Flink之DataSet数据输出（十一）

Flink Sink之TextFile

将DataSet数据以TextOutputFormat文本格式写入文件系统，其中文件系统可以是本地文件系统，也可以是HDFS文件系统，根据用户指定路径的前缀进行识别

dataSet.writeAsText(本地文件路径)
dataSet.writeAsText(HDFS文件路径)

writeAsText直接将DataSet数据输出到指定文件，在使用write相关方式输出文件的过程中，用户也可以指定写入文件的模式，分为OVERWRITE模式和NOT_OVERWRITE模式，前者代表对文件内容进行覆盖写入，后者代表输出的数据将追加到文件尾部。

//Java


import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.functions.ReduceFunction;
import org.apache.flink.api.java.DataSet;
import org.apache.flink.api.java.ExecutionEnvironment;
import org.apache.flink.api.java.io.TextOutputFormat;
import org.apache.flink.api.java.operators.DataSink;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.util.Collector;


public class TextSinkJavaDemo {
    public static void main(String[] args) throws Exception {
        ExecutionEnvironment env = ExecutionEnvironment.getExecutionEnvironment();


        DataSet<String> source = env.fromElements(
                "spark hbase java",
                "java spark hive",
                "java hbase hbase"
        );


        env.setParallelism(1);


        DataSink<String> result = source.flatMap(new FlatMapFunction<String, Tuple2<String, Integer>>() {
            @Override
            public void flatMap(String s, Collector<Tuple2<String, Integer>> collector) throws Exception {
                for(String word : s.split(" ")){
                    collector.collect(new Tuple2<>(word,1));
                }
            }
        })
                .groupBy(0)
                .reduce(new ReduceFunction<Tuple2<String, Integer>>() {
                    @Override
                    public Tuple2<String, Integer> reduce(Tuple2<String, Integer> t1, Tuple2<String, Integer> t2) throws Exception {
                        return new Tuple2<>(t1.f0,t1.f1+t2.f1);
                    }
                })
//                .writeAsText("file:///Users/zhangjingyu/Desktop/wordcount.txt",FileSystem.WriteMode.OVERWRITE);
        .writeAsFormattedText("file:///Users/zhangjingyu/Desktop/wordcount.txt", new TextOutputFormat.TextFormatter<Tuple2<String, Integer>>() {
            @Override
            public String format(Tuple2<String, Integer> stringIntegerTuple2) {
                return stringIntegerTuple2.f0+"-"+stringIntegerTuple2.f1;
            }
        });
        env.execute();


    }
}






//Scala


import org.apache.flink.api.scala.{ExecutionEnvironment,_}
import org.apache.flink.core.fs.FileSystem.WriteMode
import org.apache.flink.util.Collector


object TextSinkScalaDemo {
  def main(args: Array[String]): Unit = {
    val env = ExecutionEnvironment.getExecutionEnvironment


    val source = env.fromElements(
      "spark hbase java",
      "java spark hive",
      "java hbase hbase"
    )
    env.setParallelism(1)


    val result = source
      .flatMap((line:String,collector:Collector[(String,Int)]) => {
        (line.split(" ")).foreach(word => (collector.collect(word,1)))
      })
      .groupBy(0)
      .reduceGroup(x => x reduce((x,y) => (x._1,x._2+y._2)))
      .writeAsText("file:///Users/zhangjingyu/Desktop/wordcount.txt",WriteMode.OVERWRITE)


    env.execute()
  }


}

Flink Sink之CsvFile

该方法将数据集以CSV文件格式输出到指定文件系统中，并且可以在输出方法中指定行切割符、列切割符等基于csv文件的配置。

dataSet.writeAsCsv(本地文件路径，指定行切割符，列切割符)
例如:
dataSet.writeAsCsv('file://path/fle","\n",",")

//Java


import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.functions.ReduceFunction;
import org.apache.flink.api.java.DataSet;
import org.apache.flink.api.java.ExecutionEnvironment;
import org.apache.flink.api.java.operators.DataSink;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.core.fs.FileSystem;
import org.apache.flink.util.Collector;


public class CsvSinkJavaDemo {
    public static void main(String[] args) throws Exception{
        ExecutionEnvironment env = ExecutionEnvironment.getExecutionEnvironment();


        DataSet<String> source = env.fromElements(
                "spark hbase java",
                "java spark hive",
                "java hbase hbase"
        );


        env.setParallelism(1);


