Oracle RMAN恢复测试

IT小Chen 2021-04-13

1133

场景一：使用0级备份恢复数据库

需要0级备份+0级备份期间产生的归档日志

场景二：使用0级+1级备份恢复数据库

需要0级备份+1级备份+1级备份期间产生的归档日志

场景三：使用0级+归档备份恢复数据库

场景四：完全恢复

场景五：异机恢复常用命令

######备份######

1 启动归档

[oracle@chendb ~]$ sqlplus  as sysdba
SQL> alter system set log_archive_dest_1='location=/arch';
SQL> alter system set log_archive_format = "chendb_%t_%s_%r.arc" scope=spfile;
SQL> shutdown immediate;
SQL> startup mount;
SQL> alter database archivelog;
SQL> alter database open;
SQL> archive log list;

2 创建测试数据

SQL> conn cjc/***
SQL>
create table t1(id number,ttime varchar2(100));
CREATE OR REPLACE PROCEDURE test_pro is
begin
  for i in 1 .. 10 loop
    insert into t1 values (i, to_char(sysdate, 'yyyy/mm/dd hh24:mi:ss'));
    commit;
  end loop;
end;
/

3 创建0级备份脚本

[oracle@cjcos01 script]$ vim rmanbak/script/0_rmanbak.sh
###0_rmanbak.sh begin###
export NLS_DATE_FORMAT='yyyy-mm-dd hh24:mi:ss'
export ORACLE_SID=chendb
rman target  log=/rmanbak/db/0_rmanbak.log <<EOF
run{
allocate channel ch1 type disk maxpiecesize 1000M;
allocate channel ch2 type disk maxpiecesize 1000M;
backup incremental level = 0
filesperset = 32
format '/rmanbak/db/lev0_%d_%T_%U.bak'
skip inaccessible  database
include current controlfile
tag '0_rmanbak_cjcdb' ;
release channel ch1;
release channel ch2;
}
EOF
exit
###0_rmanbak.sh end###

执行0级备份

[oracle@cjcos01 script]$ chmod a+x 0_rmanbak.sh
[oracle@cjcos01 script]$ ./0_rmanbak.sh

执行备份期间，生成测试数据，切换归档日志

SQL> conn cjc/***
SQL> exec test_pro();
SQL> create table t2 as select * from t1;
SQL> alter system switch logfile;

4 创建1级备份

[oracle@cjcos01 script]$ cat 1_rmanbak.sh
###1_rmanbak.sh begin###
export NLS_DATE_FORMAT='yyyy-mm-dd hh24:mi:ss'
export ORACLE_SID=chendb
rman target  log=/rmanbak/db/1_rmanbak.log <<EOF
run{
allocate channel ch1 type disk maxpiecesize 1000M;
allocate channel ch2 type disk maxpiecesize 1000M;
backup incremental level = 1
filesperset = 32
format '/rmanbak/db/lev1_%d_%T_%U.bak'
skip inaccessible  database
include current controlfile
tag '1_rmanbak_cjcdb' ;
release channel ch1;
release channel ch2;
}
EOF
exit
###1_rmanbak.sh end###

执行1级备份

[oracle@cjcos01 script]$ chmod a+x 1_rmanbak.sh
[oracle@cjcos01 script]$ ./1_rmanbak.sh

执行备份期间，生成测试数据，切换归档日志

SQL> conn cjc/***
SQL> exec test_pro();
SQL> create table t3 as select * from t2;
SQL> alter system switch logfile;

5 执行归档备份

[oracle@cjcos01 script]$ cat arch_rmanbak.sh
###arch_rmanbak.sh begin###
export NLS_DATE_FORMAT='yyyy-mm-dd hh24:mi:ss'
export ORACLE_SID=chendb
rman target  log=/rmanbak/db/arch_rmanbak.log <<EOF
run{
allocate channel ch1 type disk maxpiecesize 1000M;
allocate channel ch2 type disk maxpiecesize 1000M;
sql "alter system archive log current";
backup
filesperset = 32
format '/rmanbak/db/arch_%d_%T_%U.bak'
skip inaccessible
archivelog all delete input
tag 'arch_cjcdb';
backup format='/rmandata/db/ctl_%d_%T_%U.ctl' current controlfile ;
release channel ch1;
release channel ch2;
}
EOF
exit
###arch_rmanbak.sh end###

执行归档备份

[oracle@cjcos01 script]$ ./arch_rmanbak.sh
SQL> create table t5 as select *from t1;

