0147.k kubernetes 3节点实验环境安装

rundba 2022-03-10

1128

本次环境搭建需要三台CentOS服务器（一主二从），然后在每台服务器中分别安装Docker（20.10.12）、kubeadm（1.23.4）、kubectl（1.23.4）和kubelet（1.23.4）。

0. ENV

0.1 软件版本

CentOS 7.6;

docker 20.10.12;

kubernetes 1.23.4-0(kubelet kubeadm kubectl)。

截止2022-03-08采用的docker及K8S版本。

0.2 集群类型

● Kubernetes集群大致分为两类：一主多从和多主多从。

● 一主多从：一个Master节点和多台Node节点，搭建简单，但是有单机故障风险，适合用于测试环境(本次采用方式)。

● 多主多从：多台Master和多台Node节点，搭建麻烦，安全性高，适合用于生产环境。

0.3 安装方式

● kubernetes有多种部署方式，目前主流的方式有kubeadm、minikube、二进制包。

① minikube：一个用于快速搭建单节点的kubernetes工具。

② kubeadm：一个用于快速搭建kubernetes集群的工具。

③ 二进制包：从官网上下载每个组件的二进制包，依次去安装，此方式对于理解kubernetes组件更加有效。

● 我们需要安装kubernetes的集群环境，但是又不想过于麻烦，所以选择kubeadm方式。

0.4 主机规划

角色 IP地址操作系统配置

k8s3_master 192.168.80.125 CentOS7.6 基础设施服务器 2核CPU，2G内存，50G硬盘

k8s3_node1 192.168.80.126 CentOS7.6 基础设施服务器 2核CPU，2G内存，50G硬盘

k8s3_node2 192.168.80.127 CentOS7.6 基础设施服务器 2核CPU，2G内存，50G硬盘

0.5 环境说明

当前作为实验学习环境，仅1台master，生产环境建议多主部署。

● 本次环境搭建需要三台CentOS服务器（一主二从），然后在每台服务器中分别安装Docker（20.10.12）、kubeadm（1.23.4）、kubectl（1.23.4）和kubelet（1.23.4）。

没有特殊说明，就是三台机器都需要执行。

1. 环境初始化

1) 检查操作系统版本

此方式下安装kubernetes集群要求CentOS版本要在7.5或以上

[root@k8s3_master ~]# cat etc/redhat-release
CentOS Linux release 7.6.1810 (Core)

2) 主机名解析

为方便后面集群节点间的直接调用，在这里配置主机名解析，企业中推荐使用DNS服务器。

vi etc/hosts
192.168.80.125 k8s3_master.rundba.com k8s3_master
192.168.80.126 k8s3_node1.rundba.com  k8s3_node1
192.168.80.127 k8s3_node2.rundba.com  k8s3_node2

3) 时间同步

K8S要求集群中的时间节点必须一致，这里使用chronyd进行同步，生产环境建议使用自己的时间服务器。

systemctl start chronyd
systemctl enable chronyd
date

如果时区不对，设置为东八区：

timedatectl set-timezone Asia/Shanghai

4) 禁用iptables和firewalld服务

K8S和docker在运行中会产生大量的iptables规则，为了不让系统规则跟他们混淆，直接关闭系统的规则。

systemctl stop firewalld
systemctl disable firewalld

--一般iptables服务不会启动

--systemctl stop iptables
--systemctl disable iptables

5) 禁用selinux

selinux是linux系统下的一个安全服务，建议关闭。

修改配置文件永久关闭selinux，需要重启生效

[root@k8s3_node1 ~]# sed -i 's/=enforcing/=disabled/g' etc/selinux/config

临时关闭selinux

[root@k8s3_node1 ~]# setenforce 0
[root@k8s3_node1 ~]# getenforce
Permissive

查看配置文件确认已修改

[root@k8s3_node1 ~]# grep SELINUX= etc/selinux/config
# SELINUX= can take one of these three values:
SELINUX=disabled

