Switch 之 Maipu Config

enable
configure terminal
show running-config

user admin password 0 admin123
user admin privilege 15
telnet client enable
aaa new-model
aaa authentication login default local
line vty 0 4
password 0 admin
login authentication default
privilege level 15
exit

vlan 10
exit
vlan 1001-4000
exit

int vlan 10
ip address 10.14.115.68 255.255.255.0
exit

ip route 0.0.0.0 0.0.0.0 10.14.115.1

interface gigabitethernet0/1
no shutdown
switchport mode access
switchport access vlan 10
interface gigabitethernet0/23
no shutdown
switchport mode trunk
switchport trunk allowed vlan all
interface gigabitethernet0/24
no shutdown
switchport mode trunk
switchport trunk allowed vlan all
int g0/2-0/22
no shutdown
switchport mode access
exit

# 创建session1组、并指定端口流量方向（Tx上行（传出），Rx下行（传入），both双向）
monitor session 1 filter packet-type good rx




# 镜像源端口
monitor session 1 source interface　镜像源端口 流量方向【入口rx、出口tx、双向both】


# 将ｇ1/0/1端口作为镜像源端口，入口方向流量
monitor session 1 source interface ｇ1/0/1 rx




# 镜像目的端口
monitor session 1 destination interface 目的端口　流量方向【入口rx、出口tx、双向both】


# 将ｇ1/0/2端口作为镜像目的端口
monitor session 1 destination interface g1/0/2




# 查看session 1的配置
show monitor session 1

write
