0x00 实操1.记一次 Kubernetes V1.23.x 集群证书过期或者延期处理操作实践案例

描述: 下述操作主要用于处理K8S证书已过期
或者即将过期的kubernetes集群
实践案例，当然网上百度、CSDN（捡垃圾）大多数方法均是一知半解，不同的K8S版本操作有些许不同，若全部按照其操作，有可能你需要重建K8S了，别问我怎么知道的，因为我踩过坑( Ĭ ^ Ĭ )，所以建议在遇到问题时先查询K8S官方文档。

1.前言简述

在年后上班的第一天，我像往常一样，登录到K8S集群之中依次检查应用，在检查开发测试环境的k8s集群时，发现执行kubectl命令报证书过期错误，顿时心情都不好了，却也无可奈何，只能进行证书续签了，由于是高可用集群遇到了许多坑，为了方便自己以及广大的运维工作者，解决相关问题，遂整理了此篇文章。

# 连接 Api-server 失败，报证书已过期不可用。
$ kubectl get node,pod
Unable to connect to the server: x509: certificate has expired or is not yet valid: current time 2023-01-31T16:55:27+08:00 is after 2023-01-16T04:47:34Z

2.实践环境

集群版本及其节点描述:

# 集群版本
$ kubeadm version
kubeadm version: &version.Info{Major:"1", Minor:"23", GitVersion:"v1.23.1", GitCommit:"86ec240af8cbd1b60bcc4c03c20da9b98005b92e", GitTreeState:"clean", BuildDate:"2021-12-16T11:39:51Z", GoVersion:"go1.17.5", Compiler:"gc", Platform:"linux/amd64"}

# 集群节点
$ data -s "2023-01-01"
$ kubectl get node
NAME       STATUS   ROLES                  AGE    VERSION
weiyigeek-107   Ready    control-plane,master   381d   v1.23.1
weiyigeek-108   Ready    control-plane,master   380d   v1.23.1
weiyigeek-109   Ready    control-plane,master   380d   v1.23.1
weiyigeek-223   Ready    work                   380d   v1.23.1
weiyigeek-224   Ready    work                   380d   v1.23.1
weiyigeek-225   Ready    work                   381d   v1.23.1
weiyigeek-226   Ready    work                   220d   v1.23.1

# 论保存过程配置文件的重要性，在搭建k8s集群时建议备份资源清单。
kubectl -n kube-system get cm kubeadm-config -o yaml > kubeadm-config-v1.23.1.yaml

3.实践证书续签

高可用K8S集群，证书续签操作流程步骤如下:
0.在进行操作前一定要进行备份，便于回退处理，此处我在三台master节点之一的weiyigeek-107
机器上操作，后续默认也在此机器上操作，若需在其他机器上操作我会进行说明

# 备份旧的配置文件。
cp -a etc/kubernetes{,.bak}
cp -a var/lib/kubelet{,.bak}
cp -a var/lib/etcd var/lib/etcd.bak


# 备份集群配置 (当证书到期时是无法执行的此步骤可跳过)但可以利用date命令将系统时间设置到过期前。
data -s "2023-01-01" || timedatectl set-time "2023-01-01"
kubectl -n kube-system get cm kubeadm-config -o yaml > kubeadm-init-config.yaml     # 后续会用到此原始配置文件。

