前言

虽然官方推荐SpringBoot项目采用jar包方式发布，但是也可以打成war包发布到外部web容器（如Jetty,tomcat等）。接下来我们讨论一下，如何将一个SpringBoot项目打包成war包。

更多参考：

《SpringBoot项目发布到服务器的两种方式war和jar》

https://blog.csdn.net/weixin_40763897/article/details/105521123

搭建SpringBoot项目

创建SpringBoot目录

参考：《Maven的约定》手工创建工程目录。当然，你绝对可以使用IDE来创建。

# 存放pom.xml和所有的子目录
~/Desktop$ mkdir FlowerShop
# 项目的java源代码
~/Desktop/FlowerShop$ mkdir -p src/main/java
# 创建包com.flower和com.flower.controller
~/Desktop/FlowerShop$ mkdir -p src/main/java/com/flower/controller
# 目录结构
~/Desktop/FlowerShop$ tree -L 6
.
└── src
    └── main
        └── java
            └── com
                └── flower
                    └── controller

这个目录对于我们将要演示的内容已经足够了。

初始化pom.xml

创建pom.xml

~/Desktop/FlowerShop$ touch pom.xml

pom.xml中的内容

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.flower</groupId>
    <artifactId>FlowerShop</artifactId>
    <version>1.0-SNAPSHOT</version>
    <!--指定打包类型：pom,war,jar-->
    <packaging>war</packaging>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.2.6.RELEASE</version>
        <relativePath/>
    </parent>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
    </dependencies>
    <build>
        <!--指定打包的名称:FlowerShopDemo.war或FlowerShopDemo.jar-->
        <finalName>FlowerShopDemo</finalName>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

创建启动类

创建MainApplicationStarter.java

~/Desktop/FlowerShop$ touch src/main/java/com/flower/MainApplicationStarter.java
~/Desktop/FlowerShop$ vim  src/main/java/com/flower/MainApplicationStarter.java

MainApplicationStarter.java

package com.flower;




import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.builder.SpringApplicationBuilder;








@SpringBootApplication
public class MainApplicationStarter{




    public static void main(String[] args) {
        SpringApplication.run(MainApplicationStarter.class, args);
    }
}

创建Controller

创建HomeController.java

~/Desktop/FlowerShop$ touch src/main/java/com/flower/controller/HomeController.java
~/Desktop/FlowerShop$ vim  src/main/java/com/flower/controller/HomeController.java

HomeController.java

package com.flower.controller;




import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;








@RestController
public class HomeController{




    @GetMapping("/home")
    public String getHomePage() {
       return "I Love you to come to my Flower Shop!";
    }
}

运行测试

~/Desktop/FlowerShop$ mvn spring-boot:run

SpringBoot项目创建成功！未对项目进行调整前，打出war包部署到Jetty9，启动会报错：

~/Documents/jetty-distribution-9.4.27.v20200227/bin$ ./jetty.sh start
...
2020-04-15 11:00:30.101:WARN:oejw.WebAppContext:main: Failed startup of context o.e.j.w.WebAppContext@a859c5{FlowerShopDemo,/FlowerShopDemo,file:///tmp/jetty-0_0_0_0-8888-FlowerShopDemo_war-_FlowerShopDemo-any-8018217352624732370.dir/webapp/,UNAVAILABLE}{/home/kyun/Documents/jetty-distribution-9.4.27.v20200227/webapps/FlowerShopDemo.war}
java.util.ServiceConfigurationError: org.apache.juli.logging.Log: Provider org.eclipse.jetty.apache.jsp.JuliLog not a subtype
  at java.util.ServiceLoader.fail(ServiceLoader.java:239)
  ...

调整SpringBoot工程为打war包做准备

1.修改pom.xml

org.apache.juli.logging.Log: Provider org.eclipse.jetty.apache.jsp.JuliLog not a subtype：Jetty容器提供的JuliLog不是org.apache.juli.logging.Log的子类，这是由Jetty的加载机制造成的（直接部署到tomcat是没有这个问题的）。pom.xml作如下修改：

spring-boot-starter-web依赖中将tomcat排除

引入spring-boot-starter-jetty依赖

注释掉 spring-boot-maven-plugin插件

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.flower</groupId>
    <artifactId>FlowerShop</artifactId>
    <version>1.0-SNAPSHOT</version>
    <!--指定打包类型pom, war, jar-->
    <packaging>war</packaging>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.2.6.RELEASE</version>
        <relativePath/>
    </parent>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
      <!-- 移除嵌入式tomcat插件 -->
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-tomcat</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
    <!-- 引入Jetty依赖 -->
    <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-jetty</artifactId>
        </dependency>
    </dependencies>
    <build>
  <!--指定打包的名称:FlowerShopDemo.war或FlowerShopDemo.jar-->
        <finalName>FlowerShopDemo</finalName>
        <plugins>
            <!--<plugin>-->
                <!--<groupId>org.springframework.boot</groupId>-->
                <!--<artifactId>spring-boot-maven-plugin</artifactId>-->
            <!--</plugin>-->
        </plugins>
    </build>
</project>

2.修改启动类

做因为我们要用外部web容器启动项目，所以启动类必须继承SpringBootServletInitializer，并重写configure方法。如果使用内嵌的web容器则不需要继承SpringBootServletInitializer。

package com.flower;






import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.builder.SpringApplicationBuilder;




import org.springframework.boot.web.servlet.support.SpringBootServletInitializer;








@SpringBootApplication
public class MainApplicationStarter extends SpringBootServletInitializer{




    public static void main(String[] args) {
        SpringApplication.run(MainApplicationStarter.class, args);
    }




    @Override
    protected SpringApplicationBuilder configure(SpringApplicationBuilder builder) {
        // 注意这里要指向原先用main方法执行的Application启动类
        return builder.sources(MainApplicationStarter.class);
    }
}
