MYSQL 大页内存+锁定内存

海鲨数据库架构师 2022-12-11

429

前提知识文章

如何锁定MYSQL内存在物理内存里?
探索MYSQL开启大页内存
 MYSQL locked_in_memory
Linux 64 页表，进程内存，大页
 Linux 关闭透明大页

第一步配置

1 设置好内存大小避免内存溢出

[mysqld]
#Global Memon Set###
innodb_buffer_pool_size = 2048M
innodb_log_buffer_size = 16M
key_buffer_size = 8M


###innodb buffer subordinate
innodb_sort_buffer_size = 4M  #插入排序 1M
innodb_ddl_buffer_size = 4M


innodb_buffer_pool_dump_at_shutdown = ON
innodb_buffer_pool_load_at_startup  = ON
innodb_adaptive_hash_index = OFF
large-pages #开启大页 (2048+16+8)/2=1036 Pages
memlock     #4K PAGES LOCK MEMORY
max_connections=500
#### Thread Memon Set 8+8+8+8+16+16+8+1=73M+1=74MB PGA
##PGA CACHE 74*32=2368+8(32*256K)=2376MB
join_buffer_size=8388608  #8M
sort_buffer_size=8388608   #8M
read_buffer_size=8388608    #8M
read_rnd_buffer_size=8388608  #8M
net_buffer_length = 16384    #16K max 1M
tmp_table_size   =16777216   #16M
binlog_cache_size =16777216   #16M
bulk_insert_buffer_size=8388608  #8M
thread_cache_size                  = 32
thread_stack                       = 256K


sync_binlog                        = 1
innodb_flush_log_at_trx_commit     = 1
innodb_flush_method=o_direct


##PS内存 不好统计
#performance_schema_max_sql_text_length=1024  #SQL 最大长度
#performance_schema_max_digest_length=1024     #SQL数字化后长度
#performance_schema_events_statements_history_long_size=10000 #全库SQL最近1万条 这里的SQL_TEXT,DIGEST_TEXT属于静态分配 LENGTH*SIZE
#performance_schema_events_statements_history_size=100 #每个线程最近100条 注意线程数量
#performance_schema_digests_size=100000                #数字化后保存10万条
performance_schema=ON
performance_schema_events_statements_history_size=100
performance_schema_events_statements_history_long_size=10000
performance_schema_digests_size=100000
performance_schema_max_sql_text_length=1024
performance_schema_max_digest_length=1024

#配置大页参数 my.cnf

[mysqld]
large-pages

2 配置LINUX内核参数

设置内核参数kernel.shmmax和kernel.shmall

shmmax是最大的共享内存段的大小，单位是字节，默认32M

shmall是共享内存的总大小，单位是页

vim etc/sysctl.conf

#-- kernel.shmmni这个内核参数用于设置系统范围内共享内存段的最大数量。该参数的默认值是 4096.
#-- kernel.shmall 控制共享内存页数
#-- kernel.shmmax 单个共享内存段的最大尺寸，设置为物理内存的 50%
#-- Increase total amount of shared memory.  The value
#-- is the number of pages. At 4KB/page, 4194304 = 16GB.
#--echo 4194304 > proc/sys/kernel/shmall
#--对于mysql的使用，最好是shmmax与shmall接近
#--7168MB
kernel.shmmax = 7516192768
kernel.shmall = 1835008
kernel.shmmni = 4096
vm.hugetlb_shm_group =27 #--MYSQL 所在的用户组ID
vm.nr_hugepages=2290      ##--持久化大页内存数量

3.修改ulimit

使用ulimit -l或设置/etc/security/limits.conf

vim etc/security/limits.conf
@mysql soft memlock unlimited
@mysql hard memlock unlimited

4 通过 id mysql 获取mysql所在的group id

[root@localhost ~]# id mysql
uid=27(mysql) gid=27(mysql) groups=27(mysql)


echo 27 > proc/sys/vm/hugetlb_shm_group
[root@localhost ~]#  sysctl -w vm.hugetlb_shm_group=27
vm.hugetlb_shm_group = 27

