保姆级教程教你搭建MySQL MHA高可用架构

Whoami：5年+金融、政府、医疗领域工作经验的DBA
Certificate：OCP、PCP
Skill：Oracle、Mysql、PostgreSQL
Platform：CSDN、墨天伦、公众号（呆呆的私房菜）

## 创建数据库安装用户
useradd mysql8022
mkdir -p mysql/mysql8022
chown -R mysql8022.mysql8022 mysql/mysql8022
chmod 750 -R mysql/mysql8022


## 安装包上传到/mysql/mysql8022下
cd mysql/mysql8022/
xz -d mysql-8.0.22-linux-glibc2.12-x86_64.tar.xz
tar xf mysql-8.0.22-linux-glibc2.12-x86_64.tar
mv mysql-8.0.22-linux-glibc2.12-x86_64 mysql-8.0.22
vi home/mysql8022/.bashrc
export PATH=$PATH:/mysql/mysql8022/mysql-8.0.22/bin
export LD_LIBRARY_PATH=$LD_LIBRARY_PATH:/mysql/mysql8022/mysql-8.0.22/lib


## 创建数据库相关目录
su - mysql8022
mkdir -p mysql/mysql8022/{binlog,relaylog,log,redo,data,temp,conf}


## 编辑配置文件
vi mysql/mysql8022/conf/my.cnf
[client]
port = 3306
socket = mysql/mysql8022/temp/mysql.sock
default-character-set = utf8mb4
[mysqld]
#base
user = mysql8022
port = 3306
basedir = home/mysql8022/soft/mysql-8.0.22
datadir = mysql/mysql8022/data
tmpdir = mysql/mysql8022/temp
socket = mysql/mysql8022/temp/mysql.sock
pid-file = mysql/mysql8022/temp/mysql.pid
#Open files limit
open_files_limit = 65535
#Connection
max_connections = 3000
max_user_connections = 1000
max_connect_errors = 100
wait_timeout = 600
interactive_timeout = 600
thread_cache_size = 2560
back_log = 1024
#Character
character-set-server = utf8mb4
#isolation
transaction-isolation = READ-COMMITTED
#Time
default_time_zone = '+8:00'
log_timestamps = SYSTEM
#Binlog
server-id = 21
log-bin = mysql/mysql8022/binlog/mysql-bin
binlog_cache_size = 128m
max_binlog_cache_size = 6G
max_binlog_size = 1G
binlog_error_action = ABORT_SERVER
#sql mode
sql_mode=STRICT_TRANS_TABLES,NO_ZERO_IN_DATE,NO_ZERO_DATE,ERROR_FOR_DIVISION_BY_ZERO,NO_ENGINE_SUBSTITUTION
#gtid
gtid_mode = on
enforce_gtid_consistency = 1
#InnoDB
default-storage-engine = InnoDB
innodb_data_home_dir = mysql/mysql8022/data
innodb_data_file_path = ibdata1:500M:autoextend
innodb_temp_data_file_path = ibtmp1:200M:autoextend
innodb_file_per_table = 1
innodb_log_group_home_dir = mysql/mysql8022/redo
innodb_log_files_in_group = 3
innodb_buffer_pool_instances = 4
innodb_flush_log_at_trx_commit = 1
innodb_max_dirty_pages_pct = 75
innodb_open_files = 10000
#Relay log
relay-log-recovery = 1
relay-log = mysql/mysql8022/relaylog/relay-bin
relay-log-index = mysql/mysql8022/relaylog/relay-bin.index
relay_log_purge = 0
#Sync log
sync_binlog = 1
sync_relay_log = 1
sync_relay_log_info = 1
#Table
lower_case_table_names = 1
#Table cache
table_open_cache = 2048
table_definition_cache = 1024
table_open_cache_instances = 32
#Lock
lock_wait_timeout = 3600
explicit_defaults_for_timestamp = 1
#Cache buffer
key_buffer_size = 32M
key_cache_block_size = 16384
join_buffer_size = 8M
sort_buffer_size = 8M
read_buffer_size = 8M
read_rnd_buffer_size = 4M
bulk_insert_buffer_size = 64M
myisam_sort_buffer_size = 128M
myisam_max_sort_file_size = 2G
tmp_table_size = 32M
max_heap_table_size = 32M
max_allowed_packet = 32M
#Logs
log_error = mysql/mysql8022/log/mysql-error.log
slow_query_log = 1
slow_query_log_file = mysql/mysql8022/log/slow_statement.log
long_query_time = 3
log_queries_not_using_indexes = 1
log_timestamps = SYSTEM
log_throttle_queries_not_using_indexes = 60
general_log = 0
general_log_file = mysql/mysql8022/log/general_statement.log
[mysqld_safe]
log-error =  mysql/mysql8022/log/mysql-error.log
pid-file =  mysql/mysql8022/temp/mysql.pid
[mysqldump]
quick = on
max_allowed_packet = 32M


## 注意：默认初始化的表空间是12M，innodb-data-file-path=ibdata1:12M:autoextend
## 默认的表名存储方式是0 --lower-case-table-names=0
## 初始化数据库
mysqld --initialize-insecure --basedir=/home/mysql8022/soft/mysql-8.0.22 --datadir=/mysql/mysql8022/data --user=mysql8022 --lower-case-table-names=1 --innodb-data-file-path=ibdata1:500M:autoextend


## 启动数据库
mysqld_safe --defaults-file=/mysql/mysql8022/conf/my.cnf --user=mysql8022 &


## 修改用户密码
mysql -uroot -p -S/mysql/mysql8022/temp/mysql.sock
alter user root@'localhost' identified by 'root';
flush privileges;


## 登录数据库
mysql -uroot -proot -S/mysql/mysql8022/temp/mysql.sock

# 创建同步账号（所有数据库）
mysql -uroot -proot -S/mysql/mysql8022/temp/mysql.sock
create user 'repl'@'%' identified with 'mysql_native_password' by 'repl';
grant replication slave, replication_slave_admin on *.* to 'repl'@'%';
flush privileges;


# 创建mha监控用户monitor（所有数据库）
create user 'monitor'@'%' identified with 'mysql_native_password'  by 'monitor';
grant all privileges on *.* to 'monitor'@'%';
flush privileges;


# 重置binlog（所有数据库）
reset master;


# 从库执行
mysql -uroot -proot -S/mysql/mysql8022/temp/mysql.sock
change master to
master_host="10.28.12.21",
master_user="repl",
master_password="repl",
master_auto_position=1;
start slave;
show slave status\G;


# 配置从库只读
set global read_only=on

# 在线安装依赖
curl -o etc/yum.repos.d/epel-7.repo  http://mirrors.aliyun.com/repo/epel-7.repo
curl -o etc/yum.repos.d/CentOS-Base.repo https://mirrors.aliyun.com/repo/Centos-7.repo
yum clean all && yum repolist
yum -y install perl-Config-Tiny perl-Email-Date-Format perl-Log-Dispatch perl-Mail-Sender perl-Mail-Sendmail perl-MIME-Lite perl-MIME-Types perl-Parallel-ForkManager perl-Params-Validate perl-DBI perl-DBD-MySQL


# 离线安装依赖
# 上传依赖包到/opt/soft下
perl-Config-Tiny-2.14-7.el7.src.rpm
perl-Email-Date-Format-1.002-15.el7.noarch.rpm
perl-Log-Dispatch-2.41-1.el7.1.noarch.rpm
perl-Mail-Sender-0.8.23-1.el7.noarch.rpm
perl-Mail-Sendmail-0.79-21.el7.noarch.rpm
perl-MIME-Lite-3.030-1.el7.noarch.rpm
perl-MIME-Types-1.38-2.el7.noarch.rpm
perl-Parallel-ForkManager-1.18-2.el7.noarch.rpm
perl-Params-Validate-1.08-4.el7.x86_64.rpm
# 安装依赖
cd opt/soft/
yum -y install *.rpm


