OpenCloudOS 如何利用 nettrace 进行网络故障诊断

OpenCloudOS 2023-01-10

366

在开源 Linux 操作系统 OpenCloudOS 8.6 中，增加了内核对网络工具 nettrace 的支持，允许开发者通过 bpf 进行网络丢包原因跟踪，内核也同时回合相关的丢包跟踪点。今天，就以 nettrace 为典型，介绍如何在 OpenCloudOS 中利用 nettrace 进行网络故障诊断。

一、工具简介

背景

在一些场景下（特别是云原生场景），Linux 系统中的网络部署变得越来越复杂。一个 TCP 连接，从客户端到服务端，中间可能要经过复杂的 NAT
、GRE
、IPVS
等过程，网络报文在节点（主机）上的处理路径也变得越来越长。在发生网络故障（比如网络丢包）时，如何快速、有效地定位出网络问题成为了一个难题。目前常规的网络故障定位手段，如 tcpdump
、dropwatch
、ftrace
、kprobe
等存在一定的短板：

tcpdump
：只能在链路层抓包，无法定位内核协议栈中的问题，比如常规的内核丢包问题
ftrace
：只能跟踪内核函数，无法进行报文过滤，且入手较难，需要对内核协议栈有一定了解
kprobe
：临时编写内核模块，效率和安全性低
BCC
：功能单一，临时编写 BCC
程序跟踪效率低，需要对内核有一定了解，入手难
dropwatch
：功能单一，只能查看网络丢包问题，且无法得到丢包原因和解决方案

在此背景下，笔者结合多年的 Kernel 网络协议栈故障定位经验，基于 eBPF 开发了 Linux 环境下网络故障定位工具集——nettrace
。

功能介绍

nettrace
是一款基于 eBPF 的集网络报文跟踪（故障定位）、网络故障诊断、网络异常监控于一体的网络工具集，旨在能够提供一种更加高效、易用的方法来解决复杂场景下的网络问题。目前，其实现的功能包括：

网络报文跟踪：跟踪网络报文从进入到内核协议栈到释放/丢弃的过程中在内核中所走过的路径，实现报文整个生命周期的监控，并采集生命周期各个阶段的事件、信息。通过观察报文在内核中的路径，对于有一定内核协议栈经验的人来说可以快速、有效地发现网络问题。
网络故障诊断：将以往的经验集成到工具的知识库，通过知识匹配的方式来主动诊断当前网络故障，给出诊断结果以及修复建议。该功能入手简单、易用性强，无需过多的网络经验即可进行网络问题定位。
网络异常监控：常态化地部署到生产环境中，主动地发现、上报环境上的网络异常。
droptrace：用于跟踪、监控系统中的丢包事件的工具，在文末链接中查看详情介绍。该功能已被遗弃，可以使用 nettrace --drop 实现相同的功能。

二、安装方法

nettrace 是采用 C 语言编写的基于 eBPF（libbpf）的命令行工具，在使用和安装时可以用编译好的 RPM 包和二进制程序。注意：本工具目前仅在 4.14
及以上的内核版本上进行过兼容性测试，因此请确保当前的系统所使用的的内核版本在 4.14
以上。

对于默认继承 yum 的 OpenCloudOS，本工具已经上线到对应的软件仓库，可以方便快捷地直接使用 yum 命令来进行在线安装：

sudo yum install nettrace

也可以直接从 OpenCloudOS releases 页面中下载对应的 RPM/DEB 安装包，手动进行安装。

三、使用方法

nettrace 是用来跟踪内核报文和诊断网络故障的，在进行报文跟踪时可以使用一定的过滤条件来跟踪特定的报文。其基本命令行参数为：

$ nettrace -h
nettrace: a tool to trace skb in kernel and diagnose network problem


