如何用触发器实现企业微信自动告警

海豚调度 2023-10-10

456

原理

触发器监控工作流实例表，当工作流实例表中的状态更新后，针对状态为失败的任务进行企业微信告警。

发送企业微信消息函数

su - postgres
# 必须在pg的主机上线安装requests模块
pip install requests
# 以postgres用户登陆psql客户端到etl数据库
psql etl -U postgres
# 创建插件plpython3u
create extension plpython3u;
# plpython3u为不受信语言，所以只能被超级用户使用
# 在tool模式下建立发送企业微信消息函数tool.sp_send_wechat
CREATE OR REPLACE FUNCTION tool.sp_send_wechat(message json, webhook character varying DEFAULT 'https://qyapi.weixin.qq.com/cgi-bin/webhook/send?key=你自己的key'::character varying)
 RETURNS text
 LANGUAGE plpython3u
 SECURITY DEFINER
AS $function$
import requests
import json
"""
/*
 * 作者 : v-yuzhenc
 * 功能 : 给企业微信发送一条消息
 * message : 需要发送的消息，json格式
 * webhook : 企业微信机器人的webhook
 * */
"""
import requests
import json


# 企业微信自定义机器人的webhook地址
p_webhook = webhook
# 要发送的消息内容
p_message = json.loads(message)
# 发送POST请求
response = requests.post(p_webhook, data=json.dumps(p_message), headers={"Content-Type": "application/json"})


# 打印响应结果
return response.text
$function$
;
--将函数直接转给tool
ALTER FUNCTION tool.sp_send_wechat(json, varchar) OWNER TO tool;
--公开函数的执行权限
GRANT ALL ON FUNCTION tool.sp_send_wechat(json, varchar) TO public;
--将函数的执行权限授权给tool用户
GRANT ALL ON FUNCTION tool.sp_send_wechat(json, varchar) TO tool;
\q

远程执行命令函数

• 由于海豚调度的任务日志是以文件的形式存储在操作系统中，所以，必须在数据库中实现这样一个函数，能够读取海豚服务器的日志文件。

su - postgres
# 必须在pg的主机上安装paramiko模块
pip install paramiko
# 以postgres用户登陆psql客户端到etl数据库
psql etl -U postgres
# 上面已经创建了plpython3u插件，这里不需要再次建立了
# 创建远程执行命令函数tool.sp_remote_exec_command_nopass
CREATE OR REPLACE FUNCTION tool.sp_remote_exec_command_nopass(remote_command text, remote_host character varying DEFAULT 'dpmaster'::character varying, remote_port integer DEFAULT 22222, remote_username character varying DEFAULT 'dp'::character varying, remote_return_mode character varying DEFAULT 'stdout'::character varying)
 RETURNS text
 LANGUAGE plpython3u
 SECURITY DEFINER
AS $function$
import paramiko
"""
/*
 * 作者 : v-yuzhenc
 * 功能 : 免密（需要配置ssh免密）在远程服务器执行一条命令
 * remote_command : 需要执行的命令
 * remote_host : 远程主机名或ip
 * remote_port : ssh端口
 * remote_username : 免密登陆的用户
 * remote_return_mode : 返回信息的模式，stderr返回标准错误信息，否则返回标准输出
 * */
"""
# SSH连接信息
host = remote_host
port = remote_port
username = remote_username
private_key_path = '/home/postgres/.ssh/id_rsa'
ssh_command = remote_command


# 连接SSH服务器
ssh = paramiko.SSHClient()
ssh.set_missing_host_key_policy(paramiko.AutoAddPolicy())
private_key = paramiko.RSAKey.from_private_key_file(private_key_path)
ssh.connect(host, port, username, pkey=private_key)


# 通过SSH执行命令
stdin, stdout, stderr = ssh.exec_command(ssh_command)
p_stdout = stdout.read().decode().strip()
p_stderr = stderr.read().decode().strip()
# 关闭SSH连接
ssh.close()
# 打印响应结果
if remote_return_mode == 'stderr':
    return None if p_stderr == '' else p_stderr
else:
    return None if p_stdout == '' else p_stdout
$function$
;
-- Permissions
ALTER FUNCTION tool.sp_remote_exec_command_nopass(text, varchar, int4, varchar, varchar) OWNER TO tool;
GRANT ALL ON FUNCTION tool.sp_remote_exec_command_nopass(text, varchar, int4, varchar, varchar) TO tool;
GRANT ALL ON FUNCTION tool.sp_remote_exec_command_nopass(text, varchar, int4, varchar, varchar) TO dp;
\q