1.使用openssl命令查询单个证书可用时间及其相关信息

# k8s 集群的 ca.crt 证书有效期为 十年
# k8s 集群的 apiserver.crt 、kubelet.crt、etcd.crt 证书默认有效期为 一年，当然你也可以自行修改为十年（后续有文章进行讲解）
$ for i in $(ls etc/kubernetes/pki/*.crt etc/kubernetes/pki/etcd/*.crt); do echo "===== $i ====="; openssl x509 -in $i -text -noout | grep -A 3 'Validity' ; done
# for item in `find etc/kubernetes/pki -maxdepth 2 -name "*.crt"`;do echo ======================$item===============;openssl x509 -in $item -text -noout| grep -A 3 Not;done
===== etc/kubernetes/pki/apiserver.crt =====
        Validity
            Not Before: Jan 15 10:42:56 2022 GMT  # 颁发时间
            Not After : Jan 15 10:42:57 2023 GMT  # 到期时间
        Subject: CN = kube-apiserver              # 通用名称
===== etc/kubernetes/pki/apiserver-etcd-client.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 15 10:42:59 2023 GMT
        Subject: O = system:masters, CN = kube-apiserver-etcd-client
===== etc/kubernetes/pki/apiserver-kubelet-client.crt =====
        Validity
            Not Before: Jan 15 10:42:56 2022 GMT
            Not After : Jan 15 10:42:57 2023 GMT
        Subject: O = system:masters, CN = kube-apiserver-kubelet-client
===== etc/kubernetes/pki/ca.crt =====
        Validity
            Not Before: Jan 15 10:42:56 2022 GMT
            Not After : Jan 13 10:42:56 2032 GMT
        Subject: CN = kubernetes
===== etc/kubernetes/pki/etcd/ca.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 13 10:42:58 2032 GMT
        Subject: CN = etcd-ca
===== etc/kubernetes/pki/etcd/healthcheck-client.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 15 10:42:59 2023 GMT
        Subject: O = system:masters, CN = kube-etcd-healthcheck-client
===== etc/kubernetes/pki/etcd/peer.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 15 10:42:59 2023 GMT
        Subject: CN = weiyigeek-107
===== etc/kubernetes/pki/etcd/server.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 15 10:42:59 2023 GMT
        Subject: CN = weiyigeek-107
===== etc/kubernetes/pki/front-proxy-ca.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 13 10:42:58 2032 GMT
        Subject: CN = front-proxy-ca
===== etc/kubernetes/pki/front-proxy-client.crt =====
        Validity
            Not Before: Jan 15 10:42:58 2022 GMT
            Not After : Jan 15 10:42:58 2023 GMT
        Subject: CN = front-proxy-client

2.查看当前集群证书相关信息，包含所有证书名称以及证书颁发机构、到期时间等, 此处可以看到均已经到期。

$ sudo kubeadm certs check-expiration
  # [check-expiration] Reading configuration from the cluster...
  # [check-expiration] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
  # [check-expiration] Error reading configuration from the Cluster. Falling back to default configuration

  # CERTIFICATE                EXPIRES(过期时间)         RESIDUAL TIME(剩余时间)   CERTIFICATE AUTHORITY   EXTERNALLY MANAGED(是否是外部管理)
  # admin.conf                 Jan 15, 2023 10:43 UTC   <invalid>       ca                      no
  # apiserver                  Jan 15, 2023 10:42 UTC   <invalid>       ca                      no
  # apiserver-etcd-client      Jan 15, 2023 10:42 UTC   <invalid>       etcd-ca                 no
  # apiserver-kubelet-client   Jan 15, 2023 10:42 UTC   <invalid>       ca                      no
  # controller-manager.conf    Jan 15, 2023 10:43 UTC   <invalid>       ca                      no
  # etcd-healthcheck-client    Jan 15, 2023 10:42 UTC   <invalid>       etcd-ca                 no
  # etcd-peer                  Jan 15, 2023 10:42 UTC   <invalid>       etcd-ca                 no
  # etcd-server                Jan 15, 2023 10:42 UTC   <invalid>       etcd-ca                 no
  # front-proxy-client         Jan 15, 2023 10:42 UTC   <invalid>       front-proxy-ca          no
  # scheduler.conf             Jan 15, 2023 10:43 UTC   <invalid>       ca                      no

  # CERTIFICATE AUTHORITY   EXPIRES                  RESIDUAL TIME   EXTERNALLY MANAGED
  # ca                      Jan 13, 2032 10:42 UTC   8y              no
  # etcd-ca                 Jan 13, 2032 10:42 UTC   8y              no
  # front-proxy-ca          Jan 13, 2032 10:42 UTC   8y              no

温馨提示: 如果 Etcd 是由Kubeadm创建和托管的此时也可以通过下面的方式进行证书的续期, 如果是外部高可用环境管理需要则手动进行更新证书配置;

3.使用 certs 的 renew 子命令刷新集群所有证书的到期时间进行再续期一年, 此处 --config 参数指定的是我当初创建集群的初始化配置清单，若没有可以安装步骤0进行生成。

