mac 上学习k8s系列（18）如何在pod外面的宿主机访问etcd

golang算法架构leetcode技术php 2021-11-04

106

k8s的各个组件与apiServer交互操作各种资源对象，最终都会落入到etcd中。k8s为所有对外提供服务的Restful资源实现了一套通用的符合Restful要求的etcd操作接口，每个服务接口负责处理一类(Kind)资源对象。k8s主要把自己的数据注册在/registry/前缀下面（在ETCD-v3版本后没有了目录的概念，只能一切皆前缀了）。

弄清k8s数据存储的结构，对我们快速掌握k8s和学习k8s源码非常有帮助，那么我们如何k8s的查看etcd中的存储形式呢？

% kubectl get pods -n kube-system
NAME                                     READY   STATUS    RESTARTS   AGE
coredns-558bd4d5db-qc6px                 1/1     Running   13         69d
coredns-558bd4d5db-wzcgb                 1/1     Running   13         69d
etcd-docker-desktop                      1/1     Running   13         69d
kube-apiserver-docker-desktop            1/1     Running   13         69d
kube-controller-manager-docker-desktop   1/1     Running   13         69d
kube-proxy-k6shm                         1/1     Running   13         69d
kube-scheduler-docker-desktop            1/1     Running   15         69d
storage-provisioner                      1/1     Running   26         69d
vpnkit-controller                        1/1     Running   1944       69d

我们可以看到，有一个运行etcd的pod：etcd-docker-desktop ，进一步查看下它的详细信息：

% kubectl describe pod etcd-docker-desktop -n kube-system
Name:                 etcd-docker-desktop
Namespace:            kube-system
Priority:             2000001000
Priority Class Name:  system-node-critical
Node:                 docker-desktop/192.168.65.4
Start Time:           Fri, 29 Oct 2021 16:23:09 +0800
Labels:               component=etcd
                      tier=control-plane
Annotations:          kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.65.4:2379
                      kubernetes.io/config.hash: 5d9d97b8d8daed31d6fd5c6d386c29c5
                      kubernetes.io/config.mirror: 5d9d97b8d8daed31d6fd5c6d386c29c5
                      kubernetes.io/config.seen: 2021-08-23T03:18:46.987692420Z
                      kubernetes.io/config.source: file
Status:               Running
IP:                   192.168.65.4
IPs:
  IP:           192.168.65.4
Controlled By:  Node/docker-desktop
Containers:
  etcd:
    Container ID:  docker://9d2f3cf9d7bc9a933a216f6560eb22a4c62d59555bd449161ce8a58afce29d4e
    Image:         k8s.gcr.io/etcd:3.4.13-0
    Image ID:      docker://sha256:05b738aa1bc6355db8a2ee8639f3631b908286e43f584a3d2ee0c472de033c28
    Port:          <none>
    Host Port:     <none>
    Command:
      etcd
      --advertise-client-urls=https://192.168.65.4:2379
      --cert-file=/run/config/pki/etcd/server.crt
      --client-cert-auth=true
      --data-dir=/var/lib/etcd
      --initial-advertise-peer-urls=https://192.168.65.4:2380
      --initial-cluster=docker-desktop=https://192.168.65.4:2380
      --key-file=/run/config/pki/etcd/server.key
      --listen-client-urls=https://127.0.0.1:2379,https://192.168.65.4:2379
      --listen-metrics-urls=http://127.0.0.1:2381
      --listen-peer-urls=https://192.168.65.4:2380
      --name=docker-desktop
      --peer-cert-file=/run/config/pki/etcd/peer.crt
      --peer-client-cert-auth=true
      --peer-key-file=/run/config/pki/etcd/peer.key
      --peer-trusted-ca-file=/run/config/pki/etcd/ca.crt
      --snapshot-count=10000
      --trusted-ca-file=/run/config/pki/etcd/ca.crt
    State:          Running
      Started:      Fri, 29 Oct 2021 16:23:10 +0800
    Last State:     Terminated
      Reason:       Error
      Exit Code:    255
      Started:      Mon, 25 Oct 2021 09:55:39 +0800
      Finished:     Fri, 29 Oct 2021 16:21:13 +0800
    Ready:          True
    Restart Count:  13
    Requests:
      cpu:        100m
      memory:     100Mi
    Liveness:     http-get http://127.0.0.1:2381/health delay=10s timeout=15s period=10s #success=1 #failure=8
    Startup:      http-get http://127.0.0.1:2381/health delay=10s timeout=15s period=10s #success=1 #failure=24
    Environment:  <none>
    Mounts:
      run/config/pki/etcd from etcd-certs (rw)
      var/lib/etcd from etcd-data (rw)
Conditions:
  Type              Status
  Initialized       True
  Ready             True
  ContainersReady   True
  PodScheduled      True
Volumes:
  etcd-certs:
    Type:          HostPath (bare host directory volume)
    Path:          run/config/pki/etcd
    HostPathType:  DirectoryOrCreate
  etcd-data:
    Type:          HostPath (bare host directory volume)
    Path:          var/lib/etcd
    HostPathType:  DirectoryOrCreate
QoS Class:         Burstable
Node-Selectors:    <none>
Tolerations:       :NoExecute op=Exists
Events:            <none>

