kafka的集群搭建、配置详解和Java api、延迟队列的三种思路

# 集群中配置跟如下相同


# broker 编号，集群内必须唯一
broker.id=1
# host 地址
host.name=127.0.0.1
# 端口
port=9092
# 消息日志存放地址
log.dirs=/opt/kafka/log
# ZooKeeper 地址，多个用,分隔
zookeeper.connect=localhost1:2181,localhost2:2181,localhost3:2181


# 启动
bin/kafka-server-start.sh -daemon config/server.properties
# 异步启动
nohup bin/kafka-server-start.sh config/server.properties &

# 集群中的配置相同


# 数据存放目录
dataDir=/opt/zookeeper/data
# 日志存放目录
dataLogDir=/opt/zookeeper/log
# 监听端口
clientPort=2181


# 集群配置
# server.x 分别对应myid文件的内容（每个 zoo.cfg 文件都需要添加）
# 2287(通讯端口):3387（选举端口）
server.1=localhost1:2287:3387
server.2=localhost2:2287:3387
server.3=localhost3:2287:3387


# 启动
./bin/zkServer.sh start

server:
  port: 8001
  servlet:
    context-path: /producer
spring:
  kafka:
    bootstrap-servers: 192.168.11.51:9092,192.168.11.51:9091
    producer:
      # 这个是kafka生产端最重要的选项
      # acks=0 ：生产者在成功写入消息之前不会等待任何来自服务器的响应。
      # acks=1 ：只要集群的首领节点收到消息，生产者就会收到一个来自服务器成功响应。
      # acks=-1: 表示分区leader必须等待消息被成功写入到所有的ISR副本(同步副本)中才认为producer请求成功。这种方案提供最高的消息持久性保证，但是理论上吞吐率也是最差的。
      acks: 1
      # 批量发送数据的配置
      batch-size: 16384
      # 设置kafka 生产者内存缓存区的大小（32M）
      buffer-memory: 33554432
      # kafka producer 发送消息失败时的一个重试的次数
      retries: 0
      # kafka消息的序列化配置
      key-serializer: org.apache.kafka.common.serialization.StringSerializer
      # 值的反序列化方式
      value-serializer: org.apache.kafka.common.serialization.StringSerializer

@Resource
private KafkaTemplate<String, String> kafkaTemplate;


public void sendMessage(String topic, String object) {


    ListenableFuture<SendResult<String, String>> future = kafkaTemplate.send(topic, JSON.toJSONString(object));


    future.addCallback(new ListenableFutureCallback<SendResult<String, String>>() {
        @Override
        public void onSuccess(SendResult<String, String> result) {
            log.info("发送消息成功: " + result.toString());
        }


        @Override
        public void onFailure(Throwable throwable) {
            log.error("发送消息失败: " + throwable.getMessage());
        }
    });
}

server:
  port: 8002
  servlet:
    context-path: /consumser
spring:
  kafka:
    bootstrap-servers: 192.168.11.51:9092,192.168.11.51:9091
    consumer:
      # 该属性指定了消费者在读取一个没有偏移量的分区或者偏移量无效的情况下该作何处理：
      # latest（默认值）在偏移量无效的情况下，消费者将从最新的记录开始读取数据（在消费者启动之后生成的记录）
      # earliest ：在偏移量无效的情况下，消费者将从起始位置读取分区的记录
      auto-offset-reset: earliest
      # consumer 消息的签收机制：手工签收
      enable-auto-commit: false
      # 序列化配置
      key-deserializer: org.apache.kafka.common.serialization.StringDeserializer
      # 值的反序列化方式
      value-deserializer: org.apache.kafka.common.serialization.StringDeserializer
    listener:
      # listner负责ack，每调用一次，就立即commit,可以在代码对每个消息监听设置成不同的
      ack-mode: manual
      # 在侦听器容器中运行的线程数。
      concurrency: 5

@KafkaListener(groupId = "group02", topics = "topic02")
public void onMessage(ConsumerRecord<String, Object> record, Acknowledgment acknowledgment, Consumer<?, ?> consumer) {
    log.info("消费端接收消息: {}", record.value());
    //  手工签收
    acknowledgment.acknowledge();
}

