k8s系列-15-master节点安装

运维家 2022-03-20

314

这篇我们部署k8s的master节点，也就是所谓的控制平面，为了保证高可用，我们这里采用了两个master节点，还记得master节点上部署什么内容吗？回忆一下子，分别是api-server，scheduler和controller manager。

配置Apiserver

PS：该操作在两个master节点上都需要执行。

1、移动证书

[root@node1 ~]# mkdir -p etc/kubernetes/ssl
[root@node1 ~]# mv ca.pem ca-key.pem kubernetes-key.pem kubernetes.pem \
    service-account-key.pem service-account.pem \
    proxy-client.pem proxy-client-key.pem \
    /etc/kubernetes/ssl
[root@node1 ~]# ls etc/kubernetes/ssl/
ca-key.pem  ca.pem  kubernetes-key.pem  kubernetes.pem  proxy-client-key.pem  proxy-client.pem  service-account-key.pem  service-account.pem
[root@node1 ~]#

2、配置服务

# 该master节点的IP地址，注意，两个节点需要各自配置自己的IP地址
[root@node1 ~]# IP=192.168.112.130
# 申明apiserver的数量
[root@node1 ~]# APISERVER_COUNT=2
# 申明etcd节点信息，以空格分开
[root@node1 ~]# ETCD_ENDPOINTS=(192.168.112.130 192.168.112.131 192.168.112.132)
# 创建apiserver管理服务
[root@node1 ~]# cat <<EOF > etc/systemd/system/kube-apiserver.service
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes


[Service]
ExecStart=/usr/local/bin/kube-apiserver \\
  --advertise-address=${IP} \\
  --allow-privileged=true \\
  --apiserver-count=${APISERVER_COUNT} \\
  --audit-log-maxage=30 \\
  --audit-log-maxbackup=3 \\
  --audit-log-maxsize=100 \\
  --audit-log-path=/var/log/audit.log \\
  --authorization-mode=Node,RBAC \\
  --bind-address=0.0.0.0 \\
  --client-ca-file=/etc/kubernetes/ssl/ca.pem \\
  --enable-admission-plugins=NamespaceLifecycle,NodeRestriction,LimitRanger,ServiceAccount,DefaultStorageClass,ResourceQuota \\
  --etcd-cafile=/etc/kubernetes/ssl/ca.pem \\
  --etcd-certfile=/etc/kubernetes/ssl/kubernetes.pem \\
  --etcd-keyfile=/etc/kubernetes/ssl/kubernetes-key.pem \\
  --etcd-servers=https://${ETCD_ENDPOINTS[0]}:2379,https://${ETCD_ENDPOINTS[1]}:2379,https://${ETCD_ENDPOINTS[2]}:2379 \\
  --event-ttl=1h \\
  --kubelet-certificate-authority=/etc/kubernetes/ssl/ca.pem \\
  --kubelet-client-certificate=/etc/kubernetes/ssl/kubernetes.pem \\
  --kubelet-client-key=/etc/kubernetes/ssl/kubernetes-key.pem \\
  --service-account-issuer=api \\
  --service-account-key-file=/etc/kubernetes/ssl/service-account.pem \\
  --service-account-signing-key-file=/etc/kubernetes/ssl/service-account-key.pem \\
  --api-audiences=api,vault,factors \\
  --service-cluster-ip-range=10.233.0.0/16 \\
  --service-node-port-range=30000-32767 \\
  --proxy-client-cert-file=/etc/kubernetes/ssl/proxy-client.pem \\
  --proxy-client-key-file=/etc/kubernetes/ssl/proxy-client-key.pem \\
  --runtime-config=api/all=true \\
  --requestheader-client-ca-file=/etc/kubernetes/ssl/ca.pem \\
  --requestheader-allowed-names=aggregator \\
  --requestheader-extra-headers-prefix=X-Remote-Extra- \\
  --requestheader-group-headers=X-Remote-Group \\
  --requestheader-username-headers=X-Remote-User \\
  --tls-cert-file=/etc/kubernetes/ssl/kubernetes.pem \\
  --tls-private-key-file=/etc/kubernetes/ssl/kubernetes-key.pem \\
  --v=1
Restart=on-failure
RestartSec=5


[Install]
WantedBy=multi-user.target
EOF
[root@node1 ~]#

配置controller-manager

PS：该操作在两个master节点上都需要执行。

1、移动证书

[root@node1 ~]# mv kube-controller-manager.kubeconfig etc/kubernetes/
[root@node1 ~]# ls etc/kubernetes/
kube-controller-manager.kubeconfig  ssl
[root@node1 ~]#

2、配置服务

[root@node1 ~]# cat <<EOF > etc/systemd/system/kube-controller-manager.service
[Unit]
Description=Kubernetes Controller Manager
Documentation=https://github.com/kubernetes/kubernetes