# 上传mha软件到/opt/mha下
mha4mysql-manager-0.58-0.el7.centos.noarch.rpm
mha4mysql-node-0.58-0.el7.centos.noarch.rpm
# 安装mha（安装manager，需要先装node，不然会缺少依赖）
cd opt/mha
rpm -ivh mha4mysql-node-0.58-0.el7.centos.noarch.rpm
rpm -ivh mha4mysql-manager-0.58-0.el7.centos.noarch.rpm

# 配置/etc/hosts文件(所有节点)
vi etc/hosts
10.28.12.21     host-01
10.28.12.22     host-02
10.28.12.23     host-03


# 安装用户(所有节点)
su - root
useradd mha
echo "mha" | passwd --stdin mha
# 这里是为了能够访问binlog文件
usermod -a -G mysql8022 mha
chmod -R 750 mysql/mysql8022


# 配置环境变量
vi home/mha/.bashrc
export PATH=$PATH:/mysql/mysql8022/mysql-8.0.22/bin
export LD_LIBRARY_PATH=$LD_LIBRARY_PATH:/mysql/mysql8022/mysql-8.0.22/lib


# 配置用户sudo权限(所有节点)
visudo
mha     ALL=(ALL)       NOPASSWD:ALL


# 配置互信(所有节点)
su - mha
ssh-keygen -t rsa
ssh-copy-id host-01
ssh-copy-id host-02
ssh-copy-id host-03
# 验证互信
ssh host-01 date
ssh host-02 date
ssh host-03 date


# 创建相关目录(mha node节点)
mkdir -p home/mha/masterha/{script,relaylogs_purge,work}


# 配置Slave节点relaylog自动清理脚本(两个slave节点)
vi home/mha/masterha/script/purge_relay_log.sh
#!/bin/bash
user=monitor
passwd=monitor
port=3306
log_dir='/home/mha/masterha/relaylogs_purge'
work_dir='/home/mha/masterha/work'
if [ ! -d $log_dir ]
then
   mkdir -p $log_dir
fi
/usr/bin/purge_relay_logs --user=$user --password=$passwd --port=$port --workdir=$work_dir --disable_relay_log_purge >> $log_dir/purge_relay_logs.log 2>&1
# 配置定时任务
chmod +x home/mha/masterha/script/purge_relay_log.sh
crontab -e
30 23 * * * sh home/mha/masterha/script/purge_relay_log.sh


# 配置mha配置文件(mater配置)
mkdir -p home/mha/masterha/conf
mkdir -p home/mha/masterha/log
vi home/mha/masterha/conf/mha.conf
[server default]
user=monitor
password=monitor
repl_user=repl
repl_password=repl
ssh_user=mha
ping_interval=1
master_binlog_dir=/mysql/mysql8022/binlog
manager_workdir=/home/mha/masterha/work
manager_log=/home/mha/masterha/log/manager.log
master_ip_failover_script=/home/mha/masterha/script/master_ip_failover
master_ip_online_change_script=/home/mha/masterha/script/master_ip_online_change
secondary_check_script=/usr/bin/masterha_secondary_check -s host-02 -s host-03 --user=mha --master_host=host-01 --master_ip=10.28.12.21 --master_port=3306
report_script=/home/mha/masterha/script/send_report
remote_workdir=/home/mha/masterha/work
[server1]
hostname=host-01
port=3306
[server2]
hostname=host-02
port=3306
candidate_master=1
check_repl_delay=0
[server3]
hostname=host-03
port=3306


# 配置vip（配置在mysql master节点上）
/sbin/ifconfig eth0:1 10.28.12.99/24
# 检查vip添加是否成功
ip a | grep eth0


# 配置master_ip_failover脚本
vi home/mha/masterha/script/master_ip_failover
#!/usr/bin/env perl
use strict;
use warnings FATAL => 'all';
use Getopt::Long;
my (
$command, $ssh_user, $orig_master_host, $orig_master_ip,
$orig_master_port, $new_master_host, $new_master_ip, $new_master_port
);
#############################添加内容部分#########################################
my $vip = '10.28.12.99';
my $brdc = '10.28.12.255';
my $ifdev = 'eth0';
my $key = '1';
my $ssh_start_vip = "sudo usr/sbin/ip addr add $vip/24 brd $brdc dev $ifdev label $ifdev:$key;/usr/sbin/arping -q -A -c 1 -I $ifdev $vip;";
my $ssh_stop_vip = "sudo usr/sbin/ip addr del $vip/24 dev $ifdev label $ifdev:$key";
##################################################################################
GetOptions(
'command=s' => \$command,
'ssh_user=s' => \$ssh_user,
'orig_master_host=s' => \$orig_master_host,
'orig_master_ip=s' => \$orig_master_ip,
'orig_master_port=i' => \$orig_master_port,
'new_master_host=s' => \$new_master_host,
'new_master_ip=s' => \$new_master_ip,
'new_master_port=i' => \$new_master_port,
);
exit &main();
sub main {
print "\n\nIN SCRIPT TEST====$ssh_stop_vip==$ssh_start_vip===\n\n";
if ( $command eq "stop" || $command eq "stopssh" ) {
my $exit_code = 1;
eval {
print "Disabling the VIP on old master: $orig_master_host \n";
&stop_vip();
$exit_code = 0;
};
if ($@) {
warn "Got Error: $@\n";
exit $exit_code;
}
exit $exit_code;
}
elsif ( $command eq "start" ) {
my $exit_code = 10;
eval {
print "Enabling the VIP - $vip on the new master - $new_master_host \n";
&start_vip();
$exit_code = 0;
};
if ($@) {
warn $@;
exit $exit_code;
}
exit $exit_code;
}
elsif ( $command eq "status" ) {
print "Checking the Status of the script.. OK \n";
exit 0;
}
else {
&usage();
exit 1;
}
}
sub start_vip() {
`ssh $ssh_user\@$new_master_host \" $ssh_start_vip \"`;
}
# A simple system call that disable the VIP on the old_master
sub stop_vip() {
`ssh $ssh_user\@$orig_master_host \" $ssh_stop_vip \"`;
}
sub usage {
print
"Usage: master_ip_failover --command=start|stop|stopssh|status --orig_master_host=host --orig_master_ip=ip --orig_master_port=port --new_master_host=host --new_master_ip=ip --new_master_port=port\n";
}


