WebLogic Server 10.3.6升级至p30463097后管理控制台登陆失败

东方龙马 2020-03-20

764

WebLogic Server 10.3.6升级至p30463097(JWEB|10.3.6.0.200114)后管理控制台登陆失败问题分析及临时处理办法。

案例背景

PART

Oracle 2020年1月发布了新一季的CPU，WebLogic Server 11g最新补丁版本代号JWEB，WebLogic Server版本10.3.6.0.200114。

在管理服务器侦听端口设定为80(http)/443(https)时，会出现以下问题：

1、服务器启动正常；

2、管理控制台登陆失败；

3、测试发现当管理服务器侦听端口设置为其它端口时，控制台可以登陆。

经过分析，最终确认为WebLogic Server 10.3.6.0.200114 Web Security Bug，影响的范围为使用基于JAAS Form (login-config\auth-method = FORM)登陆的应用。

临时解决的办法为通过weblogic.xml设定weblogic-web-app\container-descriptor\referer-validation为 NONE。

Oracle已经发布临时补丁Patch 18509293: SU Patch [EIL8]: 10.3.6.0.200114WLSPSU Overlay: CANNOT LOGIN TO CONSOLE, BUT CAN LOGIN TO EM WITH THE SAME USER来修正这个问题

详细的MOS DocID可参考：2637876.1

分析过程

PART

开启管理服务器调试：debug-http及debug-web-app-security为true，登陆失败时，AdminServer log有如下报错：

####<2020-3-7 下午04时48分44秒 CST> <Debug> <WebAppSecurity> <OLM-ET> <AdminServer> <[ACTIVE] ExecuteThread: '0' for queue: 'weblogic.kernel.Default (self-tuning)'> <<WLS Kernel>> <> <> <1583570924549> <BEA-000000> <ServletContext@613901058[app:consoleapp module:console path:/console spec-version:2.5] ChainedSecuirtyModule checking access with weblogic.servlet.security.internal.CertSecurityModule@56f42c88>

####<2020-3-7 下午04时48分44秒 CST> <Debug> <Http> <OLM-ET> <AdminServer> <[ACTIVE] ExecuteThread: '0' for queue: 'weblogic.kernel.Default (self-tuning)'> <<anonymous>> <> <> <1583570924552> <BEA-000000> <HttpRequest@263621588 - console/login/LoginError.jsp: URI: console/login/LoginError.jsp>

可以确定在请求经过weblogic. servlet. security. internal.FormSecurityModule后被重定向至/console/login/LoginError.jsp;代码搜索weblogic. servlet. security. internal. FormSecurityModule，我们发现该类主要存在于以下两个路径：

J:\OLMJavaEEToolkit\classscanner>run.cmd

d:\OFM weblogic.servlet.security.internal.FormSecurityModule

J:\OLMJavaEEToolkit\classscanner>echo off

Search target directory:d:\OFM

Target class full name:weblogic.servlet.security.internal.FormSecurityModule

===========

file:/d:/OFM/patch_wls1036/patch_jars/BUG30463097_10360200114.jar

file:/d:/OFM/wlserver_10.3/server/lib/weblogic.jar

============

其中BUG30463097_10360200114.jar是实施p30463097后的补丁包，反编译weblogic.servlet.security.internal.FormSecurityModule代码，我们可以看到该处有j_security_check的处理过程

WebLogic Server 10.3.6.0.200114 weblogic.servlet.security.internal.FormSecurityModule

/* */ boolean checkUserPerm(HttpServletRequest req, HttpServletResponse rsp, SessionInternal session, ResourceConstraint cons, AuthenticatedSubject waFormAuthUser, boolean applyAuthFilters)

/* */ throws IOException, ServletException

/* */ {

/* 208 */ if (req.getRequestURI().endsWith("j_security_check"))

/* */ {

/* 215 */ return processJSecurityCheck(req, rsp, session);

/* 216 */ }if (waFormAuthUser != null)

/* */ {

/* 219 */ return processLoggedInUser(req, rsp, waFormAuthUser);

/* */ }

/* */

/* 223 */ if ((this.webAppSecurity.isFullSecurityDelegationRequired()) && (this.webAppSecurity.hasPermission(req, rsp, null, cons)))

/* 224 */ return true;

/* 225 */ if ((applyAuthFilters) && (this.webAppSecurity.hasAuthFilters())) {

/* 226 */ invokeAuthFilterChain(req, rsp);

/* 227 */ return false;

/* */ }

/* 229 */ if (isForbidden(cons)) sendForbiddenResponse(req, rsp); else

/* 230 */ sendLoginPage(req, rsp);

/* 231 */ return false;

/* */ }

/* */ private boolean processJSecurityCheck(HttpServletRequest req, HttpServletResponse rsp, SessionInternal session)

/* */ throws IOException

/* */ {

/* 239 */ if (!checkRefererHeader(req, rsp)) {

/* 240 */ sendError(req, rsp);

/* 241 */ return false;

/* */ }

...

}

/* */ private boolean checkRefererHeader(HttpServletRequest req, HttpServletResponse rsp) {

/* 354 */ if (this.refererValidationType == RefererValidationType.NONE) return true;

/* */

/* 356 */ String referer = req.getHeader("Referer");

/* 357 */ if ((referer == null) && (this.refererValidationType == RefererValidationType.LENIENT)) {

/* 358 */ return true;

/* */ }

/* 360 */ if (referer == null) {

/* 361 */ return false;

/* */ }

/* */

/* 364 */ String[] refererAddr = extractRefererAddr(referer);//问题调用，referer=http://localhost/console/login/LoginForm.jsp,and only return refererAddr[0] = "localhost" ,and return false lead to checkRefererHeader failue.

