11gR2 RAC安装

0.配置网卡

0.1.配置rac01公网

vi /etc/sysconfig/network-scripts/ifcfg-eth0

DEVICE=eth0
HWADDR=66:66:66:66:66:66
TYPE=Ethernet
UUID=2e423187-4212-4ee9-9ea1-63e4daf2bb9f
ONBOOT=yes
NM_CONTROLLED=yes
BOOTPROTO=static
IPADDR=192.168.12.31
GATEWAY=192.168.12.6
PREFIX=24

0.2.配置rac02公网

vi /etc/sysconfig/network-scripts/ifcfg-eth0

DEVICE=eth0
HWADDR=66:66:66:66:66:66
TYPE=Ethernet
UUID=2e423187-4212-4ee9-9ea1-63e4daf2bb9f
ONBOOT=yes
NM_CONTROLLED=yes
BOOTPROTO=static
IPADDR=192.168.12.32
GATEWAY=192.168.12.6
PREFIX=24

0.3.配置rac01私网

vi /etc/sysconfig/network-scripts/ifcfg-eth1

DEVICE=eth1
TYPE=Ethernet
ONBOOT=yes
NM_CONTROLLED=yes
BOOTPROTO=static
IPADDR=100.100.100.10
PREFIX=24

0.4.配置rac02私网

vi /etc/sysconfig/network-scripts/ifcfg-eth1

DEVICE=eth1
TYPE=Ethernet
ONBOOT=yes
NM_CONTROLLED=yes
BOOTPROTO=static
IPADDR=100.100.100.11
PREFIX=24

2.关闭防火墙

service iptables stop
chkconfig iptables off

3.关闭selinux

setenforce 0
vi /etc/selinux/config

SELINUX=disabled

7.配置HOST

7.1.HOST文件修改

• 各节点都要配置


vi /etc/hosts

 #rac01
192.168.12.31 jyk1.com jyk1
100.100.100.10 jyk1-priv.com jyk1-priv
192.168.12.33 jyk1-vip.com jyk1-vip

#rac02
192.168.12.32 jyk2.com jyk2
100.100.100.11 jyk2-priv.com jyk2-priv
192.168.12.34 jyk2-vip.com jyk2-vip

#rac-scan
192.168.12.35 jyk-scan.com jyk-scan

7.2.配置NETWORK

配置RAC1

vi /etc/sysconfig/network

NETWORKING=yes
HOSTNAME=jyk1
NOZEROCONF=yes

配置RAC2

vi /etc/sysconfig/network

NETWORKING=yes
HOSTNAME=jyk2
NOZEROCONF=yes

10.用户组准备

10.1.创建用户组

groupadd -g 500 oinstall
groupadd -g 501 dba
groupadd -g 502 oper
groupadd -g 503 asmadmin
groupadd -g 504 asmoper
groupadd -g 505 asmdba

10.2.创建用户

useradd -s /bin/bash -g oinstall -G dba,asmdba,oper oracle
useradd -s /bin/bash -g oinstall -G asmadmin,asmdba,asmoper,oper,dba grid

10.3.更改密码

passwd grid
passwd oracle

10.4.创建目录

mkdir -p /u01/app/grid/base
mkdir -p /u01/app/grid/oraInventory
mkdir -p /u01/app/grid/11.2.0
chown -R grid:oinstall /u01/app/grid
chmod -R 775 /u01/app/grid
mkdir -p /u01/app/oracle
chown -R oracle:oinstall /u01/app/oracle/
chmod -R 775 /u01/app/oracle/

1.安装依赖

1.1.CDROM中的依赖

mount /dev/cdrom1 /mnt/
cd /mnt/Packages
rpm -ivh --nodeps unzip*.rpm
rpm -ivh --nodeps binutils*.rpm
rpm -ivh --nodeps compat-libstdc++-33*.rpm
rpm -ivh --nodeps elfutils-libelf*.rpm
rpm -ivh --nodeps elfutils-libelf-devel*.rpm
rpm -ivh --nodeps gcc*.rpm
rpm -ivh --nodeps gcc-c++*.rpm
rpm -ivh --nodeps glibc*.rpm
rpm -ivh --nodeps glibc-common*.rpm
rpm -ivh --nodeps glibc-devel*.rpm
rpm -ivh --nodeps glibc-headers*.rpm
rpm -ivh --nodeps ksh*.rpm
rpm -ivh --nodeps cvuqdisk*.rpm
rpm -ivh --nodeps libaio*.rpm
rpm -ivh --nodeps libaio-devel*.rpm
rpm -ivh --nodeps libgcc*.rpm
rpm -ivh --nodeps libgomp*.rpm
rpm -ivh --nodeps libstdc++*.rpm
rpm -ivh --nodeps libstdc++-devel*.rpm
rpm -ivh --nodeps make*.rpm
rpm -ivh --nodeps numactl-devel*.rpm
rpm -ivh --nodeps sysstat*.rpm
rpm -ivh --nodeps unixODBC*.rpm
rpm -ivh --nodeps unixODBC-devel*.rpm
rpm -ivh --nodeps cpp-4.4.6-4.el6.x86_64.rpm
rpm -ivh --nodeps ppl-0.10.2-11.el6.x86_64.rpm
rpm -ivh --nodeps cloog-ppl-0.15.7-1.2.el6.x86_64.rpm
rpm -ivh --nodeps mpfr-2.4.1-6.el6.x86_64.rpm
rpm -ivh --nodeps compat-libcap1-1.10-1.x86_64.rpm
rpm -ivh --nodeps smartmontools-5.43-1.el6.x86_64.rpm
rpm -ivh --nodeps oracle-rdbms-server-11gR2-preinstall-1.0-10.el6.x86_64.rpm