# 配置master_ip_online_change脚本
vi /home/mha/masterha/script/master_ip_online_change
#!/usr/bin/env perl
use strict;
use warnings FATAL => 'all';
use Getopt::Long;
use MHA::DBHelper;
use MHA::NodeUtil;
use Time::HiRes qw( sleep gettimeofday tv_interval );
use Data::Dumper;
my $_tstart;
my $_running_interval = 0.1;
my (
  $command,
  $orig_master_is_new_slave, $orig_master_host, $orig_master_ip,  $orig_master_port, $orig_master_user,    $orig_master_password, $orig_master_ssh_user,
  $new_master_host,          $new_master_ip,    $new_master_port, $new_master_user,  $new_master_password, $new_master_ssh_user,
);
my $vip = '10.28.12.99';
my $brdc = '10.28.12.255';
my $ifdev = 'eth0';
my $key = '1';
my $ssh_start_vip = "sudo /usr/sbin/ip addr add $vip/24 brd $brdc dev $ifdev label $ifdev:$key;/usr/sbin/arping -q -A -c 1 -I $ifdev $vip;";
my $ssh_stop_vip = "sudo /usr/sbin/ip addr del $vip/24 dev $ifdev label $ifdev:$key";
GetOptions(
  'command=s'                => \$command,
  'orig_master_is_new_slave' => \$orig_master_is_new_slave,
  'orig_master_host=s'       => \$orig_master_host,
  'orig_master_ip=s'         => \$orig_master_ip,
  'orig_master_port=i'       => \$orig_master_port,
  'orig_master_user=s'       => \$orig_master_user,
  'orig_master_password=s'   => \$orig_master_password,
  'orig_master_ssh_user=s'   => \$orig_master_ssh_user,
  'new_master_host=s'        => \$new_master_host,
  'new_master_ip=s'          => \$new_master_ip,
  'new_master_port=i'        => \$new_master_port,
  'new_master_user=s'        => \$new_master_user,
  'new_master_password=s'    => \$new_master_password,
  'new_master_ssh_user=s'    => \$new_master_ssh_user,
);
exit &main();
sub current_time_us {
  my ( $sec, $microsec ) = gettimeofday();
  my $curdate = localtime($sec);
  return $curdate . " " . sprintf( "%06d", $microsec );
}
sub sleep_until {
  my $elapsed = tv_interval($_tstart);
  if ( $_running_interval > $elapsed ) {
    sleep( $_running_interval - $elapsed );
  }
}
sub get_threads_util {
  my $dbh                    = shift;
  my $my_connection_id       = shift;
  my $running_time_threshold = shift;
  my $type                   = shift;
  $running_time_threshold = 0 unless ($running_time_threshold);
  $type                   = 0 unless ($type);
  my @threads;
  my $sth = $dbh->prepare("SHOW PROCESSLIST");
  $sth->execute();
  while ( my $ref = $sth->fetchrow_hashref() ) {
    my $id         = $ref->{Id};
    my $user       = $ref->{User};
    my $host       = $ref->{Host};
    my $command    = $ref->{Command};
    my $state      = $ref->{State};
    my $query_time = $ref->{Time};
    my $info       = $ref->{Info};
    $info =~ s/^\s*(.*?)\s*$/$1/ if defined($info);
    next if ( $my_connection_id == $id );
    next if ( defined($query_time) && $query_time < $running_time_threshold );
    next if ( defined($command)    && $command eq "Binlog Dump" );
    next if ( defined($user)       && $user eq "system user" );
    next
      if ( defined($command)
      && $command eq "Sleep"
      && defined($query_time)
      && $query_time >= 1 );
    if ( $type >= 1 ) {
      next if ( defined($command) && $command eq "Sleep" );
      next if ( defined($command) && $command eq "Connect" );
    }
    if ( $type >= 2 ) {
      next if ( defined($info) && $info =~ m/^select/i );
      next if ( defined($info) && $info =~ m/^show/i );
    }
    push @threads, $ref;
  }
  return @threads;
}
sub main {
  if ( $command eq "stop" ) {
    ## Gracefully killing connections on the current master
    # 1. Set read_only= 1 on the new master
    # 2. DROP USER so that no app user can establish new connections
    # 3. Set read_only= 1 on the current master
    # 4. Kill current queries
    # * Any database access failure will result in script die.
    my $exit_code = 1;
    eval {
      ## Setting read_only=1 on the new master (to avoid accident)
      my $new_master_handler = new MHA::DBHelper();


      # args: hostname, port, user, password, raise_error(die_on_error)_or_not
      $new_master_handler->connect( $new_master_ip, $new_master_port,
        $new_master_user, $new_master_password, 1 );
      print current_time_us() . " Set read_only on the new master.. ";
      $new_master_handler->enable_read_only();
      if ( $new_master_handler->is_read_only() ) {
        print "ok.\n";
      }
      else {
        die "Failed!\n";
      }
      $new_master_handler->disconnect();
      # Connecting to the orig master, die if any database error happens
      my $orig_master_handler = new MHA::DBHelper();
      $orig_master_handler->connect( $orig_master_ip, $orig_master_port,
        $orig_master_user, $orig_master_password, 1 );
      ## Drop application user so that nobody can connect. Disabling per-session binlog beforehand
      #$orig_master_handler->disable_log_bin_local();
      #print current_time_us() . " Drpping app user on the orig master..\n";
      #FIXME_xxx_drop_app_user($orig_master_handler);
      ## Waiting for N * 100 milliseconds so that current connections can exit
      my $time_until_read_only = 15;
      $_tstart = [gettimeofday];
      my @threads = get_threads_util( $orig_master_handler->{dbh},
        $orig_master_handler->{connection_id} );
      while ( $time_until_read_only > 0 && $#threads >= 0 ) {
        if ( $time_until_read_only % 5 == 0 ) {
          printf
"%s Waiting all running %d threads are disconnected.. (max %d milliseconds)\n",
            current_time_us(), $#threads + 1, $time_until_read_only * 100;
          if ( $#threads < 5 ) {
            print Data::Dumper->new( [$_] )->Indent(0)->Terse(1)->Dump . "\n"
              foreach (@threads);
          }
        }
        sleep_until();
        $_tstart = [gettimeofday];
        $time_until_read_only--;
        @threads = get_threads_util( $orig_master_handler->{dbh},
          $orig_master_handler->{connection_id} );
      }
      ## Setting read_only=1 on the current master so that nobody(except SUPER) can write
      print current_time_us() . " Set read_only=1 on the orig master.. ";
      $orig_master_handler->enable_read_only();
      if ( $orig_master_handler->is_read_only() ) {
        print "ok.\n";
      }
      else {
        die "Failed!\n";
      }
      ## Waiting for M * 100 milliseconds so that current update queries can complete
      my $time_until_kill_threads = 5;
      @threads = get_threads_util( $orig_master_handler->{dbh},
        $orig_master_handler->{connection_id} );
      while ( $time_until_kill_threads > 0 && $#threads >= 0 ) {
        if ( $time_until_kill_threads % 5 == 0 ) {
          printf
"%s Waiting all running %d queries are disconnected.. (max %d milliseconds)\n",
            current_time_us(), $#threads + 1, $time_until_kill_threads * 100;
          if ( $#threads < 5 ) {
            print Data::Dumper->new( [$_] )->Indent(0)->Terse(1)->Dump . "\n"
              foreach (@threads);
          }
        }
        sleep_until();
        $_tstart = [gettimeofday];
        $time_until_kill_threads--;
        @threads = get_threads_util( $orig_master_handler->{dbh},
          $orig_master_handler->{connection_id} );
      }
                print "Disabling the VIP on old master: $orig_master_host \n";
                &stop_vip();
      ## Terminating all threads
      print current_time_us() . " Killing all application threads..\n";
      $orig_master_handler->kill_threads(@threads) if ( $#threads >= 0 );
      print current_time_us() . " done.\n";
      #$orig_master_handler->enable_log_bin_local();
      $orig_master_handler->disconnect();


      ## After finishing the script, MHA executes FLUSH TABLES WITH READ LOCK
      $exit_code = 0;
    };
    if ($@) {
      warn "Got Error: $@\n";
      exit $exit_code;
    }
    exit $exit_code;
  }
  elsif ( $command eq "start" ) {
    ## Activating master ip on the new master
    # 1. Create app user with write privileges
    # 2. Moving backup script if needed
    # 3. Register new master's ip to the catalog database
# We don't return error even though activating updatable accounts/ip failed so that we don't interrupt slaves' recovery.
# If exit code is 0 or 10, MHA does not abort
    my $exit_code = 10;
    eval {
      my $new_master_handler = new MHA::DBHelper();
      # args: hostname, port, user, password, raise_error_or_not
      $new_master_handler->connect( $new_master_ip, $new_master_port,
        $new_master_user, $new_master_password, 1 );
      ## Set read_only=0 on the new master
      #$new_master_handler->disable_log_bin_local();
      print current_time_us() . " Set read_only=0 on the new master.\n";
      $new_master_handler->disable_read_only();
      ## Creating an app user on the new master
      #print current_time_us() . " Creating app user on the new master..\n";
      #FIXME_xxx_create_app_user($new_master_handler);
      #$new_master_handler->enable_log_bin_local();
      $new_master_handler->disconnect();
      ## Update master ip on the catalog database, etc
                print "Enabling the VIP - $vip on the new master - $new_master_host \n";
                &start_vip();
                $exit_code = 0;
    };
    if ($@) {
      warn "Got Error: $@\n";
      exit $exit_code;
    }
    exit $exit_code;
  }
  elsif ( $command eq "status" ) {
    # do nothing
    exit 0;
  }
  else {
    &usage();
    exit 1;
  }
}
# A simple system call that enable the VIP on the new master
sub start_vip() {
    `ssh $new_master_ssh_user\@$new_master_host \" $ssh_start_vip \"`;
}
# A simple system call that disable the VIP on the old_master
sub stop_vip() {
    `ssh $orig_master_ssh_user\@$orig_master_host \" $ssh_stop_vip \"`;
}
sub usage {
  print
"Usage: master_ip_online_change --command=start|stop|status --orig_master_host=host --orig_master_ip=ip --orig_master_port=port --orig_master_user=user --orig_master_password=password --orig_master_ssh_user=sshuser --new_master_host=host --new_master_ip=ip --new_master_port=port --new_master_user=user --new_master_password=password --new_master_ssh_user=sshuser \n";
  die;
}


