大家好，这次大表哥和大家分享的是PG的统计信息和扩展统计信息。

当然我们今天讨论的统计信息是基于表和索引的统计信息，PG 的 query planner 生成执行计划的依据就是统计信息和 cost 常量参数。

关于 planner cost 常量类似于计算成本中的各种加权因子具体可以参考官方文档： https://www.postgresql.org/docs/14/runtime-config-query.html

常见的有： seq_page_cost， cpu_tuple_cost， cpu_index_tuple_cost …

而表和索引的统计信息，为执行计划的生成提供了基础的数据统计支持。

我们先来看一下 row estimate 或者 cardinality :

对于行的基数的预估是参考： pg_class 的属性 reltuples

dbtest@[local:/tmp]:1992=#60266 create table t1(id int, name varchar(200));
CREATE TABLE
dbtest@[local:/tmp]:1992=#60266 insert into t1 values (generate_series(1,1000),'hello PG!');
INSERT 0 1000
dbtest@[local:/tmp]:1992=#60266 select reltuples from pg_class where relname = 't1';
reltuples
-----------
     1000
dbtest@[local:/tmp]:1992=#60266 explain analyze select * from t1;
                                            QUERY PLAN
----------------------------------------------------------------------------------------------------
Seq Scan on t1  (cost=0.00..16.00 rows=1000 width=14) (actual time=0.016..0.207 rows=1000 loops=1)
Planning Time: 0.214 ms
Execution Time: 0.385 ms
(3 rows)

我们看一下 SQL 语句加上 where 过滤条件之后的 cardinality 的预估：

dbtest@[local:/tmp]:1992=#92372 explain analyze select * from t1 where id <= 505;
                                           QUERY PLAN
--------------------------------------------------------------------------------------------------
Seq Scan on t1  (cost=0.00..18.50 rows=505 width=14) (actual time=0.021..0.139 rows=505 loops=1)
  Filter: (id <= 505)
  Rows Removed by Filter: 495
Planning Time: 0.344 ms
Execution Time: 0.233 ms
(5 rows)

我们来看一下 column id 的直方图分布一共100个桶，范围是10

dbtest@[local:/tmp]:1992=#60266 SELECT histogram_bounds FROM pg_stats
dbtest-# WHERE tablename='t1' AND attname='id';

histogram_bounds

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-------------------
{1,10,20,30,40,50,60,70,80,90,100,110,120,130,140,150,160,170,180,190,200,210,220,230,240,250,260,270,280,290,300,310,320,330,340,350,360,370,380,390,400,410,420,430,440,450,460,470,480,49
0,500,510,520,530,540,550,560,570,580,590,600,610,620,630,640,650,660,670,680,690,700,710,720,730,740,750,760,770,780,790,800,810,820,830,840,850,860,870,880,890,900,910,920,930,940,950,960
,970,980,990,1000}

我们看一下官方文档上给出的选择率的计算： id <= 505 所在的桶 [505,510] 所在的桶是 51号桶，由于是 height-balanced 的直方图那么默认的
公式是 N 是查询条件所在的桶的编号

selectivity = ((N-1) + (cer - bucket[N].min)/(bucket.max[N] - bucket.min[N]))/num_buckets

selectivity = (50 + (505 - bucket.min)/(bucket.max - bucket.min))/num_buckets
           = (50 + (505 - 500)/(510 - 500))/100
           =  0.505

所以过滤后的cardinality 就是

reltuples * selectivity = 1000 * 0.505 = 505 这个预期是符合我们执行计划中的 rows=505

我们现在看一下等值的情况：

dbtest@[local:/tmp]:1992=#60266 update t1 set name = 'Great PG!' where id <= 10;
UPDATE 10
dbtest@[local:/tmp]:1992=#60266 select count(1), name from t1 group by name;
count |   name
-------+-----------
   10 | Great PG!
  990 | hello PG!
(2 rows)

dbtest@[local:/tmp]:1992=#60266 analyze t1;
ANALYZE

我们分别用 where name = ‘Great PG!’ 和 where name = ‘hello PG!’ 查看一下执行计划里面的 cardinality:

