0128.T tidb集群启动报错处理记录_failed to start tidb_Err connection error

rundba 2022-01-27
4519

某套运行正常的tidb集群，重启主机后，tidb启动报错“Err: connection error”，经排查防火墙开机自启动，各端口通讯异常，从而导致启动失败。


0.ENV

tidb v5.2.1


1. 重启集群报错

重启集群，tidb启动失败：failed to start: failed to start tidb: failed to start。

[root@tidb1 ~]# tiup cluster restart tidb-test
...
Starting component tidb
  Starting instance 192.168.80.141:4000


Error: failed to start: failed to start tidb: failed to start: 192.168.80.141 tidb-4000.service, please check the instance's log(/tidb-deploy/tidb-4000/log) for more detail.: timed out waiting for port 4000 to be started after 2m0s


Verbose debug logs has been written to /root/.tiup/logs/tiup-cluster-debug-2022-01-26-10-18-20.log.


Found cluster newer version:
  The latest version:         v1.8.2
  Local installed version:    v1.6.1
  Update current component:   tiup update cluster
  Update all components:      tiup update --all
Error: run `/root/.tiup/components/cluster/v1.6.1/tiup-cluster` (wd:/root/.tiup/data/SvaM07Y) failed: exit status 1


2. 问题分析

1) 查看报错组件日志

登录tidb主机192.168.80.141,查看日志tidb.log，提示有“Err: connection error”。

[tidb@tidb1 log]$ tail -f /tidb-deploy/tidb-4000/log/tidb.log
...
1127789 [2022/01/26 10:20:31.787 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127790 [2022/01/26 10:20:31.787 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127791 [2022/01/26 10:20:31.822 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127792 [2022/01/26 10:20:31.822 +08:00] [INFO] [grpclogger.go:69] ["Subchannel picks a new address \"192.168.80.139:20160\" to connect"] [system=grpc] [grpc_log=true]
1127793 [2022/01/26 10:20:31.822 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127794 [2022/01/26 10:20:31.823 +08:00] [WARN] [grpclogger.go:81] ["grpc: addrConn.createTransport failed to connect to {192.168.80.139:20160  <nil> 0 <nil>}. Err: connection error: desc = \"transport: Error while dialing dial tcp 172.1        8.33.139:20160: connect: no route to host\". Reconnecting..."] [system=grpc] [grpc_log=true]
1127795 [2022/01/26 10:20:31.823 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127796 [2022/01/26 10:20:31.823 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127797 [2022/01/26 10:20:32.011 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127798 [2022/01/26 10:20:32.011 +08:00] [INFO] [grpclogger.go:69] ["Subchannel picks a new address \"192.168.80.138:20160\" to connect"] [system=grpc] [grpc_log=true]
1127799 [2022/01/26 10:20:32.012 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127800 [2022/01/26 10:20:32.012 +08:00] [WARN] [grpclogger.go:81] ["grpc: addrConn.createTransport failed to connect to {192.168.80.138:20160  <nil> 0 <nil>}. Err: connection error: desc = \"transport: Error while dialing dial tcp 172.1        8.33.138:20160: connect: no route to host\". Reconnecting..."] [system=grpc] [grpc_log=true]
1127801 [2022/01/26 10:20:32.012 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127802 [2022/01/26 10:20:32.012 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to TRANSIENT_FAILURE"] [system=grpc] [grpc_log=true]
1127803 [2022/01/26 10:20:32.331 +08:00] [INFO] [grpclogger.go:69] ["Subchannel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127804 [2022/01/26 10:20:32.331 +08:00] [INFO] [grpclogger.go:69] ["Subchannel picks a new address \"192.168.80.140:20160\" to connect"] [system=grpc] [grpc_log=true]
1127805 [2022/01/26 10:20:32.332 +08:00] [INFO] [grpclogger.go:69] ["Channel Connectivity change to CONNECTING"] [system=grpc] [grpc_log=true]
1127806 [2022/01/26 10:20:32.893 +08:00] [WARN] [client_batch.go:497] ["init create streaming fail"] [target=192.168.80.138:20160] [forwardedHost=] [error="context deadline exceeded"]
1127807 [2022/01/26 10:20:32.893 +08:00] [INFO] [grpclogger.go:69] ["Channel Created"] [system=grpc] [grpc_log=true]
1127808 [2022/01/26 10:20:32.893 +08:00] [INFO] [grpclogger.go:69] ["parsed scheme: \"\""] [system=grpc] [grpc_log=true]
1127809 [2022/01/26 10:20:32.893 +08:00] [INFO] [grpclogger.go:69] ["scheme \"\" not registered, fallback to default scheme"] [system=grpc] [grpc_log=true]
1127810 [2022/01/26 10:20:32.894 +08:00] [INFO] [grpclogger.go:69] ["ccResolverWrapper: sending update to cc: {[{192.168.80.138:20160  <nil> 0 <nil>}] <nil> <nil>}"] [system=grpc] [grpc_log=true]
1127811 [2022/01/26 10:20:32.894 +08:00] [INFO] [grpclogger.go:69] ["Resolver state updated: {Addresses:[{Addr:192.168.80.138:20160 ServerName: Attributes:<nil> Type:0 Metadata:<nil>}] ServiceConfig:<nil> Attributes:<nil>} (resolver retu        rned new addresses)"] [system=grpc] [grpc_log=true]