/* 365 */ if ((refererAddr == null) || (refererAddr.length != 2)) return false;//return false

/* */

/* 367 */ String serverHost = req.getServerName();

/* 368 */ int serverPort = req.getServerPort();

/* 369 */ int refererPort = 0;

/* */ try {

/* 371 */ refererPort = Integer.parseInt(refererAddr[1]);

/* */ } catch (NumberFormatException e) {

/* 373 */ return false;

/* */ }

/* */

/* 376 */ if (serverPort != refererPort) return false;

/* 377 */ if (serverHost.equals(refererAddr[0])) return true;

/* */ try

/* */ {

/* 380 */ return InetAddress.getByName(serverHost).equals(refererAddr[0]); } catch (UnknownHostException e) {

/* */ }

/* 382 */ return false;

/* */ }

问题代码：referer=http://localhost/console/login/LoginForm.jsp时，只会返回长度为1的字符串数组

/* */ private String[] extractRefererAddr(String referer)

/* */ {

/* 387 */ int hostBegin = referer.indexOf("//") + 2;

/* 388 */ if (hostBegin <= 1) return null;

/* 389 */ int addrEnd = referer.indexOf("/", hostBegin);

/* 390 */ if (addrEnd < 0) return null;

/* 391 */ String refererAddr = referer.substring(hostBegin, addrEnd);

/* 392 */ return refererAddr.split(":");

/* */ }

通过jdb调试还原问题过程，以下为调试信息：

[ACTIVE] ExecuteThread: '0' for queue: 'weblogic.kernel.Default (self-tuning)'[1] where

[1]weblogic.servlet.security.internal.FormSecurityModule.processJSecurityCheck (FormSecurityModule.java:240)

[2]weblogic.servlet.security.internal.FormSecurityModule.checkUserPerm (FormSecurityModule.java:215)

[3]weblogic.servlet.security.internal.FormSecurityModule.checkAccess (FormSecurityModule.java:98)

[4]weblogic.servlet.security.internal.ChainedSecurityModule.checkAccess (ChainedSecurityModule.java:79)

[5]weblogic.servlet.security.internal.ServletSecurityManager.checkAccess (ServletSecurityManager.java:82)

[6]weblogic.servlet.internal.WebAppServletContext.securedExecute (WebAppServletContext.java:2,219)

[7]weblogic.servlet.internal.WebAppServletContext.execute (WebAppServletContext.java:2,182)

[8] weblogic.servlet.internal.ServletRequestImpl.run (ServletRequestImpl.java:1,499)

[9] weblogic.work.ExecuteThread.execute (ExecuteThread.java:263)

[10] weblogic.work.ExecuteThread.run (ExecuteThread.java:221)

[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'[1] dump this.refererValidationType

this.refererValidationType = {

NONE: instance of weblogic.servlet.security.internal.RefererValidationType(id=11841)

LENIENT: instance of weblogic.servlet.security.internal.RefererValidationType(id=11842)

STRICT: instance of weblogic.servlet.security.internal.RefererValidationType(id=11822)

$VALUES: instance of weblogic.servlet.security.internal.RefererValidationType[3] (id=11843)

java.lang.Enum.name: "STRICT"

java.lang.Enum.ordinal: 2}

评析：

进入weblogic. servlet. security. internal. FormSecurityModule. processJSecurityCheck方法处理时，可以看到当前对象(weblogic.servlet.security. internal. FormSecurityModule)成员变量refererValidationType为STRICT;

已完成的步骤:

"线程=[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'", weblogic.servlet. security. internal. FormSecurityModule. checkRefererHeader(), 行=357 bci=21

[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'[1] where

[1]weblogic.servlet.security.internal.FormSecurityModule.checkRefererHeader (FormSecurityModule.java:357)

[2]weblogic.servlet.security.internal.FormSecurityModule.processJSecurityCheck (FormSecurityModule.java:239)

[3]weblogic.servlet.security.internal.FormSecurityModule.checkUserPerm (FormSecurityModule.java:215)

[4]weblogic.servlet.security.internal.FormSecurityModule.checkAccess (FormSecurityModule.java:98)

[5]weblogic.servlet.security.internal.ChainedSecurityModule.checkAccess (ChainedSecurityModule.java:79)

[6]weblogic.servlet.security.internal.ServletSecurityManager.checkAccess (ServletSecurityManager.java:82)

[7]weblogic.servlet.internal.WebAppServletContext.securedExecute (WebAppServletContext.java:2,219)

[8]weblogic.servlet.internal.WebAppServletContext.execute (WebAppServletContext.java:2,182)

[9] weblogic.servlet.internal.ServletRequestImpl.run (ServletRequestImpl.java:1,499)

[10] weblogic.work.ExecuteThread.execute (ExecuteThread.java:263)

[11] weblogic.work.ExecuteThread.run (ExecuteThread.java:221)

[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'[1] locals

方法参数:

req = instance of weblogic.servlet.internal.ServletRequestImpl(id=11846)

rsp = instance of weblogic.servlet.internal.ServletResponseImpl(id=11847)

本地变量:

referer = "http://localhost/console/login/LoginForm.jsp"

[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'[1]

评析：

进入weblogic.servlet.security. internal.FormSecurityModule. checkRefererHeader方法处理时，可以看到从报头上获取得到的Referer值为" http://localhost/console/login/LoginForm.jsp "并赋给局部变量referer；

[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'[1] where

[1]weblogic.servlet.security.internal.FormSecurityModule.checkRefererHeader (FormSecurityModule.java:365)