5 动态设置分配大页内存:

echo 1040 > proc/sys/vm/nr_hugepages

6 测试动态启动大页
(大页内存不会被其它进程使用,规划化太多会导致LINUX系统本身不够用)

[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821         158        5985          33        1676        6962
Swap:          8063         174        7889
[root@localhost admin_mapper]# echo 1040 > proc/sys/vm/nr_hugepages
[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        2238        3905          33        1676        4883
Swap:          8063         174        7889
# 1040*2+158=2238

第二实验

1 空初始

[root@localhost admin_mapper]# echo 0 > proc/sys/vm/nr_hugepages
[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821         157        6018          33        1645        6964
Swap:          8063         174        7889
[root@localhost admin_mapper]# cat proc/meminfo |grep -E "Huge|Mlocked|Page"
Mlocked:               0 kB
AnonPages:         40388 kB
PageTables:         3228 kB
AnonHugePages:         0 kB
HugePages_Total:       0
HugePages_Free:        0
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB

2 启动默认设置的MYSQL

[root@localhost admin_mapper]# echo 0 > proc/sys/vm/nr_hugepages
[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        1295        4848          33        1677        5825
Swap:          8063         174        7889




[root@localhost admin_mapper]# cat proc/meminfo |grep -E "Huge|Mlocked|Page"
Mlocked:               0 kB
AnonPages:       1205588 kB
PageTables:         6132 kB
AnonHugePages:         0 kB
HugePages_Total:       0
HugePages_Free:        0
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB
[root@localhost ~]#  cat  proc/$(pidof mysqld)/oom_score
62

# 1这里使用普通模式页表(PageTables)占用6132-3228=2904KB,

# 2物理内存占用1295-157=1138MB 这里的物理内存是启动分配的,随着负载增加而动态增长

# 3 OOM得分为62

3 启动锁物理内存的MYSQL

[root@localhost ~]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        3535        2831          33        1454        3523
Swap:          8063         174        7889




[root@localhost ~]# cat proc/meminfo
MemTotal:        8008964 kB
MemFree:         2899516 kB
MemAvailable:    3608024 kB
Mlocked:         3501712 kB
PageTables:        10524 kB
HugePages_Total:       0
HugePages_Free:        0
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB
DirectMap4k:       90076 kB
DirectMap2M:     3055616 kB
DirectMap1G:     7340032 kB




[root@localhost ~]# cat  proc/$(pidof mysqld)/oom_score
210

## 这里物理内存使用 3535-157=3221 这么说来使用MEMLOCK参数,会全部分配INNODB BUFFER

## 页表达到 10524KB 10524-3228=7296 =7MB

# 3 OOM得分为210

4 启动大页和锁的MYSQL

[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        2238        3905          33        1676        4883
Swap:          8063         174        7889




[root@localhost ~]# service mysqld start
Redirecting to bin/systemctl start mysqld.service

mysql> SELECT * FROM sys.memory_global_total;
+-----------------+
| total_allocated |
+-----------------+
| 2.90 GiB        |
+-----------------+
1 row in set (0.00 sec)

mysql> SELECT event_name,current_alloc FROM sys.memory_global_by_current_bytes limit 16;
+------------------------------------------------------------------------------+---------------+
| event_name                                                                   | current_alloc |
+------------------------------------------------------------------------------+---------------+
| memory/innodb/buf_buf_pool                                                   | 2.04 GiB      |
| memory/performance_schema/events_statements_summary_by_digest                | 396.73 MiB    |
| memory/performance_schema/events_statements_summary_by_digest.digest_text    | 97.66 MiB     |
| memory/innodb/hash0hash                                                      | 57.43 MiB     |
| memory/performance_schema/events_statements_history                          | 35.55 MiB     |
| memory/performance_schema/events_statements_history.sql_text                 | 25.00 MiB     |
| memory/performance_schema/events_statements_history.digest_text              | 25.00 MiB     |
| memory/innodb/ut0link_buf                                                    | 24.00 MiB     |
| memory/performance_schema/events_statements_history_long                     | 13.89 MiB     |
| memory/performance_schema/events_errors_summary_by_thread_by_error           | 12.52 MiB     |
| memory/performance_schema/events_statements_summary_by_thread_by_event_name  | 10.20 MiB     |
| memory/performance_schema/events_statements_history_long.digest_text         | 9.77 MiB      |
| memory/performance_schema/events_statements_history_long.sql_text            | 9.77 MiB      |
| memory/performance_schema/memory_summary_by_thread_by_event_name             | 9.32 MiB      |
| memory/performance_schema/table_handles                                      | 9.06 MiB      |
| memory/mysys/KEY_CACHE                                                       | 8.00 MiB      |
+------------------------------------------------------------------------------+---------------+
16 rows in set (0.00 sec)

