Flink 连接 Doris

Flink可以通过各种方式链接doris，下面是我整理的10个demo代码，亲测有效，建议收藏~

CDCSchemaChangeExample

package org.apache.doris.flink;


import com.ververica.cdc.connectors.mysql.source.MySqlSource;
import com.ververica.cdc.connectors.mysql.table.StartupOptions;
import com.ververica.cdc.connectors.shaded.org.apache.kafka.connect.json.JsonConverterConfig;
import com.ververica.cdc.debezium.JsonDebeziumDeserializationSchema;
import org.apache.doris.flink.cfg.DorisExecutionOptions;
import org.apache.doris.flink.cfg.DorisOptions;
import org.apache.doris.flink.cfg.DorisReadOptions;
import org.apache.doris.flink.sink.DorisSink;
import org.apache.doris.flink.sink.writer.JsonDebeziumSchemaSerializer;
import org.apache.doris.flink.utils.DateToStringConverter;
import org.apache.flink.api.common.eventtime.WatermarkStrategy;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;


import java.util.HashMap;
import java.util.Map;
import java.util.Properties;
import java.util.UUID;


public class CDCSchemaChangeExample {


    public static void main(String[] args) throws Exception {


        Map<String, Object> customConverterConfigs = new HashMap<>();
        customConverterConfigs.put(JsonConverterConfig.DECIMAL_FORMAT_CONFIG, "numeric");
        JsonDebeziumDeserializationSchema schema =
                new JsonDebeziumDeserializationSchema(false, customConverterConfigs);


        MySqlSource<String> mySqlSource = MySqlSource.<String>builder()
                .hostname("127.0.0.1")
                .port(3306)
                .databaseList("test") // set captured database
                .tableList("test.t1") // set captured table
                .username("root")
                .password("123456")
                .debeziumProperties(DateToStringConverter.DEFAULT_PROPS)
                .deserializer(schema)
                .serverTimeZone("Asia/Shanghai")
                .includeSchemaChanges(true) // converts SourceRecord to JSON String
                .build();
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);
        // enable checkpoint
        env.enableCheckpointing(10000);
//
        Properties props = new Properties();
        props.setProperty("format", "json");
        props.setProperty("read_json_by_line", "true");
        DorisOptions dorisOptions = DorisOptions.builder()
                .setFenodes("127.0.0.1:8030")
                .setTableIdentifier("test.t1")
                .setUsername("root")
                .setPassword("").build();
//
        DorisExecutionOptions.Builder  executionBuilder = DorisExecutionOptions.builder();
        executionBuilder.setLabelPrefix("label-doris" + UUID.randomUUID())
                .setStreamLoadProp(props).setDeletable(true);


        DorisSink.Builder<String> builder = DorisSink.builder();
        builder.setDorisReadOptions(DorisReadOptions.builder().build())
                .setDorisExecutionOptions(executionBuilder.build())
                .setDorisOptions(dorisOptions)
                .setSerializer(JsonDebeziumSchemaSerializer.builder().setDorisOptions(dorisOptions).setNewSchemaChange(true).build());


        env.fromSource(mySqlSource, WatermarkStrategy.noWatermarks(), "MySQL Source")//.print();
                .sinkTo(builder.build());


        env.execute("Print MySQL Snapshot + Binlog");
    }
}

DorisDateAndTimestampSqlTest

package org.apache.doris.flink;


import org.apache.flink.table.api.EnvironmentSettings;
import org.apache.flink.table.api.TableEnvironment;


import java.util.UUID;


public class DorisDateAndTimestampSqlTest {


    public static void main(String[] args) {
        TableEnvironment tEnv = TableEnvironment.create(EnvironmentSettings.newInstance().inBatchMode().build());
        tEnv.executeSql("create table test_source ( " +
                "        id INT, " +
                "        score DECIMAL(10, 9), " +
                "        submit_time TIMESTAMP " +
                "        ) with ( " +
                "        'password'='', " +
                "        'connector'='doris', " +
                "        'fenodes'='FE_HOST:FE_PORT', " +
                "        'table.identifier'='db.source_table', " +
                "        'username'='root' " +
                ")");