6) 禁用swap分区

临时关闭swap，需要重启

[root@dorisdb2 ~]# swapoff -a
[root@dorisdb2 ~]# swapon -s
[root@dorisdb2 ~]# free -h
              total        used        free      shared  buff/cache   available
Mem:            31G        346M         30G        8.8M        373M         30G
Swap:            0B          0B          0B

永久关闭swap

echo vm.swappiness=0 >> etc/sysctl.conf
systemctl -p

同时fstab文件中注释掉swap一行

#/dev/mapper/centos-swap swap                    swap    defaults        0 0

7) 将桥接的IPv4流量传递到iptables的链

在每个节点上将桥接的IPv4流量传递到iptables的链：

cat > /etc/sysctl.d/k8s.conf << EOF
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
net.ipv4.ip_forward = 1
EOF

# 加载br_netfilter模块

modprobe br_netfilter

# 查看是否加载

[root@k8s3-master ~]# lsmod | grep br_netfilter
br_netfilter           22256  0
bridge                151336  1 br_netfilter

# 生效

sysctl --system

8) 开启ipvs

● 在kubernetes中service有两种代理模型，一种是基于iptables，另一种是基于ipvs的。ipvs的性能要高于iptables的，但是如果要使用它，需要手动载入ipvs模块。

在每个节点安装ipset和ipvsadm：

yum -y install ipset ipvsadm

创建配置文件

cat > etc/sysconfig/modules/ipvs.modules <<EOF
#!/bin/bash
modprobe -- ip_vs
modprobe -- ip_vs_rr
modprobe -- ip_vs_wrr
modprobe -- ip_vs_sh
modprobe -- nf_conntrack_ipv4
EOF

授权、运行、检查是否加载：

chmod 755 etc/sysconfig/modules/ipvs.modules && bash etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4

检查是否加载：

lsmod | grep -e ipvs -e nf_conntrack_ipv4

9) 重启三台机器

重启三台Linux机器：

reboot

2. 每个节点安装Docker、kubeadm、kubelet和kubectl

2.1 安装Docker

1) 安装Docker

使用阿里云docker镜像

wget https://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo -O etc/yum.repos.d/docker-ce.repo

查看支持的docker的镜像版本：

yum list docker-ce --showduplicates

安装最新版本：

yum -y install docker-ce

--假如需要安装指定版本，请指定版本号：(必须指定--setopt-obsoletes=0,否则yum会自动安装更高版本)

--yum -y install --setopt-obsoletes=0 docker-ce-18.06.3.ce-3.el7

启动docker服务并设置为开机启动

systemctl enable docker && systemctl start docker

查看docker版本

[root@k8s3_master ~]# docker --version
Docker version 20.10.12, build e91ed57

2) 设置Docker镜像加速器

创建配置文件目录：

sudo mkdir -p /etc/docker

创建配置文件：

sudo tee etc/docker/daemon.json <<-'EOF'
{
  "exec-opts": ["native.cgroupdriver=systemd"],
  "registry-mirrors": ["https://du3ia00u.mirror.aliyuncs.com"],
  "live-restore": true,
  "log-driver":"json-file",
  "log-opts": {"max-size":"500m", "max-file":"3"},
  "storage-driver": "overlay2"
}
EOF

重新加载服务变更

sudo systemctl daemon-reload

重启docker服务

sudo systemctl restart docker

2.2 添加阿里云的YUM软件源

由于kubernetes的镜像源在国外，非常慢，这里切换成国内的阿里云镜像源：

cat > etc/yum.repos.d/kubernetes.repo << EOF
[kubernetes]
name=Kubernetes
baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=0
repo_gpgcheck=0
gpgkey=https://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg https://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
EOF

2.3 安装kubeadm、kubelet和kubectl

安装最新版本(截止2022-03-07最新版本为1.23.4)：

yum install -y kubelet kubeadm kubectl

查看当前支持哪些版本：

yum list kubelet --showduplicates | sort -r

--也可以指定版本号部署：

--yum -y install --setopt-obsoletes=0 kubelet-1.18.0 kubeadm-1.18.0 kubectl-1.18.0