~/.k8s$ sudo kubeadm certs renew all --config=./kubeadm-init-config.yaml
  # W1212 17:17:16.721037 1306627 configset.go:348] WARNING: kubeadm cannot validate component configs for API groups [kubelet.config.k8s.io kubeproxy.config.k8s.io]
  # certificate embedded in the kubeconfig file for the admin to use and for kubeadm itself renewed  # 嵌入在kubeconfig文件中的证书，供管理员使用，并对kubeadm本身进行更新 (admin.conf )
  # certificate for serving the Kubernetes API renewed               # 更新Kubernetes API服务证书
  # certificate the apiserver uses to access etcd renewed            # 服务器访问etcd所使用的证书已更新
  # certificate for the API server to connect to kubelet renewed     # API服务器连接到kubelet的证书已更新
  # certificate embedded in the kubeconfig file for the controller manager to use renewed  # 证书嵌入在kubeconfig文件中，供控制器管理器使用更新 (controller-manager.conf)
  # certificate for liveness probes to healthcheck etcd renewed        # 健康检查etcd激活探针证书续期
  # certificate for etcd nodes to communicate with each other renewed  # 用于etcd节点之间通信的证书更新
  # certificate for serving etcd renewed                               # 续期etcd“服务证书”
  # certificate for the front proxy client renewed                     # 前代理客户端的证书更新
  # certificate embedded in the kubeconfig file for the scheduler manager to use renewed # 证书嵌入在kubeconfig文件中，供调度器管理器使用更新 (scheduler.conf  )


# 若看到已完成续订证书，您必须重新启动kube apiserver、kube控制器管理器、kube调度器等，以便它们可以使用新证书，表示证书续期成功
Done renewing certificates. You must restart the kube-apiserver, kube-controller-manager, kube-scheduler and etcd, so that they can use the new certificates.


# 检查证书续签以及到期时间
~/.k8s$ kubeadm certs check-expiration
  # [check-expiration] Reading configuration from the cluster...
  # [check-expiration] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'

  # CERTIFICATE                EXPIRES                  RESIDUAL TIME   CERTIFICATE AUTHORITY   EXTERNALLY MANAGED
  # admin.conf                 Jan 31, 2024 09:26 UTC   364d            ca                      no
  # apiserver                  Jan 31, 2024 09:26 UTC   364d            ca                      no
  # apiserver-etcd-client      Jan 31, 2024 09:26 UTC   364d            etcd-ca                 no
  # apiserver-kubelet-client   Jan 31, 2024 09:26 UTC   364d            ca                      no
  # controller-manager.conf    Jan 31, 2024 09:26 UTC   364d            ca                      no
  # etcd-healthcheck-client    Jan 31, 2024 09:26 UTC   364d            etcd-ca                 no
  # etcd-peer                  Jan 31, 2024 09:26 UTC   364d            etcd-ca                 no
  # etcd-server                Jan 31, 2024 09:26 UTC   364d            etcd-ca                 no
  # front-proxy-client         Jan 31, 2024 09:26 UTC   364d            front-proxy-ca          no
  # scheduler.conf             Jan 31, 2024 09:26 UTC   364d            ca                      no

  # CERTIFICATE AUTHORITY   EXPIRES                  RESIDUAL TIME   EXTERNALLY MANAGED
  # ca                      Jan 13, 2032 10:42 UTC   8y              no
  # etcd-ca                 Jan 13, 2032 10:42 UTC   8y              no
  # front-proxy-ca          Jan 13, 2032 10:42 UTC   8y              no




# 使用stat命令查看 apiserver.key 与 apiserver.crt 证书修改时间
/etc/kubernetes/pki$ stat apiserver.key  apiserver.crt
  #   File: apiserver.key
  #   Size: 1675            Blocks: 8          IO Block: 4096   regular file
  # Device: fd00h/64768d    Inode: 3670556     Links: 1
  # Access: (0600/-rw-------)  Uid: (    0/    root)   Gid: (    0/    root)
  # Access: 2022-04-28 12:55:13.456040564 +0800 最近访问：
  # Modify: 2023-01-31 17:26:51.108767670 +0800 最近更改：
  # Change: 2023-01-31 17:26:51.108767670 +0800 最近改动：
  #   Birth: -