        tEnv.executeSql("create table test_sink ( " +
                "        id INT, " +
                "        score DECIMAL(10, 9), " +
                "        submit_time DATE " +
                "        ) with ( " +
                "        'password'='', " +
                "        'connector'='doris', " +
                "        'fenodes'='FE_HOST:FE_PORT', " +
                "        'sink.label-prefix' = 'label_" + UUID.randomUUID()+"' , " +
                "        'table.identifier'='db.sink_table', " +
                "        'username'='root' " +
                ")");
        tEnv.executeSql(
                "insert into " +
                        "    test_sink " +
                        "select " +
                        "    id, " +
                        "    score," +
                        "    to_date(DATE_FORMAT(submit_time, 'yyyy-MM-dd')) as submit_time " +
                        "from " +
                        "    test_source " +
                        "where " +
                        "    submit_time>='2022-05-31 00:00:00'")
                .print();
    }


}

DorisIntranetAccessSinkExample

public class DorisIntranetAccessSinkExample {


    public static void main(String[] args) throws Exception {
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        env.enableCheckpointing(10000);
        env.getCheckpointConfig()
                .enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(5, Time.milliseconds(30000)));


        DorisSink.Builder<String> builder = DorisSink.builder();
        final DorisReadOptions.Builder readOptionBuilder = DorisReadOptions.builder();
        readOptionBuilder.setDeserializeArrowAsync(false)
                .setDeserializeQueueSize(64)
                .setExecMemLimit(2147483648L)
                .setRequestQueryTimeoutS(3600)
                .setRequestBatchSize(1000)
                .setRequestConnectTimeoutMs(10000)
                .setRequestReadTimeoutMs(10000)
                .setRequestRetries(3)
                .setRequestTabletSize(1024 * 1024);


        Properties properties = new Properties();
        properties.setProperty("column_separator", ",");
        properties.setProperty("line_delimiter", "\n");
        properties.setProperty("format", "csv");
        DorisOptions.Builder dorisBuilder = DorisOptions.builder();
        dorisBuilder.setFenodes("10.20.30.1:8030")
                .setBenodes("10.20.30.1:8040, 10.20.30.2:8040, 10.20.30.3:8040")
                .setTableIdentifier("test.test_sink")
                .setUsername("root")
                .setPassword("");


        DorisExecutionOptions.Builder executionBuilder = DorisExecutionOptions.builder();
        executionBuilder
                .disable2PC().setLabelPrefix("label-doris")
                .setStreamLoadProp(properties)
                .setBufferSize(8 * 1024)
                .setBufferCount(3);


        builder.setDorisReadOptions(readOptionBuilder.build())
                .setDorisExecutionOptions(executionBuilder.build())
                .setSerializer(new SimpleStringSerializer())
                .setDorisOptions(dorisBuilder.build());


        List<Tuple2<Integer, String>> data = new ArrayList<>();
        data.add(new Tuple2<>(1, "zhangsan"));
        data.add(new Tuple2<>(2, "lisi"));
        data.add(new Tuple2<>(3, "wangwu"));
        DataStreamSource<Tuple2<Integer, String>> source = env.fromCollection(data);
        source.map((MapFunction<Tuple2<Integer, String>, String>) t -> t.f0 + "," + t.f1)
                .sinkTo(builder.build());
        env.execute("doris test");
    }
}

DorisSinkArraySQLExample

package org.apache.doris.flink;


import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.table.api.bridge.java.StreamTableEnvironment;


import java.util.UUID;