为了实现Docker使用的cgroup drvier和kubelet使用的cgroup drver一致，建议修改"/etc/sysconfig/kubelet"文件的内容：

vim etc/sysconfig/kubelet        #编辑配置文件修改内容如下：
KUBELET_EXTRA_ARGS="--cgroup-driver=systemd"
KUBE_PROXY_MODE="ipvs"

设置为开机自启动即可，由于没有生成配置文件，集群初始化后自动启动：

systemctl enable kubelet

2.4 查看k8s所需镜像

2.4.1 查看k8s所需镜像(本次采用)

[root@k8s3_master ~]# kubeadm config images list
k8s.gcr.io/kube-apiserver:v1.23.4
k8s.gcr.io/kube-controller-manager:v1.23.4
k8s.gcr.io/kube-scheduler:v1.23.4
k8s.gcr.io/kube-proxy:v1.23.4
k8s.gcr.io/pause:3.6
k8s.gcr.io/etcd:3.5.1-0
k8s.gcr.io/coredns/coredns:v1.8.6

2.4.2 查看镜像报错处理

1) 报错内容

如果查看镜像报错：“could not convert cfg to an internal cfg: nodeRegistration.name ...”

[root@k8s3_master ~]# kubeadm config images list
could not convert cfg to an internal cfg: nodeRegistration.name: Invalid value: "k8s3_master": a lowercase RFC 1123 subdomain must consist of lower case alphanumeric characters, '-' or '.', and must start and end with an alphanumeric character (e.g. 'example.com', regex used for validation is '[a-z0-9]([-a-z0-9]*[a-z0-9])?(\.[a-z0-9]([-a-z0-9]*[a-z0-9])?)*')
To see the stack trace of this error execute with --v=5 or higher

2) 报错原因

K8S系统中，遵循RFC 1123标签命名，主机名不能带下划线，可更换为中划线。

3) 报错处理

# 修改集群内所有带下划线主机名为带中划线的主机名

[root@k8s3_master ~]# hostnamectl set-hostname k8s3-master
# 修改hosts将主机名更改为带中划线的主机名
[root@k8s3_master ~]# vim etc/hosts
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
::1         localhost localhost.localdomain localhost6 localhost6.localdomain6
192.168.80.125 k8s3-master.rundba.com k8s3-master
192.168.80.126 k8s3-node1.rundba.com  k8s3-node1
192.168.80.127 k8s3-node2.rundba.com  k8s3-node2

# 再次查看K8S镜像--正常

当前支持镜像版本为v1.23.4

[root@k8s3_master ~]# kubeadm config images list
k8s.gcr.io/kube-apiserver:v1.23.4
k8s.gcr.io/kube-controller-manager:v1.23.4
k8s.gcr.io/kube-scheduler:v1.23.4
k8s.gcr.io/kube-proxy:v1.23.4
k8s.gcr.io/pause:3.6
k8s.gcr.io/etcd:3.5.1-0
k8s.gcr.io/coredns/coredns:v1.8.6

2.4.3 提前下载镜像(本次未采用)

假如由于网络原因，不能直接连接kubernetes仓库时，可以提前下载7个镜像到本地

在shell中执行设置变量：

images=(
    kube-apiserver:v1.23.4
    kube-controller-manager:v1.23.4
    kube-scheduler:v1.23.4
    kube-proxy:v1.23.4
    pause:3.6
    etcd:3.5.1-0
    coredns/coredns:v1.8.6
)

执行脚本：

for imageName in ${images[@]} ; do
  docker pull registry.cn-hangzhou.aliyuncs.com/google_containers/$imageName
  docker tag registry.cn-hangzhou.aliyuncs.com/google_containers/$imageName
k8s.gcr.io/$imageName
  docker rmi registry.cn-hangzhou.aliyuncs.com/google_containers/$imageName
done

2.5 部署k8s的Master节点

部署k8s的Master节点（192.168.80.125）：

# 由于默认拉取镜像地址k8s.gcr.io国内无法访问，这里需要指定阿里云镜像仓库地址

kubeadm init \
  --apiserver-advertise-address=192.168.80.125 \
  --image-repository registry.aliyuncs.com/google_containers \
  --kubernetes-version v1.23.4 \
  --service-cidr=10.96.0.0/12 \
  --pod-network-cidr=10.244.0.0/16

