spark源码解析（9）-Executor工作原理

override def onStart(): Unit = {
    if (env.conf.get(DECOMMISSION_ENABLED)) {
      logInfo("Registering PWR handler to trigger decommissioning.")
      SignalUtils.register("PWR", "Failed to register SIGPWR handler - " +
        "disabling executor decommission feature.") (self.askSync[Boolean](ExecutorSigPWRReceived))
    }


    logInfo("Connecting to driver: " + driverUrl)
    try {
      _resources = parseOrFindResources(resourcesFileOpt)
    } catch {
      case NonFatal(e) =>
        exitExecutor(1, "Unable to create executor due to " + e.getMessage, e)
    }
    rpcEnv.asyncSetupEndpointRefByURI(driverUrl).flatMap { ref =>
      // This is a very fast action so we can use "ThreadUtils.sameThread"
      driver = Some(ref)
      ref.ask[Boolean](RegisterExecutor(executorId, self, hostname, cores, extractLogUrls,
        extractAttributes, _resources, resourceProfile.id))
        //发送消息RegisterExecutor向Driver进程注册，
        //这里注册人RegisterExecutor与Executor没有任何关系，
        //实际注册的是ExecutorBackend，Executor实际
        //只是RegisterExecutor的一个对象。
    }(ThreadUtils.sameThread).onComplete {
      case Success(_) =>
        self.send(RegisteredExecutor)
      case Failure(e) =>
        exitExecutor(1, s"Cannot register with driver: $driverUrl", e, notifyDriver = false)
    }(ThreadUtils.sameThread)
  }

  // Executors to driver
  case class RegisterExecutor(
      executorId: String,
      executorRef: RpcEndpointRef,
      hostname: String,
      cores: Int,
      logUrls: Map[String, String],
      attributes: Map[String, String],
      resources: Map[String, ResourceInformation],
      resourceProfileId: Int)
    extends CoarseGrainedClusterMessage

  override def receive: PartialFunction[Any, Unit] = {
    case RegisteredExecutor =>
      logInfo("Successfully registered with driver")
      try {
        executor = new Executor(executorId, hostname, env, userClassPath, isLocal = false,
          resources = _resources)
        driver.get.send(LaunchedExecutor(executorId))
      } catch {
        case NonFatal(e) =>
          exitExecutor(1, "Unable to create executor due to " + e.getMessage, e)
      }

/**
 * Spark executor, backed by a threadpool to run tasks.
 *
 * This can be used with Mesos, YARN, and the standalone scheduler.
 * An internal RPC interface is used for communication with the driver,
 * except in the case of Mesos fine-grained mode.
 */
private[spark] class Executor(
    executorId: String,
    executorHostname: String,
    env: SparkEnv,
    userClassPath: Seq[URL] = Nil,
    isLocal: Boolean = false,
    uncaughtExceptionHandler: UncaughtExceptionHandler = new SparkUncaughtExceptionHandler,
    resources: immutable.Map[String, ResourceInformation])
  extends Logging {


    // Start worker thread pool
  // Use UninterruptibleThread to run tasks so that we can allow running codes without being
  // interrupted by `Thread.interrupt()`. Some issues, such as KAFKA-1894, HADOOP-10622,
  // will hang forever if some methods are interrupted.
  private val threadPool = {
    val threadFactory = new ThreadFactoryBuilder()
      .setDaemon(true)
      .setNameFormat("Executor task launch worker-%d")
      .setThreadFactory((r: Runnable) => new UninterruptibleThread(r, "unused"))
      .build()
    Executors.newCachedThreadPool(threadFactory).asInstanceOf[ThreadPoolExecutor]
  }

    case LaunchTask(data) =>
      if (executor == null) {
        exitExecutor(1, "Received LaunchTask command but executor was null")
      } else {
        val taskDesc = TaskDescription.decode(data.value)
        logInfo("Got assigned task " + taskDesc.taskId)
        taskResources(taskDesc.taskId) = taskDesc.resources
        executor.launchTask(this, taskDesc)
      }

  def launchTask(context: ExecutorBackend, taskDescription: TaskDescription): Unit = {
    val tr = new TaskRunner(context, taskDescription, plugins)
    runningTasks.put(taskDescription.taskId, tr)
    threadPool.execute(tr)
    if (decommissioned) {
      log.error(s"Launching a task while in decommissioned state.")
    }
  }

  class TaskRunner(
      execBackend: ExecutorBackend,
      private val taskDescription: TaskDescription,
      private val plugins: Option[PluginContainer])
    extends Runnable {

     override def run(): Unit = {

       val value = Utils.tryWithSafeFinally {
          val res = task.run(
            taskAttemptId = taskId,
            attemptNumber = taskDescription.attemptNumber,
            metricsSystem = env.metricsSystem,
            resources = taskDescription.resources,
            plugins = plugins)
          threwException = false
          res