Usage:
    -s, --saddr      filter source ip address
    --saddr6         filter source ip v6 address
    -d, --daddr      filter dest ip address
    --daddr6         filter dest ip v6 address
    --addr           filter source or dest ip address
    --addr6          filter source or dest ip v6 address
    -S, --sport      filter source TCP/UDP port
    -D, --dport      filter dest TCP/UDP port
    -P, --port       filter source or dest TCP/UDP port
    -p, --proto      filter L3/L4 protocol, such as 'tcp', 'arp'
    --pid            filter by current process id(pid)
    -t, --trace      enable trace group or trace
    --ret            show function return value
    --detail         show extern packet info, such as pid, ifname, etc
    --date           print timestamp in date-time format
    --basic          use 'basic' trace mode, don't trace skb's life
    --diag           enable 'diagnose' mode
    --diag-quiet     only print abnormal packet
    --diag-keep      don't quit when abnormal packet found
    --hooks          print netfilter hooks if dropping by netfilter
    --drop           skb drop monitor mode, for replace of 'droptrace'
    --drop-stack     print the kernel function call stack of kfree_skb


    -v               show log information
    --debug          show debug information
    -h, --help       show help information

其中，参数 s/d/addr/S/D/port/p/pid
用于进行报文的过滤，可以通过 IP 地址、端口、协议等属性进行过滤。其他参数的用途包括：

t/trace
：要启用的跟踪模块，默认启用所有
ret
：跟踪和显示内核函数的返回值
detail
：显示跟踪详细信息，包括当前的进程、网口和 CPU 等信息
date
：以时间格式打印（以 2022-10-24 xx:xx:xx.xxxxxx 格式打印），而不是时间戳
basic
：启用 basic
跟踪模式。默认情况下，启用的是生命周期跟踪模式。启用该模式后，会直接打印出报文所经过的内核函数 tracepoint。
diag
：启用诊断模式
diag-quiet
：只显示出现存在问题的报文，不显示正常的报文
diag-keep
：持续跟踪。diag
模式下，默认在跟踪到异常报文后会停止跟踪，使用该参数后，会持续跟踪下去。
hooks
：结合 netfilter 做的适配，详见下文
drop
：进行系统丢包监控，取代原先的 droptrace
drop-stack
: 打印 kfree_skb 内核函数的调用堆栈

下面我们首先来看一下默认模式下的工具使用方法。

生命周期

默认情况下，nettrace
会跟踪报文从进入到内核协议栈到离开（销毁）的过程。对于有一定内核网络经验的人来说，可以通过报文的内核路径来快速推断出当前的网络问题，达到快速定位的目的。

1.1 跟踪ping报文

sudo ./nettrace -p icmp
begin trace...
***************** ffff889be8fbd500,ffff889be8fbcd00 ***************
[1272349.614564] [dev_gro_receive     ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614579] [__netif_receive_skb_core] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614585] [ip_rcv              ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614592] [ip_rcv_core         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614599] [skb_clone           ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614616] [nf_hook_slow        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614629] [nft_do_chain        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614635] [ip_rcv_finish       ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614643] [ip_route_input_slow ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614647] [fib_validate_source ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614652] [ip_local_deliver    ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614658] [nf_hook_slow        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614663] [ip_local_deliver_finish] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614666] [icmp_rcv            ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614671] [icmp_echo           ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614675] [icmp_reply          ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614715] [consume_skb         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614722] [packet_rcv          ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220
[1272349.614725] [consume_skb         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 48220


***************** ffff889be8fbde00 ***************
[1272349.614681] [nf_hook_slow        ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614688] [ip_output           ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614690] [nf_hook_slow        ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614693] [ip_finish_output    ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614697] [ip_finish_output2   ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614705] [__dev_queue_xmit    ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272349.614709] [dev_hard_start_xmit ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220
[1272351.286866] [consume_skb         ] ICMP: 172.27.0.6 -> 169.254.128.15 ping reply, seq: 48220