如:

[root@k8s3-master ~]# kubeadm init \
>   --apiserver-advertise-address=192.168.80.125 \  #API Server
>   --image-repository registry.aliyuncs.com/google_containers \  #镜像仓库
>   --kubernetes-version v1.23.4 \      #指定版本为v1.23.4
>   --service-cidr=10.96.0.0/12 \
>   --pod-network-cidr=10.244.0.0/16
[init] Using Kubernetes version: v1.23.4
[preflight] Running pre-flight checks
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'    #此处占用时间可能较长，请耐心等待
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [k8s3-master kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local] and IPs [10.96.0.1 192.168.80.125]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [k8s3-master localhost] and IPs [192.168.80.125 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [k8s3-master localhost] and IPs [192.168.80.125 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 7.503806 seconds
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[kubelet] Creating a ConfigMap "kubelet-config-1.23" in namespace kube-system with the configuration for the kubelets in the cluster
NOTE: The "kubelet-config-1.23" naming of the kubelet ConfigMap is deprecated. Once the UnversionedKubeletConfigMap feature gate graduates to Beta the default name will become just "kubelet-config". Kubeadm upgrade will handle this transition transparently.
[upload-certs] Skipping phase. Please see --upload-certs
[mark-control-plane] Marking the node k8s3-master as control-plane by adding the labels: [node-role.kubernetes.io/master(deprecated) node-role.kubernetes.io/control-plane node.kubernetes.io/exclude-from-external-load-balancers]
[mark-control-plane] Marking the node k8s3-master as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
[bootstrap-token] Using token: kf6lhi.a63jikpwc7lz8p2q
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxy
Your Kubernetes control-plane has initialized successfully!            #初始化成功

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

Alternatively, if you are the root user, you can run:

  export KUBECONFIG=/etc/kubernetes/admin.conf

You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
  https://kubernetes.io/docs/concepts/cluster-administration/addons/

Then you can join any number of worker nodes by running the following on each as root:

kubeadm join 192.168.80.125:6443 --token kf6lhi.a63jikpwc7lz8p2q \
        --discovery-token-ca-cert-hash sha256:fc1aa661090d0912d98d029bd8205dd433ae3ac7b297ed97fb733a3238111021

根据提示消息，在Master节点上如果以普通用户使用kubectl工具，普通需要执行如下操作：

mkdir -p $HOME/.kube
sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

或者，因当前使用root用户，需要设置环境变量(仅在当前会话生效)：

export KUBECONFIG=/etc/kubernetes/admin.conf

设置root用户环境变量,source加载后生效：

[root@k8s3-master ~]# echo "export KUBECONFIG=/etc/kubernetes/admin.conf" >> root/.bash_profile
[root@k8s3-master ~]# source root/.bash_profile
[root@k8s3-master ~]# echo $KUBECONFIG
/etc/kubernetes/admin.conf

2.6 部署k8s的Node节点

根据上述提示，在192.168.80.126和192.168.80.127上添加如下的命令：

kubeadm join 192.168.80.125:6443 --token kf6lhi.a63jikpwc7lz8p2q \
        --discovery-token-ca-cert-hash sha256:fc1aa661090d0912d98d029bd8205dd433ae3ac7b297ed97fb733a3238111021

如:

[root@k8s3-node1 ~]# kubeadm join 192.168.80.125:6443 --token kf6lhi.a63jikpwc7lz8p2q \
>         --discovery-token-ca-cert-hash sha256:fc1aa661090d0912d98d029bd8205dd433ae3ac7b297ed97fb733a3238111021
[preflight] Running pre-flight checks
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...

This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.

Run 'kubectl get nodes' on the control-plane to see this node join the cluster.