mysql> select sys.format_bytes (sum(current_alloc)) from sys.x$memory_global_by_current_bytes where  event_name like 'memory/performance_schema%';
+---------------------------------------+
| sys.format_bytes (sum(current_alloc)) |
+---------------------------------------+
| 750.22 MiB                            |
+---------------------------------------+
1 row in set, 1 warning (0.00 sec)

[root@localhost admin_mapper]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        3793        2350          33        1677        3262
Swap:          8063         174        7889




[root@localhost admin_mapper]# cat proc/meminfo |grep -E "Huge|Mlocked|Page"
Mlocked:         1641060 kB
AnonPages:       1632036 kB
PageTables:         6856 kB
AnonHugePages:         0 kB
HugePages_Total:    1040
HugePages_Free:       50
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB




[root@localhost ~]# cat  proc/$(pidof mysqld)/oom_score
90

#启动大页MYSQL后非大页内存使用1555MB 3793-2238=1555MB

#大页消耗大部分,只剩50个页约100MB 使用 1980MB

#Mlocked: 1641060 kB 1602.59MB

#页表消耗 6856-3228=3628KB=3.54MB

# OOM 得分降低到90

5 加大大页内数量

mysql> show variables like '%heap%';
+---------------------+----------+
| Variable_name       | Value    |
+---------------------+----------+
| max_heap_table_size | 16777216 |
+---------------------+----------+
1 row in set (0.00 sec)




mysql> select sys.format_bytes (sum(current_alloc)) from sys.x$memory_global_by_current_bytes where  event_name like 'memory/performance_schema%';
+---------------------------------------+
| sys.format_bytes (sum(current_alloc)) |
+---------------------------------------+
| 750.22 MiB                            |
+---------------------------------------+
1 row in set, 1 warning (0.00 sec)


[mysqld]
#Global Memon Set###
innodb_buffer_pool_size = 2048M
innodb_log_buffer_size = 16M
key_buffer_size = 8M
max_heap_table_size =16M


#2838/2=1419
[root@localhost ~]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821         158        6203          33        1459        6966
Swap:          8063         174        7889
[root@localhost admin_mapper]# echo 1419 > proc/sys/vm/nr_hugepages
[root@localhost ~]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        2997        3364          33        1459        4127
Swap:          8063         174        7889
[root@localhost ~]# cat proc/meminfo | grep Huge
AnonHugePages:         0 kB
HugePages_Total:    1419
HugePages_Free:     1419
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB




[root@localhost ~]# service mysqld start
Redirecting to bin/systemctl start mysqld.service




[root@localhost ~]# free -m
              total        used        free      shared  buff/cache   available
Mem:           7821        4277        2083          33        1459        2781
Swap:          8063         174        7889
[root@localhost ~]# cat proc/meminfo | grep Huge
AnonHugePages:         0 kB
HugePages_Total:    1419
HugePages_Free:      363
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB




[root@localhost ~]# cat proc/meminfo | grep Mlock
Mlocked:         1360332 kB
[root@localhost ~]#  cat  proc/$(pidof mysqld)/oom_score
82


top -p 3267
  PID USER      PR  NI    VIRT    RES    SHR S  %CPU %MEM     TIME+ COMMAND
 3267 root      20   0 5532860   1.3g  67248 S   0.7 17.3   0:10.85 mysqld

mysql> select event_name,current_alloc from sys.memory_global_by_current_bytes limit 20;