上面的*中间的表示当前所跟踪的 skb 的地址，由于当前的报文被克隆过，因此当前跟踪上下文存在两个报文。

1.2 指定过滤条件

sudo ./nettrace -p icmp --saddr 169.254.128.15
begin trace...
***************** ffff889be8fbc700,ffff889be8fbdc00 ***************
[1273445.360831] [dev_gro_receive     ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360844] [__netif_receive_skb_core] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360847] [ip_rcv              ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360850] [ip_rcv_core         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360854] [skb_clone           ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360861] [nf_hook_slow        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360868] [nft_do_chain        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360875] [ip_rcv_finish       ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360878] [ip_route_input_slow ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360882] [fib_validate_source ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360887] [ip_local_deliver    ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360890] [nf_hook_slow        ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360895] [ip_local_deliver_finish] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360899] [icmp_rcv            ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360903] [icmp_echo           ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360908] [icmp_reply          ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360922] [consume_skb         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360930] [packet_rcv          ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754
[1273445.360933] [consume_skb         ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 54754

1.3 显示详细信息

sudo ./nettrace -p icmp --saddr 169.254.128.15 --detail
begin trace...
***************** ffff889be8fbcd00,ffff889be8fbcc00 ***************
[1273732.110173] [ffff889be8fbcd00][dev_gro_receive     ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110185] [ffff889be8fbcd00][__netif_receive_skb_core][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110189] [ffff889be8fbcd00][ip_rcv              ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110192] [ffff889be8fbcd00][ip_rcv_core         ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110196] [ffff889be8fbcd00][skb_clone           ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110204] [ffff889be8fbcc00][nf_hook_slow        ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110211] [ffff889be8fbcc00][nft_do_chain        ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110222] [ffff889be8fbcc00][ip_rcv_finish       ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110229] [ffff889be8fbcc00][ip_route_input_slow ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110234] [ffff889be8fbcc00][fib_validate_source ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110240] [ffff889be8fbcc00][ip_local_deliver    ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110243] [ffff889be8fbcc00][nf_hook_slow        ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110252] [ffff889be8fbcc00][ip_local_deliver_finish][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110255] [ffff889be8fbcc00][icmp_rcv            ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110260] [ffff889be8fbcc00][icmp_echo           ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110267] [ffff889be8fbcc00][icmp_reply          ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110283] [ffff889be8fbcc00][consume_skb         ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110291] [ffff889be8fbcd00][packet_rcv          ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464
[1273732.110294] [ffff889be8fbcd00][consume_skb         ][cpu:40 ][ens5 ][pid:0      ][swapper/40  ] ICMP: 169.254.128.15 -> 172.27.0.6 ping request, seq: 56464

可以看到，每个报文的地址、所在 CPU、网口和进程信息都被打印了出来。

1.4 NAT 跟踪

在对报文进行跟踪时，一旦报文被跟踪起来（命中过滤条件），那么这个报文即使内容发生了变化也会持续被跟踪，知道报文被释放。下面是 NAT 场景下的跟踪，可以看到报文的源地址由 192.168.122.8
通过 SNAT 被修改成了 9.135.224.89
，但是报文依然被跟踪到了：

$ sudo ./nettrace -p icmp --addr 192.168.122.8
begin tracing......
<------------------- skb: ffff88818f02f900 ---------------------->
463697.331957: [__netif_receive_skb_core]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.331972: [nf_hook_slow            ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.331985: [nf_hook_slow            ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.331990: [__netif_receive_skb_core]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.331994: [ip_rcv                  ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.331998: [ip_rcv_core             ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332001: [nf_hook_slow            ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332004: [ip_rcv_finish           ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332010: [ip_forward              ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332014: [nf_hook_slow            ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332024: [ip_output               ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332027: [nf_hook_slow            ]: ICMP: 192.168.122.8 -> 10.123.119.98, ping request   , seq: 0
463697.332037: [ip_finish_output        ]: ICMP: 9.135.224.89  -> 10.123.119.98, ping request   , seq: 0
463697.332039: [ip_finish_output2       ]: ICMP: 9.135.224.89  -> 10.123.119.98, ping request   , seq: 0
463697.332042: [dev_queue_xmit          ]: ICMP: 9.135.224.89  -> 10.123.119.98, ping request   , seq: 0
463697.332046: [dev_hard_start_xmit     ]: ICMP: 9.135.224.89  -> 10.123.119.98, ping request   , seq: 0
463697.332060: [consume_skb             ]: ICMP: 9.135.224.89  -> 10.123.119.98, ping request   , seq: 0