public class DorisSinkArraySQLExample {


    public static void main(String[] args) throws Exception{
        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        final StreamTableEnvironment tEnv = StreamTableEnvironment.create(env);
        tEnv.executeSql("CREATE TABLE source (\n" +
                "  `id` int,\n" +
                "  `c_1` array<INT> ,\n" +
                "  `c_2` array<TINYINT> ,\n" +
                "  `c_3` array<SMALLINT> ,\n" +
                "  `c_4` array<INT> ,\n" +
                "  `c_5` array<BIGINT> ,\n" +
                "  `c_6` array<BIGINT> ,\n" +
                "  `c_7` array<FLOAT>,\n" +
                "  `c_8` array<DOUBLE> ,\n" +
                "  `c_9` array<DECIMAL(4,2)> ,\n" +
                "  `c_10` array<DATE>  ,\n" +
                "  `c_11` array<DATE>  ,\n" +
                "  `c_12` array<TIMESTAMP>  ,\n" +
                "  `c_13` array<TIMESTAMP>  ,\n" +
                "  `c_14` array<CHAR(10)>  ,\n" +
                "  `c_15` array<VARCHAR(256)>  ,\n" +
                "  `c_16` array<STRING>  \n" +
                ") WITH (\n" +
                "  'connector' = 'datagen', \n" +
                "  'fields.c_7.element.min' = '1', \n" +
                "  'fields.c_7.element.max' = '10', \n" +
                "  'fields.c_8.element.min' = '1', \n" +
                "  'fields.c_8.element.max' = '10', \n" +
                "  'fields.c_14.element.length' = '10', \n" +
                "  'fields.c_15.element.length' = '10', \n" +
                "  'fields.c_16.element.length' = '10', \n" +
                "  'number-of-rows' = '5'  \n" +
                ");");




          tEnv.executeSql("CREATE TABLE source_doris (" +
                  "  `id` int,\n" +
                  "  `c_1` array<INT> ,\n" +
                  "  `c_2` array<TINYINT> ,\n" +
                  "  `c_3` array<SMALLINT> ,\n" +
                  "  `c_4` array<INT> ,\n" +
                  "  `c_5` array<BIGINT> ,\n" +
                  "  `c_6` array<STRING> ,\n" +
                  "  `c_7` array<FLOAT> ,\n" +
                  "  `c_8` array<DOUBLE> ,\n" +
                  "  `c_9` array<DECIMAL(4,2)> ,\n" +
                  "  `c_10` array<STRING>  ,\n" + //ARRAY<DATE>
                  "  `c_11` array<STRING>  ,\n" + //ARRAY<DATE>
                  "  `c_12` array<STRING>  ,\n" + //ARRAY<TIMESTAMP>
                  "  `c_13` array<STRING>  ,\n" + //ARRAY<TIMESTAMP>
                  "  `c_14` array<CHAR(10)>  ,\n" +
                  "  `c_15` array<VARCHAR(256)>  ,\n" +
                  "  `c_16` array<STRING>  \n" +
                ") WITH (" +
                  "  'connector' = 'doris',\n" +
                  "  'fenodes' = '127.0.0.1:8030',\n" +
                  "  'table.identifier' = 'test.array_test_type',\n" +
                  "  'username' = 'root',\n" +
                  "  'password' = ''\n" +
                ")");






        // define a dynamic aggregating query
//        final Table result = tEnv.sqlQuery("SELECT * from source_doris  ");
//
//         print the result to the console
//        tEnv.toRetractStream(result, Row.class).print();
//        env.execute();


        tEnv.executeSql(
                "CREATE TABLE sink (" +
                        "  `id` int,\n" +
                        "  `c_1` array<INT> ,\n" +
                        "  `c_2` array<TINYINT> ,\n" +
                        "  `c_3` array<SMALLINT> ,\n" +
                        "  `c_4` array<INT> ,\n" +
                        "  `c_5` array<BIGINT> ,\n" +
                        "  `c_6` array<STRING> ,\n" +
                        "  `c_7` array<FLOAT> ,\n" +
                        "  `c_8` array<DOUBLE> ,\n" +
                        "  `c_9` array<DECIMAL(4,2)> ,\n" +
                        "  `c_10` array<STRING>  ,\n" + //ARRAY<DATE>
                        "  `c_11` array<STRING>  ,\n" + //ARRAY<DATE>
                        "  `c_12` array<STRING>  ,\n" + //ARRAY<TIMESTAMP>
                        "  `c_13` array<STRING>  ,\n" + //ARRAY<TIMESTAMP>
                        "  `c_14` array<CHAR(10)>  ,\n" +
                        "  `c_15` array<VARCHAR(256)>  ,\n" +
                        "  `c_16` array<STRING>  \n" +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'doris',\n" +
                        "  'fenodes' = '127.0.0.1:8030',\n" +
                        "  'table.identifier' = 'test.array_test_type_sink',\n" +
                        "  'username' = 'root',\n" +
                        "  'password' = '',\n" +
                        "  'sink.label-prefix' = 'doris_label4"  + UUID.randomUUID() + "'" +
                        ")");
        tEnv.executeSql("INSERT INTO sink select * from source_doris");


