超详细Kubernetes集群搭建Zabbix监控平台

Zabbix开源社区 2022-10-08

1845

目录

一、检查本地k8s环境

1.检查系统pod运行状态

2.检查node节点状态

二、配置nfs共享存储

1.安装nfs

2.创建共享目录

3.配置共享目录

4.启动相关服务

5.使配置生效

6.查看nfs

7.其他节点检查nfs共享

三、安装zabbix-mysql

1.编写zabbix-mysql的yaml文件

2.创建命名空间

3.创建zabbix数据库

4.检查pod状态

四、检查zabbix数据库的service域名

1.运行测试pod

2.进入busybox的pod

3.查看域名解析

五、安装zabbix-server

1.编写zabbix_server.yaml文件

2.给node02节点打上标签

3.安装zabbix-server

4.检查pod状态

六、部署zabbix-web

1.编写zabbix_web.yaml文件

2.安装zabbix-web

3.查看pod状态

七、部署zabbix-agent

1.编辑zabbix_agent.yaml

2.安装zabbix-agent

3.查看pod状态

八、访问zabbix的web

1.查看svc

2.登录web

3.登录zabbix

4.查询zabbix-server的监控项图表

一、检查本地k8s环境

1.检查系统pod运行状态

[root@k8s-master ~]# kubectl get pods -A
NAMESPACE     NAME                                       READY   STATUS    RESTARTS        AGE
kube-system   calico-kube-controllers-7bc6547ffb-2nf66   1/1     Running   1 (9m28s ago)   2d16h
kube-system   calico-node-8c4pn                          1/1     Running   1 (9m16s ago)   2d16h
kube-system   calico-node-f28qq                          1/1     Running   1 (9m10s ago)   2d16h
kube-system   calico-node-wmc2j                          1/1     Running   1 (9m29s ago)   2d16h
kube-system   coredns-6d8c4cb4d-6gm4x                    1/1     Running   1 (9m28s ago)   2d16h
kube-system   coredns-6d8c4cb4d-7vxlz                    1/1     Running   1 (9m29s ago)   2d16h
kube-system   etcd-k8s-master                            1/1     Running   1 (9m30s ago)   2d16h
kube-system   kube-apiserver-k8s-master                  1/1     Running   1 (9m29s ago)   2d16h
kube-system   kube-controller-manager-k8s-master         1/1     Running   1 (9m30s ago)   2d16h
kube-system   kube-proxy-8dfw8                           1/1     Running   1 (9m29s ago)   2d16h
kube-system   kube-proxy-ghzrv                           1/1     Running   1 (9m9s ago)    2d16h
kube-system   kube-proxy-j867z                           1/1     Running   1 (9m15s ago)   2d16h
kube-system   kube-scheduler-k8s-master                  1/1     Running   1 (9m28s ago)   2d16h

2.检查node节点状态

[root@k8s-master ~]# kubectl get nodes -owide
NAME         STATUS   ROLES                  AGE     VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                KERNEL-VERSION          CONTAINER-RUNTIME
k8s-master   Ready    control-plane,master   2d16h   v1.23.1   192.168.3.201   <none>        CentOS Linux 7 (Core)   3.10.0-957.el7.x86_64   containerd://1.6.6
k8s-node01   Ready    <none>                 2d16h   v1.23.1   192.168.3.202   <none>        CentOS Linux 7 (Core)   3.10.0-957.el7.x86_64   containerd://1.6.6
k8s-node02   Ready    <none>                 2d16h   v1.23.1   192.168.3.203   <none>        CentOS Linux 7 (Core)   3.10.0-957.el7.x86_64   containerd://1.6.6

二、配置nfs共享存储

1.安装nfs

yum install -y nfs-utils

2.创建共享目录

mkdir -p nfs/data

3.配置共享目录

echo "/nfs/data/ *(insecure,rw,sync,no_root_squash)" > etc/exports

4.启动相关服务

systemctl enable rpcbind
systemctl enable nfs-server
systemctl start rpcbind

5.使配置生效

exportfs -r

6.查看nfs

[root@k8s-master ~]# exportfs
/nfs/data       <world>

7.其他节点检查nfs共享

[root@k8s-node01 ~]#  showmount -e 192.168.3.201
Export list for 192.168.3.201:
/nfs/data *