name = ‘Great PG!’ : 预估的 rows=10
name = ‘hello PG!’ : 预估的 rows=990

dbtest@[local:/tmp]:1992=#60266 explain analyze select * from t1 where name = 'Great PG!';
                                          QUERY PLAN
------------------------------------------------------------------------------------------------
Seq Scan on t1  (cost=0.00..18.50 rows=10 width=14) (actual time=0.090..0.091 rows=10 loops=1)
  Filter: ((name)::text = 'Great PG!'::text)
  Rows Removed by Filter: 990
Planning Time: 0.084 ms
Execution Time: 0.104 ms
(5 rows)



dbtest@[local:/tmp]:1992=#60266 explain analyze select * from t1 where name = 'hello PG!';
                                           QUERY PLAN
--------------------------------------------------------------------------------------------------
Seq Scan on t1  (cost=0.00..18.50 rows=990 width=14) (actual time=0.018..0.194 rows=990 loops=1)
  Filter: ((name)::text = 'hello PG!'::text)
  Rows Removed by Filter: 10
Planning Time: 0.061 ms
Execution Time: 0.258 ms
(5 rows)

我们看一下 name 列上的值分布：我们可以看到列上出现了类似 high frequency 的直方图：
n_distinct ：2 只有2个值
most_common_vals： {“hello PG!”,“Great PG!”}
most_common_freqs： {0.99,0.01}

由于重复值的频率很高，这里PG的并不会采用 height balance 测直方图 histogram_bounds 是 null

name = ‘Great PG!’ : 预估的 rows=10 = reltuples * most_common_freqs = 1000* 0.01 = 10
name = ‘hello PG!’ : 预估的 rows=990 = reltuples * most_common_freqs = 1000* 0.99 = 990

dbtest@[local:/tmp]:1992=#60266 SELECT *  FROM pg_stats
WHERE tablename='t1' AND attname='name';
-[ RECORD 1 ]----------+--------------------------
schemaname             | public
tablename              | t1
attname                | name
inherited              | f
null_frac              | 0
avg_width              | 10
n_distinct             | 2
most_common_vals       | {"hello PG!","Great PG!"}
most_common_freqs      | {0.99,0.01}
histogram_bounds       |
correlation            | 0.9405999
most_common_elems      |
most_common_elem_freqs |
elem_count_histogram   |

我们再来看一下 where 条件中含有2个不同的列的组合情况下，cardinality 的预估：

select * from t1 where name = ‘hello PG!’ and id > 500 ;

我们 cardinality rows=495 是如何根据统计信息预估的？其实和简单就是概率学上两个列值的 selectivity1 * selectivity2

selectivity = selectivity(name = ‘hello PG!’) * selectivity(id <= 505)
= 0.99 * (50 + (505 - 500)/(510 - 500))/100
= 0.99 * 0.505
= 0.49995‬

rows = 1000 * 0.49995‬
=499.95
= 约等于 500 （经过四舍五入）

dbtest@[local:/tmp]:1992=#92372 explain analyze select * from t1 where name = 'hello PG!' and id <= 505;
                                           QUERY PLAN
--------------------------------------------------------------------------------------------------
Seq Scan on t1  (cost=0.00..21.00 rows=500 width=14) (actual time=0.016..0.103 rows=495 loops=1)
  Filter: ((id <= 505) AND ((name)::text = 'hello PG!'::text))
  Rows Removed by Filter: 505
Planning Time: 0.078 ms
Execution Time: 0.129 ms
(5 rows)

我们再来看一下，2个表连接的情况：
准备2张表， tt1和tt2 是 1对多的关系。

dbtest@[local:/tmp]:1992=#92372 insert into tt1 values (generate_series(1,100),'inner join tt1');
INSERT 0 100
dbtest@[local:/tmp]:1992=#92372 insert into tt2 values (generate_series(1,100),'inner join tt2');
INSERT 0 100
dbtest@[local:/tmp]:1992=#92372 insert into tt2 values (generate_series(1,100),'inner join tt2');
INSERT 0 100
dbtest@[local:/tmp]:1992=#92372 select count(1) from tt1;
count
-------
  100
(1 row)

dbtest@[local:/tmp]:1992=#92372 select count(1) from tt2;
count
-------
  200
(1 row)

dbtest@[local:/tmp]:1992=#92372 analyze tt1;
ANALYZE
dbtest@[local:/tmp]:1992=#92372 analyze tt2;
ANALYZE

