完结篇 | TiDB Binlog 源码阅读系列文章 （九）同步数据到下游

TiDB Binlog（github.com/pingcap/tidb-binlog）用于收集 TiDB 的 binlog，并准实时同步给下游。同步数据这一步重要操作由 Drainer 模块支持，它可以将 binlog 同步到 TiDB MySQL Kafka File （增量备份）等下游组件。

• 对于 TiDB 和 MySQL 两种类型的下游组件，Drainer 会从 binlog 中还原出对应的 SQL 操作在下游直接执行；
• 对于 Kafka 和 File（增量备份）两种类型的下游组件，输出约定编码格式的 binlog。用户可以定制后续各种处理流程，如更新搜索引擎索引、清除缓存、增量备份等。TiDB Binlog 自带工具 Reparo 实现了将增量备份数据（下游类型为 File（增量备份））同步到 TiDB MySQL 的功能。

本文将按以下几个小节介绍 Drainer 如何将收到的 binlog 同步到下游：

// Syncer sync binlog item to downstream
type Syncer interface {
   Sync the binlog item to downstream
  Sync(item *Item) error
   will be close if Close normally or meet error, call Error() to check it
  Successes() <-chan *Item
   Return not nil if fail to sync data to downstream or nil if closed normally
  Error() <-chan error
   Close the Syncer, no more item can be added by `Sync`
  Close() error
}

type CheckPoint interface {
   Load loads checkpoint information.
  Load() error

   Save saves checkpoint information.
  Save(int64) error

   Pos gets position information.
  TS() int64

   Close closes the CheckPoint and release resources, after closed other methods should not be called again.
  Close() error
}

// Txn holds transaction info, an DDL or DML sequences
type Txn struct {
  DMLs []*DML
  DDL  *DDL

   This field is used to hold arbitrary data you wish to include so it
   will be available when receiving on the Successes channel
  Metadata interface{}
}

func (s *Schema) handlePreviousDDLJobIfNeed(version int64) error {
  var i int
  for i = 0; i < len(s.jobs); i++ {
     if s.jobs[i].BinlogInfo.SchemaVersion <= version {
        _, _, _, err := s.handleDDL(s.jobs[i])
        if err != nil {
           return errors.Annotatef(err, "handle ddl job %v failed, the schema info: %s", s.jobs[i], s)
        }
     } else {
        break
     }
  }

  s.jobs = s.jobs[i:]

  return nil
}

// BinlogName creates a binlog file name. The file name format is like binlog-0000000000000001-20181010101010
func BinlogName(index uint64) string {
  currentTime := time.Now()
  return binlogNameWithDateTime(index, currentTime)
}

// binlogNameWithDateTime creates a binlog file name.
func binlogNameWithDateTime(index uint64, datetime time.Time) string {
  return fmt.Sprintf("binlog-%016d-%s", index, datetime.Format(datetimeFormat))
}

// ReadDir reads and returns all file and dir names from directory
func ReadDir(dirpath string) ([]string, error) {
  dir, err := os.Open(dirpath)
  if err != nil {
     return nil, errors.Trace(err)
  }
  defer dir.Close()

  names, err := dir.Readdirnames(-1)
  if err != nil {
     return nil, errors.Annotatef(err, "dir %s", dirpath)
  }

  sort.Strings(names)

  return names, nil
}

func Decode(r io.Reader) (*pb.Binlog, int64, error) {
  payload, length, err := binlogfile.Decode(r)
  if err != nil {
     return nil, 0, errors.Trace(err)
  }

  binlog := &pb.Binlog{}
  err = binlog.Unmarshal(payload)
  if err != nil {
     return nil, 0, errors.Trace(err)
  }
  return binlog, length, nil
}