查看备份信息

SQL>
alter session set nls_date_format='yyyymmdd hh24:mi:ss';
col tag for a20
set lin 200 pages 200
col handle for a50
col SIZE_BYTES_DISPLAY for a10
 select BS.RECID,BS.START_TIME,BS.PIECES,BS.INCREMENTAL_LEVEL,BS.BACKUP_TYPE,BP.PIECE#,BP.HANDLE,BP.TAG,BP.STATUS,ROUND(BP.bytes/1024/1024/1024,2) gb
  from v$backup_set bs,v$backup_piece bp
  where
  bs.recid=bp.recid;
     RECID START_TIME     PIECES INCREMENTAL_LEVEL B  PIECE# HANDLE              TAG           S   GB
---------- ----------------- ---------- ----------------- - ---------- -------------------------------------------------- -------------------- - ----------
   1 20200801 14:31:54        1     0 D       1 rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak  0_RMANBAK_CJCDB      A  .41
   2 20200801 14:31:54        1     0 D       1 rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak  0_RMANBAK_CJCDB      A  .73
   3 20200801 14:33:30        1     0 D       1 rmanbak/db/lev0_CHENDB_20200801_04v6p8hq_1_1.bak  0_RMANBAK_CJCDB      A    0
   4 20200801 14:33:23        1     0 D       1 rmanbak/db/lev0_CHENDB_20200801_03v6p8hj_1_1.bak  0_RMANBAK_CJCDB      A  .01
   5 20200801 15:07:32        1     1 I       1 rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak  1_RMANBAK_CJCDB      A    0
   6 20200801 15:07:32        1     1 I       1 rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak  1_RMANBAK_CJCDB      A    0
   7 20200801 15:08:49        1     1 I       1 rmanbak/db/lev1_CHENDB_20200801_08v6pak1_1_1.bak  1_RMANBAK_CJCDB      A    0
   8 20200801 15:08:48        1     1 I       1 rmanbak/db/lev1_CHENDB_20200801_07v6pak0_1_1.bak  1_RMANBAK_CJCDB      A  .01
   9 20200801 15:13:26        1       L       1 rmanbak/db/arch_CHENDB_20200801_09v6pasm_1_1.bak  ARCH_CJCDB         A  .51
  10 20200801 15:13:26        1       L       1 rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak  ARCH_CJCDB         A  .45
  11 20200801 15:14:12        1       L       1 rmanbak/db/arch_CHENDB_20200801_0bv6pau4_1_1.bak  ARCH_CJCDB         A    0
  12 20200801 15:14:14        1       D       1 rmandata/db/ctl_CHENDB_20200801_0cv6pau6_1_1.ctl  TAG20200801T151414   A  .01


12 rows selected

BACKUP_TYPE:
Type of files that are in this backup.
If the backup contains archived redo logs, the value is L.
If this is a datafile full backup, the value is D.
If this is an incremental backup, the value is I.

查看备份信息

[oracle@cjcos01 script]$ export NLS_DATE_FORMAT='YYYYMMDD HH24:MI:SS'
[oracle@cjcos01 script]$ rman target


Recovery Manager: Release 11.2.0.4.0 - Production on Sat Aug 1 15:24:20 2020
Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved.
connected to target database: CHENDB (DBID=1831901477)


RMAN> list backup summary;
using target database control file instead of recovery catalog


List of Backups
===============
Key     TY LV S Device Type Completion Time   #Pieces #Copies Compressed Tag
------- -- -- - ----------- ----------------- ------- ------- ---------- ---
1       B  0  A DISK        20200801 14:33:06 1       1       NO         0_RMANBAK_CJCDB
2       B  0  A DISK        20200801 14:33:26 1       1       NO         0_RMANBAK_CJCDB
3       B  0  A DISK        20200801 14:33:30 1       1       NO         0_RMANBAK_CJCDB
4       B  0  A DISK        20200801 14:33:31 1       1       NO         0_RMANBAK_CJCDB
5       B  1  A DISK        20200801 15:08:41 1       1       NO         1_RMANBAK_CJCDB
6       B  1  A DISK        20200801 15:08:48 1       1       NO         1_RMANBAK_CJCDB
7       B  1  A DISK        20200801 15:08:49 1       1       NO         1_RMANBAK_CJCDB
8       B  1  A DISK        20200801 15:08:50 1       1       NO         1_RMANBAK_CJCDB
9       B  A  A DISK        20200801 15:14:07 1       1       NO         ARCH_CJCDB
10      B  A  A DISK        20200801 15:14:08 1       1       NO         ARCH_CJCDB
11      B  A  A DISK        20200801 15:14:13 1       1       NO         ARCH_CJCDB
12      B  F  A DISK        20200801 15:14:15 1       1       NO         TAG20200801T151414

######恢复######

场景一：使用0级备份恢复数据库

手动将增量和归档备份设置失效，测试只有0级备份进行恢复数据库

---生成unavailable脚本

SQL> set pagesize 2000
SQL> set heading off
SQL> spool home/oracle/unavailable.log
SQL>
select 'change backupset '||BS.RECID||' unavailable;'
from v$backup_set bs,v$backup_piece bp
where
bs.recid=bp.recid
and BS.BACKUP_TYPE!='D'
SQL>spool off
'CHANGEBACKUPSET'||BS.RECID||'UNAVAILABLE;'
----------------------------------------------------------------------
change backupset 5 unavailable;
change backupset 6 unavailable;
change backupset 7 unavailable;
change backupset 8 unavailable;
change backupset 9 unavailable;
change backupset 10 unavailable;
change backupset 11 unavailable;


RMAN>
change backupset 5 unavailable;
change backupset 6 unavailable;
change backupset 7 unavailable;
change backupset 8 unavailable;
change backupset 9 unavailable;
change backupset 10 unavailable;
change backupset 11 unavailable;

查看状态，5-12备份集已经失效

RMAN> list backup summary;