    }
}

DorisSinkBatchExample

package org.apache.doris.flink;


import org.apache.doris.flink.cfg.DorisExecutionOptions;
import org.apache.doris.flink.cfg.DorisOptions;
import org.apache.doris.flink.cfg.DorisReadOptions;
import org.apache.doris.flink.sink.batch.DorisBatchSink;
import org.apache.doris.flink.sink.writer.SimpleStringSerializer;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.source.SourceFunction;


import java.util.Arrays;
import java.util.Properties;
import java.util.UUID;




public class DorisSinkBatchExample {
    public static void main(String[] args) throws Exception {
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);
//        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);
        env.enableCheckpointing(5000);
//        env.getCheckpointConfig().enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
//        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(5, Time.milliseconds(30000)));
        DorisBatchSink.Builder<String> builder = DorisBatchSink.builder();
        final DorisReadOptions.Builder readOptionBuilder = DorisReadOptions.builder();
        readOptionBuilder.setDeserializeArrowAsync(false)
                .setDeserializeQueueSize(64)
                .setExecMemLimit(2147483648L)
                .setRequestQueryTimeoutS(3600)
                .setRequestBatchSize(1000)
                .setRequestConnectTimeoutMs(10000)
                .setRequestReadTimeoutMs(10000)
                .setRequestRetries(3)
                .setRequestTabletSize(1024 * 1024);
        Properties properties = new Properties();
        properties.setProperty("column_separator", ",");
        properties.setProperty("line_delimiter", "\n");
        properties.setProperty("format", "csv");
        DorisOptions.Builder dorisBuilder = DorisOptions.builder();
        dorisBuilder.setFenodes("127.0.0.1:8030")
                .setTableIdentifier("test.test_flink")
                .setUsername("root")
                .setPassword("");
        DorisExecutionOptions.Builder executionBuilder = DorisExecutionOptions.builder();
        executionBuilder.setLabelPrefix("label")
                .setStreamLoadProp(properties)
                .setDeletable(false)
                .setBufferFlushMaxBytes(8 * 1024)
                .setBufferFlushMaxRows(900)
                .setBufferFlushIntervalMs(1000 * 10);


        builder.setDorisReadOptions(readOptionBuilder.build())
                .setDorisExecutionOptions(executionBuilder.build())
                .setSerializer(new SimpleStringSerializer())
                .setDorisOptions(dorisBuilder.build());


        env.addSource(new SourceFunction<String>() {
            private Long id = 0L;


            @Override
            public void run(SourceContext<String> out) throws Exception {
                while (true) {
                    id = id + 1;
                    String record = id + "," + UUID.randomUUID() + "," + id + "";
                    out.collect(record);
                    Thread.sleep(500);
                }
            }


            @Override
            public void cancel() {


            }
        }).sinkTo(builder.build());


        env.execute("doris batch test");
    }


    public void testBatchFlush() throws Exception {
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);


        DorisBatchSink.Builder<String> builder = DorisBatchSink.builder();
        final DorisReadOptions.Builder readOptionBuilder = DorisReadOptions.builder();


        readOptionBuilder.setDeserializeArrowAsync(false)
                .setDeserializeQueueSize(64)
                .setExecMemLimit(2147483648L)
                .setRequestQueryTimeoutS(3600)
                .setRequestBatchSize(1000)
                .setRequestConnectTimeoutMs(10000)
                .setRequestReadTimeoutMs(10000)
                .setRequestRetries(3)
                .setRequestTabletSize(1024 * 1024);