诊断模式

使用方式与上面的一致，加个 diag
参数即可使用诊断模式。上文的生命周期模式对于使用者的要求比较高，需要了解内核协议栈各个函数的用法、返回值的意义等，易用性较差。诊断模式是在生命周期模式的基础上，提供了更加丰富的信息，使得没有网络开发经验的人也可进行复杂网络问题的定位和分析。

2.1 基本用法

下面是使用诊断模式进行报文跟踪的用法，可以看出来相比于普通模式，诊断模式提供了更多的可供参考的信息，包括当前报文经过了 iptables 的哪些表和哪些链、报文发生了 NAT、报文被克隆了等。诊断模式设置了三种提示级别：

INFO
：正常的信息提示
WARN
：警告信息，该报文可能存在一定的问题，需要关注
ERROR
：异常信息，报文发生了问题（比如被丢弃）。

./nettrace -p icmp --diag --saddr 192.168.122.8
begin trace...
***************** ffff889fad356200 ***************
[3445.575957] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.575978] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: PRE_ROUTING*
[3445.575990] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:nat, chain:PREROUT* *packet is accepted*
[3445.576005] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *bridge in chain: PRE_ROUTING*
[3445.576014] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576024] [ip_rcv              ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576029] [ip_rcv_core         ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576040] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: PRE_ROUTING*
[3445.576044] [ip_rcv_finish       ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576052] [ip_route_input_slow ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576061] [fib_validate_source ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576080] [ip_forward          ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576084] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: FORWARD*
[3445.576087] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:filter, chain:FORWARD* *packet is accepted*
[3445.576107] [ip_output           ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[3445.576113] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: POST_ROUTING*
[3445.576116] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:nat, chain:POSTROU* *packet is accepted*
[3445.576131] [nf_nat_manip_pkt    ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *NAT happens (packet address will change)*
[3445.576148] [ip_finish_output    ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0
[3445.576152] [ip_finish_output2   ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0
[3445.576158] [__dev_queue_xmit    ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0
[3445.576165] [netdev_core_pick_tx ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0
[3445.576177] [dev_hard_start_xmit ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0
[3445.576215] [consume_skb         ] ICMP: 192.168.255.10 -> 10.123.119.98 ping request, seq: 0 *packet is freed (normally)*
---------------- ANALYSIS RESULT ---------------------
[1] WARNING happens in nf_nat_manip_pkt(netfilter):
        NAT happens (packet address will change)

如果当前报文存在 ERROR
，那么工具会给出一定的诊断修复建议，并终止当前诊断操作。通过添加 diag-keep
可以在发生 ERROR
事件时不退出，继续进行跟踪分析。下面是发生异常时的日志：

./nettrace -p icmp --diag --saddr 192.168.122.8
begin trace...
***************** ffff889fb3c64f00 ***************
[4049.295546] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295566] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: PRE_ROUTING*
[4049.295578] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:nat, chain:PREROUT* *packet is accepted*
[4049.295594] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *bridge in chain: PRE_ROUTING*
[4049.295612] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295624] [ip_rcv              ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295629] [ip_rcv_core         ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295640] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: PRE_ROUTING*
[4049.295644] [ip_rcv_finish       ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295655] [ip_route_input_slow ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295664] [fib_validate_source ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295683] [ip_forward          ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[4049.295687] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: FORWARD* *packet is dropped by netfilter (NF_DROP)*
[4049.295695] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:filter, chain:FORWARD* *packet is dropped by iptables/iptables-nft*
[4049.295711] [kfree_skb           ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *packet is dropped by kernel*
---------------- ANALYSIS RESULT ---------------------
[1] ERROR happens in nf_hook_slow(netfilter):
        packet is dropped by netfilter (NF_DROP)
    fix advice:
        check your netfilter rule