我们来看一下 select * from tt1 , tt2 where tt1.id = tt2.id and tt1.name = ‘inner join tt1’; 的SQL 执行计划:

dbtest@[local:/tmp]:1992=#92372 explain analyze select * from tt1 , tt2 where tt1.id = tt2.id and  tt1.name = 'inner join tt1';
                                                 QUERY PLAN
--------------------------------------------------------------------------------------------------------------
Hash Join  (cost=3.50..10.25 rows=200 width=38) (actual time=0.053..0.117 rows=200 loops=1)
  Hash Cond: (tt2.id = tt1.id)
  ->  Seq Scan on tt2  (cost=0.00..4.00 rows=200 width=19) (actual time=0.013..0.033 rows=200 loops=1)
  ->  Hash  (cost=2.25..2.25 rows=100 width=19) (actual time=0.032..0.033 rows=100 loops=1)
        Buckets: 1024  Batches: 1  Memory Usage: 13kB
        ->  Seq Scan on tt1  (cost=0.00..2.25 rows=100 width=19) (actual time=0.008..0.021 rows=100 loops=1)
              Filter: ((name)::text = 'inner join tt1'::text)
Planning Time: 0.104 ms
Execution Time: 0.152 ms
(9 rows)

查询一下： tt1和tt2 表的 null_frac 和（空值频率） n_distinct （NDV 的数量）：
n_distinct 为 -1 的时候， num_distinct 就是 reltuples = 100
n_distinct 为 -0.5 表示数据有 0.5 （50%）是重复的，这个时候的num_distinct = reltuples * n_distinct = 200 * 0.5 = 100
（n_distinct 这个值为正数的时候，代表num_distinct ，为负数的时候，代表重复率的百分比， -1的时候，代表 num_distinct = reltuples ）

dbtest@[local:/tmp]:1992=#92372  SELECT tablename, null_frac,n_distinct FROM pg_stats WHERE tablename IN ('tt1', 'tt2') AND attname='id';
tablename | null_frac | n_distinct
-----------+-----------+------------
tt1       |         0 |         -1
tt2       |         0 |       -0.5
(2 rows)

计算公式为：

selectivity = (1 - null_frac1) * (1 - null_frac2) * min(1/num_distinct1, 1/num_distinct2)
= (1-0）* (1-0) * min(1/(1100),1/(0.5200))
= 0.01

rows = (outer_cardinality * inner_cardinality) * selectivity
= (200 * 100) * 0.01
= 200

接下来，我们看一下 Extended Statistics 扩展统计信息， PG 里面也叫 multivariate statistics, 即为多列的统计信息。这个功能是从PG 10 版本引进的
可以简单的理解为，如果一张表中有多个列是在业务上有相关联的业务联系，那么联合这几个列一起收集统计信息，对优化器生成最佳的执行计划提供准确的数据支持。

对于列的扩展统计信息，系统是不会自动收集的，需要的时候，可以手动创建。扩展的统计信息只要保存在 pg_statistic_ext 和pg_statistic_ext_data 中
命令如下：

CREATE STATISTICS stts (dependencies|ndistinct|mcv) ON col1, col2 FROM table;

大家可以看到 dependencies, ndistinct, mcv 这几个关键字，表示 col1,col2 在业务上或者生活常识上有一定的依赖关系。用官方文档上的例子，一张表中有 zipcode , city 这2个列。按照常识来说如果知道city 和 zipcode 应该是 1对1 的关系，
也就是说 where 条件中如果 city = ‘TJ’ and zipcode = ‘300100’ 可以得到一个选择率很高，row estimation (cardinality) 很低的统计信息

我们现在举一个实际的例子：

假设一下表 tt_ext 中 col1 和 col2 的业务联系：我们建立一个 col1 的值和 col2 的值是 1比1 的关系

1)co11 = ‘hello’ 的时候， col2 = ‘PG’
2)co11 = ‘你好’ 的时候， col2 = ‘Postgres’

postgres@[local:/tmp]:1992=#46124 create table tt_ext (id int, col1 varchar(20), col2 varchar(20));
CREATE TABLE
postgres@[local:/tmp]:1992=#46124 insert into tt_ext values (generate_series(1,20),'hello','PG');
INSERT 0 20
postgres@[local:/tmp]:1992=#46124 insert into tt_ext values (generate_series(21,25),'你好','Postgres');
INSERT 0 5
postgres@[local:/tmp]:1992=#46124 analyze tt_ext;
ANALYZE