1.2.ASM lib包

rpm -ivh --nodeps oracleasm-support-2.1.8-1.el6.x86_64.rpm

1.3.CVU包

rpm -ivh --nodeps cvuqdisk-1.0.9-1.rpm

4.修改SHM

df -h /dev/shm
umount tmpfs
mount -t tmpfs shmfs -o size=6g /dev/shm
vi /etc/fstab
tmpfs /dev/shm tmpfs default,size=66G 0 0

5.关闭NTP

/sbin/service ntpd stop
chkconfig ntpd off
mv /etc/ntp.conf /etc/ntp.conf.old
rm /var/run/ntpd.pid

8.配置内核参数

vi /etc/sysctl.conf

kernel.shmall = 4294967296
kernel.shmmax = 34359738368
fs.aio-max-nr = 1048576
fs.file-max = 6815744
kernel.shmmni = 65537
kernel.sem = 250 32000 100 128
net.ipv4.ip_local_port_range = 9000 65500
net.core.rmem_default = 262144
net.core.rmem_max = 4194304
net.core.wmem_default = 262144
net.core.wmem_max = 1048586

sysctl -p

9.设置oracle用户的shell限制

vi /etc/security/limits.conf

oracle soft nproc 2047
oracle hard nproc 16384
oracle soft nofile 1024
oracle hard nofile 65536
grid soft nproc 2047
grid hard nproc 16384
grid soft nofile 1024
grid hard nofile 65536

vi /etc/pam.d/login

session required /lib/security/pam_limits.so
session required pam_limits.so

11.修改环境变量

11.1.grid用户执行

vi ~/.bash_profile

export TMP=/tmp
export TMPDIR=$TMP
export ORACLE_SID=+ASM1
export ORACLE_BASE=/u01/app/grid/base
export ORACLE_HOME=/u01/app/grid/11.2.0
export ORACLE_TERM=xterm
export TNS_ADMIN=$ORACLE_HOME/network/admin
export PATH=$ORACLE_HOME/bin:$PATH
export LD_LIBRARY_PATH=$ORACLE_HOME/lib:/lib:/usr/lib
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib
export EDITOR=vi
export LANG=en_US
export NLS_LANG=AMERICAN_AMERICA.AL32UTF8
export NLS_DATE_FORMAT='YYYY-MM-DD HH24:MI:SS'
umask 022

source ~/.bash_profile

11.2.oracle用户执行

vi ~/.bash_profile

export TMP=/tmp
export TMPDIR=$TMP
export ORACLE_HOSTNAME=jyk1
export ORACLE_SID=jyk1
export ORACLE_BASE=/u01/app/oracle
export ORACLE_HOME=$ORACLE_BASE/product/11.2.0/db_1
export ORACLE_UNQNAME=jyk
export TNS_ADMIN=$ORACLE_HOME/network/admin
export ORACLE_TERM=xterm
export PATH=$ORACLE_HOME/bin:$PATH
export LD_LIBRARY_PATH=$ORACLE_HOME/lib:/lib:/usr/lib
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib
export EDITOR=vi
export LANG=en_US
export NLS_LANG=AMERICAN_AMERICA.AL32UTF8
export NLS_DATE_FORMAT='YYYY-MM-DD HH24:MI:SS'
umask 022

source ~/.bash_profile

12.设置SSH互信

12.1.grid用户执行

ssh-keygen
ssh-copy-id -i /home/grid/.ssh/id_rsa grid@jyk1
ssh-copy-id -i /home/grid/.ssh/id_rsa grid@jyk2
ssh-copy-id -i /home/grid/.ssh/id_rsa grid@jyk1-priv
ssh-copy-id -i /home/grid/.ssh/id_rsa grid@jyk2-priv

12.2.oracle用户执行

ssh-keygen
ssh-copy-id -i /home/oracle/.ssh/id_rsa oracle@jyk1
ssh-copy-id -i /home/oracle/.ssh/id_rsa oracle@jyk2
ssh-copy-id -i /home/oracle/.ssh/id_rsa oracle@jyk1-priv
ssh-copy-id -i /home/oracle/.ssh/id_rsa oracle@jyk2-priv

12.3验证

ssh jyk1 date
ssh jyk2 date
ssh jyk1-priv date
ssh jyk2-priv date

13.创建ASM磁盘

13.1.配置ASM库文件

/etc/init.d/oracleasm configure
grid
asmadmin
y
y

/etc/init.d/oracleasm enable --开启

13.2.创建ASM磁盘

13.2.1.格式化磁盘

fdisk /dev/sdb
n p 1 回车 回车 w
/etc/init.d/oracleasm createdisk ARCH /dev/sdb1

13.2.2 裸设备

vi /etc/sysconfig/rawdevices

/dev/raw/raw1 /dev/sdb1
/dev/raw/raw2 /dev/sdc1

vi /etc/udev/rules.d/60-raw.rules

ACTION=="add", KERNEL=="sdb1",RUN+="/bin/raw /dev/raw/raw1 %N"
ACTION=="add", KERNEL=="sdc1",RUN+="/bin/raw /dev/raw/raw2 %N"
ACTION=="add", KERNEL=="raw[1-3]", OWNER="oracle", GROUP="oinstall", MODE="660"

检验ASM磁盘组

oracleasm scandisks
oracleasm listdisks

14.安装grid

14.1.解压grid包

unzip p13390677_112040_Linux-x86-64_3of7.zip

14.2.环境检查

./runcluvfy.sh stage -pre crsinst -n jyk1,jyk2 -fixup -verbose > runcluvfy.rst

15.安装软件

参照之前的单节点安装，直接选择RAC就行