# 编辑发送报告模板（发送信息到系统用户mail下）
vi /home/mha/masterha/script/send_report
#!/usr/bin/perl
use strict;
use warnings FATAL => 'all';
use Getopt::Long;
#new_master_host and new_slave_hosts are set only when recovering master succeeded
my ( $dead_master_host, $new_master_host, $new_slave_hosts, $subject, $body );
GetOptions(
  'orig_master_host=s' => \$dead_master_host,
  'new_master_host=s'  => \$new_master_host,
  'new_slave_hosts=s'  => \$new_slave_hosts,
  'subject=s'          => \$subject,
  'body=s'             => \$body,
);
my $log_file = '/var/spool/mail/mha';
my $current_date = `date '+%Y-%m-%d %H:%M:%S'`;
chomp $current_date;
my $log_message = "$current_date - $subject: $body";
open my $fh, '>>', $log_file or die "Cannot open $log_file: $!";
print $fh $log_message . "\n";
close $fh;
exit 0;


# 授权脚本权限
chmod 775 /home/mha/masterha/script/master_ip_failover /home/mha/masterha/script/master_ip_online_change /home/mha/masterha/script/send_report


# 检查ssh权限（主节点）
masterha_check_ssh --conf=/home/mha/masterha/conf/mha.conf


# 检查复制集群状态（主节点）
masterha_check_repl --conf=/home/mha/masterha/conf/mha.conf


# 配置mha启动脚本
vi /home/mha/masterha/script/mha_start.sh
nohup masterha_manager --conf=/home/mha/masterha/conf/mha.conf --remove_dead_master_conf --ignore_last_failover < /dev/null > /home/mha/masterha/log/manager.log 2>&1 &
chmod +x /home/mha/masterha/script/mha_start.sh


# 配置查看MHA manager状态脚本
vi /home/mha/masterha/script/mha_status.sh
masterha_check_status --conf=/home/mha/masterha/conf/mha.conf
chmod +x /home/mha/masterha/script/mha_status.sh


# 配置mha关闭脚本
vi /home/mha/masterha/script/mha_stop.sh
masterha_stop --conf=/home/mha/masterha/conf/mha.conf
chmod +x /home/mha/masterha/script/mha_stop.sh

1. 启动mha服务
sh /home/mha/masterha/script/mha_start.sh


# 启动日志如下
Sun Jul 28 22:21:08 2024 - [warning] Global configuration file /etc/masterha_default.cnf not found. Skipping.
Sun Jul 28 22:21:08 2024 - [info] Reading application default configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 22:21:08 2024 - [info] Reading server configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 22:21:08 2024 - [info] MHA::MasterMonitor version 0.58.
Sun Jul 28 22:21:09 2024 - [info] GTID failover mode = 0
Sun Jul 28 22:21:09 2024 - [info] Dead Servers:
Sun Jul 28 22:21:09 2024 - [info] Alive Servers:
Sun Jul 28 22:21:09 2024 - [info]   host-01(10.28.12.21:3306)
Sun Jul 28 22:21:09 2024 - [info]   host-02(10.28.12.22:3306)
Sun Jul 28 22:21:09 2024 - [info]   host-03(10.28.12.23:3306)
Sun Jul 28 22:21:09 2024 - [info] Alive Slaves:
Sun Jul 28 22:21:09 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:21:09 2024 - [info]     GTID ON
Sun Jul 28 22:21:09 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:21:09 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:21:09 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:21:09 2024 - [info]     GTID ON
Sun Jul 28 22:21:09 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:21:09 2024 - [info] Current Alive Master: host-01(10.28.12.21:3306)
Sun Jul 28 22:21:09 2024 - [info] Checking slave configurations..
Sun Jul 28 22:21:09 2024 - [info]  read_only=1 is not set on slave host-02(10.28.12.22:3306).
Sun Jul 28 22:21:09 2024 - [info]  read_only=1 is not set on slave host-03(10.28.12.23:3306).
Sun Jul 28 22:21:09 2024 - [info] Checking replication filtering settings..
Sun Jul 28 22:21:09 2024 - [info]  binlog_do_db= , binlog_ignore_db=
Sun Jul 28 22:21:09 2024 - [info]  Replication filtering check ok.
Sun Jul 28 22:21:09 2024 - [info] GTID (with auto-pos) is not supported
Sun Jul 28 22:21:09 2024 - [info] Starting SSH connection tests..
Sun Jul 28 22:21:12 2024 - [info] All SSH connection tests passed successfully.
Sun Jul 28 22:21:12 2024 - [info] Checking MHA Node version..
Sun Jul 28 22:21:12 2024 - [info]  Version check ok.
Sun Jul 28 22:21:12 2024 - [info] Checking SSH publickey authentication settings on the current master..
Sun Jul 28 22:21:13 2024 - [info] HealthCheck: SSH to host-01 is reachable.
Sun Jul 28 22:21:13 2024 - [info] Checking recovery script configurations on host-01(10.28.12.21:3306)..
Sun Jul 28 22:21:13 2024 - [info]   Executing command: save_binary_logs --command=test --start_pos=4 --binlog_dir=/mysql/mysql8022/binlog --output_file=/home/mha/masterha/work/save_binary_logs_test --manager_version=0.58 --start_file=mysql-bin.000001
Sun Jul 28 22:21:13 2024 - [info]   Connecting to mha@10.28.12.21(host-01:22)..
  Creating /home/mha/masterha/work if not exists..    ok.
  Checking output directory is accessible or not..
   ok.
  Binlog found at /mysql/mysql8022/binlog, up to mysql-bin.000001
Sun Jul 28 22:21:13 2024 - [info] Binlog setting check done.
Sun Jul 28 22:21:13 2024 - [info] Checking SSH publickey authentication and checking recovery script configurations on all alive slave servers..
Sun Jul 28 22:21:13 2024 - [info]   Executing command : apply_diff_relay_logs --command=test --slave_user='monitor' --slave_host=host-02 --slave_ip=10.28.12.22 --slave_port=3306 --workdir=/home/mha/masterha/work --target_version=8.0.22 --manager_version=0.58 --relay_dir=/mysql/mysql8022/relaylog --current_relay_log=relay-bin.000002  --slave_pass=xxx
Sun Jul 28 22:21:13 2024 - [info]   Connecting to mha@10.28.12.22(host-02:22)..
  Checking slave recovery environment settings..
    Relay log found at /mysql/mysql8022/relaylog, up to relay-bin.000002
    Temporary relay log file is /mysql/mysql8022/relaylog/relay-bin.000002
    Checking if super_read_only is defined and turned on.. not present or turned off, ignoring.
    Testing mysql connection and privileges..
mysql: [Warning] Using a password on the command line interface can be insecure.
 done.
    Testing mysqlbinlog output.. done.
    Cleaning up test file(s).. done.
Sun Jul 28 22:21:13 2024 - [info]   Executing command : apply_diff_relay_logs --command=test --slave_user='monitor' --slave_host=host-03 --slave_ip=10.28.12.23 --slave_port=3306 --workdir=/home/mha/masterha/work --target_version=8.0.22 --manager_version=0.58 --relay_dir=/mysql/mysql8022/relaylog --current_relay_log=relay-bin.000002  --slave_pass=xxx
Sun Jul 28 22:21:13 2024 - [info]   Connecting to mha@10.28.12.23(host-03:22)..
  Checking slave recovery environment settings..
    Relay log found at /mysql/mysql8022/relaylog, up to relay-bin.000002
    Temporary relay log file is /mysql/mysql8022/relaylog/relay-bin.000002
    Checking if super_read_only is defined and turned on.. not present or turned off, ignoring.
    Testing mysql connection and privileges..
mysql: [Warning] Using a password on the command line interface can be insecure.
 done.
    Testing mysqlbinlog output.. done.
    Cleaning up test file(s).. done.
Sun Jul 28 22:21:14 2024 - [info] Slaves settings check done.
Sun Jul 28 22:21:14 2024 - [info]
host-01(10.28.12.21:3306) (current master)
 +--host-02(10.28.12.22:3306)
 +--host-03(10.28.12.23:3306)