List of Backups
===============
Key     TY LV S Device Type Completion Time   #Pieces #Copies Compressed Tag
------- -- -- - ----------- ----------------- ------- ------- ---------- ---
1       B  0  A DISK        20200801 14:33:06 1       1       NO         0_RMANBAK_CJCDB
2       B  0  A DISK        20200801 14:33:26 1       1       NO         0_RMANBAK_CJCDB
3       B  0  A DISK        20200801 14:33:30 1       1       NO         0_RMANBAK_CJCDB
4       B  0  A DISK        20200801 14:33:31 1       1       NO         0_RMANBAK_CJCDB
5       B  1  U DISK        20200801 15:08:41 1       1       NO         1_RMANBAK_CJCDB
6       B  1  U DISK        20200801 15:08:48 1       1       NO         1_RMANBAK_CJCDB
7       B  1  U DISK        20200801 15:08:49 1       1       NO         1_RMANBAK_CJCDB
8       B  1  U DISK        20200801 15:08:50 1       1       NO         1_RMANBAK_CJCDB
9       B  A  U DISK        20200801 15:14:07 1       1       NO         ARCH_CJCDB
10      B  A  U DISK        20200801 15:14:08 1       1       NO         ARCH_CJCDB
11      B  A  U DISK        20200801 15:14:13 1       1       NO         ARCH_CJCDB
12      B  F  A DISK        20200801 15:14:15 1       1       NO         TAG20200801T151414

0级恢复

SQL> shutdown immediate
冷备
[oracle@cjcos01 oradata]$ pwd
/u01/app/oracle11/oradata
[oracle@cjcos01 oradata]$ cp chendb chendb_0801bak -r
SQL> startup mount

开始0级恢复

默认执行完全恢复，归档备份已经设置失效，所以会提示找不到归档

RMAN>
run{
allocate channel d1 type disk;
restore database;
recover database;
release channel d1;
}

恢复日志如下：

using target database control file instead of recovery catalog
allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 15:30:43


channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00002 to u01/app/oracle11/oradata/chendb/sysaux01.dbf
channel d1: restoring datafile 00004 to u01/app/oracle11/oradata/chendb/users01.dbf
channel d1: restoring datafile 00006 to u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:01:05
channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00001 to u01/app/oracle11/oradata/chendb/system01.dbf
channel d1: restoring datafile 00003 to u01/app/oracle11/oradata/chendb/undotbs01.dbf
channel d1: restoring datafile 00005 to u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:01:15
Finished restore at 20200801 15:33:04


Starting recover at 20200801 15:33:05


starting media recovery


released channel: d1
RMAN-00571: ===========================================================
RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============
RMAN-00571: ===========================================================
RMAN-03002: failure of recover command at 08/01/2020 15:33:06
RMAN-06053: unable to perform media recovery because of missing log
RMAN-06025: no backup of archived log for thread 1 with sequence 39 and starting SCN of 2280954 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 38 and starting SCN of 2280793 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 37 and starting SCN of 2280705 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 36 and starting SCN of 2278640 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 35 and starting SCN of 2278619 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 34 and starting SCN of 2277662 found to restore

查看控制文件记录的数据文件scn

SQL> select file#,checkpoint_change# from v$datafile;
     FILE# CHECKPOINT_CHANGE#
---------- ------------------
   1        2281863
   2        2281863
   3        2281863
   4        2281863
   5        2281863
   6        2281863
6 rows selected.

查看数据文件头记录的SCN

SQL> select file#,checkpoint_change# from v$datafile_header;
     FILE# CHECKPOINT_CHANGE#
---------- ------------------
   1        2278590
   2        2278591
   3        2278590
   4        2278591
   5        2278590
   6        2278591
6 rows selected.

0级别恢复，执行不完全恢复，恢复到数据文件头最大的scn

RMAN>
run{
allocate channel d1 type disk;
restore database until scn 2278591;
recover database until scn 2278591;
release channel d1;
}


released channel: d1
RMAN-00571: ===========================================================
RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============
RMAN-00571: ===========================================================
RMAN-03002: failure of recover command at 08/01/2020 15:41:12
RMAN-06053: unable to perform media recovery because of missing log
RMAN-06025: no backup of archived log for thread 1 with sequence 34 and starting SCN of 2277662 found to restore

提示恢复需要34号归档文件，查看34号归档所在备份集

RMAN> list backupset of archivelog sequence 34;


List of Backup Sets
===================


BS Key  Size       Device Type Elapsed Time Completion Time
------- ---------- ----------- ------------ -----------------
10      463.58M    DISK        00:00:42     20200801 15:14:08
        BP Key: 10   Status: AVAILABLE  Compressed: NO  Tag: ARCH_CJCDB
        Piece Name: /rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak


  List of Archived Logs in backup set 10
  Thrd Seq     Low SCN    Low Time          Next SCN   Next Time
  ---- ------- ---------- ----------------- ---------- ---------
  1    34      2277662    20200801 14:16:55 2278619    20200801 14:32:15

手动将10号备份置为有效

RMAN> change backupset 10 available;
using channel ORA_DISK_1
changed backup piece available
backup piece handle=/rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak RECID=10 STAMP=1047309207
Changed 1 objects to AVAILABLE status

解压出34号归档文件

RMAN> restore archivelog sequence 34;


Starting restore at 20200801 15:46:11
using channel ORA_DISK_1


channel ORA_DISK_1: starting archived log restore to default destination
channel ORA_DISK_1: restoring archived log
archived log thread=1 sequence=34
channel ORA_DISK_1: reading from backup piece rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak
channel ORA_DISK_1: piece handle=/rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak tag=ARCH_CJCDB
channel ORA_DISK_1: restored backup piece 1
channel ORA_DISK_1: restore complete, elapsed time: 00:00:07
Finished restore at 20200801 15:46:18


