一个基于Dapr框架开发的演示项目

apiVersion: dapr.io/v1alpha1
kind: Component
metadata:
  name: zcy-test1
  namespace: default
spec:
  type: bindings.http
  version: v1
  metadata:
    - name: url
      value: http://zcy-middleware-efficiency-agent:18099

apiVersion: apps/v1
kind: Deployment
metadata:
  name: zcy-middleware-efficiency-console
  labels:
    app: java
spec:
  replicas: 1
  selector:
    matchLabels:
      app: java
  template:
    metadata:
      labels:
        app: java
        k8s-app: middleware-efficiency-console
      annotations:
        dapr.io/enabled: "true"
        dapr.io/app-id: "zcy-middleware-efficiency-console"
    spec:
      containers:
        - name: java
          image: zhangjb/zcy-middleware-efficiency-console:latest
          env:
            - name: "spring.datasource.url"
              value: "jdbc:mysql://localhost:3306/db_middleware?useUnicode=true&characterEncoding=UTF-8&useSSL=false"
            - name: "spring.datasource.username"
              value: "zcy_middleware"
            - name: "spring.datasource.password"
              value: "123456"


---
apiVersion: v1
kind: Service
metadata:
  name: zcy-middleware-efficiency-console
  namespace: default
spec:
  ports:
    - name: default
      port: 18090
      protocol: TCP
  selector:
    k8s-app: middleware-efficiency-console
  type: NodePort

apiVersion: apps/v1
kind: Deployment
metadata:
  name: zcy-middleware-efficiency-agent
  labels:
    app: java
spec:
  replicas: 1
  selector:
    matchLabels:
      app: java
  template:
    metadata:
      labels:
        app: java
        k8s-app: middleware-efficiency-agent
      annotations:
        dapr.io/enabled: "true"
        dapr.io/app-id: "zcy-middleware-efficiency-agent"
    spec:
      containers:
        - name: java
          image: zhangjb/zcy-middleware-efficiency-agent:latest
          env:
            - name: "spring.datasource.url"
              value: "jdbc:mysql://localhost:3306/db_middleware?useUnicode=true&characterEncoding=UTF-8&useSSL=false"
            - name: "spring.datasource.username"
              value: "zcy_middleware"
            - name: "spring.datasource.password"
              value: "123456"
---
apiVersion: v1
kind: Service
metadata:
  name: zcy-middleware-efficiency-agent
  namespace: default
spec:
  clusterIP: None
  ports:
    - port: 8080
      protocol: TCP
      targetPort: 18099
  selector:
    workloadID_zcy-middleware-efficiency-agent: "true"
  sessionAffinity: None
  type: ClusterIP
status:
  loadBalancer: {}

@Value("${dapr.enabled:false}")
private boolean daprEnabled;
@Value("${dapr.port:3500}")
private int daprPort;


private static final String BINDINGS_HTTP_URL = "http://localhost:%d/v1.0/bindings/%s";
private static final String CONTENT_TYPE_JSON = "application/json; charset=utf-8";
private static final String CONTENT_TYPE_FORM = "application/x-www-form-urlencoded; charset=utf-8";


/**
     * 查询redis db概要信息
     *
     * @param productId 中间件产品Id
     * @param dbIndex   查询所有db信息
     * @return
     */
    @GetMapping(value = "/productId/{productId}/dbIndex/{dbIndex}", produces = MediaType.APPLICATION_JSON_UTF8_VALUE)
    public Mono<Response<List<DbMsg>>> getDbMsgList(
            @PathVariable Long productId,
            @PathVariable Integer dbIndex) {


        MiddlewareConnectionMessage connectionMessage = connectionMessageService.getConnectMessageByProductId(productId);
        if (connectionMessage == null) {
            log.warn("Can not get connection message with productId: {}", productId);
            return Mono.just(Response.failOfMessage("Can not get connection message"));
        }


        String originPath = "/redis/operate/metaName/%s/dbIndex/%d";
        String result;
        try {
            if (!daprEnabled) {
                // 调用对应环境的agent接口
                String originAgentUrl = connectionMessage.getLocalAgentUrl() + String.format(originPath, connectionMessage.getMetaName(), dbIndex);
                log.info("originAgentUrl: {}", originAgentUrl);
                result = HttpClientUtil.get(originAgentUrl);
            } else {
                MiddlewareProductInfo productInfo = middlewareProductInfoService.getMiddlewareProductInfoById(productId);
                String metaName = productInfo.getRegion() + "-" + productInfo.getEnv();


                log.info("begin call dapr bindings.http, metadata.name: {}", metaName);
                String daprBindingsUrl = String.format(BINDINGS_HTTP_URL, daprPort, metaName);
                BindingsData bindingsData = new BindingsData();
                bindingsData.setOperation("get");
                bindingsData.setMetadata(ImmutableMap.<String, String>builder().put("path",
                        String.format(originPath, connectionMessage.getMetaName(), dbIndex)).put("Content-Type", CONTENT_TYPE_JSON).build());


                result = HttpClientUtil.postJsonBody(daprBindingsUrl, mapper.writeValueAsString(bindingsData), "utf-8");
                log.info("call dapr bindings.http finished, metadata.name: {}", metaName);
            }
            return Mono.just(mapper.readValue(result, Response.class));
        } catch (IOException e) {
            log.error("getDbMsgList fail: {}", Throwables.getStackTraceAsString(e));
        }
        return Mono.just(Response.failOfMessage("getDbMsgList fail"));
    }

public class BindingsData {


    private String operation;
    private Object data;
    private Map<String, String> metadata;


    public String getOperation() {
        return operation;
    }


    public void setOperation(String operation) {
        this.operation = operation;
    }


    public Object getData() {
        return data;
    }


    public void setData(Object data) {
        this.data = data;
    }


    public Map<String, String> getMetadata() {
        return metadata;
    }


    public void setMetadata(Map<String, String> metadata) {
        this.metadata = metadata;
    }


    @Override
    public String toString() {
        return "BindingsData{" +
                "operation='" + operation + '\'' +
                ", data=" + data +
                ", metadata=" + metadata +
                '}';
    }
}

{
    "operation": "get", # request method
    "data": null,  # 请求参数，可以是字符串，也可以是request json body
    "metadata": {
        "path": "/redis/operate/metaName/redis/dbIndex/0",
        "Content-Type": "application/json; charset=utf-8"
    }
}