# 监听的时候指定 containerFactory 精确配置
@KafkaListener(containerFactory = "recordListenerContainerFactory" , topics = "test")


/**
 * 定制 接收 配置
 * @return
 */
public ConsumerFactory<String, Object> consumerFactory() {
    Map<String, Object> props = new HashMap<>();
    props.put(ConsumerConfig.BOOTSTRAP_SERVERS_CONFIG, kafkaProperties.getBootstrapServers());
//        props.put(ConsumerConfig.GROUP_ID_CONFIG, groupId);
//        props.put(ConsumerConfig.ENABLE_AUTO_COMMIT_CONFIG, enableAutoCommit);
    props.put(ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG, StringDeserializer.class);
    props.put(ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG, StringDeserializer.class);
    return new DefaultKafkaConsumerFactory<>(props);
}


@Bean("recordListenerContainerFactory")
public ConcurrentKafkaListenerContainerFactory<?, ?> kafkaListenerContainerFactory(
            ConcurrentKafkaListenerContainerFactoryConfigurer configurer,
            ConsumerFactory consumerFactory) {
    ConcurrentKafkaListenerContainerFactory<Object, Object> factory = new ConcurrentKafkaListenerContainerFactory<>();
    // 可以定制 消息队列 接收 的配置
    factory.setConsumerFactory(consumerFactory);
    //开启批量消费功能
    factory.setBatchListener(true);
    //不自动启动
    factory.setAutoStartup(false);
    factory.getContainerProperties().setPollTimeout(1500);
    //配置手动提交offset
    // MANUAL   当每一批poll()的数据被消费者监听器（ListenerConsumer）处理之后, 手动调用Acknowledgment.acknowledge()后提交
    factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.MANUAL);


    // COUNT　当每一批poll()的数据被消费者监听器（ListenerConsumer）处理之后，被处理record数量大于等于COUNT时提交，配合 使用
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.MANUAL);
    // factory.getContainerProperties().setAckCount(5);


    // TIME     当每一批poll()的数据被消费者监听器（ListenerConsumer）处理之后，距离上次提交时间大于PollTimeout时提交
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.TIME);


    // COUNT_TIME   TIME |　COUNT　有一个条件满足时提交
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.COUNT_TIME);


    // BATCH    当每一批poll()的数据被消费者监听器（ListenerConsumer）处理之后提交
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.BATCH);


    // RECORD   当每一条记录被消费者监听器（ListenerConsumer）处理之后提交
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.RECORD);


    // MANUAL_IMMEDIATE 手动调用Acknowledgment.acknowledge()后立即提交
    // factory.getContainerProperties().setAckMode(ContainerProperties.AckMode.MANUAL_IMMEDIATE);


    configurer.configure(factory, consumerFactory);
    return factory;
}

@KafkaListener(topics = "myJob")
@SendTo("myJob-delay")
public String onMessage(ConsumerRecord<?, ?> cr, Acknowledgment ack) {
    // 传入参数
    String json = (String) cr.value();
    JSONObject data = JSON.parseObject(json);
    long msToDelay = data.getLong("msToDelay");
    if (msToDelay > 0) {
        // 提交
        ack.acknowledge();
        // 发送到 @SendTo
        data.put("until", System.currentTimeMillis() + msToDelay);
        return data.toString();
    }


    // 正常处理
    // do real work


    // 提交
    ack.acknowledge();
    return null;
}


@KafkaListener(topics = "myJob-delay")
@SendTo("myJob")
public String delayMessage(ConsumerRecord<?, ?> cr, Acknowledgment ack) throws InterruptedException {
    // 传入参数
    String json = (String) cr.value();
    JSONObject data = JSON.parseObject(json);
    Long until = data.getLong("until");
    // 阻塞直到 until
    while (System.currentTimeMillis() < until) {
        Thread.sleep(Math.max(0, until - System.currentTimeMillis()));
    }
    // 提交
    ack.acknowledge();
    // 转移到 @SendTo
    return json;
}

