【K6】使用InfluxDB和Grafana图形化展示k6压测工具的测试数据【测试成功】

sudo dnf install https://dl.k6.io/rpm/repo.rpm
sudo dnf install k6

 import http from "k6/http";
 import {group, check} from "k6";

 export let options = {
   stages: [
     {duration: '30s', target: 5},
     {duration: '30s', target: 20},
     {duration: '30s', target: 50},
     {duration: '60s', target: 100},
   ]
 };

 export default function () {

   group('html page', function () {
     const res = http.get("http://www.xxx.com/about");
     check(res, {
       "status was 200": (r) => r.status === 200
     });
   });

 };


这个脚本是用于使用 k6 对网站进行负载测试的，k6 是一个流行的开源负载测试工具。


以下是脚本的功能：


1. 它从 k6 导入必要的模块：`http` 用于发出 HTTP 请求，`check` 用于验证响应。


2. 它在 `options` 对象中定义了测试的负载配置。测试将从 30 秒的 5 个虚拟用户开始，然后在接下来的 30 秒内增加到 20 个用户，再在接下来的 30 秒内增加到 50 个用户，最后在 60 秒内增加到 100 个用户。


3. `default` 函数是测试的入口点。它定义了每个虚拟用户在测试期间将执行的操作。


4. 在 `default` 函数内部，它将操作分组在 'html page' 下。这对于组织测试结果非常有用。


5. 它向网站的 "/about" 页面发送 GET 请求（将 "www.xxx.com" 替换为你要测试的实际网站）。


6. 它检查响应状态码以确保它是 200（HTTP OK）。如果状态码不是 200，检查将失败，并在测试结果中报告失败。

[root@ELK-Master k6]# k6 run --out influxdb=http://106.14.67.15:8086/load_test index.js


          \      |‾‾| ‾‾/   ‾‾/
     \    \     |  |/
      \/    \    |     (      ‾‾\
   /          \   |  |\  \ |  (‾)  |
  / __________ \  |__| \__\ \_____/ .io


  execution: local
     script: index.js
     output: InfluxDBv1 (http://106.14.67.15:8086)


  scenarios: (100.00%) 1 scenario, 100 max VUs, 3m0s max duration (incl. graceful stop)
           * default: Up to 100 looping VUs for 2m30s over 4 stages (gracefulRampDown: 30s, gracefulStop: 30s)




     █ html page


       ✓ status was 200


     checks.........................: 100.00% ✓ 6002      ✗ 0
     data_received..................: 34 MB   530 kB/s
     data_sent......................: 524 kB  8.2 kB/s
     group_duration.................: avg=86.04ms  min=21.73ms med=35.59ms max=1.99s    p(90)=178.68ms p(95)=360.78ms
     http_req_blocked...............: avg=378.7µs  min=542ns   med=1.91µs  max=88.07ms  p(90)=2.61µs   p(95)=3.23µs
     http_req_connecting............: avg=365.52µs min=0s      med=0s      max=51.53ms  p(90)=0s       p(95)=0s
     http_req_duration..............: avg=85.57ms  min=21.62ms med=35.34ms max=1.99s    p(90)=177.92ms p(95)=360.72ms
       { expected_response:true }...: avg=85.57ms  min=21.62ms med=35.34ms max=1.99s    p(90)=177.92ms p(95)=360.72ms
     http_req_failed................: 0.00%   ✓ 0         ✗ 6002
     http_req_receiving.............: avg=52.9ms   min=12.44µs med=2.17ms  max=1.95s    p(90)=142.23ms p(95)=294.33ms
     http_req_sending...............: avg=10.51µs  min=2.82µs  med=8.62µs  max=295.55µs p(90)=12.89µs  p(95)=22.87µs
     http_req_tls_handshaking.......: avg=0s       min=0s      med=0s      max=0s       p(90)=0s       p(95)=0s
     http_req_waiting...............: avg=32.65ms  min=21.26ms med=28.11ms max=729.15ms p(90)=35.89ms  p(95)=38.79ms
     http_reqs......................: 6002    93.535367/s
     iteration_duration.............: avg=86.05ms  min=21.75ms med=35.6ms  max=1.99s    p(90)=178.69ms p(95)=360.79ms
     iterations.....................: 6002    93.535367/s
     vus............................: 23      min=1       max=23
     vus_max........................: 100     min=100     max=100




running (1m04.2s), 000/100 VUs, 6002 complete and 24 interrupted iterations
default ✗ [===============>----------------------] 003/100 VUs  1m04.2s/2m30.0s

参考链接：
https://www.leeguangxing.cn/blog_post_76.html
https://blog.csdn.net/weixin_55018452/article/details/129054327
在此特别鸣谢参考链接原作者的创作。