select * from tt_ext where col1 = ‘hello’ and col2=‘PG’ 的执行计划中，我们看到的 rows = 16 的计算方式是

selectivity = selectivity(col1 = ‘hello’) * selectivity(col2=‘PG’)
= 0.8*0.8
= 0.64 ‬

rows = reltuples * selectivity
= 25 * 0.64 ‬
= 16

postgres-# WHERE tablename='tt_ext' AND attname in ('col1','col2');
-[ RECORD 1 ]----------+--------------
schemaname             | public
tablename              | tt_ext
attname                | col1
inherited              | f
null_frac              | 0
avg_width              | 6
n_distinct             | 2
most_common_vals       | {hello,你好}
most_common_freqs      | {0.8,0.2}
histogram_bounds       |
correlation            | 1
most_common_elems      |
most_common_elem_freqs |
elem_count_histogram   |
-[ RECORD 2 ]----------+--------------
schemaname             | public
tablename              | tt_ext
attname                | col2
inherited              | f
null_frac              | 0
avg_width              | 4
n_distinct             | 2
most_common_vals       | {PG,Postgres}
most_common_freqs      | {0.8,0.2}
histogram_bounds       |
correlation            | 1
most_common_elems      |
most_common_elem_freqs |
elem_count_histogram   |

postgres@[local:/tmp]:1992=#46124 explain analyze select * from tt_ext where col1 = 'hello' and col2='PG';
                                           QUERY PLAN
---------------------------------------------------------------------------------------------------
Seq Scan on tt_ext  (cost=0.00..1.38 rows=16 width=14) (actual time=0.021..0.032 rows=20 loops=1)
  Filter: (((col1)::text = 'hello'::text) AND ((col2)::text = 'PG'::text))
  Rows Removed by Filter: 5
Planning Time: 0.098 ms
Execution Time: 0.062 ms
(5 rows)

我们来手动的创建一下 col1和 col2的 multivariate statistics，这里需要注意的是，执行完 create statistics 的命令之后，必须要执行一下 analyze 命令，才会真正的收集扩展的统计信息。
关于扩展统计信息的查询可以通过 pg_statistic_ext 和 pg_statistic_ext_data 的表连接查询或者 pg_stats_ext 直接查询

stxname： create statistic 指定的统计信息名称
stxkeys：第2列和第3列: col1 和 col 2
stxddependencies： “2 => 3”: 1.000000 这个表示 col1 可以 100%决定 col2 的值
“3 => 2”: 1.000000 这个表示 col2 可以 100%决定 col1 的值

postgres@[local:/tmp]:1992=#46124 create statistics stats_ext_tt_col1_col2 (dependencies) on col1,col2 from tt_ext;
CREATE STATISTICS

postgres@[local:/tmp]:1992=#46124 analyze tt_ext;
ANALYZE

postgres@[local:/tmp]:1992=#46124 SELECT stxname, stxkeys, stxddependencies
FROM pg_statistic_ext join pg_statistic_ext_data on (oid = stxoid)
WHERE stxname = 'stats_ext_tt_col1_col2';
       stxname         | stxkeys |             stxddependencies
------------------------+---------+------------------------------------------
stats_ext_tt_col1_col2 | 2 3     | {"2 => 3": 1.000000, "3 => 2": 1.000000}
(1 row)

postgres@[local:/tmp]:1992=#46124  SELECT * FROM pg_stats_ext WHERE tablename = 'tt_ext';
-[ RECORD 1 ]----------+-----------------------------------------
schemaname             | public
tablename              | tt_ext
statistics_schemaname  | public
statistics_name        | stats_ext_tt_col1_col2
statistics_owner       | postgres
attnames               | {col1,col2}
exprs                  |
kinds                  | {f}
inherited              | f
n_distinct             |
dependencies           | {"2 => 3": 1.000000, "3 => 2": 1.000000}
most_common_vals       |
most_common_val_nulls  |
most_common_freqs      |
most_common_base_freqs |

这个时候再来看一下： rows=20 是精准的了

由于 selectivity(col1 = ‘hello’) 是可以决定 selectivity(col2=‘PG’)
或者说是 selectivity(col2=‘PG’) 是可以决定 selectivity(col1 = ‘hello’)