  #   File: apiserver.crt
  #   Size: 1338            Blocks: 8          IO Block: 4096   regular file
  # Device: fd00h/64768d    Inode: 3670557     Links: 1
  # Access: (0644/-rw-r--r--)  Uid: (    0/    root)   Gid: (    0/    root)
  # Access: 2023-01-31 17:28:58.104917185 +0800
  # Modify: 2023-01-31 17:26:51.108767670 +0800
  # Change: 2023-01-31 17:26:51.108767670 +0800
  #   Birth: -

4.完成证书更新后，此时我们需要重新生成新的K8S集群master节点所需的相关配置文件，例如 /etc/kubernetes
目录下的 admin.conf controller-manager.conf kubelet.conf scheduler.conf
相关文件。

# 初始化所需配置文件
$ rm -rf etc/kubernetes/*.conf
$ kubeadm init phase kubeconfig all --config=kubeadm-init-config.yaml
  # [kubeconfig] Using kubeconfig folder "/etc/kubernetes"
  # [kubeconfig] Writing "admin.conf" kubeconfig file
  # [kubeconfig] Writing "kubelet.conf" kubeconfig file
  # [kubeconfig] Writing "controller-manager.conf" kubeconfig file
  # [kubeconfig] Writing "scheduler.conf" kubeconfig file


# 可以看到文件时间已经发生变化
$ ls -alh etc/kubernetes/*.conf
-rw------- 1 root root 5.6K Jan 31 21:53 etc/kubernetes/admin.conf
-rw------- 1 root root 5.6K Jan 31 21:53 etc/kubernetes/controller-manager.conf
-rw------- 1 root root 5.6K Jan 31 21:53 etc/kubernetes/kubelet.conf
-rw------- 1 root root 5.5K Jan 31 21:53 etc/kubernetes/scheduler.conf


# 为防止 kubelet 客户端证书轮换失败，我们需要将（此处坑有点大）kubelet-client-* 进行删除，在kubelet服务重启时又会自动生成
# 如果此轮换过程失败，你可能会在 kube-apiserver 日志中看到诸如 x509: certificate has expired or is not yet valid 之类的错误
# https://kubernetes.io/zh/docs/setup/production-environment/tools/kubeadm/troubleshooting-kubeadm/#kubelet-client-cert
rm -rf var/lib/kubelet/pki/kubelet-client-*

补充: 若要生成其他master节点的K8S配置文件请参考如下，例如，此处是 weiyigeek-108 控制平面节点的conf配置文件。

# $ mkdir -vp tmp/kubernetes/
# $ kubeadm init phase kubeconfig all --node-name weiyigeek-108 --kubeconfig-dir tmp/kubernetes/

5.按照提示将当前操作集群 master（weiyigeek-107）节点上重启 kube-apiserver, kube-controller-manager, kube-scheduler 以及 etcd 等相关服务。

# 将新生成的集群连接配置文件覆盖到 ~/.kube/config
mkdir -p $HOME/.kube
echo 'yes' |  sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config


# 重启 kube-apiserver, kube-controller-manager, kube-scheduler 及 etcd 等相关服务（建议一个一个pod删除，启动后再进行下一步操作）
kubectl -n kube-system delete pod -l 'component=kube-apiserver'
kubectl -n kube-system delete pod -l 'component=kube-controller-manager'
kubectl -n kube-system delete pod -l 'component=kube-scheduler'
kubectl -n kube-system delete pod -l 'component=etcd'


# 重启节点上 kubelet 服务
systemctl restart kubelet.service


# 查看 kubelet 服务状态
systemctl status -l kubelet.service


# 查看 kubelet 服务运行日志有无异常（有异常请依次解决）
journalctl -xefu kubelet


# 重启 kubelet 后 kubelet 客户端证书轮换自动生成新的 pem 证书
ls -alh var/lib/kubelet/pki/kubelet-client-current.pem
  # lrwxrwxrwx 1 root root 59 Jan 31 22:29 var/lib/kubelet/pki/kubelet-client-current.pem -> var/lib/kubelet/pki/kubelet-client-2023-01-31-22-29-20.pem

6.此时在（weiyigeek-107）节点上运行kubectl相关命令，则不会报证书到期了，我们可正常使用相关命令.