Sun Jul 28 22:21:14 2024 - [info] Checking master_ip_failover_script status:
Sun Jul 28 22:21:14 2024 - [info]   /home/mha/masterha/script/master_ip_failover --command=status --ssh_user=mha --orig_master_host=host-01 --orig_master_ip=10.28.12.21 --orig_master_port=3306




IN SCRIPT TEST====sudo /usr/sbin/ip addr del 10.28.12.99/24 dev eth0 label eth0:1==sudo /usr/sbin/ip addr add 10.28.12.99/24 brd 10.28.12.255 dev eth0 label eth0:1;/usr/sbin/arping -q -A -c 1 -I eth0 10.28.12.99;===


Checking the Status of the script.. OK
Sun Jul 28 22:21:14 2024 - [info]  OK.
Sun Jul 28 22:21:14 2024 - [warning] shutdown_script is not defined.
Sun Jul 28 22:21:14 2024 - [info] Set master ping interval 1 seconds.
Sun Jul 28 22:21:14 2024 - [info] Set secondary check script: /usr/bin/masterha_secondary_check -s host-02 -s host-03 --user=mha --master_host=host-01 --master_ip=10.28.12.21 --master_port=3306
Sun Jul 28 22:21:14 2024 - [info] Starting ping health check on host-01(10.28.12.21:3306)..
Sun Jul 28 22:21:14 2024 - [info] Ping(SELECT) succeeded, waiting until MySQL doesn't respond..




2. 模拟master节点故障
mysqladmin -uroot -proot -S/mysql/mysql8022/temp/mysql.sock shutdown


# 观察到MHA已经实现主备自动切换
# 业务IP从原master节点切换到新的master节点上
# 原slave节点同步指向了新的master节点上
Sun Jul 28 22:33:55 2024 - [warning] Got error on MySQL select ping: 1053 (Server shutdown in progress)
Sun Jul 28 22:33:55 2024 - [info] Executing secondary network check script: /usr/bin/masterha_secondary_check -s host-02 -s host-03 --user=mha --master_host=host-01 --master_ip=10.28.12.21 --master_port=3306  --user=mha  --master_host=host-01  --master_ip=10.28.12.21  --master_port=3306 --master_user=monitor --master_password=monitor --ping_type=SELECT
Sun Jul 28 22:33:55 2024 - [info] Executing SSH check script: exit 0
Sun Jul 28 22:33:55 2024 - [info] HealthCheck: SSH to host-01 is reachable.
Monitoring server host-02 is reachable, Master is not reachable from host-02. OK.
Monitoring server host-03 is reachable, Master is not reachable from host-03. OK.
Sun Jul 28 22:33:56 2024 - [info] Master is not reachable from all other monitoring servers. Failover should start.
Sun Jul 28 22:33:56 2024 - [warning] Got error on MySQL connect: 2003 (Can't connect to MySQL server on '10.28.12.21' (111))
Sun Jul 28 22:33:56 2024 - [warning] Connection failed 2 time(s)..
Sun Jul 28 22:33:57 2024 - [warning] Got error on MySQL connect: 2003 (Can't connect to MySQL server on '10.28.12.21' (111))
Sun Jul 28 22:33:57 2024 - [warning] Connection failed 3 time(s)..
Sun Jul 28 22:33:58 2024 - [warning] Got error on MySQL connect: 2003 (Can't connect to MySQL server on '10.28.12.21' (111))
Sun Jul 28 22:33:58 2024 - [warning] Connection failed 4 time(s)..
Sun Jul 28 22:33:58 2024 - [warning] Master is not reachable from health checker!
Sun Jul 28 22:33:58 2024 - [warning] Master host-01(10.28.12.21:3306) is not reachable!
Sun Jul 28 22:33:58 2024 - [warning] SSH is reachable.
Sun Jul 28 22:33:58 2024 - [info] Connecting to a master server failed. Reading configuration file /etc/masterha_default.cnf and /home/mha/masterha/conf/mha.conf again, and trying to connect to all servers to check server status..
Sun Jul 28 22:33:58 2024 - [warning] Global configuration file /etc/masterha_default.cnf not found. Skipping.
Sun Jul 28 22:33:58 2024 - [info] Reading application default configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 22:33:58 2024 - [info] Reading server configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 22:34:00 2024 - [info] GTID failover mode = 1
Sun Jul 28 22:34:00 2024 - [info] Dead Servers:
Sun Jul 28 22:34:00 2024 - [info]   host-01(10.28.12.21:3306)
Sun Jul 28 22:34:00 2024 - [info] Alive Servers:
Sun Jul 28 22:34:00 2024 - [info]   host-02(10.28.12.22:3306)
Sun Jul 28 22:34:00 2024 - [info]   host-03(10.28.12.23:3306)
Sun Jul 28 22:34:00 2024 - [info] Alive Slaves:
Sun Jul 28 22:34:00 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:00 2024 - [info]     GTID ON
Sun Jul 28 22:34:00 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:00 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:34:00 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:00 2024 - [info]     GTID ON
Sun Jul 28 22:34:00 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:00 2024 - [info] Checking slave configurations..
Sun Jul 28 22:34:00 2024 - [info]  read_only=1 is not set on slave host-02(10.28.12.22:3306).
Sun Jul 28 22:34:00 2024 - [info]  read_only=1 is not set on slave host-03(10.28.12.23:3306).
Sun Jul 28 22:34:00 2024 - [info] Checking replication filtering settings..
Sun Jul 28 22:34:00 2024 - [info]  Replication filtering check ok.
Sun Jul 28 22:34:00 2024 - [info] Master is down!
Sun Jul 28 22:34:00 2024 - [info] Terminating monitoring script.
Sun Jul 28 22:34:00 2024 - [info] Got exit code 20 (Master dead).
Sun Jul 28 22:34:01 2024 - [info] MHA::MasterFailover version 0.58.
Sun Jul 28 22:34:01 2024 - [info] Starting master failover.
Sun Jul 28 22:34:01 2024 - [info]
Sun Jul 28 22:34:01 2024 - [info] * Phase 1: Configuration Check Phase..
Sun Jul 28 22:34:01 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] GTID failover mode = 1
Sun Jul 28 22:34:02 2024 - [info] Dead Servers:
Sun Jul 28 22:34:02 2024 - [info]   host-01(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info] Checking master reachability via MySQL(double check)...
Sun Jul 28 22:34:02 2024 - [info]  ok.
Sun Jul 28 22:34:02 2024 - [info] Alive Servers:
Sun Jul 28 22:34:02 2024 - [info]   host-02(10.28.12.22:3306)
Sun Jul 28 22:34:02 2024 - [info]   host-03(10.28.12.23:3306)
Sun Jul 28 22:34:02 2024 - [info] Alive Slaves:
Sun Jul 28 22:34:02 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:34:02 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info] Starting GTID based failover.
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] ** Phase 1: Configuration Check Phase completed.
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] * Phase 2: Dead Master Shutdown Phase..
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] Forcing shutdown so that applications never connect to the current master..
Sun Jul 28 22:34:02 2024 - [info] Executing master IP deactivation script:
Sun Jul 28 22:34:02 2024 - [info]   /home/mha/masterha/script/master_ip_failover --orig_master_host=host-01 --orig_master_ip=10.28.12.21 --orig_master_port=3306 --command=stopssh --ssh_user=mha