默认的token有效期为24小时，当过期之后，该token就不能用了，这时可以使用如下的命令创建token：

kubeadm token create --print-join-command

# 生成一个永不过期的token

kubeadm token create --ttl 0 --print-join-command

2.7 部署CNI网络插件

● 根据提示，在Master节点上使用kubectl工具查看节点状态：

[root@k8s3-master ~]# kubectl get nodes
NAME          STATUS     ROLES                  AGE    VERSION
k8s3-master   NotReady   control-plane,master   17m    v1.23.4
k8s3-node1    NotReady   <none>                 4m6s   v1.23.4
k8s3-node2    NotReady   <none>                 100s   v1.23.4

● kubernetes支持多种网络插件，比如flannel、calico、canal等，任选一种即可，本次选择flannel，如果网络不行，可以许大仙提供的kube-flannel.yml，当然，你也可以安装calico，请点这里calico.yaml，推荐安装calico。

--注:

--kube-flannel.yml详参考章节的原文链接

--https://www.yuque.com/raw?filekey=yuque%2F0%2F2021%2Fyml%2F513185%2F1609860138490-0ef90b45-9b0e-47e2-acfa-0c041f083bf9.yml&from=https%3A%2F%2Fwww.yuque.com%2Ffairy-era%2Fyg511q%2Fhg3u04

--calico.yaml详参考章节的原文链接

--https://www.yuque.com/raw?filekey=yuque%2F0%2F2021%2Fyaml%2F513185%2F1612184315393-f2d1b11a-d9fa-481e-ba77-06cf1ab526f0.yaml&from=https%3A%2F%2Fwww.yuque.com%2Ffairy-era%2Fyg511q%2Fhg3u04

● 在Master节点上获取flannel配置文件(可能会失败，如果失败，请下载到本地，然后安装)：

[root@k8s3-master ~]# wget https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml
--2022-03-07 16:17:07--  https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml
Resolving raw.githubusercontent.com (raw.githubusercontent.com)... 185.199.110.133, 185.199.109.133, 185.199.108.133, ...
Connecting to raw.githubusercontent.com (raw.githubusercontent.com)|185.199.110.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 5692 (5.6K) [text/plain]
Saving to: ‘kube-flannel.yml’

100%[=============================================================================================================================>] 5,692       --.-K/s   in 0s

2022-03-07 16:17:08 (12.7 MB/s) - ‘kube-flannel.yml’ saved [5692/5692]

使用配置文件启动flannel(远程加载)：

kubectl apply -f https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml

也可以下载到本地的kube-flannel.yml启动flannel(本地加载):

[root@k8s3-master ~]# kubectl apply -f kube-flannel.yml
Warning: policy/v1beta1 PodSecurityPolicy is deprecated in v1.21+, unavailable in v1.25+
podsecuritypolicy.policy/psp.flannel.unprivileged created
clusterrole.rbac.authorization.k8s.io/flannel created
clusterrolebinding.rbac.authorization.k8s.io/flannel created
serviceaccount/flannel created
configmap/kube-flannel-cfg created
daemonset.apps/kube-flannel-ds created

查看部署CNI网络插件进度：

[root@k8s3-master ~]# kubectl get pods -n kube-system
NAME                                  READY   STATUS    RESTARTS   AGE
coredns-6d8c4cb4d-k5drx               1/1     Running   0          55m
coredns-6d8c4cb4d-vmz46               1/1     Running   0          55m
etcd-k8s3-master                      1/1     Running   0          56m
kube-apiserver-k8s3-master            1/1     Running   0          56m
kube-controller-manager-k8s3-master   1/1     Running   0          56m
kube-flannel-ds-c8jg7                 1/1     Running   0          4m8s
kube-flannel-ds-s2q6d                 1/1     Running   0          4m8s
kube-flannel-ds-t98m6                 1/1     Running   0          4m8s
kube-proxy-4dw2j                      1/1     Running   0          39m
kube-proxy-q6ljp                      1/1     Running   0          42m
kube-proxy-rqgkf                      1/1     Running   0          55m
kube-scheduler-k8s3-master            1/1     Running   0          56m

再次在Master节点使用kubectl工具查看节点状态：

[root@k8s3-master ~]# kubectl get nodes
NAME          STATUS   ROLES                  AGE   VERSION
k8s3-master   Ready    control-plane,master   57m   v1.23.4
k8s3-node1    Ready    <none>                 43m   v1.23.4
k8s3-node2    Ready    <none>                 41m   v1.23.4