可以看到容器ID，我们进入容器内部，用etcd客户端先访问一下试试

% docker exec -it 05b738aa1bc6 sh

%ETCDCTL_API=3  etcdctl --endpoints=https://127.0.0.1:2379 --cacert=/run/config/pki/etcd/ca.crt --key=/run/config/pki/etcd/peer.key --cert=/run/config/pki/etcd/peer.crt get registry/namespaces --prefix -w=jso

可以看到返回的数据

{"header":{"cluster_id":4202879228857769416,"member_id":16554063148076462710,"revision":1911370,"raft_term":15},"kvs":[{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMvZGVmYXVsdA==","create_revision":208,"mod_revision":208,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEoYCCusBCgdkZWZhdWx0EgAaACIAKiQzYjg0ZWMzMy02MzQ2LTRiMjgtOTI2MS0yNzU3ZWYzNWM4NWIyADgAQggIo6eMiQYQAFomChtrdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUSB2RlZmF1bHR6AIoBewoOa3ViZS1hcGlzZXJ2ZXISBlVwZGF0ZRoCdjEiCAijp4yJBhAAMghGaWVsZHNWMTpJCkd7ImY6bWV0YWRhdGEiOnsiZjpsYWJlbHMiOnsiLiI6e30sImY6a3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lIjp7fX19fRIMCgprdWJlcm5ldGVzGggKBkFjdGl2ZRoAIgA="},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1ub2RlLWxlYXNl","create_revision":52,"mod_revision":52,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEpYCCvsBCg9rdWJlLW5vZGUtbGVhc2USABoAIgAqJDQ5OTMxMzYxLTkzMzYtNGIwZC04MDQxLWQ3YzRiZDc2ZmIyNjIAOABCCAihp4yJBhAAWi4KG2t1YmVybmV0ZXMuaW8vbWV0YWRhdGEubmFtZRIPa3ViZS1ub2RlLWxlYXNlegCKAXsKDmt1YmUtYXBpc2VydmVyEgZVcGRhdGUaAnYxIggIoaeMiQYQADIIRmllbGRzVjE6SQpHeyJmOm1ldGFkYXRhIjp7ImY6bGFiZWxzIjp7Ii4iOnt9LCJmOmt1YmVybmV0ZXMuaW8vbWV0YWRhdGEubmFtZSI6e319fX0SDAoKa3ViZXJuZXRlcxoICgZBY3RpdmUaACIA"},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1wdWJsaWM=","create_revision":45,"mod_revision":45,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEo4CCvMBCgtrdWJlLXB1YmxpYxIAGgAiACokNTIxM2Q4NzAtNWRmNC00MzhlLWI1ZDgtMzc4OTA0ZmI5ZGQ5MgA4AEIICKGnjIkGEABaKgoba3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lEgtrdWJlLXB1YmxpY3oAigF7Cg5rdWJlLWFwaXNlcnZlchIGVXBkYXRlGgJ2MSIICKGnjIkGEAAyCEZpZWxkc1YxOkkKR3siZjptZXRhZGF0YSI6eyJmOmxhYmVscyI6eyIuIjp7fSwiZjprdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUiOnt9fX19EgwKCmt1YmVybmV0ZXMaCAoGQWN0aXZlGgAiAA=="},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1zeXN0ZW0=","create_revision":13,"mod_revision":13,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEo4CCvMBCgtrdWJlLXN5c3RlbRIAGgAiACokZWJhZDc5YzMtNmI3OC00OGQwLWI1ZGItZmI4YzNiYjk1MWVhMgA4AEIICKGnjIkGEABaKgoba3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lEgtrdWJlLXN5c3RlbXoAigF7Cg5rdWJlLWFwaXNlcnZlchIGVXBkYXRlGgJ2MSIICKGnjIkGEAAyCEZpZWxkc1YxOkkKR3siZjptZXRhZGF0YSI6eyJmOmxhYmVscyI6eyIuIjp7fSwiZjprdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUiOnt9fX19EgwKCmt1YmVybmV0ZXMaCAoGQWN0aXZlGgAiAA=="}],"count":4}

我们可以看下全部的key

% ETCDCTL_API=3  etcdctl --endpoints=https://127.0.0.1:2379 --cacert=/run/config/pki/etcd/ca.crt --key=/run/config/pki/etcd/peer.key --cert=/run/config/pki/etcd/peer.crt get "" --prefix --keys-only |grep -Ev "^$"
/registry/apiregistration.k8s.io/apiservices/v1.