/**
 * kafka监听工厂
 * 不自动启动
 * @param configurer
 * @return
 */
@Bean("batchFactory")
public ConcurrentKafkaListenerContainerFactory<?, ?> kafkaListenerContainerFactory(
        ConcurrentKafkaListenerContainerFactoryConfigurer configurer,
        ConsumerFactory consumerFactory) {
    ConcurrentKafkaListenerContainerFactory<Object, Object> factory = new ConcurrentKafkaListenerContainerFactory<>();
    // 可以定制 消息队列 接收 的配置
    factory.setConsumerFactory(consumerFactory);
    //开启批量消费功能
    factory.setBatchListener(true);
    //不自动启动
    factory.setAutoStartup(false);
    configurer.configure(factory, consumerFactory);
    return factory;
}


/**
 * 定时执行
 * containerFactory 属性对应上面bean的名称
 * @param recordList
 * @param acknowledgment
 */
@KafkaListener(id = "test-task", topics = {"test-task"}, groupId = "test-topic", containerFactory = "batchFactory")
public void listenFailEmail(List<ConsumerRecord> recordList, Acknowledgment acknowledgment) {
    for (ConsumerRecord record : recordList) {
        log.info("fail email-消息：【{}】。", record.toString());
    }
    acknowledgment.acknowledge();
}


@Scheduled(cron = "0 53 20 * * ?")
public void startListener() {
    log.info("开启监听");
    MessageListenerContainer container = registry.getListenerContainer("test-task");
    if (!container.isRunning()) {
        container.start();
    }
    //恢复
    container.resume();
}


@Scheduled(cron = "0 54 20 * * ?")
public void shutdownListener() {
    log.info("关闭监听");
    //暂停
    MessageListenerContainer container = registry.getListenerContainer("test-task");
    container.pause();
}

@Resource
private KafkaTemplate<String, String> kafkaTemplate;


// 集合
private static DelayQueue<MyDelayQueue> delayQueue = new DelayQueue<>();


/**
 * 监听
 * @param json
 * @return
 * @throws Throwable
 */
@KafkaListener(topics = {KafkaConstants.KAFKA_TOPIC_MESSAGE_DELAY}, containerFactory = "kafkaContainerFactory")
public boolean onMessage(String json) throws Throwable {
    try {
        DelayMessage delayMessage = JSON.parseObject(json, DelayMessage.class);
        if (!isDelay(delayMessage)) {
            // 如果接收到消息时，消息已经可以发送了，直接发送到实际的队列
            sendActualTopic(delayMessage);
        } else {
            // 存储
            localStorage(delayMessage);
        }
    } catch (Throwable e) {
        log.error("consumer kafka delay message[{}] error!", json, e);
        throw e;
    }
    return true;
}


/**
 * 立即执行
 * @param delayMessage
 * @return
 */
private boolean isDelay(DelayMessage delayMessage) {
    if (delayMessage.getTime().compareTo(0L) == 0){
        return false;
    }
    return true;
}


/**
 * 发送消息
 * @param delayMessage
 */
private void sendActualTopic(DelayMessage delayMessage) {
    kafkaTemplate.send(delayMessage.getActualTopic(), JSON.toJSONString(delayMessage));
}


/**
 * 添加集合
 * @param delayMessage
 */
@SneakyThrows
private void localStorage(DelayMessage delayMessage) {
    delayQueue.add(new MyDelayQueue(delayMessage));
}


/**
 * 加载监听
 */
@PostConstruct
private void handleDelayQueue() {
    while (true){
        try {
            if (delayQueue.size() > 0){
                // 取出队列
                MyDelayQueue take = delayQueue.take();
                if (null == take){
                    // 延迟
                    Thread.sleep(1000);


                    continue;
                }
                // 将队列发送到队列中
                DelayMessage delayMessage = take.getDelayMessage();
                sendActualTopic(delayMessage);
            }
        } catch (InterruptedException e) {
            e.printStackTrace();
            log.error("handler kafka rocksdb delay message error!", e);
        }
    }
}

##每一个broker在集群中的唯一标示，要求是正数。在改变IP地址，不改变broker.id的话不会影响consumers
broker.id=0


# Switch to enable topic deletion or not, default value is false
## 是否允许自动创建topic ，若是false，就需要通过命令创建topic
delete.topic.enable=true


