上一篇文章我们配置好了FSFO，本文将分别在failover、switchover和压测场景下通过日志去观察FSFO的切换过程。

failover场景

通过对主库进行shutdown abort触发DG Broker的fast-start failover，观察FSFO过程中主库、备库、观察者和客户端的日志。

1) 查看主备库及DGB信息

确认主备库处于同步状态并且DGB中开启了FSFO。

主库：

sys@test> select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database;

DB_UNIQUE_NAME DATABASE_ROLE OPEN_MODE FS_FAILOVER_STATUS FS_FAILOVER_CURRENT_TARGET

---------------------------------------

TEST_PRI PRIMARY READ WRITE SYNCHRONIZED test_std

Elapsed: 00:00:00.01

备库：

sys@test> select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database;

DB_UNIQUE_NAME DATABASE_ROLE OPEN_MODE FS_FAILOVER_STATUS FS_FAILOVER_CURRENT_TARGET

----------------------------------------

test_std PHYSICAL STANDBY READ ONLY WITH APPLY SYNCHRONIZED test_std

Elapsed: 00:00:00.01

确认DGB 状态正常：

DGMGRL> show configuration verbose;

Configuration - test

Protection Mode: MaxAvailability

Databases:

TEST_PRI - Primary database

test_std - (*) Physical standby database

(*) Fast-Start Failover target

Properties:

FastStartFailoverThreshold = '15'

OperationTimeout = '300'

……

PrimaryLostWriteAction = 'CONTINUE'

Fast-Start Failover: ENABLED

Threshold: 15 seconds

Target: test_std

Observer: 10-110-110-30

Lag Limit: 30 seconds (not in use)

……

Configuration Status:

SUCCESS

2) shutdown abort关闭主库，触发failover

sys@test> shutdown abort

ORACLE instance shut down.

3) 观察者输出内容

DGMGRL> start observer;

Observer started

11:44:11.03 Monday, January 09, 2017

Initiating Fast-Start Failover to database "test_std"...

Performing failover NOW, please wait...

Failover succeeded, new primary is "test_std" --切换成功

11:44:26.86 Monday, January 09, 2017

4) TAF 客户端无缝切换日志

在30上以fsfo连接串连接到主库：

[oracle]$ sqlplus sys/123456@fsfo as sysdba

sys@TEST>select database_role,db_unique_name from v$database;

DATABASE_ROLE DB_UNIQUE_NAME

---------------- ------------------------------

PRIMARY TEST_PRI

切换前：DB_UNIQUE_NAME为TEST_PRI

在当前会话中执行：

sys@TEST>select * from dba_objects; --执行耗时sql

LAST_DDL_ TIMESTAMP STATUS T G S

--------- ------------------- ------- - - -

NAMESPACE EDITION_NAME

---------- ------------------------------

24-AUG-13 2013-08-24:11:37:35 VALID N N N

…………

切换期间，屏幕输出停顿一定时间，然后继续打印输出：

…………

12-JAN-17 2017-01-12:08:24:46 VALID N N N

16-JAN-17 2017-01-16:11:49:37 VALID N N N

86282 rows selected.

最终返回所有结果集。

再查看当前会话：

sys@TEST>select database_role,db_unique_name from v$database;

DATABASE_ROLE DB_UNIQUE_NAME

-------------------------------------

PRIMARY test_std

当前连接已经转到test_std上。

5) 查看test_std状态和DGB信息

查看test_std状态：

sys@test> select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database;

DB_UNIQUE_NAME DATABASE_ROLE OPEN_MODE FS_FAILOVER_STATUS FS_FAILOVER_CURRENT_TARGET

--------------------------------------

test_std PRIMARY READ WRITE REINSTATE REQUIRED TEST_PRI

Elapsed: 00:00:00.00

查看DGB状态：

DGMGRL> show configuration verbose;

Configuration - test

Protection Mode: MaxAvailability

Databases:

test_std - Primary database

Warning: ORA-16817: unsynchronized fast-start failover configuration

TEST_PRI - (*) Physical standby database (disabled)

ORA-16661: the standby database needs to be reinstated--需要恢复

(*) Fast-Start Failover target

Properties:

FastStartFailoverThreshold = '15'

OperationTimeout = '300'

……

PrimaryLostWriteAction = 'CONTINUE'

Fast-Start Failover: ENABLED

Threshold: 15 seconds

Target: TEST_PRI

Observer: 10-110-110-30

……

Configuration Status:

WARNING

6) 启动test_pri到mount触发恢复操作

-bash-4.2$ sqlplus as sysdba

SQL*Plus: Release 11.2.0.4.0 Production on Mon Jan 9 11:50:13 2017

Connected to an idle instance.

idle> startup mount;

ORACLE instance started.

……

Database mounted.