/registry/apiregistration.k8s.io/apiservices/v1.admissionregistration.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.apiextensions.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.apps


/registry/apiregistration.k8s.io/apiservices/v1.authentication.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.authorization.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.autoscaling


/registry/apiregistration.k8s.io/apiservices/v1.batch


/registry/apiregistration.k8s.io/apiservices/v1.certificates.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.coordination.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.discovery.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.events.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.networking.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.node.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.policy


/registry/apiregistration.k8s.io/apiservices/v1.rbac.authorization.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.scheduling.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1.storage.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.admissionregistration.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.apiextensions.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.authentication.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.authorization.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.batch


/registry/apiregistration.k8s.io/apiservices/v1beta1.certificates.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.coordination.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.discovery.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.events.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.extensions


/registry/apiregistration.k8s.io/apiservices/v1beta1.flowcontrol.apiserver.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.networking.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.node.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.policy


/registry/apiregistration.k8s.io/apiservices/v1beta1.rbac.authorization.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.scheduling.k8s.io


/registry/apiregistration.k8s.io/apiservices/v1beta1.storage.k8s.io


/registry/apiregistration.k8s.io/apiservices/v2beta1.autoscaling


/registry/apiregistration.k8s.io/apiservices/v2beta2.autoscaling


/registry/clusterrolebindings/cluster-admin


/registry/clusterrolebindings/docker-for-desktop-binding


/registry/clusterrolebindings/ingress-nginx


/registry/clusterrolebindings/ingress-nginx-admission


/registry/clusterrolebindings/kubeadm:get-nodes


/registry/clusterrolebindings/kubeadm:kubelet-bootstrap


/registry/clusterrolebindings/kubeadm:node-autoapprove-bootstrap


/registry/clusterrolebindings/kubeadm:node-autoapprove-certificate-rotation


/registry/clusterrolebindings/kubeadm:node-proxier


/registry/clusterrolebindings/storage-provisioner


/registry/clusterrolebindings/system:basic-user


/registry/clusterrolebindings/system:controller:attachdetach-controller


/registry/clusterrolebindings/system:controller:certificate-controller


/registry/clusterrolebindings/system:controller:clusterrole-aggregation-controller


/registry/clusterrolebindings/system:controller:cronjob-controller


/registry/clusterrolebindings/system:controller:daemon-set-controller


/registry/clusterrolebindings/system:controller:deployment-controller


/registry/clusterrolebindings/system:controller:disruption-controller


/registry/clusterrolebindings/system:controller:endpoint-controller


/registry/clusterrolebindings/system:controller:endpointslice-controller


/registry/clusterrolebindings/system:controller:endpointslicemirroring-controller


/registry/clusterrolebindings/system:controller:ephemeral-volume-controller


/registry/clusterrolebindings/system:controller:expand-controller


/registry/clusterrolebindings/system:controller:generic-garbage-collector


/registry/clusterrolebindings/system:controller:horizontal-pod-autoscaler


/registry/clusterrolebindings/system:controller:job-controller


/registry/clusterrolebindings/system:controller:namespace-controller


/registry/clusterrolebindings/system:controller:node-controller


/registry/clusterrolebindings/system:controller:persistent-volume-binder


/registry/clusterrolebindings/system:controller:pod-garbage-collector


/registry/clusterrolebindings/system:controller:pv-protection-controller


/registry/clusterrolebindings/system:controller:pvc-protection-controller


/registry/clusterrolebindings/system:controller:replicaset-controller


/registry/clusterrolebindings/system:controller:replication-controller


/registry/clusterrolebindings/system:controller:resourcequota-controller


/registry/clusterrolebindings/system:controller:root-ca-cert-publisher


/registry/clusterrolebindings/system:controller:route-controller


/registry/clusterrolebindings/system:controller:service-account-controller


/registry/clusterrolebindings/system:controller:service-controller


/registry/clusterrolebindings/system:controller:statefulset-controller


/registry/clusterrolebindings/system:controller:ttl-after-finished-controller


/registry/clusterrolebindings/system:controller:ttl-controller


/registry/clusterrolebindings/system:coredns


/registry/clusterrolebindings/system:discovery


/registry/clusterrolebindings/system:kube-controller-manager


/registry/clusterrolebindings/system:kube-dns


/registry/clusterrolebindings/system:kube-scheduler


/registry/clusterrolebindings/system:monitoring


/registry/clusterrolebindings/system:node


/registry/clusterrolebindings/system:node-proxier


/registry/clusterrolebindings/system:public-info-viewer


/registry/clusterrolebindings/system:service-account-issuer-discovery


/registry/clusterrolebindings/system:volume-scheduler


/registry/clusterrolebindings/vpnkit-controller


/registry/clusterroles/admin


/registry/clusterroles/cluster-admin


/registry/clusterroles/edit


/registry/clusterroles/ingress-nginx


/registry/clusterroles/ingress-nginx-admission


/registry/clusterroles/kubeadm:get-nodes


/registry/clusterroles/secret-reader


/registry/clusterroles/system:aggregate-to-admin


/registry/clusterroles/system:aggregate-to-edit


/registry/clusterroles/system:aggregate-to-view


/registry/clusterroles/system:auth-delegator


/registry/clusterroles/system:basic-user


/registry/clusterroles/system:certificates.k8s.io:certificatesigningrequests:nodeclient


/registry/clusterroles/system:certificates.k8s.io:certificatesigningrequests:selfnodeclient


/registry/clusterroles/system:certificates.k8s.io:kube-apiserver-client-approver


/registry/clusterroles/system:certificates.k8s.io:kube-apiserver-client-kubelet-approver