        Properties properties = new Properties();
        properties.setProperty("column_separator", ",");
        properties.setProperty("line_delimiter", "\n");
        properties.setProperty("format", "csv");
        DorisOptions.Builder dorisBuilder = DorisOptions.builder();
        dorisBuilder.setFenodes("127.0.0.1:8030")
                .setTableIdentifier("test.testd")
                .setUsername("root")
                .setPassword("");


        DorisExecutionOptions.Builder executionBuilder = DorisExecutionOptions.builder();


        executionBuilder.setLabelPrefix("label")
                .setStreamLoadProp(properties)
                .setDeletable(false)
                .setBufferFlushMaxBytes(8 * 1024)
                .setBufferFlushMaxRows(1)
                .setBufferFlushIntervalMs(1000 * 10);


        builder.setDorisReadOptions(readOptionBuilder.build())
                .setDorisExecutionOptions(executionBuilder.build())
                .setSerializer(new SimpleStringSerializer())
                .setDorisOptions(dorisBuilder.build());




        DataStreamSource<String> stringDataStreamSource = env.fromCollection(
                Arrays.asList("1,-74159.9193252453", "2,-74159.9193252453", "3,-19.7004480979", "4,43385.2170333507", "5,-16.2602598554"));
        stringDataStreamSource.sinkTo(builder.build());


        env.execute("doris batch test");


    }
}

DorisSinkExample

package org.apache.doris.flink;


import org.apache.doris.flink.cfg.DorisExecutionOptions;
import org.apache.doris.flink.cfg.DorisOptions;
import org.apache.doris.flink.cfg.DorisReadOptions;
import org.apache.doris.flink.sink.DorisSink;
import org.apache.doris.flink.sink.writer.SimpleStringSerializer;
import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.api.common.functions.MapFunction;
import org.apache.flink.api.common.restartstrategy.RestartStrategies;
import org.apache.flink.api.common.time.Time;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.streaming.api.TimeCharacteristic;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.CheckpointConfig;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;


import java.util.ArrayList;
import java.util.List;
import java.util.Properties;




public class DorisSinkExample {


    public static void main(String[] args) throws Exception{
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        env.enableCheckpointing(10000);
        env.getCheckpointConfig().enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(5, Time.milliseconds(30000)));
        DorisSink.Builder<String> builder = DorisSink.builder();
        final DorisReadOptions.Builder readOptionBuilder = DorisReadOptions.builder();
        readOptionBuilder.setDeserializeArrowAsync(false)
                .setDeserializeQueueSize(64)
                .setExecMemLimit(2147483648L)
                .setRequestQueryTimeoutS(3600)
                .setRequestBatchSize(1000)
                .setRequestConnectTimeoutMs(10000)
                .setRequestReadTimeoutMs(10000)
                .setRequestRetries(3)
                .setRequestTabletSize(1024 * 1024);
        Properties properties = new Properties();
        properties.setProperty("column_separator", ",");
        properties.setProperty("line_delimiter", "\n");
        properties.setProperty("format", "csv");
        DorisOptions.Builder dorisBuilder = DorisOptions.builder();
        dorisBuilder.setFenodes("127.0.0.1:8040")
                .setTableIdentifier("db.table")
                .setUsername("test")
                .setPassword("test");
        DorisExecutionOptions.Builder  executionBuilder = DorisExecutionOptions.builder();
        executionBuilder.setLabelPrefix("label-doris")
                .setStreamLoadProp(properties)
                .setBufferSize(8*1024)
                .setBufferCount(3);


        builder.setDorisReadOptions(readOptionBuilder.build())
                .setDorisExecutionOptions(executionBuilder.build())
                .setSerializer(new SimpleStringSerializer())
                .setDorisOptions(dorisBuilder.build());


        List<Tuple2<String, Integer>> data = new ArrayList<>();
        data.add(new Tuple2<>("doris",1));
        DataStreamSource<Tuple2<String, Integer>> source = env.fromCollection(data);
        source.map((MapFunction<Tuple2<String, Integer>, String>) t -> t.f0 + "," + t.f1)
                .sinkTo(builder.build());
        env.execute("doris test");
    }
}