        DataSink<Tuple2<String, Integer>> result = source.flatMap(new FlatMapFunction<String, Tuple2<String, Integer>>() {
            @Override
            public void flatMap(String s, Collector<Tuple2<String, Integer>> collector) throws Exception {
                for(String word : s.split(" ")){
                    collector.collect(new Tuple2<>(word,1));
                }
            }
        })
                .groupBy(0)
                .reduce(new ReduceFunction<Tuple2<String, Integer>>() {
                    @Override
                    public Tuple2<String, Integer> reduce(Tuple2<String, Integer> t1, Tuple2<String, Integer> t2) throws Exception {
                        return new Tuple2<>(t1.f0,t1.f1+t2.f1);
                    }
                }).writeAsCsv("file:///Users/zhangjingyu/Desktop/wordcount.csv",
                        "\n",
                        "|",
                        FileSystem.WriteMode.OVERWRITE);
        env.execute();
    }
}




//Scala
import org.apache.flink.api.scala.{ExecutionEnvironment,_}
import org.apache.flink.core.fs.FileSystem.WriteMode
import org.apache.flink.util.Collector


object CsvSinkScalaDemo {
  def main(args: Array[String]): Unit = {
    val env = ExecutionEnvironment.getExecutionEnvironment


    val source = env.fromElements(
      "spark hbase java",
      "java spark hive",
      "java hbase hbase"
    )
    env.setParallelism(1)


    val result = source
      .flatMap((line:String,collector:Collector[(String,Int)]) => {
        (line.split(" ")).foreach(word => (collector.collect(word,1)))
      })
      .groupBy(0)
      .reduceGroup(x => x reduce((x,y) => (x._1,x._2+y._2)))
      .writeAsCsv("file:///Users/zhangjingyu/Desktop/wordcount.csv",
        "\n",
      "|",
        WriteMode.OVERWRITE)


    env.execute()
  }


}

Flink Sink之Mysql

//Mysql配置参数
Dataset.output(
                JDBCOutputFormat.buildJDBCOutputFormat()
                        .setDrivername("com.mysql.jdbc.Driver")
                        .setDBUrl("jdbc:mysql://bigdata-pro-m01.kfk.com/flink")
                        .setUsername("root")
                        .setPassword("12345678")
                        .setQuery("insert into wordcount (word, count) values (?,?)")
                        .finish());

//Java


import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.functions.MapFunction;
import org.apache.flink.api.common.functions.ReduceFunction;
import org.apache.flink.api.java.DataSet;
import org.apache.flink.api.java.ExecutionEnvironment;
import org.apache.flink.api.java.io.jdbc.JDBCOutputFormat;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.types.Row;
import org.apache.flink.util.Collector;


public class MysqlSinkJavaDemo {
    public static void main(String[] args) throws Exception {
        ExecutionEnvironment env = ExecutionEnvironment.getExecutionEnvironment();
        DataSet<String> source = env.fromElements(
                "spark hbase java",
                "java spark hive",
                "java hbase hbase"
        );


        DataSet<Row> result = source
                .flatMap(new FlatMapFunction<String, Tuple2<String, Integer>>() {
                    @Override
                    public void flatMap(String s, Collector<Tuple2<String, Integer>> collector) throws Exception {
                        for(String word : s.toUpperCase().split(" ")){
                            collector.collect(new Tuple2<>(word,1));
                        }
                    }
                })
                .groupBy(0)
                .reduce(new ReduceFunction<Tuple2<String, Integer>>() {
                    @Override
                    public Tuple2<String, Integer> reduce(Tuple2<String, Integer> t1, Tuple2<String, Integer> t2) throws Exception {
                        return new Tuple2<>(t1.f0,t1.f1+t2.f1);
                    }
                })
                .map(new MapFunction<Tuple2<String, Integer>, Row>() {
                    @Override
                    public Row map(Tuple2<String, Integer> stringIntegerTuple2) throws Exception {
                        return Row.of(stringIntegerTuple2.f0,stringIntegerTuple2.f1);
                    }
                });
        result.output(
                JDBCOutputFormat.buildJDBCOutputFormat()
                        .setDrivername("com.mysql.jdbc.Driver")
                        .setDBUrl("jdbc:mysql://bigdata-pro-m01.kfk.com/flink")
                        .setUsername("root")
                        .setPassword("12345678")
                        .setQuery("insert overwrite wordcount (word, count) values (?,?)")
                        .finish());
        env.execute();
    }
}