/registry/clusterroles/system:certificates.k8s.io:kubelet-serving-approver


/registry/clusterroles/system:certificates.k8s.io:legacy-unknown-approver


/registry/clusterroles/system:controller:attachdetach-controller


/registry/clusterroles/system:controller:certificate-controller


/registry/clusterroles/system:controller:clusterrole-aggregation-controller


/registry/clusterroles/system:controller:cronjob-controller


/registry/clusterroles/system:controller:daemon-set-controller


/registry/clusterroles/system:controller:deployment-controller


/registry/clusterroles/system:controller:disruption-controller


/registry/clusterroles/system:controller:endpoint-controller


/registry/clusterroles/system:controller:endpointslice-controller


/registry/clusterroles/system:controller:endpointslicemirroring-controller


/registry/clusterroles/system:controller:ephemeral-volume-controller


/registry/clusterroles/system:controller:expand-controller


/registry/clusterroles/system:controller:generic-garbage-collector


/registry/clusterroles/system:controller:horizontal-pod-autoscaler


/registry/clusterroles/system:controller:job-controller


/registry/clusterroles/system:controller:namespace-controller


/registry/clusterroles/system:controller:node-controller


/registry/clusterroles/system:controller:persistent-volume-binder


/registry/clusterroles/system:controller:pod-garbage-collector


/registry/clusterroles/system:controller:pv-protection-controller


/registry/clusterroles/system:controller:pvc-protection-controller


/registry/clusterroles/system:controller:replicaset-controller


/registry/clusterroles/system:controller:replication-controller


/registry/clusterroles/system:controller:resourcequota-controller


/registry/clusterroles/system:controller:root-ca-cert-publisher


/registry/clusterroles/system:controller:route-controller


/registry/clusterroles/system:controller:service-account-controller


/registry/clusterroles/system:controller:service-controller


/registry/clusterroles/system:controller:statefulset-controller


/registry/clusterroles/system:controller:ttl-after-finished-controller


/registry/clusterroles/system:controller:ttl-controller


/registry/clusterroles/system:coredns


/registry/clusterroles/system:discovery


/registry/clusterroles/system:heapster


/registry/clusterroles/system:kube-aggregator


/registry/clusterroles/system:kube-controller-manager


/registry/clusterroles/system:kube-dns


/registry/clusterroles/system:kube-scheduler


/registry/clusterroles/system:kubelet-api-admin


/registry/clusterroles/system:monitoring


/registry/clusterroles/system:node


/registry/clusterroles/system:node-bootstrapper


/registry/clusterroles/system:node-problem-detector


/registry/clusterroles/system:node-proxier


/registry/clusterroles/system:persistent-volume-provisioner


/registry/clusterroles/system:public-info-viewer


/registry/clusterroles/system:service-account-issuer-discovery


/registry/clusterroles/system:volume-scheduler


/registry/clusterroles/view


/registry/clusterroles/vpnkit-controller


/registry/configmaps/default/ingress-controller-leader-nginx


/registry/configmaps/default/ingress-nginx-controller


/registry/configmaps/default/kube-root-ca.crt


/registry/configmaps/default/redis-config


/registry/configmaps/kube-node-lease/kube-root-ca.crt


/registry/configmaps/kube-public/cluster-info


/registry/configmaps/kube-public/kube-root-ca.crt


/registry/configmaps/kube-system/coredns


/registry/configmaps/kube-system/extension-apiserver-authentication


/registry/configmaps/kube-system/kube-proxy


/registry/configmaps/kube-system/kube-root-ca.crt


/registry/configmaps/kube-system/kubeadm-config


/registry/configmaps/kube-system/kubelet-config-1.21


/registry/controllerrevisions/kube-system/kube-proxy-7cdcb64568


/registry/csinodes/docker-desktop


/registry/daemonsets/kube-system/kube-proxy


/registry/deployments/default/ingress-nginx-controller


/registry/deployments/default/minio-deployment


/registry/deployments/default/redis


/registry/deployments/kube-system/coredns


