k8s系列-14-部署Etcd集群

运维家 2022-03-19

478

老板们，点个关注吧。

kubernetes各个组件都是无状态的服务，都存储在etcd中，为了保证集群的高可用，所以etcd也是需要高可用的。

copy证书

在上一篇中，我们生成了很多证书，也分发给了各个节点，本篇中我们就需要使用和etcd相关的证书了。

PS：该操作在每一个节点上执行哈。

# 创建存放证书的目录
[root@node1 ~]# mkdir -pv /etc/etcd /var/lib/etcd
mkdir: 已创建目录 "/etc/etcd"
mkdir: 已创建目录 "/var/lib/etcd"
[root@node1 ~]#
# 授权相关目录为700的权限
[root@node1 ~]# chmod 700 var/lib/etcd
[root@node1 ~]# ll var/lib/ | grep etcd
drwx------   2 root           root              6 3月  18 22:36 etcd
[root@node1 ~]#
# 拷贝证书
[root@node1 ~]# pwd
/root
[root@node1 ~]# cp ca.pem kubernetes-key.pem kubernetes.pem etc/etcd/
[root@node1 ~]# ls etc/etcd/
ca.pem  kubernetes-key.pem  kubernetes.pem
[root@node1 ~]#

配置etcd启动文件

PS：该步骤在每一个节点上执行。

# 获取对应节点的主机名
[root@node1 ~]# ETCD_NAME=$(hostname -s)
# 在每个节点服务器上，配置自己IP地址
[root@node1 ~]# ETCD_IP=192.168.112.130
# 配置节点所有的hostname
[root@node1 ~]# ETCD_NAMES=(node1 node2 node3)
# 配置节点所有的IP地址
[root@node1 ~]# ETCD_IPS=(192.168.112.130 192.168.112.131 192.168.112.132)
# 生成配置文件
[root@node1 ~]# cat <<EOF > etc/systemd/system/etcd.service
[Unit]
Description=etcd
Documentation=https://github.com/coreos


[Service]
Type=notify
ExecStart=/usr/local/bin/etcd \\
  --name ${ETCD_NAME} \\
  --cert-file=/etc/etcd/kubernetes.pem \\
  --key-file=/etc/etcd/kubernetes-key.pem \\
  --peer-cert-file=/etc/etcd/kubernetes.pem \\
  --peer-key-file=/etc/etcd/kubernetes-key.pem \\
  --trusted-ca-file=/etc/etcd/ca.pem \\
  --peer-trusted-ca-file=/etc/etcd/ca.pem \\
  --peer-client-cert-auth \\
  --client-cert-auth \\
  --initial-advertise-peer-urls https://${ETCD_IP}:2380 \\
  --listen-peer-urls https://${ETCD_IP}:2380 \\
  --listen-client-urls https://${ETCD_IP}:2379,https://127.0.0.1:2379 \\
  --advertise-client-urls https://${ETCD_IP}:2379 \\
  --initial-cluster-token etcd-cluster-0 \\
  --initial-cluster ${ETCD_NAMES[0]}=https://${ETCD_IPS[0]}:2380,${ETCD_NAMES[1]}=https://${ETCD_IPS[1]}:2380,${ETCD_NAMES[2]}=https://${ETCD_IPS[2]}:2380 \\
  --initial-cluster-state new \\
  --data-dir=/var/lib/etcd
Restart=on-failure
RestartSec=5


[Install]
WantedBy=multi-user.target
EOF
[root@node1 ~]#

启动ETCD服务

PS：该步骤在每一个节点上执行。

# 重新加载linux服务列表
[root@node1 ~]# systemctl daemon-reload
# 将etcd放入自启动
[root@node1 ~]# systemctl enable etcd
# 重启etcd服务
[root@node1 ~]# systemctl restart etcd
# 查看etcd节点状态
[root@node1 ~]# systemctl status etcd
● etcd.service - etcd
   Loaded: loaded (/etc/systemd/system/etcd.service; enabled; vendor preset: disabled)
   Active: active (running) since 五 2022-03-18 22:56:00 CST; 1min 16s ago
     Docs: https://github.com/coreos
 Main PID: 3663 (etcd)
    Tasks: 8
   CGroup: /system.slice/etcd.service
           └─3663 /usr/local/bin/etcd --name node1 --cert-file=/etc/etcd/kubernetes.pem --key-file=/etc/etcd/kubernetes-key.pem --peer-cert-file=/etc/etcd/kubernetes.pem...
3月 18 22:56:00 node1 systemd[1]: Started etcd.
3月 18 22:56:00 node1 etcd[3663]: health check for peer 2deb614427922fac could not connect: dial tcp 192.168.112.132:2380: connect: connection refused
3月 18 22:56:00 node1 etcd[3663]: health check for peer 2deb614427922fac could not connect: dial tcp 192.168.112.132:2380: connect: connection refused
3月 18 22:56:00 node1 etcd[3663]: peer 2deb614427922fac became active
3月 18 22:56:00 node1 etcd[3663]: established a TCP streaming connection with peer 2deb614427922fac (stream MsgApp v2 writer)
3月 18 22:56:00 node1 etcd[3663]: established a TCP streaming connection with peer 2deb614427922fac (stream Message writer)
3月 18 22:56:00 node1 etcd[3663]: established a TCP streaming connection with peer 2deb614427922fac (stream Message reader)
3月 18 22:56:00 node1 etcd[3663]: established a TCP streaming connection with peer 2deb614427922fac (stream MsgApp v2 reader)
3月 18 22:56:04 node1 etcd[3663]: updated the cluster version from 3.0 to 3.4
3月 18 22:56:04 node1 etcd[3663]: enabled capabilities for version 3.4
[root@node1 ~]#

验证etcd集群

# 输入命令
[root@node1 ~]# ETCDCTL_API=3 etcdctl member list \
  --endpoints=https://127.0.0.1:2379 \
  --cacert=/etc/etcd/ca.pem \
  --cert=/etc/etcd/kubernetes.pem \
  --key=/etc/etcd/kubernetes-key.pem

# 输出信息为：
2deb614427922fac, started, node3, https://192.168.112.132:2380, https://192.168.112.132:2379, false
a47c9892fd8a7e8a, started, node1, https://192.168.112.130:2380, https://192.168.112.130:2379, false
d884949f280137ba, started, node2, https://192.168.112.131:2380, https://192.168.112.131:2379, false
[root@node1 ~]#

至此，etcd高可用部署完毕，明天我们开始搭建worker节点上的服务。