查看test_pri状态：

idle> select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database;

select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database

ERROR at line 1:

ORA-03135: connection lost contact

Process ID: 26511

Session ID: 5 Serial number: 3

7) 观察者恢复test_pri

查看观察者输出日志：

11:51:02.37 Monday, January 09, 2017

Initiating reinstatement for database "TEST_PRI"...

Reinstating database "TEST_PRI", please wait...

Operation requires shutdown of instance "test" on database "TEST_PRI"

Shutting down instance "test"...

ORA-01109: database not open

Database dismounted.

ORACLE instance shut down.

Operation requires startup of instance "test" on database "TEST_PRI"

Starting instance "test"...

ORACLE instance started.

Database mounted.

Continuing to reinstate database "TEST_PRI" ...

Reinstatement of database "TEST_PRI" succeeded--完成恢复

11:52:14.38 Monday, January 09, 2017

恢复完成后再查看test_pri

sys@test> select DB_UNIQUE_NAME,database_role,open_mode,FS_FAILOVER_STATUS, FS_FAILOVER_CURRENT_TARGET from v$database;

DB_UNIQUE_NAME DATABASE_ROLE OPEN_MODE FS_FAILOVER_STATUS FS_FAILOVER_CURRENT_TARGET

----------------------------------------

TEST_PRI PHYSICAL STANDBY READ ONLY WITH APPLY SYNCHRONIZED TEST_PRI

Elapsed: 00:00:00.01

sys@test>

查看DGB状态：

DGMGRL> show configuration verbose;

Configuration - test

Protection Mode: MaxAvailability

Databases:

test_std - Primary database

TEST_PRI - (*) Physical standby database

(*) Fast-Start Failover target

Properties:

FastStartFailoverThreshold = '15'

OperationTimeout = '300'

……

PrimaryLostWriteAction = 'CONTINUE'

Fast-Start Failover: ENABLED

Threshold: 15 seconds

Target: TEST_PRI

……

Configuration Status:

SUCCESS

8) 切换过程中test_pri的alert 日志：

[BEGIN] 2017/1/9 11:42:08

Mon Jan 09 11:43:54 2017

Shutting down instance (abort) --强制关库

License high water mark = 12

USER (ospid: 25916): terminating the instance

Instance terminated by USER, pid = 25916

Mon Jan 09 11:43:55 2017

Instance shutdown complete

以下为test_pri 启动到mount状态触发的日志

Mon Jan 09 11:50:23 2017

Starting ORACLE instance (normal)

……

Completed: ALTER DATABASE MOUNT

Mon Jan 09 11:50:44 2017

……

FLASHBACK DATABASE TO SCN 7902949

Flashback Restore Start

……

Flashback Restore Complete

Flashback Media Recovery Start

started logmerger process

Parallel Media Recovery started with 4 slaves

Mon Jan 09 11:51:13 2017

Recovery of Online Redo Log: Thread 1 Group 3 Seq 299 Reading mem 0

Mem# 0: home/oracle/app/oradata/test/redo103.log

Incomplete Recovery applied until change 7902950 time 01/09/2017 11:43:54

Flashback Media Recovery Complete

Completed: FLASHBACK DATABASE TO SCN 7902949 --恢复到切换前的scn

alter database convert to physical standby

ALTER DATABASE CONVERT TO PHYSICAL STANDBY (test)--转换为备库

Flush standby redo logfile failed:1649

Clearing standby activation ID 2410103509 (0x8fa742d5)

……

Completed: alter database convert to physical standby

Mon Jan 09 11:51:18 2017

Shutting down instance (immediate)

……

Instance shutdown complete

Mon Jan 09 11:51:30 2017

Starting ORACLE instance (normal)

……

Primary database is in MAXIMUM AVAILABILITY mode

Standby controlfile consistent with primary

……

Media Recovery Log home/oracle/arch/test_1_6_932816657.arc

Media Recovery Waiting for thread 1 sequence 7 (in transit)

Recovery of Online Redo Log: Thread 1 Group 11 Seq 7 Reading mem 0

Mem# 0: home/oracle/app/oradata/test/stdbyredo11.log

[END] 2017/1/9 11:58:18

9) 切换过程中test_std的alert日志

[BEGIN] 2017/1/9 11:43:14

Mon Jan 09 11:43:54 2017

RFS[7]: Assigned to RFS process 13988

RFS[7]: Possible network disconnect with primary database --监测到丢失连接

Mon Jan 09 11:43:54 2017

RFS[8]: Assigned to RFS process 13881

RFS[8]: Possible network disconnect with primary database

……

Mon Jan 09 11:43:54 2017

RFS[3]: Possible network disconnect with primary database

Mon Jan 09 11:44:10 2017

Attempting Fast-Start Failover because the threshold of 15 seconds has elapsed.--超时