/registry/endpointslices/default/apple-service-5f9zk


/registry/endpointslices/default/ingress-nginx-controller-admission-shdx6


/registry/endpointslices/default/ingress-nginx-controller-jjm9l


/registry/endpointslices/default/kubernetes


/registry/endpointslices/default/minio-service-fd4dl


/registry/endpointslices/default/redis-gztm7


/registry/endpointslices/kube-system/kube-dns-wqqx2


/registry/events/kube-system/vpnkit-controller.16b272c39baa616d


/registry/events/kube-system/vpnkit-controller.16b272c39cb40bae


/registry/events/kube-system/vpnkit-controller.16b272c3a1d78e07


/registry/events/kube-system/vpnkit-controller.16b2742b54d7628e


/registry/flowschemas/catch-all


/registry/flowschemas/exempt


/registry/flowschemas/global-default


/registry/flowschemas/kube-controller-manager


/registry/flowschemas/kube-scheduler


/registry/flowschemas/kube-system-service-accounts


/registry/flowschemas/probes


/registry/flowschemas/service-accounts


/registry/flowschemas/system-leader-election


/registry/flowschemas/system-nodes


/registry/flowschemas/workload-leader-election


/registry/ingress/default/ingress-with-auth


/registry/jobs/default/ingress-nginx-admission-create


/registry/jobs/default/ingress-nginx-admission-patch


/registry/leases/kube-node-lease/docker-desktop


/registry/leases/kube-system/kube-scheduler


/registry/masterleases/192.168.65.4


/registry/minions/docker-desktop


/registry/namespaces/default


/registry/namespaces/kube-node-lease


/registry/namespaces/kube-public


/registry/namespaces/kube-system


/registry/persistentvolumeclaims/default/minio-pv-claim


/registry/persistentvolumeclaims/default/redis


/registry/persistentvolumes/minio


/registry/persistentvolumes/redis


/registry/pods/default/apple-app


/registry/pods/default/ingress-nginx-admission-create-vjn92


/registry/pods/default/ingress-nginx-admission-patch-wlq6p


/registry/pods/default/ingress-nginx-controller-57648496fc-84wl8


/registry/pods/default/minio-deployment-55bf5bff5d-cvq7v


/registry/pods/default/redis-f9f74787-tq6tw


/registry/pods/kube-system/coredns-558bd4d5db-qc6px


/registry/pods/kube-system/coredns-558bd4d5db-wzcgb


/registry/pods/kube-system/etcd-docker-desktop


/registry/pods/kube-system/kube-apiserver-docker-desktop


/registry/pods/kube-system/kube-controller-manager-docker-desktop


/registry/pods/kube-system/kube-proxy-k6shm


/registry/pods/kube-system/kube-scheduler-docker-desktop


/registry/pods/kube-system/storage-provisioner


/registry/pods/kube-system/vpnkit-controller


/registry/priorityclasses/system-cluster-critical


/registry/priorityclasses/system-node-critical


/registry/prioritylevelconfigurations/catch-all


/registry/prioritylevelconfigurations/exempt


/registry/prioritylevelconfigurations/global-default


/registry/prioritylevelconfigurations/leader-election


/registry/prioritylevelconfigurations/system


/registry/prioritylevelconfigurations/workload-high


/registry/prioritylevelconfigurations/workload-low


/registry/ranges/serviceips


/registry/ranges/servicenodeports


/registry/replicasets/default/ingress-nginx-controller-57648496fc


/registry/replicasets/default/minio-deployment-55bf5bff5d


/registry/replicasets/default/minio-deployment-6cfc69548


/registry/replicasets/default/minio-deployment-857cc8bbdf


/registry/replicasets/default/redis-f9f74787


/registry/replicasets/kube-system/coredns-558bd4d5db


/registry/rolebindings/default/ingress-nginx


/registry/rolebindings/default/ingress-nginx-admission


/registry/rolebindings/default/read-pods


/registry/rolebindings/kube-public/kubeadm:bootstrap-signer-clusterinfo


/registry/rolebindings/kube-public/system:controller:bootstrap-signer


/registry/rolebindings/kube-system/kube-proxy


/registry/rolebindings/kube-system/kubeadm:kubelet-config-1.21


/registry/rolebindings/kube-system/kubeadm:nodes-kubeadm-config


/registry/rolebindings/kube-system/system::extension-apiserver-authentication-reader


/registry/rolebindings/kube-system/system::leader-locking-kube-controller-manager