[2] ERROR happens in nft_do_chain(netfilter):
        packet is dropped by iptables/iptables-nft
    fix advice:
        check your iptables rule


[3] ERROR happens in kfree_skb(life):
        packet is dropped by kernel
    location:
        nf_hook_slow+0x96
    drop reason:
        NETFILTER_DROP


analysis finished!


end trace...

从这里的日志可以看出，在报文经过 iptables 的 filter 表的 forward 链的时候，发生了丢包。在诊断结果里，会列出所有的异常事件，一个报文跟踪可能会命中多条诊断结果。这里的诊断建议是让用户检查 iptables 中的规则是否存在问题。

其中，kfree_skb
这个跟踪点是对 drop reason
内核特性做了适配的，可以理解为将 droptrace 的功能集成到了这里的诊断结果中，这里可以看出其给出的对包原因是 NETFILTER_DROP
。

2.2 netfilter支持

网络防火墙是网络故障、网络不同发生的重灾区，因此 netfilter
工具对 netfilter
提供了完美适配，包括老版本的 iptables-legacy
和新版本的 iptables-nft
。诊断模式下，nettrace
能够跟踪报文所经过的 iptables
表和 iptables
链，并在发生由于 iptables 导致的丢包时给出一定的提示，上面的示例充分展现出了这部分。

除了对 iptables 的支持，nettrace
对整个 netfilter 大模块也提供了支持，能够显示在经过每个 HOOK 点时对应的协议族和链的名称。除此之外，为了应对一些注册到 netfilter 中的第三方内核模块导致的丢包问题，nettrace 还可以通过添加参数 hooks
来打印出当前 HOOK
上所有的的钩子函数，从而深入分析问题：

./nettrace -p icmp --diag --saddr 192.168.122.8 --hooks
begin trace...
***************** ffff889faa054500 ***************
[5810.702473] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702491] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *ipv4 in chain: PRE_ROUTING*
[5810.702504] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *iptables table:nat, chain:PREROUT* *packet is accepted*
[5810.702519] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *bridge in chain: PRE_ROUTING*
[5810.702527] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702535] [ip_rcv              ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702540] [ip_rcv_core         ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702546] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *ipv4 in chain: PRE_ROUTING*
[5810.702551] [ip_rcv_finish       ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702556] [ip_route_input_slow ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702565] [fib_validate_source ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702579] [ip_forward          ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943
[5810.702583] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *ipv4 in chain: FORWARD* *packet is dropped by netfilter (NF_DROP)*
[5810.702586] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *iptables table:filter, chain:FORWARD* *packet is dropped by iptables/iptables-nft*
[5810.702599] [kfree_skb           ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 943 *packet is dropped by kernel*
---------------- ANALYSIS RESULT ---------------------
[1] ERROR happens in nf_hook_slow(netfilter):
        packet is dropped by netfilter (NF_DROP)


    following hook functions are blamed:
        nft_do_chain_ipv4


    fix advice:
        check your netfilter rule


[2] ERROR happens in nft_do_chain(netfilter):
        packet is dropped by iptables/iptables-nft
    fix advice:
        check your iptables rule


[3] ERROR happens in kfree_skb(life):
        packet is dropped by kernel
    location:
        nf_hook_slow+0x96
    drop reason:
        NETFILTER_DROP


analysis finished!


end trace...