+------------------------------------------------------------------------------+---------------+
| event_name                                                                   | current_alloc |
+------------------------------------------------------------------------------+---------------+
| memory/innodb/buf_buf_pool                                                   | 2.06 GiB      |
| memory/performance_schema/events_statements_summary_by_digest                | 396.73 MiB    |
| memory/performance_schema/events_statements_summary_by_digest.digest_text    | 97.66 MiB     |
| memory/innodb/hash0hash                                                      | 57.43 MiB     |
| memory/innodb/ut0link_buf                                                    | 24.00 MiB     |
| memory/performance_schema/events_statements_summary_by_thread_by_event_name  | 10.20 MiB     |


mysql> select sys.format_bytes (sum(current_alloc)) from sys.x$memory_global_by_current_bytes where  event_name like 'memory/performance_schema%';
+---------------------------------------+
| sys.format_bytes (sum(current_alloc)) |
+---------------------------------------+
| 606.74 MiB                            |
+---------------------------------------+
1 row in set, 1 warning (0.08 sec)

#分析除了PS内存降低了150M 主要是HISTORY_SIZE 回归1000行的结果

#物理内存4277-2997=1280MB

#top 物理内存1.3G显示那些无法放进共享大页内存的和线程级别的内存.

#大页内存有363页空闲等于726MB没有被使用,使用了2112 MB .

#MEMLOCK 锁定物理内存1328MB,多锁了48MB内存.

对比第四个实验

1 物理内存小页使用 1555MB 这里是1280MB 1555-1280=275 物理内存少了275MB

2 MEMLOCK 1602.59-1328 =274.59 锁定物理内存页少了275MB

3 大页内存 (1419-363)-(1040-50)=66*2=132MB

4 我这里使用的是750PS内存,第四步的时候. 第五步PS内存是606, 750-606=144; 275-144=131MB

这样就怼上了,物理内存少的那么多,就被加入到了大页内存中132MB

留下的疑问

1 这132MB是谁呢?

大页内存使用(1419-363)*2=2112MB -2048(INNODBBUF)=64MB

这又对不上了,扣掉INNODBBUF 才64MB

再扣掉40MB(LOG_BUF,KEY_BUF,HEAP) 就剩24MB

这24MB又是谁啊? 再说大页内存相对加入了132MB,

2 系统内存与MYSQL内存差异

从系统上MYSQL累积使用内存大页内存+锁定内存=(1419-363)*2+(1280)=3392 大于MYSQL看到的内存 2.78 且相差 -545.28MB

mysql>  select sys.format_bytes (sum(current_alloc))
        from sys.x$memory_global_by_current_bytes ;
+---------------------------------------+
| sys.format_bytes (sum(current_alloc)) |
+---------------------------------------+
| 2.78 GiB                              |
+---------------------------------------+
1 row in set, 1 warning (0.00 sec)

3 PS 统计内存不准
INNODB BUF 看样子确实分配了

mysql> show engine innodb status;
----------------------
BUFFER POOL AND MEMORY
----------------------
Total large memory allocated 0
Dictionary memory allocated 446200
Buffer pool size   131056
Buffer pool size, bytes 2147221504
Free buffers       129263
Database pages     1784
Old database pages 0
Modified db pages  0
Pending reads      0
Pending writes: LRU 0, flush list 0, single page 0
Pages made young 0, not young 0
0.00 youngs/s, 0.00 non-youngs/s
Pages read 1642, created 142, written 169
0.00 reads/s, 0.00 creates/s, 0.00 writes/s
Buffer pool hit rate 1000  1000, young-making rate 0  1000 not 0  1000
Pages read ahead 0.00/s, evicted without access 0.00/s, Random read ahead 0.00/s
LRU len: 1784, unzip_LRU len: 0
I/O sum[0]:cur[0], unzip sum[0]:cur[0]

mysql> select event_name,current_alloc
from sys.x$memory_global_by_current_bytes
where  event_name  like 'memory/innodb%';
+-------------------------------------------+---------------+
| event_name                                | current_alloc |
+-------------------------------------------+---------------+
| memory/innodb/buf_buf_pool                |    2213220352 |

# 这里PS占用2110MB 明显统计INNODB BUFSIZE 不准确

4 INNODB BUF 是否完全分配

第4次实验大页内存使用1980MB,明显低于INNODBBUF SIZE 2048MB

SYSBENCH OLTP 压测

10万笔数据 4个表,4个线程

传统页

sysbench 1.0.20 (using bundled LuaJIT 2.1.0-beta2)




Running the test with following options:
Number of threads: 4
Initializing random number generator from current time








Initializing worker threads...




