手把手入门 | 使用SeaTunnel从InfluxDB同步数据到Doris

版本信息：
SeaTunnel 2.3.3
InfluxDB 2.7.6
Doris 2.1.3 rc09

env {
  execution.parallelism = 1
  job.mode = "BATCH"
  checkpoint.interval = 10000
}

source {
  influxdb {
    url = "http://X.X.X.X:8086"
    token = "写自己的token" #可有可无
    org = "自己的组织名称"
    bucket = "自己的桶" #可有可无
    database = "自己的桶"
    username = "写在第四步自己新建的influxdb账号"
    password = "写在第四步自己新建的influxdb密码"
    epoch = "H" #这个有好几级，可以去官网查看
    query_timeout_sec = 600
    measurement = "prometheus_remote_write" #数据表
    fields = ["node_cpu_seconds_total", "node_memory_MemTotal_bytes"] #可有可无，配置自己的字段
    sql = """SELECT node_cpu_seconds_total as system_cpu_usage,cpu as process_occupy_physical_memory_size,job as create_dept,node_memory_MemTotal_bytes as process_read_written_file_system_total_bytes,node_memory_MemAvailable_bytes as process_open_file_describe_quantity,time as create_time FROM "prometheus_remote_write" where time > now() - 1h"""
    where = " where time > now() - 1h"
     #经过本人测试。上面的sql查询的字段必须经过重命名，或者doris建表的字段必须和influxdb2的字段完全一致，不然transform 中进行转换的时候就会成为空值，这个我还没研究明白为什么，研究明白了在补上说明，doris的表字段类型也必须和influxdb2中查询的字段类型一致，不然数据存不到doris中。schema 重定义的事influxdb2查到的字段和类型
     schema {
      fields {
        #node_cpu_seconds_total = FLOAT
        system_cpu_usage = FLOAT
        process_occupy_physical_memory_size = INT
        create_dept = STRING
        process_read_written_file_system_total_bytes = FLOAT
        process_open_file_describe_quantity = FLOAT
        create_time = BIGINT
      }
    }

  }
}

sink {
  Doris {
    fenodes = "X.X.X.X:8030"
    username = "账号"
    password = "密码"
    table.identifier = "sbyw_data_acquisition.sbyw_application_process_type_tmp"
    sink.label-prefix = "test-cdc"
    sink.enable-2pc = "true"
    sink.enable-delete = "true"
    sink.max-retries = 3
    batch_size = 10000
    result_table_name = "sbyw_application_process_type_tmp"
    doris.config {
      format = "json"
      read_json_by_line = "true"
    }
  }
}


transform {
  FieldMapper {
    source_table_name = "prometheus_remote_write"
    result_table_name = "sbyw_application_process_type_tmp"
    field_mapper = {
        #node_cpu_seconds_total = system_cpu_usage
        system_cpu_usage = system_cpu_usage
        process_occupy_physical_memory_size = process_occupy_physical_memory_size
        process_read_written_file_system_total_bytes = process_read_written_file_system_total_bytes
        process_open_file_describe_quantity = process_open_file_describe_quantity
        create_time = create_time
        create_dept = create_dept
    }
  }
}