2) 问题分析

初步判断是网络通信问题或防火墙问题


3. 问题处理

3.1 网络验证

各节点ping测试，网络连接正常。


3.2 防火墙验证

1) 关闭防火墙

查看各节点，防火墙均已打开

[root@tikv1 ~]# systemctl status firewalld
● firewalld.service - firewalld - dynamic firewall daemon
   Loaded: loaded (/usr/lib/systemd/system/firewalld.service; enabled; vendor preset: enabled)
   Active: active (running) since Wed 2022-01-26 10:01:17 CST; 26min ago
     Docs: man:firewalld(1)
 Main PID: 9884 (firewalld)
   CGroup: /system.slice/firewalld.service
           └─9884 /usr/bin/python -Es /usr/sbin/firewalld --nofork --nopid


Jan 26 10:01:16 tikv1 systemd[1]: Starting firewalld - dynamic firewall daemon...
Jan 26 10:01:17 tikv1 systemd[1]: Started firewalld - dynamic firewall daemon.


2) 停止防火墙

关闭防火墙

[root@tikv1 ~]# systemctl stop firewalld


关闭开机启动

[root@tikv1 ~]# systemctl disable firewalld


3) 查看防火墙状态-已关闭

[root@tikv1 ~]# systemctl status firewalld
● firewalld.service - firewalld - dynamic firewall daemon
   Loaded: loaded (/usr/lib/systemd/system/firewalld.service; enabled; vendor preset: enabled)
   Active: inactive (dead) since Wed 2022-01-26 10:28:30 CST; 55s ago
     Docs: man:firewalld(1)
  Process: 9884 ExecStart=/usr/sbin/firewalld --nofork --nopid $FIREWALLD_ARGS (code=exited, status=0/SUCCESS)
 Main PID: 9884 (code=exited, status=0/SUCCESS)


Jan 26 10:01:16 tikv1 systemd[1]: Starting firewalld - dynamic firewall daemon...
Jan 26 10:01:17 tikv1 systemd[1]: Started firewalld - dynamic firewall daemon.
Jan 26 10:28:30 tikv1 systemd[1]: Stopping firewalld - dynamic firewall daemon...
Jan 26 10:28:30 tikv1 systemd[1]: Stopped firewalld - dynamic firewall daemon.


4. 再次重启集群-OK

1) 再次启动防火墙-OK

[root@tidb1 ~]# tiup cluster restart tidb-test
...(skip)


2) 查看防火墙状态-OK

[root@tidb1 ~]# tiup cluster display tidb-test
Starting component `cluster`: /root/.tiup/components/cluster/v1.6.1/tiup-cluster display tidb-test
Cluster type:       tidb
Cluster name:       tidb-test
Cluster version:    v5.2.1
Deploy user:        tidb
SSH type:           builtin
Dashboard URL:      http://192.168.80.135:2379/dashboard
ID                   Role          Host           Ports        OS/Arch       Status  Data Dir                      Deploy Dir
--                   ----          ----           -----        -------       ------  --------                      ----------
192.168.80.135:9093   alertmanager  192.168.80.135  9093/9094    linux/x86_64  Up      /tidb-data/alertmanager-9093  /tidb-deploy/alertmanager-9093
192.168.80.135:3000   grafana       192.168.80.135  3000         linux/x86_64  Up      -                             /tidb-deploy/grafana-3000
192.168.80.135:2379   pd            192.168.80.135  2379/2380    linux/x86_64  Up|UI   /tidb-data/pd-2379            /tidb-deploy/pd-2379
192.168.80.136:2379   pd            192.168.80.136  2379/2380    linux/x86_64  Up|L    /tidb-data/pd-2379            /tidb-deploy/pd-2379
192.168.80.137:2379   pd            192.168.80.137  2379/2380    linux/x86_64  Up      /tidb-data/pd-2379            /tidb-deploy/pd-2379
192.168.80.135:9090   prometheus    192.168.80.135  9090         linux/x86_64  Up      /tidb-data/prometheus-9090    /tidb-deploy/prometheus-9090
192.168.80.141:4000   tidb          192.168.80.141  4000/10080   linux/x86_64  Up      -                             /tidb-deploy/tidb-4000
192.168.80.138:20160  tikv          192.168.80.138  20160/20180  linux/x86_64  Up      /tidb-data/tikv-20160         /tidb-deploy/tikv-20160
192.168.80.139:20160  tikv          192.168.80.139  20160/20180  linux/x86_64  Up      /tidb-data/tikv-20160         /tidb-deploy/tikv-20160
192.168.80.140:20160  tikv          192.168.80.140  20160/20180  linux/x86_64  Up      /tidb-data/tikv-20160         /tidb-deploy/tikv-20160
Total nodes: 10




Found cluster newer version:
  The latest version:         v1.8.2
  Local installed version:    v1.6.1
  Update current component:   tiup update cluster
  Update all components:      tiup update --all


- 完 -