可以看出，上面 following hook functions are blamed
中列出了导致当前 netfilter
丢包的所有的钩子函数，这里只有 iptables
一个钩子函数。

2.3 其他场景

由于对 drop reason
内核特性进行了适配，因此对于支持 drop reason
的系统，基于 drop reason
本工具可以诊断 70+ 种丢包问题。nettrace
通过将网络诊断经验翻译成规则存储到规则库的方式来进行诊断分析，通过扩充规则配置文件的方式能够不断增强其诊断功能。目前，本工具已经集成了 20+ 典型网络故障诊断功能，并且在实践中不断完善知识库（规则库）。

端口未监听导致的丢包：

./nettrace --diag --diag-quiet
begin trace...
***************** ffff888f97730ee0 ***************
[365673.326016] [ip_output           ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326026] [ip_finish_output    ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326029] [ip_finish_output2   ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326032] [__dev_queue_xmit    ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326039] [dev_hard_start_xmit ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326042] [enqueue_to_backlog  ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326051] [__netif_receive_skb_core] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326059] [ip_rcv              ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326061] [ip_rcv_core         ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326068] [ip_rcv_finish       ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326072] [ip_local_deliver    ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326075] [ip_local_deliver_finish] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326078] [tcp_v4_rcv          ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326084] [__inet_lookup_listener] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S *tcp port is not listened*
[365673.326090] [tcp_v4_send_reset   ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S
[365673.326125] [kfree_skb           ] TCP: 127.0.0.1:40392 -> 127.0.0.1:9999 seq:3067626996, ack:0, flags:S *packet is dropped by kernel*
---------------- ANALYSIS RESULT ---------------------
[1] WARNING happens in __inet_lookup_listener(tcp-in):
        tcp port is not listened
    fix advice:
        check your target tcp port


[2] ERROR happens in kfree_skb(life):
        packet is dropped by kernel
    location:
        tcp_v4_rcv+0x4a

XDP 导致的丢包（XDP 转发会给提示）：

./nettrace -p icmp --diag --diag-quiet
begin trace...
***************** ffff889f015acc00 ***************
[18490.607809] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[18490.607828] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *ipv4 in chain: PRE_ROUTING*
[18490.607840] [nft_do_chain        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *iptables table:nat, chain:PREROUT* *packet is accepted*
[18490.607855] [nf_hook_slow        ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *bridge in chain: PRE_ROUTING*
[18490.607874] [__netif_receive_skb_core] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0
[18490.607882] [netif_receive_generic_xdp] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *packet is dropped by XDP program*
[18490.607888] [kfree_skb           ] ICMP: 192.168.122.8 -> 10.123.119.98 ping request, seq: 0 *packet is dropped by kernel*
---------------- ANALYSIS RESULT ---------------------
[1] ERROR happens in netif_receive_generic_xdp(link-in):
        packet is dropped by XDP program
    fix advice:
        check your XDP eBPF program


[2] ERROR happens in kfree_skb(life):
        packet is dropped by kernel
    location:
        netif_receive_generic_xdp+0x259
    drop reason:
        NOT_SPECIFIED


analysis finished!

丢包监控

使用命令 nettrace --drop
可以对系统中的丢包事件进行监控，对于支持内核特性 skb drop reason
的内核，这里还会打印出丢包原因。可以通过查看 /tracing/events/skb/kfree_skb/format
来判断当前系统是否支持该特性：

cat tracing/events/skb/kfree_skb/format
name: kfree_skb
ID: 1524
format:
        field:unsigned short common_type;       offset:0;       size:2; signed:0;
        field:unsigned char common_flags;       offset:2;       size:1; signed:0;
        field:unsigned char common_preempt_count;       offset:3;       size:1; signed:0;
        field:int common_pid;   offset:4;       size:4; signed:1;


        field:void * skbaddr;   offset:8;       size:8; signed:0;
        field:void * location;  offset:16;      size:8; signed:0;
        field:unsigned short protocol;  offset:24;      size:2; signed:0;
        field:enum skb_drop_reason reason;      offset:28;      size:4; signed:0;