DorisSinkExampleRowData

package org.apache.doris.flink;


import org.apache.doris.flink.cfg.DorisExecutionOptions;
import org.apache.doris.flink.cfg.DorisOptions;
import org.apache.doris.flink.sink.DorisSink;
import org.apache.doris.flink.sink.writer.LoadConstants;
import org.apache.doris.flink.sink.writer.RowDataSerializer;
import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.restartstrategy.RestartStrategies;
import org.apache.flink.api.common.time.Time;
import org.apache.flink.streaming.api.TimeCharacteristic;
import org.apache.flink.streaming.api.datastream.DataStream;
import org.apache.flink.streaming.api.environment.CheckpointConfig;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.table.api.DataTypes;
import org.apache.flink.table.data.GenericRowData;
import org.apache.flink.table.data.RowData;
import org.apache.flink.table.data.StringData;
import org.apache.flink.table.types.DataType;
import org.apache.flink.util.Collector;


import java.util.Properties;
import java.util.UUID;




public class DorisSinkExampleRowData {


    public static void main(String[] args) throws Exception{
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        env.enableCheckpointing(10000);
        env.setParallelism(1);
        env.getCheckpointConfig().enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(5, Time.milliseconds(30000)));
        DorisSink.Builder<RowData> builder = DorisSink.builder();


        Properties properties = new Properties();
        properties.setProperty("column_separator", ",");
        properties.setProperty("line_delimiter", "\n");
//        properties.setProperty("read_json_by_line", "true");
//        properties.setProperty("format", "json");
        DorisOptions.Builder dorisBuilder = DorisOptions.builder();
        dorisBuilder.setFenodes("127.0.0.1:8030")
                .setTableIdentifier("db.tbl")
                .setUsername("root")
                .setPassword("");
        DorisExecutionOptions.Builder  executionBuilder = DorisExecutionOptions.builder();
        executionBuilder.setLabelPrefix(UUID.randomUUID().toString())
                .setStreamLoadProp(properties);


        //flink rowdata‘s schema
        String[] fields = {"name", "age"};
        DataType[] types = {DataTypes.VARCHAR(256), DataTypes.INT()};


        builder.setDorisExecutionOptions(executionBuilder.build())
                .setSerializer(RowDataSerializer.builder()  //serialize according to rowdata
                        .setType(LoadConstants.CSV) //.setType(LoadConstants.CSV)
                        .setFieldDelimiter(",")
                        .setFieldNames(fields) //.setFieldDelimiter(",")
                        .setFieldType(types).build())
                .setDorisOptions(dorisBuilder.build());


        //mock rowdata source
        DataStream<RowData> source = env.fromElements("")
                .flatMap(new FlatMapFunction<String, RowData>() {
                    @Override
                    public void flatMap(String s, Collector<RowData> out) throws Exception {
                        GenericRowData genericRowData = new GenericRowData(2);
                        genericRowData.setField(0, StringData.fromString("beijing"));
                        genericRowData.setField(1, 123);
                        out.collect(genericRowData);


                        GenericRowData genericRowData2 = new GenericRowData(2);
                        genericRowData2.setField(0, StringData.fromString("shanghai"));
                        genericRowData2.setField(1, 1234);
                        out.collect(genericRowData2);
                    }
                });


        source.sinkTo(builder.build());
        env.execute("doris test");
    }
}

DorisSinkSQLExample

package org.apache.doris.flink;


import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.table.api.bridge.java.StreamTableEnvironment;


import java.util.ArrayList;
import java.util.List;


import static org.apache.flink.table.api.Expressions.$;


public class DorisSinkSQLExample {


    public static void main(String[] args) {
        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        final StreamTableEnvironment tEnv = StreamTableEnvironment.create(env);