IN SCRIPT TEST====sudo /usr/sbin/ip addr del 10.28.12.99/24 dev eth0 label eth0:1==sudo /usr/sbin/ip addr add 10.28.12.99/24 brd 10.28.12.255 dev eth0 label eth0:1;/usr/sbin/arping -q -A -c 1 -I eth0 10.28.12.99;===


Disabling the VIP on old master: host-01
RTNETLINK answers: Cannot assign requested address
Sun Jul 28 22:34:02 2024 - [info]  done.
Sun Jul 28 22:34:02 2024 - [warning] shutdown_script is not set. Skipping explicit shutting down of the dead master.
Sun Jul 28 22:34:02 2024 - [info] * Phase 2: Dead Master Shutdown Phase completed.
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] * Phase 3: Master Recovery Phase..
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] * Phase 3.1: Getting Latest Slaves Phase..
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] The latest binary log file/position on all slaves is mysql-bin.000001:335
Sun Jul 28 22:34:02 2024 - [info] Retrieved Gtid Set: 4c96b5ab-4cc1-11ef-9d49-02420a1c0c15:1
Sun Jul 28 22:34:02 2024 - [info] Latest slaves (Slaves that received relay log files to the latest):
Sun Jul 28 22:34:02 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:34:02 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info] The oldest binary log file/position on all slaves is mysql-bin.000001:335
Sun Jul 28 22:34:02 2024 - [info] Retrieved Gtid Set: 4c96b5ab-4cc1-11ef-9d49-02420a1c0c15:1
Sun Jul 28 22:34:02 2024 - [info] Oldest slaves:
Sun Jul 28 22:34:02 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:34:02 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] * Phase 3.3: Determining New Master Phase..
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] Searching new master from slaves..
Sun Jul 28 22:34:02 2024 - [info]  Candidate masters from the configuration file:
Sun Jul 28 22:34:02 2024 - [info]   host-02(10.28.12.22:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 22:34:02 2024 - [info]     GTID ON
Sun Jul 28 22:34:02 2024 - [info]     Replicating from 10.28.12.21(10.28.12.21:3306)
Sun Jul 28 22:34:02 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 22:34:02 2024 - [info]  Non-candidate masters:
Sun Jul 28 22:34:02 2024 - [info]  Searching from candidate_master slaves which have received the latest relay log events..
Sun Jul 28 22:34:02 2024 - [info] New master is host-02(10.28.12.22:3306)
Sun Jul 28 22:34:02 2024 - [info] Starting master failover..
Sun Jul 28 22:34:02 2024 - [info]
From:
host-01(10.28.12.21:3306) (current master)
 +--host-02(10.28.12.22:3306)
 +--host-03(10.28.12.23:3306)


To:
host-02(10.28.12.22:3306) (new master)
 +--host-03(10.28.12.23:3306)
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info] * Phase 3.3: New Master Recovery Phase..
Sun Jul 28 22:34:02 2024 - [info]
Sun Jul 28 22:34:02 2024 - [info]  Waiting all logs to be applied..
Sun Jul 28 22:34:02 2024 - [info]   done.
Sun Jul 28 22:34:02 2024 - [info] Getting new master's binlog name and position..
Sun Jul 28 22:34:02 2024 - [info]  mysql-bin.000001:342
Sun Jul 28 22:34:02 2024 - [info]  All other slaves should start replication from here. Statement should be: CHANGE MASTER TO MASTER_HOST='host-02 or 10.28.12.22', MASTER_PORT=3306, MASTER_AUTO_POSITION=1, MASTER_USER='repl', MASTER_PASSWORD='xxx';
Sun Jul 28 22:34:02 2024 - [info] Master Recovery succeeded. File:Pos:Exec_Gtid_Set: mysql-bin.000001, 342, 4c96b5ab-4cc1-11ef-9d49-02420a1c0c15:1
Sun Jul 28 22:34:02 2024 - [info] Executing master IP activate script:
Sun Jul 28 22:34:02 2024 - [info]   /home/mha/masterha/script/master_ip_failover --command=start --ssh_user=mha --orig_master_host=host-01 --orig_master_ip=10.28.12.21 --orig_master_port=3306 --new_master_host=host-02 --new_master_ip=10.28.12.22 --new_master_port=3306 --new_master_user='monitor'   --new_master_password=xxx
Unknown option: new_master_user
Unknown option: new_master_password




IN SCRIPT TEST====sudo /usr/sbin/ip addr del 10.28.12.99/24 dev eth0 label eth0:1==sudo /usr/sbin/ip addr add 10.28.12.99/24 brd 10.28.12.255 dev eth0 label eth0:1;/usr/sbin/arping -q -A -c 1 -I eth0 10.28.12.99;===


Enabling the VIP - 10.28.12.99 on the new master - host-02
RTNETLINK answers: File exists
Sun Jul 28 22:34:03 2024 - [info]  OK.
Sun Jul 28 22:34:03 2024 - [info] ** Finished master recovery successfully.
Sun Jul 28 22:34:03 2024 - [info] * Phase 3: Master Recovery Phase completed.
Sun Jul 28 22:34:03 2024 - [info]
Sun Jul 28 22:34:03 2024 - [info] * Phase 4: Slaves Recovery Phase..
Sun Jul 28 22:34:03 2024 - [info]
Sun Jul 28 22:34:03 2024 - [info]
Sun Jul 28 22:34:03 2024 - [info] * Phase 4.1: Starting Slaves in parallel..
Sun Jul 28 22:34:03 2024 - [info]
Sun Jul 28 22:34:03 2024 - [info] -- Slave recovery on host host-03(10.28.12.23:3306) started, pid: 22068. Check tmp log /home/mha/masterha/work/host-03_3306_20240728223400.log if it takes time..
Sun Jul 28 22:34:05 2024 - [info]
Sun Jul 28 22:34:05 2024 - [info] Log messages from host-03 ...
Sun Jul 28 22:34:05 2024 - [info]
Sun Jul 28 22:34:03 2024 - [info]  Resetting slave host-03(10.28.12.23:3306) and starting replication from the new master host-02(10.28.12.22:3306)..
Sun Jul 28 22:34:03 2024 - [info]  Executed CHANGE MASTER.
Sun Jul 28 22:34:04 2024 - [info]  Slave started.
Sun Jul 28 22:34:04 2024 - [info]  gtid_wait(4c96b5ab-4cc1-11ef-9d49-02420a1c0c15:1) completed on host-03(10.28.12.23:3306). Executed 0 events.
Sun Jul 28 22:34:05 2024 - [info] End of log messages from host-03.
Sun Jul 28 22:34:05 2024 - [info] -- Slave on host host-03(10.28.12.23:3306) started.
Sun Jul 28 22:34:05 2024 - [info] All new slave servers recovered successfully.
Sun Jul 28 22:34:05 2024 - [info]
Sun Jul 28 22:34:05 2024 - [info] * Phase 5: New master cleanup phase..
Sun Jul 28 22:34:05 2024 - [info]
Sun Jul 28 22:34:05 2024 - [info] Resetting slave info on the new master..
Sun Jul 28 22:34:05 2024 - [info]  host-02: Resetting slave info succeeded.
Sun Jul 28 22:34:05 2024 - [info] Master failover to host-02(10.28.12.22:3306) completed successfully.
Sun Jul 28 22:34:05 2024 - [info] Deleted server1 entry from /home/mha/masterha/conf/mha.conf .
Sun Jul 28 22:34:05 2024 - [info]


----- Failover Report -----


mha: MySQL Master failover host-01(10.28.12.21:3306) to host-02(10.28.12.22:3306) succeeded


Master host-01(10.28.12.21:3306) is down!


Check MHA Manager logs at host-03:/home/mha/masterha/log/manager.log for details.