查看集群健康状况：

[root@k8s3-master ~]# kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME                 STATUS    MESSAGE                         ERROR
scheduler            Healthy   ok
controller-manager   Healthy   ok
etcd-0               Healthy   {"health":"true","reason":""}

查看集群信息：

[root@k8s3-master ~]# kubectl cluster-info
Kubernetes control plane is running at https://192.168.80.125:6443
CoreDNS is running at https://192.168.80.125:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

3 服务部署

3.1 前言

● 在Kubernetes集群中部署一个Nginx程序，测试下集群是否正常工作。

3.2 步骤

● 部署Nginx：

[root@k8s3-master ~]# kubectl create deployment nginx --image=nginx:1.14-alpine
deployment.apps/nginx created

● 暴露端口：

[root@k8s3-master ~]# kubectl expose deployment nginx --port=80 --type=NodePort
service/nginx exposed

● 查看服务状态：

[root@k8s3-master ~]# kubectl get pods,svc
NAME                         READY   STATUS    RESTARTS   AGE
pod/nginx-7cbb8cd5d8-6p9rr   1/1     Running   0          69s

NAME                 TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)        AGE
service/kubernetes   ClusterIP   10.96.0.1        <none>        443/TCP        61m
service/nginx        NodePort    10.108.254.134   <none>        80:31950/TCP   46s

访问nginx(使用master/node1/node2 IP地址均可，端口使用80映射的31950)：

http://192.168.80.125:31950        #此时页面nginx页面可正常打开

4. kubernetes中kubectl命令自动补全

kubectl 为 Bash、Zsh、Fish 和 PowerShell 提供了自动补全支持，可以为节省大量输入。

可以使用命令生成 Bash 的 kubectl 的自动补全功能，补全脚本依赖于bash-completion，下文以Bash设置自动补全功能进行演示。

Fish 和 Zsh 设置自动完成的过程，请参考文末链接。

4.1 安装bash-completion

yum install -y bash-completion

4.2 配置bash补全

1) 用户下补全方法(二选一)

echo 'source /usr/share/bash-completion/bash_completion' >> ~/.bashrc
echo 'source <(kubectl completion bash)' >> ~/.bashrc

2) 系统补全方法(二选一)

kubectl completion bash | sudo tee /etc/bash_completion.d/kubectl > /dev/null

4.3 kubectl别名设置

如果需要kubectl的别名，可以扩展 shell 补全以使用该别名：

echo 'alias k=kubectl' >> ~/.bashrc
echo 'complete -F __start_kubectl k' >> ~/.bashrc

4.4 注意

bash-completion 将所有完成脚本都放在/etc/bash_completion.d.

两种方法是等效的。重新加载 shell 后，kubectl 自动完成功能应该可以工作了。

4.5 验证kubectl自动补全功能

[root@k8s3-master ~]# . .bashrc    #加载配置，使配置生效
[root@k8s3-master ~]# k v          #输入k v，点击tab键，此时会自动补全参数version的全部信息
[root@k8s3-master ~]# k version

5. 参考

语雀安装kubernetes：
https://www.yuque.com/fairy-era/yg511q/hg3u04


JAVA黑马安装kubernetes教程：
https://www.bilibili.com/video/BV1Qv41167ck?p=7&spm_id_from=pageDriver


kubectl自动补全参考：
https://kubernetes.io/docs/tasks/tools/install-kubectl-linux/


kubernetes网络插件参考：
https://kubernetes.io/docs/concepts/cluster-administration/addons/

- 完 -

旨在交流，不足之处，还望抛砖。

作者:王坤，微信公众号:rundba，欢迎转载，转载请注明出处。

如需公众号转发，请联系wx: landnow。

长按二维码

欢迎加入>>国产DB学习交流群

请注明:来自rundba，加入国产DB学习交流群

数据库

文章转载自rundba，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

0147.k kubernetes 3节点实验环境安装

评论