三、安装zabbix-mysql

1.编写zabbix-mysql的yaml文件

[root@k8s-master zabbix]# cat zabbix_mysql.yaml
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: zabbixdb-pv
spec:
  capacity:   #创建存储的大小
    storage: 10Gi
  volumeMode: Filesystem  #存储的类型
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Recycle
  nfs:
    path: nfs/data/zabbix
    server: 192.168.3.201
  mountOptions:
    - hard
    - nfsvers=4.1
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: zabbixdb-pvc
  namespace: zabbix
spec:
  accessModes:
    - ReadWriteOnce
  volumeMode: Filesystem   #存储类型 ，块存储Block
  resources:
    requests:
      storage: 8Gi
---
apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: zabbixdb
  name: zabbixdb
  namespace: zabbix
spec:
  replicas: 1
  selector:
    matchLabels:
      app: zabbixdb
  strategy: {}
  template:
    metadata:
      labels:
        app: zabbixdb
    spec:
      volumes:
      - name: zabbixdb-data
        persistentVolumeClaim:
          claimName: zabbixdb-pvc
      containers:
      - image: mysql:8.0
        name: mysql
        ports:
        - name: mysql
          containerPort: 3306
          protocol: TCP
        volumeMounts:
        - name: zabbixdb-data
          mountPath: var/lib/mysql
        env:
        - name: MYSQL_DATABASE
          value: 'zabbix'
        - name: MYSQL_USER
          value: 'zabbix'
        - name: MYSQL_PASSWORD
          value: 'zabbix'
        - name: MYSQL_ROOT_PASSWORD
          value: 'zabbix'
        resources:
          requests:
             cpu: 0.1
             memory: 128Mi
          limits:
             cpu: 0.3
             memory:  512Mi
---


apiVersion: v1
kind: Service
metadata:
  creationTimestamp: null
  labels:
    app: zabbixdb
  name: zabbixdb
  namespace: zabbix
spec:
  clusterIP: 10.96.1.99
  ports:
  - name: 3306-3306
    port: 3306
    protocol: TCP
    targetPort: 3306
  selector:
    app: zabbixdb
  type: ClusterIP
status:
  loadBalancer: {}

2.创建命名空间

[root@k8s-master zabbix]# kubectl create namespace zabbix
namespace/zabbix created

3.创建zabbix数据库

kubectl apply -f zabbix_mysql.yaml

4.检查pod状态

[root@k8s-master zabbix]# kubectl get pods -n zabbix
NAME                        READY   STATUS    RESTARTS   AGE
zabbixdb-69b7cd8dff-jnpjd   1/1     Running   0          11m

四、检查zabbix数据库的service域名

1.运行测试pod

[root@k8s-master ~]# kubectl run busybox --image=busybox:1.28 -- sleep 3600
pod/busybox created

2.进入busybox的pod

[root@k8s-master ~]# kubectl exec -it busybox -- bin/sh
/ #

3.查看域名解析

[root@k8s-master ~]# kubectl exec -it busybox -- bin/sh
/ # nslookup zabbixdb.zabbix.svc.cluster.local
Server:    10.96.0.10
Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local




Name:      zabbixdb.zabbix.svc.cluster.local
Address 1: 10.96.1.99 zabbixdb.zabbix.svc.cluster.local
/ #

五、安装zabbix-server

1.编写zabbix_server.yaml文件

[root@k8s-master zabbix]# cat zabbix_server.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  creationTimestamp: null
  labels:
    app: zabbix-server
  name: zabbix-server
  namespace: zabbix
spec:
  replicas: 1
  selector:
    matchLabels:
      app: zabbix-server
  strategy: {}
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: zabbix-server
    spec:
      volumes:
      - name: zabbix-scripts
        hostPath:
          path: usr/lib/zabbix/
      - name: zabbix-file
        hostPath:
          path: var/lib/zabbix
      nodeSelector:
        zabbix-server: "true"
      hostNetwork: true
      containers:
      - image: zabbix/zabbix-server-mysql:6.0-ubuntu-latest
        name: zabbix-server-mysql
        env:
        - name: DB_SERVER_HOST
          value:  10.96.1.99
        - name: MYSQL_USER
          value: zabbix
        - name: MYSQL_PASSWORD
          value: zabbix
        resources: {}
status: {}

