简单介绍下背景：

近期公司在做系统迁移，之前有个系统是研发自己管理的，所有的中间件都是单点，而且没有开启认证，存在很大的风险隐患，趁着这次迁移，将相关中间件进行了重新部署。

今天先做的是mongodb集群的搭建，mongodb集群有三种模式，一种是主从模式、一种是副本集模式，还有一种和分片集群，本文介绍的是副本集模式。

♦️

准备工作

服务器准备：

序号	IP	角色	架构模式
1	172.168.5.26	SECONDARY	Replica Set
2	172.168.5.27	SECONDARY	Replica Set
3	172.168.5.28	PRIMARY	Replica Set

具体角色是根据实际部署完后集群间确定的

安装包准备，三台同步，不同版本根据需要调整：

wget  https://fastdl.mongodb.org/linux/mongodb-linux-x86_64-rhel62-4.0.8.tgz

或者到官方网址中寻找：

https://www.mongodb.com/try/download/community

♦️

集群部署

解压部署包：

tar -xvf  mongodb-linux-x86_64-rhel62-4.0.3.tgz -C data
cd /data
mv   mongodb-linux-x86_64-rhel62-4.0.3  mongodb

mkdir -p data/mongodb/data/{db,log}
mkdir -p data/mongodb/conf

初始化配置文件

vim data/mongosb/conf/mongodb.conf

dbpath=/data/mongodb/data/db
logpath=/data/mongodb/data/log/mongodb.log
pidfilepath=/data/mongodb/mongo.pid
logappend=true
port=23017
bind_ip=0.0.0.0
fork=true
directoryperdb=true
replSet=myset

启动mongo服务，三台执行

cd /data/mongodb/bin
./mongod --config data/mongodb/conf/mongodb.conf

配置主从设置，其中一个节点执行

./mongo 172.168.5.26:23017

use adminrs

cfg = {_id: "myset",members:[{_id: 0,host: '172.168.5.26:23017',priority: 3},{_id: 1,host: '172.168.5.28:23017',priority: 2},{_id: 2,host: '172.168.5.27:23017',priority: 1}]};

rs.initiate(cfg)

rs.status()

