有关Clickhouse中remote_url_allow_hosts配置项端口的说明

运维笔谈 2025-01-23
328
remote_url_allow_hosts是Clickhouse的一个安全特性,我们需要在配置中添加对应URL才可以访问外部主机。我们可以在Clickhouse主配置文件找下如下官方说明:
     <!--<remote_url_allow_hosts>-->
            <!-- Host should be specified exactly as in URL. The name is checked before DNS resolution.
                Example: "yandex.ru", "yandex.ru." and "www.yandex.ru" are different hosts.
                        If port is explicitly specified in URL, the host:port is checked as a whole.
                        If host specified here without port, any port with this host allowed.
                        "yandex.ru" -> "yandex.ru:443", "yandex.ru:80" etc. is allowed, but "yandex.ru:80" -> only "yandex.ru:80" is allowed.
                If the host is specified as IP address, it is checked as specified in URL. Example: "[2a02:6b8:a::a]".
                If there are redirects and support for redirects is enabled, every redirect (the Location field) is checked.
                Host should be specified using the host xml tag:
                        <host>yandex.ru</host>
            -->


            <!-- Regular expression can be specified. RE2 engine is used for regexps.
                Regexps are not aligned: don't forget to add ^ and $. Also don't forget to escape dot (.) metacharacter
                (forgetting to do so is a common source of error).
            -->
        <!--</remote_url_allow_hosts>-->
    1、URL不带端口号
    如果配置中只指定了主机名(例如 yandex.ru),则允许访问该主机的所有端口。
      <remote_url_allow_hosts>
          <host>yandex.ru</host>
      </remote_url_allow_hosts>

      这意味着:

      • yandex.ru:80 是允许的。

      • yandex.ru:443 是允许的。

      • yandex.ru:8080 是允许的。


      2. URL带端口号

      如果配置中指定了主机名和端口号,例如 yandex.ru:80 则只允许访问该主机的指定端口

        <remote_url_allow_hosts>
            <host>yandex.ru:80</host>
        </remote_url_allow_hosts>

        这意味着:

        • yandex.ru:80 是允许的。

        • yandex.ru:443 是不允许的。

        • yandex.ru:8080 是不允许的。


        3、使用IP和端口号

        使用 IP 地址,规则与主机名相同。

          <remote_url_allow_hosts>
              <host>192.168.1.1</host>  <!-- 允许 192.168.1.1 的所有端口 -->
              <host>192.168.2.1:8080</host>  <!-- 只允许 192.168.2.1:8080 -->
          </remote_url_allow_hosts>

          IPv6 地址,需要用方括号 [ ] 包裹地址。

            <remote_url_allow_hosts>
                <host>[2001:db8::1]</host>  <!-- 允许 [2001:db8::1] 的所有端口 -->
                <host>[2001:db8::1]:8080</host>  <!-- 只允许 [2001:db8::1]:8080 -->
            </remote_url_allow_hosts>