2.给node02节点打上标签

[root@k8s-master zabbix]# kubectl label nodes k8s-node02  zabbix-server=true
node/k8s-node02 labeled

3.安装zabbix-server

[root@k8s-master zabbix]# kubectl apply -f zabbix_server.yaml
deployment.apps/zabbix-server created

4.检查pod状态

[root@k8s-master zabbix]# kubectl get pods -n zabbix
NAME                             READY   STATUS    RESTARTS   AGE
zabbix-server-5f48d9d57d-rkr5p   1/1     Running   0          66s
zabbixdb-69b7cd8dff-krt2w        1/1     Running   0          4m22s

六、部署zabbix-web

1.编写zabbix_web.yaml文件

[root@k8s-master zabbix]# cat zabbix_web.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  creationTimestamp: null
  labels:
    app: zabbix-web
  name: zabbix-web
  namespace: zabbix
spec:
  replicas: 1
  selector:
    matchLabels:
      app: zabbix-web
  strategy: {}
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: zabbix-web
    spec:
      containers:
      - image: zabbix/zabbix-web-nginx-mysql:6.0-ubuntu-latest
        name: zabbix-web-nginx-mysql
        env:
        - name: DB_SERVER_HOST
          value: zabbixdb.zabbix.svc.cluster.local
        - name: MYSQL_USER
          value: zabbix
        - name: MYSQL_PASSWORD
          value: zabbix
        - name: ZBX_SERVER_HOST
          value: 192.168.3.201
        - name: PHP_TZ
          value: Asia/shanghai
        resources: {}
status: {}
---
apiVersion: v1
kind: Service
metadata:
  creationTimestamp: null
  labels:
    app: zabbix-web
  name: zabbix-web
  namespace: zabbix
spec:
  ports:
  - name: 8080-8080
    port: 8080
    protocol: TCP
    targetPort: 8080
  selector:
    app: zabbix-web
  type: NodePort
status:
  loadBalancer: {}

2.安装zabbix-web

[root@k8s-master zabbix]# kubectl apply -f zabbix_web.yaml
deployment.apps/zabbix-web created
service/zabbix-web created

3.查看pod状态

[root@k8s-master zabbix]# kubectl get pods -n zabbix
NAME                             READY   STATUS    RESTARTS   AGE
zabbix-server-5f48d9d57d-rkr5p   1/1     Running   0          2m36s
zabbix-web-55cd66f74f-9f284      1/1     Running   0          18s
zabbixdb-69b7cd8dff-krt2w        1/1     Running   0          5m52s

七、部署zabbix-agent

1.编辑zabbix_agent.yaml

[root@k8s-master zabbix]# cat zabbix_agent.yaml
apiVersion: apps/v1
kind: DaemonSet
metadata:
  labels:
    app: zabbix-agent
  name: zabbix-agent
  namespace: zabbix
spec:
  selector:
    matchLabels:
      app: zabbix-agent
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: zabbix-agent
    spec:
      hostNetwork: true
      containers:
      - image: zabbix/zabbix-agent:6.0-ubuntu-latest
        name: zabbix-agent
        env:
        - name: ZBX_SERVER_HOST
          value: 192.168.3.201
        resources: {}

2.安装zabbix-agent

kubectl apply -f zabbix_agent.yaml

3.查看pod状态

[root@k8s-master zabbix]# kubectl get pods -n zabbix
NAME                             READY   STATUS    RESTARTS   AGE
zabbix-agent-h2qwf               1/1     Running   0          3s
zabbix-agent-plnbd               1/1     Running   0          3s
zabbix-server-5f48d9d57d-rkr5p   1/1     Running   0          3m2s
zabbix-web-55cd66f74f-9f284      1/1     Running   0          44s
zabbixdb-69b7cd8dff-krt2w        1/1     Running   0          6m18s

八、访问zabbix的web

1.查看svc

[root@k8s-master zabbix]#  kubectl get svc -n zabbix
NAME         TYPE        CLUSTER-IP    EXTERNAL-IP   PORT(S)          AGE
zabbix-web   NodePort    10.100.50.7   <none>        8080:30775/TCP   59s
zabbixdb     ClusterIP   10.96.1.99    <none>        3306/TCP         6m33s