############################# Socket Server Settings #############################


# The address the socket server listens on. It will get the value returned from
# java.net.InetAddress.getCanonicalHostName() if not configured.
#   FORMAT:
#     listeners = listener_name://host_name:port
#   EXAMPLE:
#     listeners = PLAINTEXT://your.host.name:9092
#listeners=PLAINTEXT://:9092
##提供给客户端响应的端口
port=9092
host.name=192.168.1.128
# The number of threads handling network requests
## broker 处理消息的最大线程数，一般情况下不需要去修改
num.network.threads=3


# The number of threads doing disk I/O
## broker处理磁盘IO 的线程数 ，数值应该大于你的硬盘数
num.io.threads=8


# The send buffer (SO_SNDBUF) used by the socket server
## socket的发送缓冲区，socket的调优参数SO_SNDBUFF
socket.send.buffer.bytes=102400


# The receive buffer (SO_RCVBUF) used by the socket server
## socket的接受缓冲区，socket的调优参数SO_RCVBUFF
socket.receive.buffer.bytes=102400


# The maximum size of a request that the socket server will accept (protection against OOM)
## socket请求的最大数值，防止serverOOM，message.max.bytes必然要小于socket.request.max.bytes，会被topic创建时的指定参数覆盖
socket.request.max.bytes=104857600


############################# Log Basics #############################


# A comma seperated list of directories under which to store log files
##kafka数据的存放地址，多个地址的话用逗号分割/data/kafka-logs-1，/data/kafka-logs-2
log.dirs=/tmp/kafka-logs


# The default number of log partitions per topic. More partitions allow greater
# parallelism for consumption, but this will also result in more files across
# the brokers.
##每个topic的分区个数，若是在topic创建时候没有指定的话会被topic创建时的指定参数覆盖
num.partitions=1


# The number of threads per data directory to be used for log recovery at startup and flushing at shutdown.
# This value is recommended to be increased for installations with data dirs located in RAID array.
##我们知道segment文件默认会被保留7天的时间，超时的话就
##会被清理，那么清理这件事情就需要有一些线程来做。这里就是
##用来设置恢复和清理data下数据的线程数量
num.recovery.threads.per.data.dir=1


############################# Log Retention Policy #############################


# The following configurations control the disposal of log segments. The policy can
# be set to delete segments after a period of time, or after a given size has accumulated.
# A segment will be deleted whenever *either* of these criteria are met. Deletion always happens
# from the end of the log.


# The minimum age of a log file to be eligible for deletion due to age
##segment文件保留的最长时间，默认保留7天（168小时），
##超时将被删除，也就是说7天之前的数据将被清理掉。
log.retention.hours=168


# A size-based retention policy for logs. Segments are pruned from the log as long as the remaining
# segments don't drop below log.retention.bytes. Functions independently of log.retention.hours.
#log.retention.bytes=1073741824


# The maximum size of a log segment file. When this size is reached a new log segment will be created.
###日志文件中每个segment的大小，默认为1G
log.segment.bytes=1073741824


# The interval at which log segments are checked to see if they can be deleted according
# to the retention policies
##上面的参数设置了每一个segment文件的大小是1G，那么
##就需要有一个东西去定期检查segment文件有没有达到1G，
##多长时间去检查一次，就需要设置一个周期性检查文件大小
##的时间（单位是毫秒）。
log.retention.check.interval.ms=300000


############################# Zookeeper #############################


# Zookeeper connection string (see zookeeper docs for details).
# This is a comma separated host:port pairs, each corresponding to a zk
# server. e.g. "127.0.0.1:3000,127.0.0.1:3001,127.0.0.1:3002".
# You can also append an optional chroot string to the urls to specify the
# root directory for all kafka znodes.
#zookeeper.connect=localhost:2181
##消费者集群通过连接Zookeeper来找到broker。
##zookeeper连接服务器地址
zookeeper.connect=master:2181,worker1:2181,worker2:2181


# Timeout in ms for connecting to zookeeper
zookeeper.connection.timeout.ms=6000

https://gitee.com/hzy100java/hzy.git