[oracle@cjcos01 db]$ ls arch/
chendb_1_34_1042210216.arc

再次执行恢复

此次使用了0级备份+34号归档完成了恢复

RMAN>
run{
allocate channel d1 type disk;
restore database until scn 2278591;
recover database until scn 2278591;
release channel d1;
}


released channel: ORA_DISK_1
allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 15:47:12


skipping datafile 1; already restored to file u01/app/oracle11/oradata/chendb/system01.dbf
skipping datafile 3; already restored to file u01/app/oracle11/oradata/chendb/undotbs01.dbf
skipping datafile 5; already restored to file u01/app/oracle11/oradata/chendb/example01.dbf
skipping datafile 2; already restored to file u01/app/oracle11/oradata/chendb/sysaux01.dbf
skipping datafile 4; already restored to file u01/app/oracle11/oradata/chendb/users01.dbf
skipping datafile 6; already restored to file u01/app/oracle11/oradata/chendb/cjctbs01.dbf
restore not done; all files read only, offline, or already restored
Finished restore at 20200801 15:47:12


Starting recover at 20200801 15:47:12


starting media recovery


archived log for thread 1 with sequence 34 is already on disk as file arch/chendb_1_34_1042210216.arc
archived log file name=/arch/chendb_1_34_1042210216.arc thread=1 sequence=34
media recovery complete, elapsed time: 00:00:00
Finished recover at 20200801 15:47:12


released channel: d1

恢复成功

查看当前数据文件scn

SQL> select file#,checkpoint_change# from v$datafile_header;
     FILE# CHECKPOINT_CHANGE#
---------- ------------------
   1        2278591
   2        2278591
   3        2278591
   4        2278591
   5        2278591
   6        2278591
6 rows selected.

场景二：使用0级+1级备份恢复数据库

将增量备份设置为有效

RMAN>
change backupset 5 available;
change backupset 6 available;
change backupset 7 available;
change backupset 8 available;

查看备份状态

RMAN> list backup summary;


List of Backups
===============
Key     TY LV S Device Type Completion Time   #Pieces #Copies Compressed Tag
------- -- -- - ----------- ----------------- ------- ------- ---------- ---
1       B  0  A DISK        20200801 14:33:06 1       1       NO         0_RMANBAK_CJCDB
2       B  0  A DISK        20200801 14:33:26 1       1       NO         0_RMANBAK_CJCDB
3       B  0  A DISK        20200801 14:33:30 1       1       NO         0_RMANBAK_CJCDB
4       B  0  A DISK        20200801 14:33:31 1       1       NO         0_RMANBAK_CJCDB
5       B  1  A DISK        20200801 15:08:41 1       1       NO         1_RMANBAK_CJCDB
6       B  1  A DISK        20200801 15:08:48 1       1       NO         1_RMANBAK_CJCDB
7       B  1  A DISK        20200801 15:08:49 1       1       NO         1_RMANBAK_CJCDB
8       B  1  A DISK        20200801 15:08:50 1       1       NO         1_RMANBAK_CJCDB
9       B  A  U DISK        20200801 15:14:07 1       1       NO         ARCH_CJCDB
10      B  A  U DISK        20200801 15:14:08 1       1       NO         ARCH_CJCDB
11      B  A  U DISK        20200801 15:14:13 1       1       NO         ARCH_CJCDB
12      B  F  A DISK        20200801 15:14:15 1       1       NO         TAG20200801T151414

删除解压的归档

[oracle@cjcos01 db]$ rm -rf arch/chendb_1_34_1042210216.arc

恢复冷备份

SQL> shutdown immediate
[oracle@cjcos01 oradata]$ rm -rf chendb/*
[oracle@cjcos01 oradata]$ cp chendb_0801bak/* chendb/ -r
SQL> startup mount

开始0+1级恢复，默认执行完全恢复

归档备份已经设置失效，所有会提示找不到归档

RMAN>
run{
allocate channel d1 type disk;
restore database;
recover database;
release channel d1;
}


allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 16:15:57


channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00002 to /u01/app/oracle11/oradata/chendb/sysaux01.dbf
channel d1: restoring datafile 00004 to /u01/app/oracle11/oradata/chendb/users01.dbf
channel d1: restoring datafile 00006 to /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:25
channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00001 to /u01/app/oracle11/oradata/chendb/system01.dbf
channel d1: restoring datafile 00003 to /u01/app/oracle11/oradata/chendb/undotbs01.dbf
channel d1: restoring datafile 00005 to /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:35
Finished restore at 20200801 16:16:58


Starting recover at 20200801 16:16:58
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00002: /u01/app/oracle11/oradata/chendb/sysaux01.dbf
destination for restore of datafile 00004: /u01/app/oracle11/oradata/chendb/users01.dbf
destination for restore of datafile 00006: /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00001: /u01/app/oracle11/oradata/chendb/system01.dbf
destination for restore of datafile 00003: /u01/app/oracle11/oradata/chendb/undotbs01.dbf
destination for restore of datafile 00005: /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01


starting media recovery


released channel: d1
RMAN-00571: ===========================================================
RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============
RMAN-00571: ===========================================================
RMAN-03002: failure of recover command at 08/01/2020 16:17:00
RMAN-06053: unable to perform media recovery because of missing log
RMAN-06025: no backup of archived log for thread 1 with sequence 39 and starting SCN of 2280954 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 38 and starting SCN of 2280793 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 37 and starting SCN of 2280705 found to restore
RMAN-06025: no backup of archived log for thread 1 with sequence 36 and starting SCN of 2278640 found to restore

查看数据文件头scn

SQL> select file#,checkpoint_change# from v$datafile_header;
     FILE# CHECKPOINT_CHANGE#
---------- ------------------
   1        2280683
   2        2280684
   3        2280683
   4        2280684
   5        2280683
   6        2280684
6 rows selected.