        List<Tuple2<String, Integer>> data = new ArrayList<>();
        data.add(new Tuple2<>("doris",1));
        DataStreamSource<Tuple2<String, Integer>> source = env.fromCollection(data);
        tEnv.createTemporaryView("doris_test",source,$("name"),$("age"));


        tEnv.executeSql(
                "CREATE TABLE doris_test_sink (" +
                        "name STRING," +
                        "age INT" +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'doris',\n" +
                        "  'fenodes' = 'FE_IP:8030',\n" +
                        "  'table.identifier' = 'db.table',\n" +
                        "  'username' = 'root',\n" +
                        "  'password' = '',\n" +
                        "  'sink.properties.format' = 'json',\n" +
                        "  'sink.buffer-count' = '4',\n" +
                        "  'sink.buffer-size' = '4086'," +
                        "  'sink.label-prefix' = 'doris_label',\n" +
                        "  'sink.properties.read_json_by_line' = 'true'\n" +
                        ")");
        tEnv.executeSql("INSERT INTO doris_test_sink select name,age from doris_test");
    }
}

DorisSourceDataStream

package org.apache.doris.flink;


import org.apache.doris.flink.cfg.DorisStreamOptions;
import org.apache.doris.flink.datastream.DorisSourceFunction;
import org.apache.doris.flink.deserialization.SimpleListDeserializationSchema;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;


import java.util.Properties;






public class DorisSourceDataStream {


    public static void main(String[] args) throws Exception {
        Properties properties = new Properties();
        properties.put("fenodes","FE_IP:8030");
        properties.put("username","root");
        properties.put("password","");
        properties.put("table.identifier","db.table");
        properties.put("doris.read.field","id,code,name");
        properties.put("doris.filter.query","name='doris'");
        DorisStreamOptions  options = new DorisStreamOptions(properties);


        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(2);
        env.addSource(new DorisSourceFunction(options,new SimpleListDeserializationSchema())).print();
        env.execute("Flink doris test");
    }
}

DorisSourceExample

package org.apache.doris.flink;


import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.table.api.Table;
import org.apache.flink.table.api.bridge.java.StreamTableEnvironment;


public class DorisSourceExample {


    public static void main(String[] args) throws Exception {


        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);


        final StreamTableEnvironment tEnv = StreamTableEnvironment.create(env);


        // register a table in the catalog
        tEnv.executeSql(
                "CREATE TABLE doris_source (" +
                        "bigint_1 BIGINT," +
                        "char_1 STRING," +
                        "date_1 STRING," +
                        "datetime_1 STRING," +
                        "decimal_1 DECIMAL(5,2)," +
                        "double_1 DOUBLE," +
                        "float_1 FLOAT ," +
                        "int_1 INT ," +
                        "largeint_1 STRING, " +
                        "smallint_1 SMALLINT, " +
                        "tinyint_1 TINYINT, " +
                        "varchar_1 STRING " +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'doris',\n" +
                        "  'fenodes' = 'FE_IP:8030',\n" +
                        "  'table.identifier' = 'db.table',\n" +
                        "  'username' = 'root',\n" +
                        "  'password' = ''\n" +
                        ")");


        // define a dynamic aggregating query
        final Table result = tEnv.sqlQuery("SELECT * from doris_source  ");


        // print the result to the console
        tEnv.toDataStream(result).print();
        env.execute();
    }
}

DorisSourceSinkExample

package org.apache.doris.flink;


import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.table.api.Table;
import org.apache.flink.table.api.bridge.java.StreamTableEnvironment;
import org.apache.flink.types.Row;


import java.util.UUID;