Started automated(non-interactive) failover.
Invalidated master IP address on host-01(10.28.12.21:3306)
Selected host-02(10.28.12.22:3306) as a new master.
host-02(10.28.12.22:3306): OK: Applying all logs succeeded.
host-02(10.28.12.22:3306): OK: Activated master IP address.
host-03(10.28.12.23:3306): OK: Slave started, replicating from host-02(10.28.12.22:3306)
host-02(10.28.12.22:3306): Resetting slave info succeeded.
Master failover to host-02(10.28.12.22:3306) completed successfully.
Sun Jul 28 22:34:05 2024 - [info] Sending mail..
Unknown option: conf


3. 修复故障节点，重新加入集群中
# 注意：当原Master恢复后，不会自动转成Slave，需要手动处理，并将原Master加入到复制集群。
mysqld_safe --defaults-file=/mysql/mysql8022/conf/my.cnf --user=mysql8022 &
mysql -uroot -proot -S/mysql/mysql8022/temp/mysql.sock
CHANGE MASTER TO MASTER_HOST='10.28.12.22', MASTER_PORT=3306, MASTER_AUTO_POSITION=1, MASTER_USER='repl', MASTER_PASSWORD='repl';
start slave;
# 配置新主库只读
mysql -uroot -proot -S/mysql/mysql8022/temp/mysql.sock -e"set global read_only=on
# 修复mha.conf配置文件
# 由于在mha服务启动脚本中添加了--remove_dead_master_conf选项，切换后会自动将Master节点信息从/etc/masterha/mha.cnf中移除
vi /home/mha/masterha/conf/mha.conf
[server default]
manager_log=/home/mha/masterha/log/manager.log
manager_workdir=/home/mha/masterha/work
master_binlog_dir=/mysql/mysql8022/binlog
master_ip_failover_script=/home/mha/masterha/script/master_ip_failover
master_ip_online_change_script=/home/mha/masterha/script/master_ip_online_change
password=monitor
ping_interval=1
remote_workdir=/home/mha/masterha/work
repl_password=repl
repl_user=repl
report_script=/home/mha/masterha/script/send_report
secondary_check_script=/usr/bin/masterha_secondary_check -s host-02 -s host-03 --user=mha --master_host=host-02 --master_ip=10.28.12.22 --master_port=3306
ssh_user=mha
user=monitor
[server1]
hostname=host-02
port=3306
[server2]
candidate_master=1
check_repl_delay=0
hostname=host-01
port=3306
[server3]
hostname=host-03
port=3306


# 检查ssh状态
/usr/bin/masterha_check_ssh --conf=/home/mha/masterha/conf/mha.conf
# 检查主备复制
/usr/bin/masterha_check_repl --conf=/home/mha/masterha/conf/mha.conf

1. 启动mha服务
sh /home/mha/masterha/script/mha_start.sh


2. 执行主备切换
masterha_master_switch --conf=/home/mha/masterha/conf/mha.conf --master_state=alive --new_master_host=host-01 --new_master_port=3306 --orig_master_is_new_slave --running_updates_limit=10000
# 主备切换日志如下
Sun Jul 28 23:25:08 2024 - [info] MHA::MasterRotate version 0.58.
Sun Jul 28 23:25:08 2024 - [info] Starting online master switch..
Sun Jul 28 23:25:08 2024 - [info]
Sun Jul 28 23:25:08 2024 - [info] * Phase 1: Configuration Check Phase..
Sun Jul 28 23:25:08 2024 - [info]
Sun Jul 28 23:25:08 2024 - [warning] Global configuration file /etc/masterha_default.cnf not found. Skipping.
Sun Jul 28 23:25:08 2024 - [info] Reading application default configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 23:25:08 2024 - [info] Reading server configuration from /home/mha/masterha/conf/mha.conf..
Sun Jul 28 23:25:09 2024 - [info] GTID failover mode = 1
Sun Jul 28 23:25:09 2024 - [info] Current Alive Master: host-02(10.28.12.22:3306)
Sun Jul 28 23:25:09 2024 - [info] Alive Slaves:
Sun Jul 28 23:25:09 2024 - [info]   host-01(10.28.12.21:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 23:25:09 2024 - [info]     GTID ON
Sun Jul 28 23:25:09 2024 - [info]     Replicating from 10.28.12.22(10.28.12.22:3306)
Sun Jul 28 23:25:09 2024 - [info]     Primary candidate for the new Master (candidate_master is set)
Sun Jul 28 23:25:09 2024 - [info]   host-03(10.28.12.23:3306)  Version=8.0.22 (oldest major version between slaves) log-bin:enabled
Sun Jul 28 23:25:09 2024 - [info]     GTID ON
Sun Jul 28 23:25:09 2024 - [info]     Replicating from 10.28.12.22(10.28.12.22:3306)


It is better to execute FLUSH NO_WRITE_TO_BINLOG TABLES on the master before switching. Is it ok to execute on host-02(10.28.12.22:3306)? (YES/no): YES
Sun Jul 28 23:25:23 2024 - [info] Executing FLUSH NO_WRITE_TO_BINLOG TABLES. This may take long time..
Sun Jul 28 23:25:23 2024 - [info]  ok.
Sun Jul 28 23:25:23 2024 - [info] Checking MHA is not monitoring or doing failover..
Sun Jul 28 23:25:23 2024 - [info] Checking replication health on host-01..
Sun Jul 28 23:25:23 2024 - [info]  ok.
Sun Jul 28 23:25:23 2024 - [info] Checking replication health on host-03..
Sun Jul 28 23:25:23 2024 - [info]  ok.
Sun Jul 28 23:25:23 2024 - [info] host-01 can be new master.
Sun Jul 28 23:25:23 2024 - [info]
From:
host-02(10.28.12.22:3306) (current master)
 +--host-01(10.28.12.21:3306)
 +--host-03(10.28.12.23:3306)


To:
host-01(10.28.12.21:3306) (new master)
 +--host-03(10.28.12.23:3306)
 +--host-02(10.28.12.22:3306)