print fmt: "skbaddr=%p protocol=%u location=%p reason: %s", REC->skbaddr, REC->protocol, REC->location, __print_symbolic(REC->reason, { 1, "NOT_SPECIFIED" }, { 2, "NO_SOCKET" }, { 3, "PKT_TOO_SMALL" }, { 4, "TCP_CSUM" }, { 5, "SOCKET_FILTER" }, { 6, "UDP_CSUM" }, { 7, "NETFILTER_DROP" }, { 8, "OTHERHOST" }, { 9, "IP_CSUM" }, { 10, "IP_INHDR" }, { 11, "IP_RPFILTER" }, { 12, "UNICAST_IN_L2_MULTICAST" }, { 13, "XFRM_POLICY" }, { 14, "IP_NOPROTO" }, { 15, "SOCKET_RCVBUFF" }, { 16, "PROTO_MEM" }, { 17, "TCP_MD5NOTFOUND" }, { 18, "TCP_MD5UNEXPECTED" }, { 19, "TCP_MD5FAILURE" }, { 20, "SOCKET_BACKLOG" }, { 21, "TCP_FLAGS" }, { 22, "TCP_ZEROWINDOW" }, { 23, "TCP_OLD_DATA" }, { 24, "TCP_OVERWINDOW" }, { 25, "TCP_OFOMERGE" }, { 26, "TCP_RFC7323_PAWS" }, { 27, "TCP_INVALID_SEQUENCE" }, { 28, "TCP_RESET" }, { 29, "TCP_INVALID_SYN" }, { 30, "TCP_CLOSE" }, { 31, "TCP_FASTOPEN" }, { 32, "TCP_OLD_ACK" }, { 33, "TCP_TOO_OLD_ACK" }, { 34, "TCP_ACK_UNSENT_DATA" }, { 35, "TCP_OFO_QUEUE_PRUNE" }, { 36, "TCP_OFO_DROP" }, { 37, "IP_OUTNOROUTES" }, { 38, "BPF_CGROUP_EGRESS" }, { 39, "IPV6DISABLED" }, { 40, "NEIGH_CREATEFAIL" }, { 41, "NEIGH_FAILED" }, { 42, "NEIGH_QUEUEFULL" }, { 43, "NEIGH_DEAD" }, { 44, "TC_EGRESS" }, { 45, "QDISC_DROP" }, { 46, "CPU_BACKLOG" }, { 47, "XDP" }, { 48, "TC_INGRESS" }, { 49, "UNHANDLED_PROTO" }, { 50, "SKB_CSUM" }, { 51, "SKB_GSO_SEG" }, { 52, "SKB_UCOPY_FAULT" }, { 53, "DEV_HDR" }, { 54, "DEV_READY" }, { 55, "FULL_RING" }, { 56, "NOMEM" }, { 57, "HDR_TRUNC" }, { 58, "TAP_FILTER" }, { 59, "TAP_TXFILTER" }, { 60, "ICMP_CSUM" }, { 61, "INVALID_PROTO" }, { 62, "IP_INADDRERRORS" }, { 63, "IP_INNOROUTES" }, { 64, "PKT_TOO_BIG" }, { 65, "MAX" })