public class DorisSourceSinkExample {


    public static void main(String[] args) throws Exception {
        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);
        env.setRuntimeMode(RuntimeExecutionMode.BATCH);
        final StreamTableEnvironment tEnv = StreamTableEnvironment.create(env);
        tEnv.executeSql(
                "CREATE TABLE doris_test (" +
                        "  id int,\n" +
                        "  c_1 boolean,\n" +
                        "  c_2 tinyint,\n" +
                        "  c_3 smallint,\n" +
                        "  c_4 int,\n" +
                        "  c_5 bigint,\n" +
                        "  c_6 bigint,\n" +
                        "  c_7 float,\n" +
                        "  c_8 double,\n" +
                        "  c_9 DECIMAL(4,2),\n" +
                        "  c_10 DECIMAL(4,1),\n" +
                        "  c_11 date,\n" +
                        "  c_12 date,\n" +
                        "  c_13 timestamp,\n" +
                        "  c_14 timestamp,\n" +
                        "  c_15 string,\n" +
                        "  c_16 string,\n" +
                        "  c_17 string,\n" +
                        "  c_18 array<int>,\n" +
                        "  c_19 Map<String,int>\n" +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'datagen', \n" +
                        "  'fields.c_6.max' = '5', \n" +
                        "  'fields.c_9.max' = '5', \n" +
                        "  'fields.c_10.max' = '5', \n" +
                        "  'fields.c_15.length' = '5', \n" +
                        "  'fields.c_16.length' = '5', \n" +
                        "  'fields.c_17.length' = '5', \n" +
                        "  'fields.c_19.key.length' = '5', \n" +
                        "  'connector' = 'datagen', \n" +
                        "  'number-of-rows' = '1'  \n" +
                        ")");


        final Table result = tEnv.sqlQuery("SELECT * from doris_test  ");


        // print the result to the console
        tEnv.toRetractStream(result, Row.class).print();
        env.execute();


        tEnv.executeSql(
                "CREATE TABLE source_doris (" +
                        "  id int,\n" +
                        "  c_1 boolean,\n" +
                        "  c_2 tinyint,\n" +
                        "  c_3 smallint,\n" +
                        "  c_4 int,\n" +
                        "  c_5 bigint,\n" +
                        "  c_6 string,\n" +
                        "  c_7 float,\n" +
                        "  c_8 double,\n" +
                        "  c_9 DECIMAL(4,2),\n" +
                        "  c_10 DECIMAL(4,1),\n" +
                        "  c_11 date,\n" +
                        "  c_12 date,\n" +
                        "  c_13 timestamp,\n" +
                        "  c_14 timestamp,\n" +
                        "  c_15 string,\n" +
                        "  c_16 string,\n" +
                        "  c_17 string,\n" +
                        "  c_18 array<int>,\n" +
                        "  c_19 string\n" +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'doris',\n" +
                        "  'fenodes' = '127.0.0.1:8030',\n" +
                        "  'table.identifier' = 'test.test_all_type',\n" +
                        "  'username' = 'root',\n" +
                        "  'password' = ''\n" +
                        ")");


        tEnv.executeSql(
                "CREATE TABLE doris_test_sink (" +
                        "  id int,\n" +
                        "  c_1 boolean,\n" +
                        "  c_2 tinyint,\n" +
                        "  c_3 smallint,\n" +
                        "  c_4 int,\n" +
                        "  c_5 bigint,\n" +
                        "  c_6 string,\n" +
                        "  c_7 float,\n" +
                        "  c_8 double,\n" +
                        "  c_9 DECIMAL(4,2),\n" +
                        "  c_10 DECIMAL(4,1),\n" +
                        "  c_11 date,\n" +
                        "  c_12 date,\n" +
                        "  c_13 timestamp,\n" +
                        "  c_14 timestamp,\n" +
                        "  c_15 string,\n" +
                        "  c_16 string,\n" +
                        "  c_17 string,\n" +
                        "  c_18 array<int>,\n" +
                        "  c_19 string\n" +
                        ") " +
                        "WITH (\n" +
                        "  'connector' = 'doris',\n" +
                        "  'fenodes' = '127.0.0.1:8030',\n" +
                        "  'table.identifier' = 'test.test_all_type_sink',\n" +
                        "  'username' = 'root',\n" +
                        "  'password' = '',\n" +
                        "  'sink.properties.format' = 'csv',\n" +
                        "  'sink.label-prefix' = 'doris_label4"  + UUID.randomUUID() + "'" +
                        ")");
//
        tEnv.executeSql("INSERT INTO doris_test_sink select * from source_doris");
    }
}

文章转载自大数据技能圈，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

建议收藏 | 这10个Flink操作doris代码demo助你效率翻倍！

评论