/registry/rolebindings/kube-system/system::leader-locking-kube-scheduler


/registry/rolebindings/kube-system/system:controller:bootstrap-signer


/registry/rolebindings/kube-system/system:controller:cloud-provider


/registry/rolebindings/kube-system/system:controller:token-cleaner


/registry/roles/default/ingress-nginx


/registry/roles/default/ingress-nginx-admission


/registry/roles/default/pod-reader


/registry/roles/kube-public/kubeadm:bootstrap-signer-clusterinfo


/registry/roles/kube-public/system:controller:bootstrap-signer


/registry/roles/kube-system/extension-apiserver-authentication-reader


/registry/roles/kube-system/kube-proxy


/registry/roles/kube-system/kubeadm:kubelet-config-1.21


/registry/roles/kube-system/kubeadm:nodes-kubeadm-config


/registry/roles/kube-system/system::leader-locking-kube-controller-manager


/registry/roles/kube-system/system::leader-locking-kube-scheduler


/registry/roles/kube-system/system:controller:bootstrap-signer


/registry/roles/kube-system/system:controller:cloud-provider


/registry/roles/kube-system/system:controller:token-cleaner


/registry/secrets/default/basic-auth


/registry/secrets/default/default-token-cg2vq


/registry/secrets/default/ingress-nginx-admission


/registry/secrets/default/ingress-nginx-admission-token-xblnc


/registry/secrets/default/ingress-nginx-token-7clh8


/registry/secrets/default/tls-secret


/registry/secrets/kube-node-lease/default-token-q97sv


/registry/secrets/kube-public/default-token-jq4g9


/registry/secrets/kube-system/attachdetach-controller-token-6lg9w


/registry/secrets/kube-system/bootstrap-signer-token-nnrn5


/registry/secrets/kube-system/certificate-controller-token-mwsrf


/registry/secrets/kube-system/clusterrole-aggregation-controller-token-27mp8


/registry/secrets/kube-system/coredns-token-5r4fz


/registry/secrets/kube-system/cronjob-controller-token-bvgp6


/registry/secrets/kube-system/daemon-set-controller-token-xx2z8


/registry/secrets/kube-system/default-token-pbdlw


/registry/secrets/kube-system/deployment-controller-token-8j72x


/registry/secrets/kube-system/disruption-controller-token-w9mmh


/registry/secrets/kube-system/endpoint-controller-token-t8dwq


/registry/secrets/kube-system/endpointslice-controller-token-dnbfm


/registry/secrets/kube-system/endpointslicemirroring-controller-token-plknt


/registry/secrets/kube-system/ephemeral-volume-controller-token-xm679


/registry/secrets/kube-system/expand-controller-token-9wgwf


/registry/secrets/kube-system/generic-garbage-collector-token-smjfw


/registry/secrets/kube-system/horizontal-pod-autoscaler-token-6jsj2


/registry/secrets/kube-system/job-controller-token-cft9x


/registry/secrets/kube-system/kube-proxy-token-c9bth


/registry/secrets/kube-system/namespace-controller-token-6rtph


/registry/secrets/kube-system/node-controller-token-ztkld


/registry/secrets/kube-system/persistent-volume-binder-token-zntw5


/registry/secrets/kube-system/pod-garbage-collector-token-qt297


/registry/secrets/kube-system/pv-protection-controller-token-fq7jx


/registry/secrets/kube-system/pvc-protection-controller-token-4krd7


/registry/secrets/kube-system/replicaset-controller-token-jjtjx


/registry/secrets/kube-system/replication-controller-token-kxdqb


/registry/secrets/kube-system/resourcequota-controller-token-n9zqv


/registry/secrets/kube-system/root-ca-cert-publisher-token-wldpn


/registry/secrets/kube-system/service-account-controller-token-wzgng


/registry/secrets/kube-system/service-controller-token-djmtc


/registry/secrets/kube-system/statefulset-controller-token-96msw


/registry/secrets/kube-system/storage-provisioner-token-n575g


/registry/secrets/kube-system/token-cleaner-token-vqxd2


/registry/secrets/kube-system/ttl-after-finished-controller-token-lmxng


/registry/secrets/kube-system/ttl-controller-token-xg5kg


/registry/secrets/kube-system/vpnkit-controller-token-8ztzx


/registry/serviceaccounts/default/default


/registry/serviceaccounts/default/ingress-nginx


/registry/serviceaccounts/default/ingress-nginx-admission


/registry/serviceaccounts/kube-node-lease/default


/registry/serviceaccounts/kube-public/default


/registry/serviceaccounts/kube-system/attachdetach-controller


/registry/serviceaccounts/kube-system/bootstrap-signer


/registry/serviceaccounts/kube-system/certificate-controller


/registry/serviceaccounts/kube-system/clusterrole-aggregation-controller


/registry/serviceaccounts/kube-system/coredns


/registry/serviceaccounts/kube-system/cronjob-controller


/registry/serviceaccounts/kube-system/daemon-set-controller


/registry/serviceaccounts/kube-system/default


/registry/serviceaccounts/kube-system/deployment-controller


/registry/serviceaccounts/kube-system/disruption-controller


/registry/serviceaccounts/kube-system/endpoint-controller


/registry/serviceaccounts/kube-system/endpointslice-controller


/registry/serviceaccounts/kube-system/endpointslicemirroring-controller


/registry/serviceaccounts/kube-system/ephemeral-volume-controller


/registry/serviceaccounts/kube-system/expand-controller


/registry/serviceaccounts/kube-system/generic-garbage-collector


/registry/serviceaccounts/kube-system/horizontal-pod-autoscaler


/registry/serviceaccounts/kube-system/job-controller


