wildcard 0.0.0.0:123
Jul 20 23:39:09 node0 ntpd[2271]: Listen normally on 2 lo 127.0.0.1:123
Jul 20 23:39:09 node0 ntpd[2271]: Listen normally on 3 ens33 192.168.192.129:123
Jul 20 23:39:09 node0 ntpd[2271]: Listen normally on 4 lo [::1]:123
Jul 20 23:39:09 node0 ntpd[2271]: Listen normally on 5 ens33 [fe80::20c:29ff:fe0f:5e3f%2]:123
Jul 20 23:39:09 node0 ntpd[2271]: Listening on routing socket on fd #22 for interface updates
Jul 20 23:39:09 node0 ntpd[2271]: kernel reports TIME_ERROR: 0x2041: Clock Unsynchronized
Jul 20 23:39:09 node0 ntpd[2271]: kernel reports TIME_ERROR: 0x2041: Clock Unsynchronized
Jul 20 23:39:09 node0 systemd[1]: Started Network Time Service.

查看ntp状态，如果发现ntp没有安装
- 安装ntp服务
- 启动ntp服务

重新执行初始化安装

[root@node0 openGauss]# cd /opt/software/openGauss/script

执行初始化安装

[root@node0 script]# ./gs_preinstall -U omm -G dbgrp -X /opt/software/openGauss/cluster_config.xml

打印信息

Parsing the configuration file.
Successfully parsed the configuration file.
Installing the tools on the local node.
Successfully installed the tools on the local node.
Setting host ip env
Successfully set host ip env.
Are you sure you want to create the user[omm] (yes/no)? yes
Preparing SSH service.
Successfully prepared SSH service.
Checking OS software.
Successfully check os software.
Checking OS version.
Successfully checked OS version.
Creating cluster's path.
Successfully created cluster's path.
Set and check OS parameter.
Setting OS parameters.
Successfully set OS parameters.
Set and check OS parameter completed.
Preparing CRON service.
Successfully prepared CRON service.
Setting user environmental variables.
Successfully set user environmental variables.
Setting the dynamic link library.
Successfully set the dynamic link library.
Setting Core file
Successfully set core path.
Setting pssh path
Successfully set pssh path.
Setting Cgroup.
Successfully set Cgroup.
Set ARM Optimization.
No need to set ARM Optimization.
Fixing server package owner.
Setting finish flag.
Successfully set finish flag.
Preinstallation succeeded.

无警告信息

执行安装

# 切换至omm用户
[root@node0 script]# su - omm
Last login: Thu Jul 20 23:45:39 CST 2023


Welcome to 5.10.0-153.12.0.92.oe2203sp2.x86_64

System information as of time:  2023年 07月 20日 星期四 23:47:15 CST

System load:    0.09
Processes:      176
Memory used:    6.6%
Swap used:      0.0%
Usage On:       6%
IP address:     192.168.192.129
Users online:   3
To run a command as administrator(user "root"),use "sudo <command>".
[omm@node0 ~]$

# 执行安装
# gs_install -X /opt/software/openGauss/cluster_config.xml --gsinit-parameter="--locale=en_US.utf8"
# 此处密码设置为：openGauss!666

[omm@node0 ~]$ gs_install -X /opt/software/openGauss/cluster_config.xml --gsinit-parameter="--locale=en_US.utf8"
Parsing the configuration file.
Check preinstall on every node.
Successfully checked preinstall on every node.
Creating the backup directory.
Successfully created the backup directory.
begin deploy..
Installing the cluster.
begin prepare Install Cluster..
Checking the installation environment on all nodes.
begin install Cluster..
Installing applications on all nodes.
Successfully installed APP.
begin init Instance..
encrypt cipher and rand files for database.

# 设置数据库密码
Please enter password for database:
# 确认数据库密码
Please repeat for database:

begin to create CA cert files
The sslcert will be generated in /opt/huawei/install/app/share/sslcert/om
NO cm_server instance, no need to create CA for CM.
Non-dss_ssl_enable, no need to create CA for DSS
Cluster installation is completed.
Configuring.
Deleting instances from all nodes.
Successfully deleted instances from all nodes.
Checking node configuration on all nodes.
Initializing instances on all nodes.
Updating instance configuration on all nodes.
Check consistence of memCheck and coresCheck on database nodes.
Configuring pg_hba on all nodes.
Configuration is completed.
The cluster status is Normal.
Successfully started cluster.
Successfully installed application.
end deploy..

安装验证

查看数据库启动状态

通过openGauss提供的gs_om工具可以完成数据库状态检查
以omm用户身份登录服务器
检查数据库状态是否正常

[omm@node0 ~]$ gs_om -t status --detail
[   Cluster State   ]

cluster_state   : Normal
redistributing  : No
current_az      : AZ_ALL

[  Datanode State   ]

    node node_ip         port      instance                            state
--------------------------------------------------------------------------------------------
1  node0 192.168.192.129 15400      6001 /opt/huawei/install/data/dn   P Primary Normal

服务器IP地址： 192.168.192.129
数据库的端口号： 15400
数据库数据路径： /opt/huawei/install/data/dn
P：安装时指定的角色为Primary
Primary： 实例为主实例
Normal： openGauss可用

登录数据库

数据库安装完成后，默认生成名称为postgres的数据库。第一次连接数据库时可以连接到此数据库。

[omm@node0 ~]$ gsql -d postgres -p 15400
gsql ((openGauss 5.0.0 build a07d57c3) compiled at 2023-03-29 03:37:13 commit 0 last mr  )
Non-SSL connection (SSL connection is recommended when requiring high-security)
Type "help" for help.

openGauss=# \l
                             List of databases
   Name    | Owner | Encoding |  Collate   |   Ctype    | Access privileges
-----------+-------+----------+------------+------------+-------------------
 postgres  | omm   | UTF8     | en_US.utf8 | en_US.utf8 |
 template0 | omm   | UTF8     | en_US.utf8 | en_US.utf8 | =c/omm           +
           |       |          |            |            | omm=CTc/omm
 template1 | omm   | UTF8     | en_US.utf8 | en_US.utf8 | =c/omm           +
           |       |          |            |            | omm=CTc/omm
(3 rows)

openGauss=# select sysdate;
       sysdate
---------------------
 2023-07-20 23:57:28
(1 row)

openGauss=#

postgres： openGauss安装完成后默认生成的数据库。初始可以连接到此数据库进行新数据库的创建。
15400： 数据库主节点的端口号

「喜欢这篇文章，您的关注和赞赏是给作者最好的鼓励」

关注作者

【我和openGauss的故事】记录在openEuler-22.03中安装openGauss_5.0.0企业版

【我和openGauss的故事】记录在openEuler-22.03中安装openGauss_5.0.0企业版

环境准备

获取openGauss安装包

安装依赖包

修改操作系统配置

关闭操作系统防火墙

关闭SELINUX

设置操作系统字符集

设置时区和时间

修改硬件时钟

关闭swap交换内存

设置网卡MTU值

关闭RemoveIPC

修改systemd-logind.service文件

关闭HISTORY记录

设置root用户远程登录

创建用户和用户组

创建目录

上传安装包

解压安装包

创建xml文件

执行安装

采用交互模式执行预安装脚本

警告信息处理

查看详情

A6警告信息

A7警告信息

A11警告信息

A12警告信息

重新执行初始化安装

执行安装

安装验证

查看数据库启动状态

登录数据库

评论