获取子工作流实例下所有子任务实例

su - postgres
psql etl -U dp
CREATE OR REPLACE FUNCTION dp.get_subtaskins_all(dp_p_ins_id integer)
 RETURNS integer[]
 LANGUAGE plpgsql
 SECURITY DEFINER
AS $function$
/*
 * 作者 : v-yuzhenc
 * 功能 : 根据工作流实例id获取子工作流实例下所有子任务实例，返回int类型的数组
 * dp_p_ins_id : 工作流实例id
 * */
declare
    p_process_instance_id int := dp_p_ins_id;
    v_result int[];
begin
    with recursive recursive_query as (
      -- 初始查询
      select
           parent_process_instance_id
          ,process_instance_id
          ,parent_task_instance_id
      from t_ds_relation_process_instance
      where parent_process_instance_id = p_process_instance_id
      union all
      -- 递归查询
      select
            t.parent_process_instance_id
           ,t.process_instance_id
           ,t.parent_task_instance_id
      from t_ds_relation_process_instance t
      inner join recursive_query r
      on (t.parent_process_instance_id = r.process_instance_id)
  ), tmp_b as (
      select parent_task_instance_id task_instance_id from recursive_query a
      union
      select b.id task_instance_id
      from recursive_query a, t_ds_task_instance b
      where a.process_instance_id = b.process_instance_id
  )
  select (string_to_array(string_agg(task_instance_id::text,','),','))::int[]
  into v_result
  from tmp_b
    ;
    return v_result;
end;
$function$
;


-- Permissions


ALTER FUNCTION dp.get_subtaskins_all(int4) OWNER TO dp;
GRANT ALL ON FUNCTION dp.get_subtaskins_all(int4) TO dp;
\q

企业微信告警触发器

• 由于企业微信markdown格式的消息艾特指定的人只能通过企业微信中的userid(即用户在企业微信中的账号)调用，所以，我们在海豚调度的元数据表t_ds_user中增加wechat_userid字段，人工将海豚的用户对应的企业微信的userid维护上去

