select list
from left_tab join_type right_tab
on join_condition;

#数学中
A = {1,2,3} B = {4,5}
AXB = {<1,4>,<1,5>,<2,4>,<2,5>,<3,4>,<3,5>}


#数据库中
表就是一个集合,每一行就是一个元素
A表:
a1 a2
1 1
1 2
1 3
B表:
b1 b2
2 2
2 3
2 4


a1 a2 b1 b2
1 1 2 2
1 1 2 3
1 1 2 4
1 2 2 2
1 2 2 3
1 2 2 4
1 3 2 2
1 3 2 3
1 3 2 4


left_tab: m rows x cols
right_tab: n rows y cols
left_tab*right_tab:
m*n rows x+y cols

select list
from left_tab cross join right_tab;

#连接条件
on A.a2 = B.b2 #tab_name.col_name


#交叉连接返回的结果
a1 a2 b1 b2
1 1 2 2
1 1 2 3
1 1 2 4


1 2 2 2
1 2 2 3
1 2 2 4


1 3 2 2
1 3 2 3
1 3 2 4


#内连接返回的结果
a1 a2 b1 b2
1 2 2 2
1 3 2 3

select list
from left_tab inner join right_tab
on join_condition;

#连接条件
on A.a2 = B.b2 #tab_name.col_name
#内连接返回的结果
a1 a2 b1 b2
1 2 2 2
1 3 2 3
#左外连接返回的结果
a1 a2 b1 b2
1 2 2 2
1 3 2 3
1 1 null null

#连接条件
on A.a2 = B.b2 #tab_name.col_name
#内连接返回的结果
a1 a2 b1 b2
1 2 2 2
1 3 2 3


#右外连接返回的结果
a1 a2 b1 b2
1 2 2 2
1 3 2 3
null null 2 4

select list
from left_tab left|right outer join right_tab
on join_condition;

#查询示例
SELECT * FROM a;
SELECT * FROM b;
SELECT * FROM a CROSS JOIN b;
SELECT * FROM a INNER JOIN b ON a.a2 = b.b2;
SELECT * FROM a LEFT OUTER JOIN b ON a.a2 = b.b2;
SELECT * FROM a RIGHT OUTER JOIN b ON a.a2 = b.b2;

select list
from left_tab inner join right_tab
on join_condition
where search_condition
order by sort_columns;

#哪些商品被用户购买过?
#思路
1.确定表
数据来源于哪些表中,或需要将哪些表结合起来查询
SELECT * FROM ecs_goods;
SELECT * FROM ecs_order_goods;


2.确定连接条件
找出左表与右表中有逻辑关系的列,将两个表中的列值进行比较来描述连接条件


3.确定连接类型
若仅返回满足连接条件的行则使用内连接;否则使用外连接


SELECT DISTINCT ecs_goods.goods_id, ecs_goods.goods_name, ecs_goods.shop_price
FROM ecs_goods INNER JOIN ecs_order_goods
ON ecs_goods.goods_id = ecs_order_goods.goods_id;

select list from tab_name alias_name ... #表名 别名
select list from tab_name as alias_name ... #表名 AS 别名

SELECT DISTINCT g.goods_id, g.goods_name, g.shop_price
#此处不能写成 ecs_goods.goods_id
FROM ecs_goods AS g INNER JOIN ecs_order_goods AS og
ON g.goods_id = og.goods_id;
#此处不能写成 ecs_goods.goods_id

#列出商品表中商品类型编号对应的类型名称
SELECT * FROM ecs_goods;
SELECT * FROM ecs_goods_types;
SELECT g.goods_id,g.goods_name,gt.cat_name,shop_price
FROM ecs_goods AS g INNER JOIN ecs_goods_type AS gt
ON g.goods_type = gt.cat_id;

#列出哪些用户购买了哪些商品,每一次购买该商品的花费是多少?
SELECT * FROM ecs_users;
SELECT * FROM ecs_order_info;
SELECT * FROM ecs_order_goods;

SELECT u.user_id,u.user_name,og.order_id,og.goods_name,
og.goods_price*og.goods_number amount
FROM (ecs_order_goods og INNER JOIN ecs_order_info oi
ON og.order_id = oi.order_id) INNER JOIN ecs_users u
ON oi.user_id = u.user_id
ORDER BY u.user_id,og.order_id;


假设有三个表:t1,t2,t3
(t1,t2),t3
t1,(t2,t3)


转换成连接语法的方法:
将","改为连接类型,在右表(连接类型后的表)后加上连接的条件


select list
from (t1 inner join t2 on jc1) inner join t3 on jc2;
select list
from t1 inner join (t1 inner join t3 on jc1) on jc2;


四个表: t1,t2,t3,t4
((t1,t2),t3),t4
(t1,t2),(t3,t4)
t1,((t2,t3),t4)
t1,(t2,(t3,t4))
select list
from ((t1 inner join t2 on jc1) inner join t3 on jc2) inner join t4 on jc3;

#练习
1)列出客户信息和订单日期，并按订单日期排序;#FROM_UNIXTIME()
2)列出被购买过的商品的商品名称,类型名称与交易价格;
3)显示各订单下每个商品与商品类型以及该商品的销售额，按照订单号排序;
4)列出被购买过的商品的商品名称,品牌名称与客户信息;
5)找出ecshop用户所有的订单信息;

select list
from left_tab left|right outer join right_tab
on join_condition
[where keyword is null] #过滤满足条件的数据,保留不满足条件的数据
order by sort_columns;

#哪些商品没有被客户购买过?
SELECT * FROM ecs_goods;
SELECT * FROM ecs_order_goods;
SELECT DISTINCT g.goods_id, g.goods_name, g.shop_price,og.goods_id
FROM ecs_goods g LEFT OUTER JOIN ecs_order_goods og
ON g.goods_id = og.goods_id
WHERE og.goods_id IS NULL;


#商品类型表中哪些商品类型没有出现在商品表中
SELECT gt.*
FROM ecs_goods AS g RIGHT OUTER JOIN ecs_goods_type AS gt
ON g.goods_type = gt.cat_id
WHERE g.goods_type IS NULL;

#找出没有购买过诺基亚E66商品的客户信息
SELECT * FROM ecs_users;
SELECT * FROM ecs_order_info;
SELECT * FROM ecs_order_goods;


SELECT u.user_id,u.user_name,u.email
FROM (ecs_order_goods og INNER JOIN ecs_order_info oi ON
og.order_id = oi.order_id AND og.goods_name = '诺基亚E66') RIGHT OUTER JOIN ecs_users
u
ON oi.user_id = u.user_id
WHERE oi.user_id IS NULL;

#练习
7)列出从来没有购买过手机的客户名单;
8)所有订单中哪种邮寄方式没有被采用过;
9)列出所有商品和各商品相关的所有订单的日期;