Starting master switch from host-02(10.28.12.22:3306) to host-01(10.28.12.21:3306)? (yes/NO): yes
Sun Jul 28 23:25:39 2024 - [info] Checking whether host-01(10.28.12.21:3306) is ok for the new master..
Sun Jul 28 23:25:39 2024 - [info]  ok.
Sun Jul 28 23:25:39 2024 - [info] host-02(10.28.12.22:3306): SHOW SLAVE STATUS returned empty result. To check replication filtering rules, temporarily executing CHANGE MASTER to a dummy host.
Sun Jul 28 23:25:39 2024 - [info] host-02(10.28.12.22:3306): Resetting slave pointing to the dummy host.
Sun Jul 28 23:25:39 2024 - [info] ** Phase 1: Configuration Check Phase completed.
Sun Jul 28 23:25:39 2024 - [info]
Sun Jul 28 23:25:39 2024 - [info] * Phase 2: Rejecting updates Phase..
Sun Jul 28 23:25:39 2024 - [info]
Sun Jul 28 23:25:39 2024 - [info] Executing master ip online change script to disable write on the current master:
Sun Jul 28 23:25:39 2024 - [info]   /home/mha/masterha/script/master_ip_online_change --command=stop --orig_master_host=host-02 --orig_master_ip=10.28.12.22 --orig_master_port=3306 --orig_master_user='monitor' --new_master_host=host-01 --new_master_ip=10.28.12.21 --new_master_port=3306 --new_master_user='monitor' --orig_master_ssh_user=mha --new_master_ssh_user=mha   --orig_master_is_new_slave --orig_master_password=xxx --new_master_password=xxx
Sun Jul 28 23:25:39 2024 918726 Set read_only on the new master.. ok.
Sun Jul 28 23:25:39 2024 922218 Waiting all running 3 threads are disconnected.. (max 1500 milliseconds)
{'Time' => '3448','db' => undef,'Id' => '7','User' => 'event_scheduler','State' => 'Waiting on empty queue','Command' => 'Daemon','Info' => undef,'Host' => 'localhost'}
{'Time' => '3096','db' => undef,'Id' => '37','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-03.docker-chen:50486'}
{'Time' => '2780','db' => undef,'Id' => '38','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-01.docker-chen:32654'}
Sun Jul 28 23:25:40 2024 428103 Waiting all running 3 threads are disconnected.. (max 1000 milliseconds)
{'Time' => '3449','db' => undef,'Id' => '7','User' => 'event_scheduler','State' => 'Waiting on empty queue','Command' => 'Daemon','Info' => undef,'Host' => 'localhost'}
{'Time' => '3097','db' => undef,'Id' => '37','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-03.docker-chen:50486'}
{'Time' => '2781','db' => undef,'Id' => '38','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-01.docker-chen:32654'}
Sun Jul 28 23:25:40 2024 937856 Waiting all running 3 threads are disconnected.. (max 500 milliseconds)
{'Time' => '3449','db' => undef,'Id' => '7','User' => 'event_scheduler','State' => 'Waiting on empty queue','Command' => 'Daemon','Info' => undef,'Host' => 'localhost'}
{'Time' => '3097','db' => undef,'Id' => '37','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-03.docker-chen:50486'}
{'Time' => '2781','db' => undef,'Id' => '38','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-01.docker-chen:32654'}
Sun Jul 28 23:25:41 2024 451314 Set read_only=1 on the orig master.. ok.
Sun Jul 28 23:25:41 2024 451933 Waiting all running 3 queries are disconnected.. (max 500 milliseconds)
{'Time' => '3450','db' => undef,'Id' => '7','User' => 'event_scheduler','State' => 'Waiting on empty queue','Command' => 'Daemon','Info' => undef,'Host' => 'localhost'}
{'Time' => '3098','db' => undef,'Id' => '37','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-03.docker-chen:50486'}
{'Time' => '2782','db' => undef,'Id' => '38','User' => 'repl','State' => 'Master has sent all binlog to slave; waiting for more updates','Command' => 'Binlog Dump GTID','Info' => undef,'Host' => 'host-01.docker-chen:32654'}
Disabling the VIP on old master: host-02
Sun Jul 28 23:25:42 2024 129349 Killing all application threads..
Sun Jul 28 23:25:42 2024 131797 done.
Sun Jul 28 23:25:42 2024 - [info]  ok.
Sun Jul 28 23:25:42 2024 - [info] Locking all tables on the orig master to reject updates from everybody (including root):
Sun Jul 28 23:25:42 2024 - [info] Executing FLUSH TABLES WITH READ LOCK..
Sun Jul 28 23:25:42 2024 - [info]  ok.
Sun Jul 28 23:25:42 2024 - [info] Orig master binlog:pos is mysql-bin.000001:342.
Sun Jul 28 23:25:42 2024 - [info]  Waiting to execute all relay logs on host-01(10.28.12.21:3306)..
Sun Jul 28 23:25:42 2024 - [info]  master_pos_wait(mysql-bin.000001:342) completed on host-01(10.28.12.21:3306). Executed 0 events.
Sun Jul 28 23:25:42 2024 - [info]   done.
Sun Jul 28 23:25:42 2024 - [info] Getting new master's binlog name and position..
Sun Jul 28 23:25:42 2024 - [info]  mysql-bin.000002:196
Sun Jul 28 23:25:42 2024 - [info]  All other slaves should start replication from here. Statement should be: CHANGE MASTER TO MASTER_HOST='host-01 or 10.28.12.21', MASTER_PORT=3306, MASTER_AUTO_POSITION=1, MASTER_USER='repl', MASTER_PASSWORD='xxx';
Sun Jul 28 23:25:42 2024 - [info] Executing master ip online change script to allow write on the new master:
Sun Jul 28 23:25:42 2024 - [info]   /home/mha/masterha/script/master_ip_online_change --command=start --orig_master_host=host-02 --orig_master_ip=10.28.12.22 --orig_master_port=3306 --orig_master_user='monitor' --new_master_host=host-01 --new_master_ip=10.28.12.21 --new_master_port=3306 --new_master_user='monitor' --orig_master_ssh_user=mha --new_master_ssh_user=mha   --orig_master_is_new_slave --orig_master_password=xxx --new_master_password=xxx
Sun Jul 28 23:25:42 2024 247802 Set read_only=0 on the new master.
Enabling the VIP - 10.28.12.99 on the new master - host-01
Sun Jul 28 23:25:42 2024 - [info]  ok.
Sun Jul 28 23:25:42 2024 - [info]
Sun Jul 28 23:25:42 2024 - [info] * Switching slaves in parallel..
Sun Jul 28 23:25:42 2024 - [info]
Sun Jul 28 23:25:42 2024 - [info] -- Slave switch on host host-03(10.28.12.23:3306) started, pid: 24678
Sun Jul 28 23:25:42 2024 - [info]
Sun Jul 28 23:25:43 2024 - [info] Log messages from host-03 ...
Sun Jul 28 23:25:43 2024 - [info]
Sun Jul 28 23:25:42 2024 - [info]  Waiting to execute all relay logs on host-03(10.28.12.23:3306)..
Sun Jul 28 23:25:42 2024 - [info]  master_pos_wait(mysql-bin.000001:342) completed on host-03(10.28.12.23:3306). Executed 0 events.
Sun Jul 28 23:25:42 2024 - [info]   done.
Sun Jul 28 23:25:42 2024 - [info]  Resetting slave host-03(10.28.12.23:3306) and starting replication from the new master host-01(10.28.12.21:3306)..
Sun Jul 28 23:25:42 2024 - [info]  Executed CHANGE MASTER.
Sun Jul 28 23:25:42 2024 - [info]  Slave started.
Sun Jul 28 23:25:43 2024 - [info] End of log messages from host-03 ...
Sun Jul 28 23:25:43 2024 - [info]
Sun Jul 28 23:25:43 2024 - [info] -- Slave switch on host host-03(10.28.12.23:3306) succeeded.
Sun Jul 28 23:25:43 2024 - [info] Unlocking all tables on the orig master:
Sun Jul 28 23:25:43 2024 - [info] Executing UNLOCK TABLES..
Sun Jul 28 23:25:43 2024 - [info]  ok.
Sun Jul 28 23:25:43 2024 - [info] Starting orig master as a new slave..
Sun Jul 28 23:25:43 2024 - [info]  Resetting slave host-02(10.28.12.22:3306) and starting replication from the new master host-01(10.28.12.21:3306)..
Sun Jul 28 23:25:43 2024 - [info]  Executed CHANGE MASTER.
Sun Jul 28 23:25:43 2024 - [info]  Slave started.
Sun Jul 28 23:25:43 2024 - [info] All new slave servers switched successfully.
Sun Jul 28 23:25:43 2024 - [info]
Sun Jul 28 23:25:43 2024 - [info] * Phase 5: New master cleanup phase..
Sun Jul 28 23:25:43 2024 - [info]
Sun Jul 28 23:25:43 2024 - [info]  host-01: Resetting slave info succeeded.
Sun Jul 28 23:25:43 2024 - [info] Switching master to host-01(10.28.12.21:3306) completed successfully.




3. 恢复mha.conf配置文件，恢复MHA监控服务
vi /home/mha/masterha/conf/mha.conf
[server default]
manager_log=/home/mha/masterha/log/manager.log
manager_workdir=/home/mha/masterha/work
master_binlog_dir=/mysql/mysql8022/binlog
master_ip_failover_script=/home/mha/masterha/script/master_ip_failover
master_ip_online_change_script=/home/mha/masterha/script/master_ip_online_change
password=monitor
ping_interval=1
remote_workdir=/home/mha/masterha/work
repl_password=repl
repl_user=repl
report_script=/home/mha/masterha/script/send_report
secondary_check_script=/usr/bin/masterha_secondary_check -s host-02 -s host-03 --user=mha --master_host=host-01 --master_ip=10.28.12.21 --master_port=3306
ssh_user=mha
user=monitor
[server1]
hostname=host-01
port=3306
[server2]
candidate_master=1
check_repl_delay=0
hostname=host-02
port=3306
[server3]
hostname=host-03
port=3306


4. 启动MHA服务，继续进行监控
sh /home/mha/masterha/script/mha_start.sh