/registry/serviceaccounts/kube-system/kube-proxy


/registry/serviceaccounts/kube-system/namespace-controller


/registry/serviceaccounts/kube-system/node-controller


/registry/serviceaccounts/kube-system/persistent-volume-binder


/registry/serviceaccounts/kube-system/pod-garbage-collector


/registry/serviceaccounts/kube-system/pv-protection-controller


/registry/serviceaccounts/kube-system/pvc-protection-controller


/registry/serviceaccounts/kube-system/replicaset-controller


/registry/serviceaccounts/kube-system/replication-controller


/registry/serviceaccounts/kube-system/resourcequota-controller


/registry/serviceaccounts/kube-system/root-ca-cert-publisher


/registry/serviceaccounts/kube-system/service-account-controller


/registry/serviceaccounts/kube-system/service-controller


/registry/serviceaccounts/kube-system/statefulset-controller


/registry/serviceaccounts/kube-system/storage-provisioner


/registry/serviceaccounts/kube-system/token-cleaner


/registry/serviceaccounts/kube-system/ttl-after-finished-controller


/registry/serviceaccounts/kube-system/ttl-controller


/registry/serviceaccounts/kube-system/vpnkit-controller


/registry/services/endpoints/default/apple-service


/registry/services/endpoints/default/ingress-nginx-controller


/registry/services/endpoints/default/ingress-nginx-controller-admission


/registry/services/endpoints/default/kubernetes


/registry/services/endpoints/default/minio-service


/registry/services/endpoints/default/redis


/registry/services/endpoints/kube-system/docker.io-hostpath


/registry/services/endpoints/kube-system/kube-dns


/registry/services/specs/default/apple-service


/registry/services/specs/default/ingress-nginx-controller


/registry/services/specs/default/ingress-nginx-controller-admission


/registry/services/specs/default/kubernetes


/registry/services/specs/default/minio-service


/registry/services/specs/default/redis


/registry/services/specs/kube-system/kube-dns


/registry/storageclasses/hostpath


/registry/validatingwebhookconfigurations/ingress-nginx-admission


compact_rev_key

通过观察k8s中deployment、namespace、pod等在ETCD中的表示，可以知道这部分资源的key的格式为/registry/#{k8s对象}/#{命名空间}/#{具体实例名}。存在一个与众不同的key值compact_rev_key，搜索可以知道这是apiserver/compact.go中用来记录无效数据版本使用的；运行etcdctl get compact_rev_key可以发现，输出的是一个整形数值。在查看ETCD时，k8s中除了必要的网络插件canal，未部署其他的应用，此时ETCD中只有240条数据。

我们还可以看下某个key里面存储的内容

% ETCDCTL_API=3  etcdctl --endpoints=https://127.0.0.1:2379 --cacert=/run/config/pki/etcd/ca.crt --key=/run/config/pki/etcd/peer.key --cert=/run/config/pki/etcd/peer.crt get registry/ranges/serviceips


/registry/ranges/serviceips
k8s


v1RangeAllocation�


"*28Bz
      10.96.0.0/12�"

可以很明显看出来，ETCD中保存的并不是输出友好的数据（比如json或xml等就是输出友好型数据）。当然，如果进一步研究可以知道，ETCD保存的是Protocol Buffers序列化后的值。如果像看到json格式的数据可以在后面加上命令

 -w=json

我们需要进入docker内部去查看etcd存储的数据，显然是很不方便的，我们有没有办法在宿主机上看etcd的数据呢？答案是有，首先我们硬访问下，试试：

% ETCDCTL_API=3 Users/xiazemin/source/etcd/bin/etcdctl --endpoints=https://127.0.0.1:2379 \
--cacert=/Users/xiazemin/Library/Group\ Containers/group.com.docker/pki/etcd/ca.crt \
--key=/Users/xiazemin/Library/Group\ Containers/group.com.docker/pki/etcd/peer.key \
--cert=/Users/xiazemin/Library/Group\ Containers/group.com.docker/pki/etcd/peer.crt \
get registry/namespaces --prefix -w=json




{"level":"warn","ts":"2021-11-01T11:59:31.114+0800","logger":"etcd-client","caller":"v3/retry_interceptor.go:62","msg":"retrying of unary invoker failed","target":"etcd-endpoints://0x1400039c540/#initially=[https://127.0.0.1:2379]","attempt":0,"error":"rpc error: code = DeadlineExceeded desc = latest balancer error: last connection error: connection error: desc = \"transport: Error while dialing dial tcp 127.0.0.1:2379: connect: connection refused\""}
Error: context deadline exceeded

连接超时，显然网络连不上。

kubectl get svc -n kube-system

我们发现没有etcd相关的svc，在k8s中，如果我们想访问某些服务，我们需要通过svc（服务发现），把pod的端口暴露出来，如果我们通过svc把etcd的pod端口暴露出来，我们是不是可以在宿主机上访问了？

创建一个service，通过NodePort的方式做端口转发：

apiVersion: v1
kind: Service
metadata:
  creationTimestamp: "2021-11-04T05:30:37Z"
  labels:
    component: etcd
    tier: control-plane
  name: etcd-svc-docker-desktop-xzm
  namespace: kube-system
  resourceVersion: "2055694"
  uid: 9cc9abbf-2edc-44ba-b359-157a8b643c62
spec:
  clusterIP: 10.111.136.178
  clusterIPs:
  - 10.111.136.178
  externalTrafficPolicy: Cluster
  ipFamilies:
  - IPv4
  ipFamilyPolicy: SingleStack
  ports:
  - nodePort: 32379
    port: 2379
    protocol: TCP
    targetPort: 2379
  selector:
    component: etcd
    tier: control-plane
  sessionAffinity: None
  type: NodePort
status:
  loadBalancer:
    ingress:
    - hostname: localhost

% kubectl apply -f etcd/etcd-svc-docker-desktop-xzm.svc.yaml
service/etcd-svc-docker-desktop-xzm created

查看下我们的service

 % kubectl get svc etcd-svc-docker-desktop-xzm -n kube-system
NAME                          TYPE       CLUSTER-IP       EXTERNAL-IP   PORT(S)          AGE
etcd-svc-docker-desktop-xzm   NodePort   10.105.187.254   <none>        2379:32379/TCP   35s

发现端口已经转发了，接着我们尝试下是否连接成功，发现仍然超时，难道我们找的证书位置不对？把pod里面的证书copy出来对比下：

% docker cp 9d2f3cf9d7bc9a933a216f6560eb22a4c62d59555bd449161ce8a58afce29d4e:/run/config/pki/etcd/peer.key etcd

 vimdiff ./etcd/peer.key Users/xiazemin/Library/Group\ Containers/group.com.docker/pki/etcd/peer.key