执行不完全恢复

RMAN>
run{
allocate channel d1 type disk;
###restore database until scn 2280684;
recover database until scn 2280684;
release channel d1;
}


allocated channel: d1
channel d1: SID=20 device type=DISK


Starting recover at 20200801 16:18:27


starting media recovery


released channel: d1
RMAN-00571: ===========================================================
RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============
RMAN-00571: ===========================================================
RMAN-03002: failure of recover command at 08/01/2020 16:18:28
RMAN-06053: unable to perform media recovery because of missing log
RMAN-06025: no backup of archived log for thread 1 with sequence 36 and starting SCN of 2278640 found to restore

提示需要36号归档文件

查看sequence 36

RMAN> list backupset of archivelog sequence 36;


List of Backup Sets
===================


BS Key  Size       Device Type Elapsed Time Completion Time
------- ---------- ----------- ------------ -----------------
10      463.58M    DISK        00:00:42     20200801 15:14:08
        BP Key: 10   Status: UNAVAILABLE  Compressed: NO  Tag: ARCH_CJCDB
        Piece Name: /rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak


  List of Archived Logs in backup set 10
  Thrd Seq     Low SCN    Low Time          Next SCN   Next Time
  ---- ------- ---------- ----------------- ---------- ---------
  1    36      2278640    20200801 14:33:01 2280705    20200801 15:07:56

需要备份片10

RMAN> change backupset 10 available;

解压归档

RMAN> restore archivelog sequence 36;
[oracle@cjcos01 chendb]$ ls /arch/
chendb_1_36_1042210216.arc

恢复数据库

RMAN>
run{
allocate channel d1 type disk;
restore database until scn 2280684;
recover database until scn 2280684;
release channel d1;
}


allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 16:53:20


channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00002 to /u01/app/oracle11/oradata/chendb/sysaux01.dbf
channel d1: restoring datafile 00004 to /u01/app/oracle11/oradata/chendb/users01.dbf
channel d1: restoring datafile 00006 to /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:25
channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00001 to /u01/app/oracle11/oradata/chendb/system01.dbf
channel d1: restoring datafile 00003 to /u01/app/oracle11/oradata/chendb/undotbs01.dbf
channel d1: restoring datafile 00005 to /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:35
Finished restore at 20200801 16:54:21


Starting recover at 20200801 16:54:21
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00002: /u01/app/oracle11/oradata/chendb/sysaux01.dbf
destination for restore of datafile 00004: /u01/app/oracle11/oradata/chendb/users01.dbf
destination for restore of datafile 00006: /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:03
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00001: /u01/app/oracle11/oradata/chendb/system01.dbf
destination for restore of datafile 00003: /u01/app/oracle11/oradata/chendb/undotbs01.dbf
destination for restore of datafile 00005: /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01


starting media recovery


archived log for thread 1 with sequence 36 is already on disk as file /arch/chendb_1_36_1042210216.arc
archived log file name=/arch/chendb_1_36_1042210216.arc thread=1 sequence=36
media recovery complete, elapsed time: 00:00:01
Finished recover at 20200801 16:54:26


released channel: d1

恢复成功

SQL> select file#,checkpoint_change# from v$datafile_header;
     FILE# CHECKPOINT_CHANGE#
---------- ------------------
   1        2280684
   2        2280684
   3        2280684
   4        2280684
   5        2280684
   6        2280684
6 rows selected.

场景三：使用0级+归档备份恢复数据库

设置增量备份失效

RMAN>
change backupset 5 unavailable;
change backupset 6 unavailable;
change backupset 7 unavailable;
change backupset 8 unavailable;
change backupset 9 available;
change backupset 10 available;
change backupset 11 available;

查看备份状态

RMAN> list backupset summary;


List of Backups
===============
Key     TY LV S Device Type Completion Time   #Pieces #Copies Compressed Tag
------- -- -- - ----------- ----------------- ------- ------- ---------- ---
1       B  0  A DISK        20200801 14:33:06 1       1       NO         0_RMANBAK_CJCDB
2       B  0  A DISK        20200801 14:33:26 1       1       NO         0_RMANBAK_CJCDB
3       B  0  A DISK        20200801 14:33:30 1       1       NO         0_RMANBAK_CJCDB
4       B  0  A DISK        20200801 14:33:31 1       1       NO         0_RMANBAK_CJCDB
5       B  1  U DISK        20200801 15:08:41 1       1       NO         1_RMANBAK_CJCDB
6       B  1  U DISK        20200801 15:08:48 1       1       NO         1_RMANBAK_CJCDB
7       B  1  U DISK        20200801 15:08:49 1       1       NO         1_RMANBAK_CJCDB
8       B  1  U DISK        20200801 15:08:50 1       1       NO         1_RMANBAK_CJCDB
9       B  A  A DISK        20200801 15:14:07 1       1       NO         ARCH_CJCDB
10      B  A  A DISK        20200801 15:14:08 1       1       NO         ARCH_CJCDB
11      B  A  A DISK        20200801 15:14:13 1       1       NO         ARCH_CJCDB
12      B  F  A DISK        20200801 15:14:15 1       1       NO         TAG20200801T151414