Threads started!




SQL statistics:
    queries performed:
        read:                            263158
        write:                           75188
        other:                           37594
        total:                           375940
    transactions:                        18797  (313.13 per sec.)
    queries:                             375940 (6262.59 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)




General statistics:
    total time:                          60.0279s
    total number of events:              18797




Latency (ms):
         min:                                    4.05
         avg:                                   12.77
         max:                                  333.28
         95th percentile:                       36.24
         sum:                               239973.87




Threads fairness:
    events (avg/stddev):           4699.2500/21.13
    execution time (avg/stddev):   59.9935/0.01

sysbench 1.0.20 (using bundled LuaJIT 2.1.0-beta2)




Running the test with following options:
Number of threads: 4
Initializing random number generator from current time








Initializing worker threads...




Threads started!




SQL statistics:
    queries performed:
        read:                            272524
        write:                           77864
        other:                           38932
        total:                           389320
    transactions:                        19466  (324.32 per sec.)
    queries:                             389320 (6486.44 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)




General statistics:
    total time:                          60.0189s
    total number of events:              19466




Latency (ms):
         min:                                    4.19
         avg:                                   12.33
         max:                                  335.01
         95th percentile:                       34.33
         sum:                               239989.53




Threads fairness:
    events (avg/stddev):           4866.5000/31.61
    execution time (avg/stddev):   59.9974/0.00

大页+锁

[root@localhost ~]# sh sysbench_oltp_4thread_test_run.sh

sysbench 1.0.20 (using bundled LuaJIT 2.1.0-beta2)




Running the test with following options:
Number of threads: 4
Initializing random number generator from current time








Initializing worker threads...




Threads started!




SQL statistics:
    queries performed:
        read:                            264656
        write:                           75616
        other:                           37808
        total:                           378080
    transactions:                        18904  (315.01 per sec.)
    queries:                             378080 (6300.11 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)




General statistics:
    total time:                          60.0101s
    total number of events:              18904




Latency (ms):
         min:                                    4.25
         avg:                                   12.69
         max:                                  357.71
         95th percentile:                       38.94
         sum:                               239956.15




Threads fairness:
    events (avg/stddev):           4726.0000/20.58
    execution time (avg/stddev):   59.9890/0.00

[root@localhost ~]# sh sysbench_oltp_4thread_test_run.sh

sysbench 1.0.20 (using bundled LuaJIT 2.1.0-beta2)




Running the test with following options:
Number of threads: 4
Initializing random number generator from current time








Initializing worker threads...




Threads started!




SQL statistics:
    queries performed:
        read:                            286048
        write:                           81728
        other:                           40864
        total:                           408640
    transactions:                        20432  (340.46 per sec.)
    queries:                             408640 (6809.12 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)




General statistics:
    total time:                          60.0116s
    total number of events:              20432




Latency (ms):
         min:                                    4.21
         avg:                                   11.74
         max:                                  267.91
         95th percentile:                       30.81
         sum:                               239955.77




Threads fairness:
    events (avg/stddev):           5108.0000/26.05
    execution time (avg/stddev):   59.9889/0.00


    transactions:                        19466  (324.32 per sec.)
    queries:                             389320 (6486.44 per sec.)
  95th percentile:                       34.33

    transactions:                        20432  (340.46 per sec.) 5%
    queries:                             408640 (6809.12 per sec.)   5%
  95th percentile:                       30.81                     10.2%

总结下

1开启大页内存有效降低了OOM得分,减少被KILL风险.

2 有效降低了LINUX内核页表大小,提高性能.

3 锁定在物理内存不被SWAP,提高性能.

4 比较难精确计算出大页内存被谁使用了

5 存在系统内存与MYSQL内存统计差异大

6 PS内存统计与INNNODB STATUS统计差异大

7 大页内存8GB 4线程下提升5%的性能

文章转载自海鲨数据库架构师，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

MYSQL 大页内存+锁定内存

评论