所以2者的 selectivity 选一即可

selectivity = selectivity(col1 = ‘hello’) | selectivity(col2=‘PG’)
= 0.8

rows = reltuples * selectivity
= 25 * 0.8‬
= 20

postgres@[local:/tmp]:1992=#46124 explain analyze select * from tt_ext where col1 = 'hello' and col2='PG';
                                           QUERY PLAN
---------------------------------------------------------------------------------------------------
Seq Scan on tt_ext  (cost=0.00..1.38 rows=20 width=14) (actual time=0.008..0.012 rows=20 loops=1)
  Filter: (((col1)::text = 'hello'::text) AND ((col2)::text = 'PG'::text))
  Rows Removed by Filter: 5
Planning Time: 0.160 ms
Execution Time: 0.026 ms
(5 rows)

接下来，我们看一下 Multivariate N-Distinct Counts ，简单地说就是收集多列的 number of distinct count 的统计信息：

我们还使用之前的表 tt_ext :

postgres@[local:/tmp]:1992=#46124 select col1,col2  from tt_ext group by col1,col2;
col1  |   col2
-------+----------
hello | PG
你好  | Postgres
(2 rows)

创建 Multivariate N-Distinct Counts 的统计信息如下：
n_distinct ： {“2, 3”: 2} 表示 {col1,col2} 的 distinct number of value 是 2

postgres@[local:/tmp]:1992=#46124 create statistics stats_ext_tt_col1_col2_nvd (ndistinct) on col1,col2 from tt_ext;
CREATE STATISTICS
postgres@[local:/tmp]:1992=#46124 analyze tt_ext;
ANALYZE

postgres@[local:/tmp]:1992=#46124 select * from pg_stats_ext where tablename = 'tt_ext';

-[ RECORD 2 ]----------+-----------------------------------------
schemaname             | public
tablename              | tt_ext
statistics_schemaname  | public
statistics_name        | stats_ext_tt_col1_col2_nvd
statistics_owner       | postgres
attnames               | {col1,col2}
exprs                  |
kinds                  | {d}
inherited              | f
n_distinct             | {"2, 3": 2}
dependencies           |
most_common_vals       |
most_common_val_nulls  |
most_common_freqs      |
most_common_base_freqs |

接下来，我们看一下 Multivariate MCV Lists ，简单地说就是收集多列的 most common values 的信息进行统计：

most_common_vals： {{hello,PG},{你好,Postgres}} – 最常见的2组值
most_common_val_nulls：{{f,f},{f,f}} – f 表示不存在空值
most_common_freqs： {0.8,0.2} 2个列组合起来的概率： {hello,PG} 出现是概率是 80%, {你好,Postgres} 出现的概率是 20%
most_common_base_freqs：col1 的基础概率是 64% = 0.8 * 0.8 = 0.64 ， col2的基础概率是 4% = 0.2*0.2 = 0.04

postgres@[local:/tmp]:1992=#46124 create statistics stats_ext_tt_col1_col2_mcv (mcv) on col1,col2 from tt_ext;
CREATE STATISTICS

postgres@[local:/tmp]:1992=#46124 analyze tt_ext;
ANALYZE

postgres@[local:/tmp]:1992=#95670 select * from pg_stats_ext where tablename = 'tt_ext';
-[ RECORD 1 ]----------+-----------------------------------------
schemaname             | public
tablename              | tt_ext
statistics_schemaname  | public
statistics_name        | stats_ext_tt_col1_col2_mcv
statistics_owner       | postgres
attnames               | {col1,col2}
exprs                  |
kinds                  | {m}
inherited              | f
n_distinct             |
dependencies           |
most_common_vals       | {{hello,PG},{你好,Postgres}}
most_common_val_nulls  | {{f,f},{f,f}}
most_common_freqs      | {0.8,0.2}
most_common_base_freqs | {0.6400000000000001,0.04000000000000001}

最后我们来总结一下 PG 表的统计信息：
1）基础的统计信息可以通过 pg_stats, pg_class 来查询
2）扩展的统计信息（多列的联合统计信息）可以通过 pg_statistic_ext 和 pg_statistic_ext_data 的表连接查询或者 pg_stats_ext 直接查询。支持如下几种：
Dependencies，Multivariate N-Distinct Count， Multivariate MCV Lists

Have a fun 🙂 !

「喜欢这篇文章，您的关注和赞赏是给作者最好的鼓励」

关注作者

PG 的 statistics 与 extended statistics

评论