执行完全恢复

RMAN>
run{
allocate channel d1 type disk;
restore database;
recover database;
release channel d1;
}


released channel: ORA_DISK_1
allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 17:12:20


channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00002 to /u01/app/oracle11/oradata/chendb/sysaux01.dbf
channel d1: restoring datafile 00004 to /u01/app/oracle11/oradata/chendb/users01.dbf
channel d1: restoring datafile 00006 to /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:25
channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00001 to /u01/app/oracle11/oradata/chendb/system01.dbf
channel d1: restoring datafile 00003 to /u01/app/oracle11/oradata/chendb/undotbs01.dbf
channel d1: restoring datafile 00005 to /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:35
Finished restore at 20200801 17:13:20


Starting recover at 20200801 17:13:20


starting media recovery


archived log for thread 1 with sequence 36 is already on disk as file /arch/chendb_1_36_1042210216.arc
channel d1: starting archived log restore to default destination
channel d1: restoring archived log
archived log thread=1 sequence=34
channel d1: restoring archived log
archived log thread=1 sequence=35
channel d1: reading from backup piece /rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak
channel d1: piece handle=/rmanbak/db/arch_CHENDB_20200801_0av6pasm_1_1.bak tag=ARCH_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:15
archived log file name=/arch/chendb_1_34_1042210216.arc thread=1 sequence=34
archived log file name=/arch/chendb_1_35_1042210216.arc thread=1 sequence=35
archived log file name=/arch/chendb_1_36_1042210216.arc thread=1 sequence=36
channel d1: starting archived log restore to default destination
channel d1: restoring archived log
archived log thread=1 sequence=37
channel d1: restoring archived log
archived log thread=1 sequence=38
channel d1: restoring archived log
archived log thread=1 sequence=39
channel d1: reading from backup piece /rmanbak/db/arch_CHENDB_20200801_0bv6pau4_1_1.bak
channel d1: piece handle=/rmanbak/db/arch_CHENDB_20200801_0bv6pau4_1_1.bak tag=ARCH_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01
archived log file name=/arch/chendb_1_37_1042210216.arc thread=1 sequence=37
media recovery complete, elapsed time: 00:00:01
Finished recover at 20200801 17:13:44
released channel: d1

恢复成功

场景四：完全恢复

将所有备份设置为可用

RMAN>
change backupset 5 available;
change backupset 6 available;
change backupset 7 available;
change backupset 8 available;

查看备份状态

RMAN> list backupset summary;


List of Backups
===============
Key     TY LV S Device Type Completion Time   #Pieces #Copies Compressed Tag
------- -- -- - ----------- ----------------- ------- ------- ---------- ---
1       B  0  A DISK        20200801 14:33:06 1       1       NO         0_RMANBAK_CJCDB
2       B  0  A DISK        20200801 14:33:26 1       1       NO         0_RMANBAK_CJCDB
3       B  0  A DISK        20200801 14:33:30 1       1       NO         0_RMANBAK_CJCDB
4       B  0  A DISK        20200801 14:33:31 1       1       NO         0_RMANBAK_CJCDB
5       B  1  A DISK        20200801 15:08:41 1       1       NO         1_RMANBAK_CJCDB
6       B  1  A DISK        20200801 15:08:48 1       1       NO         1_RMANBAK_CJCDB
7       B  1  A DISK        20200801 15:08:49 1       1       NO         1_RMANBAK_CJCDB
8       B  1  A DISK        20200801 15:08:50 1       1       NO         1_RMANBAK_CJCDB
9       B  A  A DISK        20200801 15:14:07 1       1       NO         ARCH_CJCDB
10      B  A  A DISK        20200801 15:14:08 1       1       NO         ARCH_CJCDB
11      B  A  A DISK        20200801 15:14:13 1       1       NO         ARCH_CJCDB
12      B  F  A DISK        20200801 15:14:15 1       1       NO         TAG20200801T151414


released channel: ORA_DISK_1
allocated channel: d1
channel d1: SID=20 device type=DISK


Starting restore at 20200801 17:25:24


channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00002 to /u01/app/oracle11/oradata/chendb/sysaux01.dbf
channel d1: restoring datafile 00004 to /u01/app/oracle11/oradata/chendb/users01.dbf
channel d1: restoring datafile 00006 to /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_02v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:25
channel d1: starting datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
channel d1: restoring datafile 00001 to /u01/app/oracle11/oradata/chendb/system01.dbf
channel d1: restoring datafile 00003 to /u01/app/oracle11/oradata/chendb/undotbs01.dbf
channel d1: restoring datafile 00005 to /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak
channel d1: piece handle=/rmanbak/db/lev0_CHENDB_20200801_01v6p8eq_1_1.bak tag=0_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:35
Finished restore at 20200801 17:26:24