 /**
   * Called by [[org.apache.spark.executor.Executor]] to run this task.
   *
   * @param taskAttemptId an identifier for this task attempt that is unique within a SparkContext.
   * @param attemptNumber how many times this task has been attempted (0 for the first attempt)
   * @param resources other host resources (like gpus) that this task attempt can access
   * @return the result of the task along with updates of Accumulators.
   */
  final def run(
      taskAttemptId: Long,
      attemptNumber: Int,
      metricsSystem: MetricsSystem,
      resources: Map[String, ResourceInformation],
      plugins: Option[PluginContainer]): T = {
    SparkEnv.get.blockManager.registerTask(taskAttemptId)
    // TODO SPARK-24874 Allow create BarrierTaskContext based on partitions, instead of whether
    // the stage is barrier.
    val taskContext = new TaskContextImpl(
      stageId,
      stageAttemptId, // stageAttemptId and stageAttemptNumber are semantically equal
      partitionId,
      taskAttemptId,
      attemptNumber,
      taskMemoryManager,
      localProperties,
      metricsSystem,
      metrics,
      resources)


    context = if (isBarrier) {
      new BarrierTaskContext(taskContext)
    } else {
      taskContext
    }


    InputFileBlockHolder.initialize()
    TaskContext.setTaskContext(context)
    taskThread = Thread.currentThread()


    if (_reasonIfKilled != null) {
      kill(interruptThread = false, _reasonIfKilled)
    }


    new CallerContext(
      "TASK",
      SparkEnv.get.conf.get(APP_CALLER_CONTEXT),
      appId,
      appAttemptId,
      jobId,
      Option(stageId),
      Option(stageAttemptId),
      Option(taskAttemptId),
      Option(attemptNumber)).setCurrentContext()


    plugins.foreach(_.onTaskStart())


    try {
      runTask(context)
    } catch {
      case e: Throwable =>
        // Catch all errors; run task failure callbacks, and rethrow the exception.
        try {
          context.markTaskFailed(e)
        } catch {
          case t: Throwable =>
            e.addSuppressed(t)
        }
        context.markTaskCompleted(Some(e))
        throw e
    } finally {
      try {
        // Call the task completion callbacks. If "markTaskCompleted" is called twice, the second
        // one is no-op.
        context.markTaskCompleted(None)
      } finally {
        try {
          Utils.tryLogNonFatalError {
            // Release memory used by this thread for unrolling blocks
            SparkEnv.get.blockManager.memoryStore.releaseUnrollMemoryForThisTask(MemoryMode.ON_HEAP)
            SparkEnv.get.blockManager.memoryStore.releaseUnrollMemoryForThisTask(
              MemoryMode.OFF_HEAP)
            // Notify any tasks waiting for execution memory to be freed to wake up and try to
            // acquire memory again. This makes impossible the scenario where a task sleeps forever
            // because there are no other tasks left to notify it. Since this is safe to do but may
            // not be strictly necessary, we should revisit whether we can remove this in the
            // future.
            val memoryManager = SparkEnv.get.memoryManager
            memoryManager.synchronized { memoryManager.notifyAll() }
          }
        } finally {
          // Though we unset the ThreadLocal here, the context member variable itself is still
          // queried directly in the TaskRunner to check for FetchFailedExceptions.
          TaskContext.unset()
          InputFileBlockHolder.unset()
        }
      }
    }
  }

  def runTask(context: TaskContext): T

/**
 * A unit of execution. We have two kinds of Task's in Spark:
 *
 *  - [[org.apache.spark.scheduler.ShuffleMapTask]]
 *  - [[org.apache.spark.scheduler.ResultTask]]