如下结果

myset:PRIMARY> rs.status()
{
        "set" : "myset",
        "date" : ISODate("2022-10-10T12:03:23.256Z"),
        "myState" : 1,
        "term" : NumberLong(8),
        "syncingTo" : "",
        "syncSourceHost" : "",
        "syncSourceId" : -1,
        "heartbeatIntervalMillis" : NumberLong(2000),
        "optimes" : {
                "lastCommittedOpTime" : {
                        "ts" : Timestamp(1665403394, 1),
                        "t" : NumberLong(8)
                },
                "readConcernMajorityOpTime" : {
                        "ts" : Timestamp(1665403394, 1),
                        "t" : NumberLong(8)
                },
                "appliedOpTime" : {
                        "ts" : Timestamp(1665403394, 1),
                        "t" : NumberLong(8)
                },
                "durableOpTime" : {
                        "ts" : Timestamp(1665403394, 1),
                        "t" : NumberLong(8)
                }
        },
        "lastStableCheckpointTimestamp" : Timestamp(1665403384, 1),
        "members" : [
                {
                        "_id" : 0,
                        "name" : "172.168.5.26:23017",
                        "health" : 1,
                        "state" : 1,
                        "stateStr" : "PRIMARY",
                        "uptime" : 1393,
                        "optime" : {
                                "ts" : Timestamp(1665403394, 1),
                                "t" : NumberLong(8)
                        },
                        "optimeDate" : ISODate("2022-10-10T12:03:14Z"),
                        "syncingTo" : "",
                        "syncSourceHost" : "",
                        "syncSourceId" : -1,
                        "infoMessage" : "",
                        "electionTime" : Timestamp(1665402022, 1),
                        "electionDate" : ISODate("2022-10-10T11:40:22Z"),
                        "configVersion" : 1,
                        "self" : true,
                        "lastHeartbeatMessage" : ""
                },
                {
                        "_id" : 1,
                        "name" : "172.168.5.27:23017",
                        "health" : 1,
                        "state" : 2,
                        "stateStr" : "SECONDARY",
                        "uptime" : 1392,
                        "optime" : {
                                "ts" : Timestamp(1665403394, 1),
                                "t" : NumberLong(8)
                        },
                        "optimeDurable" : {
                                "ts" : Timestamp(1665403394, 1),
                                "t" : NumberLong(8)
                        },
                        "optimeDate" : ISODate("2022-10-10T12:03:14Z"),
                        "optimeDurableDate" : ISODate("2022-10-10T12:03:14Z"),
                        "lastHeartbeat" : ISODate("2022-10-10T12:03:22.636Z"),
                        "lastHeartbeatRecv" : ISODate("2022-10-10T12:03:22.570Z"),
                        "pingMs" : NumberLong(0),
                        "lastHeartbeatMessage" : "",
                        "syncingTo" : "172.16.52.30:24017",
                        "syncSourceHost" : "172.16.52.30:24017",
                        "syncSourceId" : 2,
                        "infoMessage" : "",
                        "configVersion" : 1
                },
                {
                        "_id" : 2,
                        "name" : "172.168.5.28:23017",
                        "health" : 1,
                        "state" : 2,
                        "stateStr" : "SECONDARY",
                        "uptime" : 1392,
                        "optime" : {
                                "ts" : Timestamp(1665403394, 1),
                                "t" : NumberLong(8)
                        },
                        "optimeDurable" : {
                                "ts" : Timestamp(1665403394, 1),
                                "t" : NumberLong(8)
                        },
                        "optimeDate" : ISODate("2022-10-10T12:03:14Z"),
                        "optimeDurableDate" : ISODate("2022-10-10T12:03:14Z"),
                        "lastHeartbeat" : ISODate("2022-10-10T12:03:22.627Z"),
                        "lastHeartbeatRecv" : ISODate("2022-10-10T12:03:22.793Z"),
                        "pingMs" : NumberLong(0),
                        "lastHeartbeatMessage" : "",
                        "syncingTo" : "172.16.52.22:24017",
                        "syncSourceHost" : "172.16.52.22:24017",
                        "syncSourceId" : 0,
                        "infoMessage" : "",
                        "configVersion" : 1
                }
        ],
        "ok" : 1,
        "operationTime" : Timestamp(1665403394, 1),
        "$clusterTime" : {
                "clusterTime" : Timestamp(1665403394, 1),
                "signature" : {
                        "hash" : BinData(0,"C3Oa+jLMS7aIOE2cDbvt6+hEInw="),
                        "keyId" : NumberLong("7152819770046283777")
                }
        }
}

♦️

开启认证

添加用户

use admin
db.createUser({user:"root",pwd:"mongo&prd",roles:["root"]})
use scyw
db.createUser({user: "yw", pwd: "ywprd", roles: ["readWrite"]})

生成key文件

openssl rand -base64 90 -out ./mongo.keyfile
chmod 400 ./mongo.keyfile

同步上述文件到三台

配置文件调整,添加如下行

keyFile=/data/mongodb/mongo.keyfile
auth=true

重启三个mongo实例

验证,可以看到没有认证是会报错的

myset:PRIMARY> db.system.users.find()
Error: error: {
        "operationTime" : Timestamp(1665405804, 1),
        "ok" : 0,
        "errmsg" : "command find requires authentication",
        "code" : 13,
        "codeName" : "Unauthorized",
        "$clusterTime" : {
                "clusterTime" : Timestamp(1665405804, 1),
                "signature" : {
                        "hash" : BinData(0,"qJB/hKg54xFEGj0O9gben+ZR80g="),
                        "keyId" : NumberLong("7152819770046283777")
                }
        }
}

需要 db.auth('root','mongo&prd')