Mon Jan 09 11:44:11 2017

Data Guard Broker: Beginning failover--开始切换

Mon Jan 09 11:44:11 2017

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL

Mon Jan 09 11:44:11 2017

MRP0: Background Media Recovery cancelled with status 16037

Errors in file home/oracle/app/diag/rdbms/test_std/test/trace/test_pr00_9424.trc:

……

Managed Standby Recovery Canceled (test)

Completed: ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE FINISH FORCE

Attempt to do a Terminal Recovery (test)

Media Recovery Start: Managed Standby Recovery (test)

started logmerger process

Mon Jan 09 11:44:12 2017

……

Completed: ALTER DATABASE RECOVER MANAGED STANDBY DATABASE FINISH FORCE

ALTER DATABASE COMMIT TO SWITCHOVER TO PRIMARY WAIT WITH SESSION SHUTDOWN

ALTER DATABASE SWITCHOVER TO PRIMARY (test)

Maximum wait for role transition is 15 minutes.

All dispatchers and shared servers shutdown

CLOSE: killing server sessions.

……

Mon Jan 09 11:44:17 2017

Setting recovery target incarnation to 4

Switchover: Complete - Database mounted as primary

Completed: ALTER DATABASE COMMIT TO SWITCHOVER TO PRIMARY WAIT WITH SESSION SHUTDOWN

ALTER DATABASE SET STANDBY DATABASE TO MAXIMIZE AVAILABILITY

Completed: ALTER DATABASE SET STANDBY DATABASE TO MAXIMIZE AVAILABILITY

ALTER DATABASE OPEN

Data Guard Broker initializing...

Mon Jan 09 11:44:18 2017

……

Failover succeeded. Primary database is now test_std.--切换完成

……

ALTER SYSTEM ARCHIVE LOG

******************************************************************

LGWR: Setting 'active' archival for destination LOG_ARCHIVE_DEST_2

******************************************************************

LGWR: Standby redo logfile selected to archive thread 1 sequence 7

LGWR: Standby redo logfile selected for thread 1 sequence 7 for destination LOG_ARCHIVE_DEST_2

Thread 1 advanced to log sequence 7 (LGWR switch)

Current log# 1 seq# 7 mem# 0: home/oracle/app/oradata/test/redo101.log

Archived Log entry 551 added for thread 1 sequence 6 ID 0x90370840 dest 1:

Switchover切换

开启配置FSFO的情况下，只可以SWITCHOVER到目标主库。执行切换前，确认工作请参考DG Broker文档。测试过程如下：

1）先查看DGB FSFO状态

DGMGRL> show configuration verbose;

Configuration - test

Protection Mode: MaxAvailability

Databases:

test_std - Primary database

TEST_PRI - (*) Physical standby database

(*) Fast-Start Failover target

Properties:

FastStartFailoverThreshold = '15'

OperationTimeout = '300'

……

PrimaryLostWriteAction = 'CONTINUE'

Fast-Start Failover: ENABLED

Threshold: 15 seconds

Target: TEST_PRI

Observer: 10-110-110-30

……

Configuration Status:

SUCCESS

2）使用DGB 发起切换命令

DGMGRL> SWITCHOVER TO 'TEST_PRI';

Performing switchover NOW, please wait...

Operation requires a connection to instance "test" on database "TEST_PRI"

Connecting to instance "test"...

Connected.

New primary database "TEST_PRI" is opening...

Operation requires startup of instance "test" on database "test_std"

Starting instance "test"...

ORACLE instance started.

Database mounted.

Database opened.

Switchover succeeded, new primary is "TEST_PRI" --切换完成

DGMGRL>

3）确认DGB FSFO状态

DGMGRL> show configuration verbose;

Configuration - test

Protection Mode: MaxAvailability

Databases:

TEST_PRI - Primary database --完成切换

test_std - (*) Physical standby database

(*) Fast-Start Failover target

Properties:

FastStartFailoverThreshold = '15'

OperationTimeout = '300'

……

PrimaryLostWriteAction = 'CONTINUE'

Fast-Start Failover: ENABLED

Threshold: 15 seconds

Target: test_std

Observer: 10-110-110-30

……

Configuration Status:

SUCCESS

压测场景failover

1) JDBC中连接串的配置

jdbc-1.druid.url=jdbc:oracle:thin:@(DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=oracle.data1.com)(PORT=9539))(ADDRESS=(PROTOCOL=tcp)(HOST=oracle.data2.com)(PORT=9539))(LOAD_BALANCE=off)(FAILOVER=on)(CONNECT_DATA=(SERVER=DEDICATED)(SERVICE_NAME=SERVICE_PRI)(FAILOVER_MODE=(TYPE=session)(METHOD=basic)(RETRIES=180)(DELAY=10))))