发现完全没有diff，说明问题不在这里。是不是端口冲突了？

 % lsof |grep 32379
com.docke 71118 xiazemin   69u     IPv6  0xb7573feed65f41d         0t0                 TCP localhost:32379->localhost:62688 (CLOSE_WAIT)
com.docke 71118 xiazemin   89u     IPv6  0xb7573fef567a0bd         0t0                 TCP *:32379 (LISTEN)

果然如此，我们该下转发的端口到32389，再试下？





% lsof |grep 32389






% ETCDCTL_API=3 etcdctl --cacert=./etcd/ca.crt \
--cert=./etcd/peer.crt \
--key=./etcd/peer.key \
--endpoints=https://127.0.0.1:32389 \
get /registry/namespaces --prefix -w=json


{"header":{"cluster_id":4202879228857769416,"member_id":16554063148076462710,"revision":2056701,"raft_term":18},"kvs":[{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMvZGVmYXVsdA==","create_revision":208,"mod_revision":208,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEoYCCusBCgdkZWZhdWx0EgAaACIAKiQzYjg0ZWMzMy02MzQ2LTRiMjgtOTI2MS0yNzU3ZWYzNWM4NWIyADgAQggIo6eMiQYQAFomChtrdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUSB2RlZmF1bHR6AIoBewoOa3ViZS1hcGlzZXJ2ZXISBlVwZGF0ZRoCdjEiCAijp4yJBhAAMghGaWVsZHNWMTpJCkd7ImY6bWV0YWRhdGEiOnsiZjpsYWJlbHMiOnsiLiI6e30sImY6a3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lIjp7fX19fRIMCgprdWJlcm5ldGVzGggKBkFjdGl2ZRoAIgA="},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1ub2RlLWxlYXNl","create_revision":52,"mod_revision":52,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEpYCCvsBCg9rdWJlLW5vZGUtbGVhc2USABoAIgAqJDQ5OTMxMzYxLTkzMzYtNGIwZC04MDQxLWQ3YzRiZDc2ZmIyNjIAOABCCAihp4yJBhAAWi4KG2t1YmVybmV0ZXMuaW8vbWV0YWRhdGEubmFtZRIPa3ViZS1ub2RlLWxlYXNlegCKAXsKDmt1YmUtYXBpc2VydmVyEgZVcGRhdGUaAnYxIggIoaeMiQYQADIIRmllbGRzVjE6SQpHeyJmOm1ldGFkYXRhIjp7ImY6bGFiZWxzIjp7Ii4iOnt9LCJmOmt1YmVybmV0ZXMuaW8vbWV0YWRhdGEubmFtZSI6e319fX0SDAoKa3ViZXJuZXRlcxoICgZBY3RpdmUaACIA"},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1wdWJsaWM=","create_revision":45,"mod_revision":45,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEo4CCvMBCgtrdWJlLXB1YmxpYxIAGgAiACokNTIxM2Q4NzAtNWRmNC00MzhlLWI1ZDgtMzc4OTA0ZmI5ZGQ5MgA4AEIICKGnjIkGEABaKgoba3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lEgtrdWJlLXB1YmxpY3oAigF7Cg5rdWJlLWFwaXNlcnZlchIGVXBkYXRlGgJ2MSIICKGnjIkGEAAyCEZpZWxkc1YxOkkKR3siZjptZXRhZGF0YSI6eyJmOmxhYmVscyI6eyIuIjp7fSwiZjprdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUiOnt9fX19EgwKCmt1YmVybmV0ZXMaCAoGQWN0aXZlGgAiAA=="},{"key":"L3JlZ2lzdHJ5L25hbWVzcGFjZXMva3ViZS1zeXN0ZW0=","create_revision":13,"mod_revision":13,"version":1,"value":"azhzAAoPCgJ2MRIJTmFtZXNwYWNlEo4CCvMBCgtrdWJlLXN5c3RlbRIAGgAiACokZWJhZDc5YzMtNmI3OC00OGQwLWI1ZGItZmI4YzNiYjk1MWVhMgA4AEIICKGnjIkGEABaKgoba3ViZXJuZXRlcy5pby9tZXRhZGF0YS5uYW1lEgtrdWJlLXN5c3RlbXoAigF7Cg5rdWJlLWFwaXNlcnZlchIGVXBkYXRlGgJ2MSIICKGnjIkGEAAyCEZpZWxkc1YxOkkKR3siZjptZXRhZGF0YSI6eyJmOmxhYmVscyI6eyIuIjp7fSwiZjprdWJlcm5ldGVzLmlvL21ldGFkYXRhLm5hbWUiOnt9fX19EgwKCmt1YmVybmV0ZXMaCAoGQWN0aXZlGgAiAA=="}],"count":4}

果然成功了.从此我们就可以在pod外面查看etcd里面的存储内容了。

总结：在掌握了k8s svc的基础原理后，我们稍微联想发散一下，就可以解决很多我们看上去很茫然，很陌生的问题。很多看上去很复杂的事务的外衣下都有一个简单的内核。

文章转载自golang算法架构leetcode技术php，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

mac 上学习k8s系列（18）如何在pod外面的宿主机访问etcd

评论