该模式下使用的效果与原先的 droptrace
完全相同，如下所示：

nettrace --drop
begin trace...
[142.097193] TCP: 162.241.189.135:57022 -> 172.27.0.6:22 seq:299038593, ack:3843597961, flags:AR, reason: NOT_SPECIFIED, tcp_v4_rcv+0x81
[142.331798] TCP: 162.241.189.135:57022 -> 172.27.0.6:22 seq:299038593, ack:3843597961, flags:A, reason: NOT_SPECIFIED, tcp_v4_do_rcv+0x83
[142.331857] TCP: 162.241.189.135:57022 -> 172.27.0.6:22 seq:299038593, ack:3843597961, flags:AP, reason: NOT_SPECIFIED, tcp_v4_do_rcv+0x83
[146.136576] TCP: 127.0.0.1:43582 -> 127.0.0.1:9999 seq:3819454691, ack:0, flags:S, reason: NO_SOCKET, tcp_v4_rcv+0x81
[146.220414] TCP: 169.254.0.138:8186 -> 172.27.0.6:40634 seq:8486084, ack:2608831141, flags:A, reason: TCP_INVALID_SEQUENCE, tcp_validate_incoming+0x126
[146.533728] TCP: 127.0.0.1:36338 -> 127.0.0.1:56100 seq:1110580666, ack:1951926207, flags:A, reason: TCP_INVALID_SEQUENCE, tcp_validate_incoming+0x126
[147.255946] TCP: 20.44.10.122:443 -> 192.168.255.10:42878 seq:2950381253, ack:211751623, flags:A, reason: NOT_SPECIFIED, tcp_rcv_state_process+0xe9

同样可以使用 man dropreason 命令来查看对应的丢包原因的详细解释。对于不支持 skb drop reason 特性的内核，该模式下将不会打印丢包原因字段，效果如下所示：

nettrace --drop
begin trace...
[2016.965295] TCP: 162.241.189.135:45432 -> 172.27.0.6:22 seq:133152310, ack:2529234288, flags:AR, tcp_v4_rcv+0x50
[2017.201315] TCP: 162.241.189.135:45432 -> 172.27.0.6:22 seq:133152310, ack:2529234288, flags:A, tcp_v4_do_rcv+0x70
[2019.041344] TCP: 176.58.124.134:37441 -> 172.27.0.6:443 seq:1160140493, ack:0, flags:S, tcp_v4_rcv+0x50
[2021.867340] TCP: 127.0.0.1:34936 -> 127.0.0.1:9999 seq:1309795878, ack:0, flags:S, tcp_v4_rcv+0x50
[2024.997146] TCP: 162.241.189.135:46756 -> 172.27.0.6:22 seq:1304582308, ack:1354418612, flags:AR, tcp_v4_rcv+0x50
[2025.235953] TCP: 162.241.189.135:46756 -> 172.27.0.6:22 seq:1304582308, ack:1354418612, flags:A, tcp_v4_do_rcv+0x70
[2025.235967] TCP: 162.241.189.135:46756 -> 172.27.0.6:22 seq:1304582308, ack:1354418612, flags:AP, tcp_v4_do_rcv+0x70

四、小结

nettrace工具自上线 OpenCloud 社区以来，受到了业界的广泛关注，并在 OpenCloudOS 的网络故障诊断中得到了大量应用。特别是复杂的云原生网络环境中，nettrace 工具通过报文跟踪、网络诊断的方式为用户解决了多次疑难网络问题。

同时，nettrace与 OpenCloudOS 进行了完美的兼容和适配，并上架了 OpenCloudOS 的软件仓库，使得 OpenCloudOS 用户可以很方便地直接使用 yum 命令来进行安装和使用。

本月，OpenCloudOS 源社区 2301 版本已发布，拥有更多技术新特性，欢迎开发者下载使用。

OpenCloudOS ISO 下载地址：https://www.opencloudos.org/iso（亦可选用腾讯云上V8即8.6最新版）

如果在使用过程中遇到技术问题，扫描下方二维码，加入社区用户群，即可了解 OpenCloudOS 最新动态，获取技术相关的支持，分享交流使用体验。

相关链接

droptrace：https://github.com/OpenCloudOS/nettrace/blob/master/docs/droptrace.md
OpenCloudOS release 页面：https://github.com/OpenCloudOS/nettrace/releases
OpenCloudOS 社区官网：https://www.opencloudos.org

文章转载自OpenCloudOS，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。