[Service]
ExecStart=/usr/local/bin/kube-controller-manager \\
  --bind-address=0.0.0.0 \\
  --cluster-cidr=10.200.0.0/16 \\
  --cluster-name=kubernetes \\
  --cluster-signing-cert-file=/etc/kubernetes/ssl/ca.pem \\
  --cluster-signing-key-file=/etc/kubernetes/ssl/ca-key.pem \\
  --cluster-signing-duration=876000h0m0s \\
  --kubeconfig=/etc/kubernetes/kube-controller-manager.kubeconfig \\
  --leader-elect=true \\
  --root-ca-file=/etc/kubernetes/ssl/ca.pem \\
  --service-account-private-key-file=/etc/kubernetes/ssl/service-account-key.pem \\
  --service-cluster-ip-range=10.233.0.0/16 \\
  --use-service-account-credentials=true \\
  --v=1
Restart=on-failure
RestartSec=5


[Install]
WantedBy=multi-user.target
EOF
[root@node1 ~]#

配置scheduler服务

PS：该操作在两个master节点上都需要执行。

1、移动证书

[root@node1 ~]# mv kube-scheduler.kubeconfig etc/kubernetes
[root@node1 ~]# ls etc/kubernetes/
kube-controller-manager.kubeconfig  kube-scheduler.kubeconfig  ssl
[root@node1 ~]#

2、配置服务

[root@node1 ~]# cat <<EOF > etc/systemd/system/kube-scheduler.service
[Unit]
Description=Kubernetes Scheduler
Documentation=https://github.com/kubernetes/kubernetes


[Service]
ExecStart=/usr/local/bin/kube-scheduler \\
  --authentication-kubeconfig=/etc/kubernetes/kube-scheduler.kubeconfig \\
  --authorization-kubeconfig=/etc/kubernetes/kube-scheduler.kubeconfig \\
  --kubeconfig=/etc/kubernetes/kube-scheduler.kubeconfig \\
  --leader-elect=true \\
  --bind-address=0.0.0.0 \\
  --port=0 \\
  --v=1
Restart=on-failure
RestartSec=5


[Install]
WantedBy=multi-user.target
EOF
[root@node1 ~]#

启动服务

PS：该操作在两个master节点上都需要执行。

[root@node1 ~]# systemctl daemon-reload
[root@node1 ~]# systemctl enable kube-apiserver
Created symlink from etc/systemd/system/multi-user.target.wants/kube-apiserver.service to /etc/systemd/system/kube-apiserver.service.
[root@node1 ~]# systemctl enable kube-controller-manager
Created symlink from /etc/systemd/system/multi-user.target.wants/kube-controller-manager.service to /etc/systemd/system/kube-controller-manager.service.
[root@node1 ~]# systemctl enable kube-scheduler
Created symlink from /etc/systemd/system/multi-user.target.wants/kube-scheduler.service to /etc/systemd/system/kube-scheduler.service.
[root@node1 ~]# systemctl restart kube-apiserver
[root@node1 ~]# systemctl restart kube-controller-manager
[root@node1 ~]# systemctl restart kube-scheduler

验证服务

端口验证，看下端口是否都启动了，确保不会有服务没有启动。

[root@node1 ~]# netstat -ntlp | grep kube
tcp6       0      0 :::6443                 :::*                    LISTEN      4834/kube-apiserver
tcp6       0      0 :::10252                :::*                    LISTEN      4855/kube-controlle
tcp6       0      0 :::10257                :::*                    LISTEN      4855/kube-controlle
tcp6       0      0 :::10259                :::*                    LISTEN      4872/kube-scheduler
[root@node1 ~]#

日志验证，查看是否有错误日志，确保相关服务是正常启动的。

[root@node1 ~]# journalctl -xe

配置kubectl

PS：该操作在两个master节点上都需要执行。

# 创建配置目录
[root@node1 ~]# mkdir ~/.kube/
# 移动证书
[root@node1 ~]# mv ~/admin.kubeconfig ~/.kube/config
# 测试
[root@node1 ~]# kubectl get nodes
No resources found
[root@node1 ~]#

空的是正常的，因为我们还没有启动任何pod服务。由于在执行kubectl的一些命令时，apiserver会转发到kubelet，这里需要定义一些规则，授权apiserver可以访问kubelet api。

PS：这个命令只需要在一个master节点上执行即可。

[root@node1 ~]# kubectl create clusterrolebinding kube-apiserver:kubelet-apis --clusterrole=system:kubelet-api-admin --user kubernetes
clusterrolebinding.rbac.authorization.k8s.io/kube-apiserver:kubelet-apis created
[root@node1 ~]#

至此，本文结束，我们已经将master上的所需服务全部安装完成了，下一篇我们将开始安装worker节点上的服务。