Starting recover at 20200801 17:26:24
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00002: /u01/app/oracle11/oradata/chendb/sysaux01.dbf
destination for restore of datafile 00004: /u01/app/oracle11/oradata/chendb/users01.dbf
destination for restore of datafile 00006: /u01/app/oracle11/oradata/chendb/cjctbs01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_06v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01
channel d1: starting incremental datafile backup set restore
channel d1: specifying datafile(s) to restore from backup set
destination for restore of datafile 00001: /u01/app/oracle11/oradata/chendb/system01.dbf
destination for restore of datafile 00003: /u01/app/oracle11/oradata/chendb/undotbs01.dbf
destination for restore of datafile 00005: /u01/app/oracle11/oradata/chendb/example01.dbf
channel d1: reading from backup piece /rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak
channel d1: piece handle=/rmanbak/db/lev1_CHENDB_20200801_05v6pahk_1_1.bak tag=1_RMANBAK_CJCDB
channel d1: restored backup piece 1
channel d1: restore complete, elapsed time: 00:00:01


starting media recovery


archived log for thread 1 with sequence 36 is already on disk as file /arch/chendb_1_36_1042210216.arc
archived log for thread 1 with sequence 37 is already on disk as file /arch/chendb_1_37_1042210216.arc
archived log for thread 1 with sequence 38 is already on disk as file /arch/chendb_1_38_1042210216.arc
archived log for thread 1 with sequence 39 is already on disk as file /arch/chendb_1_39_1042210216.arc
archived log file name=/arch/chendb_1_36_1042210216.arc thread=1 sequence=36
archived log file name=/arch/chendb_1_37_1042210216.arc thread=1 sequence=37
media recovery complete, elapsed time: 00:00:01
Finished recover at 20200801 17:26:28
released channel: d1

恢复完成，启动数据库

SQL> alter database open;

查看数据

SQL> conn cjc/cjc
SQL> select *from tab;
TNAME             TABTYPE  CLUSTERID
------------------------------ ------- ----------
T1             TABLE
T2             TABLE
T3             TABLE
T5             TABLE
T6             TABLE
6 rows selected.

场景五：异地恢复常用命令

1 恢复参数文件

RMAN> startup nomount
RMAN> restore spfile to '/rmandata/spfilecjcdb01.ora' from '/0712/rman/db/lev0_CJCDB01_20200711_04v52r5k_1_1.bak';
SQL> shutdown immedaite
SQL> create pfile='/rmandata/initcjcdb01.ora' from spfile='/rmandata/spfilecjcdb01.ora';
---修改initcjcdb01.ora参数
SQL> startup nomount pfile='/rmandata/initcjcdb01.ora'

2 恢复控制文件

RMAN> list backupset of controlfile;
run
{
allocate channel c1 type disk;
restore controlfile from '/0712/rman/db/ctl_CJCDB01_20200712_1vv54j7m_1_1.ctl';
release channel c1;
}

3 查看文件路径

select name from v$datafile
union all
select name from v$tempfile
union all
select name from v$controlfile
union all select member from v$logfile;

4 生成转换文件位置的语句

SQL>
set line 150
set page 100
set heading off
select 'set newname for datafile ' || '''' || name || '''' || ' to ' ||
       chr(39) ||
       replace(name, '+DATA/cjcdb/datafile/', '/rmandata/db/') ||
       ''';'
  from (select name
          from v$datafile
        union all
        select name
          from v$tempfile
        union all
        select name
          from v$controlfile
        union all
        select member from v$logfile);


###
set newname for datafile '+DATA/cjcdb/datafile/system.256.1039343535' to '/rmandata/db/system.256.1039343535';
set newname for datafile '+DATA/cjcdb/datafile/sysaux.257.1039343537' to '/rmandata/db/sysaux.257.1039343537';
set newname for datafile '+DATA/cjcdb/datafile/undotbs1.258.1039343539' to '/rmandata/db/undotbs1.258.1039343539';
set newname for datafile '+DATA/cjcdb/datafile/users.259.1039343539' to '/rmandata/db/users.259.1039343539';
set newname for datafile '+DATA/cjcdb/datafile/undotbs2.264.1039343919' to '/rmandata/db/undotbs2.264.1039343919';
set newname for datafile '+DATA/cjcdb/datafile/cjctbs.268.1043622893' to '/rmandata/db/cjctbs.268.1043622893';
set newname for datafile '+DATA/cjcdb/datafile/chentbs.267.1046799153' to '/rmandata/db/chentbs.267.1046799153';
set newname for datafile '+DATA/cjcdb/datafile/chentbs01.272.1046799329' to '/rmandata/db/chentbs01.272.1046799329';
set newname for datafile '+DATA/cjcdb/tempfile/temp.263.1039343731' to '+DATA/cjcdb/tempfile/temp.263.1039343731';
set newname for datafile '/rmandata/control01.ctl' to '/rmandata/control01.ctl';
set newname for datafile '+DATA/cjcdb/onlinelog/group_2.262.1039343705' to '+DATA/cjcdb/onlinelog/group_2.262.1039343705';
set newname for datafile '+DATA/cjcdb/onlinelog/group_1.261.1039343703' to '+DATA/cjcdb/onlinelog/group_1.261.1039343703';
set newname for datafile '+DATA/cjcdb/onlinelog/group_3.265.1039344119' to '+DATA/cjcdb/onlinelog/group_3.265.1039344119';
set newname for datafile '+DATA/cjcdb/onlinelog/group_4.266.1039344121' to '+DATA/cjcdb/onlinelog/group_4.266.1039344121';
###