# 以dp用户登录etl数据库
psql etl -U dp
# 增加字段
alter table t_ds_user add wechat_userid varchar(100);
comment on column t_ds_user.wechat_userid is '对应的企业微信的userid';
# 维护wechat_userid中的数据
# 这里根据自己的企业实际情况做
update t_ds_user
set wechat_userid = 'YuZhenChao'
where user_name = 'yuzhenchao'
;
CREATE OR REPLACE FUNCTION dp.tg_ds_udef_alert_wechat()
 RETURNS trigger
 LANGUAGE plpgsql
AS $function$
/*
 * 作者：v-yuzhenc
 * 功能：海豚调度工作流失败自动告警
 * */
declare
    i record;
    v_content text;
    v_message varchar;
begin
  case
    when new.state = 6 then
    begin
      for i in (
              select
             '<@'||coalesce(d.wechat_userid,'')||'>\r\n# [DolphinScheduler Job ]\r\n> 实例  id  :  ['||coalesce(a.id::varchar,'')||'/'||coalesce(b.id::varchar,'')||'](https://dolphin.tclpv.com/dolphinscheduler/ui/projects/'||coalesce(g.code::varchar,'')||'/workflow/instances/'||coalesce(a.id::varchar,'')||'?code='||coalesce(a.process_definition_code::varchar,'')||')\r\n> 项目名称 : <font color=\"comment\">'||coalesce(g.name,'')||'('||coalesce(g.code::varchar,'')||')</font>'||'\r\n> 工作流名 : <font color=\"comment\">'||coalesce(e.name,'')||'('||coalesce(a.process_definition_code::varchar,'')||')</font>'||'\r\n> 任务名称 : <font color=\"comment\">'||coalesce(b.name,'')||'('||coalesce(b.task_code::varchar,'')||')</font>'||'\r\n> 任务类型 : <font color=\"comment\">'||coalesce(b.task_type,'')||'</font>\r\n> 开始时间 : <font color=\"comment\">'||to_char(b.start_time,'yyyy-mm-dd hh24:mi:ss')||'</font>\r\n> 结束时间 : <font color=\"comment\">'||to_char(b.end_time,'yyyy-mm-dd hh24:mi:ss')||'</font>\r\n> 所属用户 : <font color=\"comment\">'||coalesce(d.user_name,'')||'('||coalesce(c.user_id::varchar,'')||')</font>\r\n> 任务状态 : <font color=\"warning\">Failed</font>'||'\r\n> 报错信息 : <font color=\"warning\">'||coalesce(tool.sp_remote_exec_command_nopass($remote_command$cat $remote_command$||b.log_path||$remote_command$ | grep "\[ERROR\]\|等表超时" | awk -F' - ' '{print $2!=null ? $2 : $1}' | head -1 | sed 's/\"/\\\"/g'$remote_command$,split_part(b.host,':',1)),'')||'</font>' as wechat_content
        from t_ds_process_instance a
        inner join t_ds_task_instance b
        on (a.id = b.process_instance_id)
        inner join t_ds_task_definition c
        on (b.task_code = c.code and b.task_definition_version = c."version")
        inner join t_ds_user d
        on (c.user_id = d.id)
        inner join t_ds_process_definition e
        on (a.process_definition_code = e.code and a.process_definition_version = e."version")
        inner join t_ds_project g
        on (e.project_code = g.code)
        where c.task_type <> 'SUB_PROCESS'
            and a.state = 6
            and b.state = 6
            and a.id = new.id
          ) loop
              v_content := i.wechat_content;
              v_message := $v_message${
    "msgtype":"markdown",
    "markdown": {
        "content":"$v_message$||v_content||$v_message$"
    }
}$v_message$;
                if v_message is not null then
                  --告警
                  perform tool.sp_send_wechat(v_message::json);
              end if;
            end loop;
      end;
      when new.state in (4,5) then
      begin
          --先告警
            select
           '# [DolphinScheduler Job ]\r\n> 实例  id  :  ['||coalesce(a.id::varchar,'')||'](https://dolphin.tclpv.com/dolphinscheduler/ui/projects/'||coalesce(g.code::varchar,'')||'/workflow/instances/'||coalesce(a.id::varchar,'')||'?code='||coalesce(a.process_definition_code::varchar,'')||')\r\n> 项目名称 : <font color=\"comment\">'||coalesce(g.name,'')||'('||coalesce(g.code::varchar,'')||')</font>'||'\r\n> 工作流名 : <font color=\"comment\">'||coalesce(e.name,'')||'('||coalesce(a.process_definition_code::varchar,'')||')</font>'||'\r\n> 开始时间 : <font color=\"comment\">'||to_char(a.start_time,'yyyy-mm-dd hh24:mi:ss')||'</font>\r\n> 结束时间 : <font color=\"comment\">'||to_char(coalesce(a.end_time,current_timestamp),'yyyy-mm-dd hh24:mi:ss')||'</font>'||'\r\n> 任务状态 : <font color=\"warning\">'||'Killed'||'</font>' as wechat_content
      into v_content
      from t_ds_process_instance a
      inner join t_ds_process_definition e
      on (a.process_definition_code = e.code and a.process_definition_version = e."version")
      inner join t_ds_project g
      on (e.project_code = g.code)
      where a.state in (4,5)
          and a.id = new.id
      ;
      v_message := $v_message${
    "msgtype":"markdown",
    "markdown": {
        "content":"$v_message$||v_content||$v_message$"
    }
}$v_message$;
            if v_message is not null then
                --告警
          perform tool.sp_send_wechat(v_message::json);
            end if;
        --先把工作流对应的任务实例置为失败
        update t_ds_task_instance
        set state = 6
        where state not in (6,7)
            and id = any(get_subtaskins_all(new.id))
        ;
            --更新工作流状态为失败
        update t_ds_process_instance
        set state = 6
        where id = new.id
        ;
      end;
      else
          null;
  end case;
    return new;
    exception when others then
        insert into t_ds_trigger_log (trigger_name,error_msg) values ('tg_ds_udef_alert_wechat',sqlerrm);
        return new;
end;
$function$
;


-- Permissions


ALTER FUNCTION dp.tg_ds_udef_alert_wechat() OWNER TO dp;
GRANT ALL ON FUNCTION dp.tg_ds_udef_alert_wechat() TO dp;




# 创建时候触发器
create trigger tg_state_ds_process_instance after update on dp.t_ds_process_instance for each row execute function dp.tg_ds_udef_alert_wechat();
\q