5 修改文件路径

如果Restore执行后执行了SWITCH DATAFILE ALL;语句，可以不用执行下面的操作。

SQL>
set line 150
set page 100
set heading off
select 'alter database rename file ' || '''' || name || '''' || ' to ' ||
       chr(39) ||
       replace(name, '+DATA/cjcdb/datafile/', '/rmandata/db/') ||
       ''';'
  from (select name
          from v$datafile
        union all
        select name
          from v$tempfile
        union all
        select name
          from v$controlfile
        union all
        select member from v$logfile);
###
alter database rename file '+DATA/cjcdb/datafile/system.256.1039343535' to '/rmandata/db/system.256.1039343535';
alter database rename file '+DATA/cjcdb/datafile/sysaux.257.1039343537' to '/rmandata/db/sysaux.257.1039343537';
alter database rename file '+DATA/cjcdb/datafile/undotbs1.258.1039343539' to '/rmandata/db/undotbs1.258.1039343539';
alter database rename file '+DATA/cjcdb/datafile/users.259.1039343539' to '/rmandata/db/users.259.1039343539';
alter database rename file '+DATA/cjcdb/datafile/undotbs2.264.1039343919' to '/rmandata/db/undotbs2.264.1039343919';
alter database rename file '+DATA/cjcdb/datafile/cjctbs.268.1043622893' to '/rmandata/db/cjctbs.268.1043622893';
alter database rename file '+DATA/cjcdb/datafile/chentbs.267.1046799153' to '/rmandata/db/chentbs.267.1046799153';
alter database rename file '+DATA/cjcdb/datafile/chentbs01.272.1046799329' to '/rmandata/db/chentbs01.272.1046799329';
alter database rename file '+DATA/cjcdb/tempfile/temp.263.1039343731' to '+DATA/cjcdb/tempfile/temp.263.1039343731';
alter database rename file '/rmandata/control01.ctl' to '/rmandata/control01.ctl';
alter database rename file '+DATA/cjcdb/onlinelog/group_2.262.1039343705' to '+DATA/cjcdb/onlinelog/group_2.262.1039343705';
alter database rename file '+DATA/cjcdb/onlinelog/group_1.261.1039343703' to '+DATA/cjcdb/onlinelog/group_1.261.1039343703';
alter database rename file '+DATA/cjcdb/onlinelog/group_3.265.1039344119' to '+DATA/cjcdb/onlinelog/group_3.265.1039344119';
alter database rename file '+DATA/cjcdb/onlinelog/group_4.266.1039344121' to '+DATA/cjcdb/onlinelog/group_4.266.1039344121';
###

6 异机恢复示例(RAC备份恢复到单机)：

RMAN>
run{
allocate channel d1 type disk;
set newname for datafile '+DATA/cjcdb/datafile/system.256.1039343535' to '/rmandata/db/system.256.1039343535';
set newname for datafile '+DATA/cjcdb/datafile/sysaux.257.1039343537' to '/rmandata/db/sysaux.257.1039343537';
set newname for datafile '+DATA/cjcdb/datafile/undotbs1.258.1039343539' to '/rmandata/db/undotbs1.258.1039343539';
set newname for datafile '+DATA/cjcdb/datafile/users.259.1039343539' to '/rmandata/db/users.259.1039343539';
set newname for datafile '+DATA/cjcdb/datafile/undotbs2.264.1039343919' to '/rmandata/db/undotbs2.264.1039343919';
set newname for datafile '+DATA/cjcdb/datafile/cjctbs.268.1043622893' to '/rmandata/db/cjctbs.268.1043622893';
set newname for datafile '+DATA/cjcdb/datafile/chentbs.267.1046799153' to '/rmandata/db/chentbs.267.1046799153';
set newname for datafile '+DATA/cjcdb/datafile/chentbs01.272.1046799329' to '/rmandata/db/chentbs01.272.1046799329';
set newname for datafile '+DATA/cjcdb/tempfile/temp.263.1039343731' to '+DATA/cjcdb/tempfile/temp.263.1039343731';
set newname for datafile '/rmandata/control01.ctl' to '/rmandata/control01.ctl';
set newname for datafile '+DATA/cjcdb/onlinelog/group_2.262.1039343705' to '+DATA/cjcdb/onlinelog/group_2.262.1039343705';
set newname for datafile '+DATA/cjcdb/onlinelog/group_1.261.1039343703' to '+DATA/cjcdb/onlinelog/group_1.261.1039343703';
set newname for datafile '+DATA/cjcdb/onlinelog/group_3.265.1039344119' to '+DATA/cjcdb/onlinelog/group_3.265.1039344119';
set newname for datafile '+DATA/cjcdb/onlinelog/group_4.266.1039344121' to '+DATA/cjcdb/onlinelog/group_4.266.1039344121';
restore database until time "to_date('2020-07-31 22:17:47','yyyy-mm-dd hh24:mi:ss')";
SWITCH DATAFILE ALL;
recover database until time "to_date('2020-07-31 22:17:47','yyyy-mm-dd hh24:mi:ss')";
release channel d1;
}

7 在某些特定场景下：

先执行了

restore database until time xxx;
recover database until time xxx;

recover结束后没有启动数据库，数据库处于mouont状态。

这时如果想将数据库recover到更新的时间，不需要在执行

restore database until time xxx;

数据量大时，restore database耗时，耗空间。

只需要执行

recover database until time xxx+time;

但是如果在这个时间段内生成了新的数据文件，不能直接进行recover。

需要单独restore新增的数据文件，或通过下面的命令生成一个新的文件。

alter database create datafile '+DATA/cjcdb/datafile/cjc_data_5.dbf' as '/oradata/cjcdb/datafile/cjc_data_5.dbf';

然后可以进行执行recover。

更多数据库相关学习资料，可以查看我的ITPUB博客，网名chenoracle：

http://blog.itpub.net/29785807/

oracle

文章转载自IT小Chen，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

Oracle RMAN恢复测试

评论