$ kubectl get nodes
  # NAME       STATUS   ROLES                  AGE     VERSION   INTERNAL-IP      EXTERNAL-IP   OS-IMAGE             KERNEL-VERSION      CONTAINER-RUNTIME
  # weiyigeek-107   Ready    control-plane,master   381d    v1.23.1   192.168.12.107   <none>        Ubuntu 20.04.1 LTS   5.4.0-137-generic   containerd://1.4.12
  # weiyigeek-108   Ready    control-plane,master   57m     v1.23.1   192.168.12.108   <none>        Ubuntu 20.04.3 LTS   5.4.0-137-generic   containerd://1.4.12
  # weiyigeek-109   Ready    control-plane,master   2m19s   v1.23.1   192.168.12.109   <none>        Ubuntu 20.04.3 LTS   5.4.0-137-generic   containerd://1.4.12
  # weiyigeek-223   Ready    work                   380d    v1.23.1   192.168.12.223   <none>        Ubuntu 20.04.3 LTS   5.4.0-94-generic    containerd://1.4.12
  # weiyigeek-224   Ready    work                   380d    v1.23.1   192.168.12.224   <none>        Ubuntu 20.04.3 LTS   5.4.0-42-generic    containerd://1.4.12
  # weiyigeek-225   Ready    work                   381d    v1.23.1   192.168.12.225   <none>        Ubuntu 20.04.3 LTS   5.4.0-94-generic    containerd://1.4.12
  # weiyigeek-226   Ready    work                   220d    v1.23.1   192.168.12.226   <none>        Ubuntu 20.04.3 LTS   5.4.0-80-generic    containerd://1.4.12


$ kubectl get pod -n kube-system  | egrep "kube-apiserver|kube-controller-manager|kube-scheduler|etcd"
  # etcd-weiyigeek-107                             1/1     Running   1              380d
  # etcd-weiyigeek-108                             1/1     Running   0              96d
  # etcd-weiyigeek-109                             1/1     Running   0              380d
  # kube-apiserver-weiyigeek-107                   1/1     Running   0              380d
  # kube-apiserver-weiyigeek-108                   1/1     Running   0              380d
  # kube-apiserver-weiyigeek-109                   1/1     Running   0              380d
  # kube-controller-manager-weiyigeek-107          1/1     Running   2 (380d ago)   380d
  # kube-controller-manager-weiyigeek-108          1/1     Running   1 (15d ago)    380d
  # kube-controller-manager-weiyigeek-109          1/1     Running   1 (380d ago)   380d
  # kube-scheduler-weiyigeek-107                   1/1     Running   3 (15d ago)    380d
  # kube-scheduler-weiyigeek-108                   1/1     Running   2 (15d ago)    380d
  # kube-scheduler-weiyigeek-109                   1/1     Running   1 (380d ago)   380d

7.查看集群的健康状态，即调度器、控制器以及etcd数据库是否正常。

$ kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME                 STATUS    MESSAGE                         ERROR
scheduler            Healthy   ok
controller-manager   Healthy   ok
etcd-0               Healthy   {"health":"true","reason":""}

你是否认为，实践到这里就结束了，当然不是由于此处是高可用K8S集群，更新证书后坑，远不止于此。

有兴趣的，请继续看下节。

偷偷的告诉你哟？【极客全栈修炼】微信小程序已经上线了，

可直接在微信里面直接浏览博主博客了哟，后续将上线更多有趣的小工具。

4.集群证书更新后 calico && kube-proxy 相关操作

描述：在进行该K8S高可用集群安装时，参照了我博客中的《在Ubuntu安装部署K8S高可用集群使用初体验》文章，我将文章链接地址( https://blog.weiyigeek.top/2020/4-27-470.html#0x04-高可用集群使用初体验 ), 其中在使用calico网络插件时选择将 Calico 数据存储在 etcd datastore 之中，所以在进行calico安装或者使用时需要将数据存储到etcd中，则肯定需要链接到etcd数据中，此处 calico-etcd.yaml 配置清单中的etcd-ca、etcd-cert、etcd-key 字段的值仍然为原证书，由于我们前面已经更新了所有组件证书，所以再进行数据的CURD肯定是无法链接到etcd，则此时我们需要重新该 calico-etcd.yaml
资源配置文件。

在更新集群证书后发现的calico以及业务应用的异常情况，其中最明显的就是calic无法正常启动。

$ kubectl get pod -n kube-system
  NAME                                      READY   STATUS              RESTARTS        AGE
  calico-kube-controllers-6cf9b574f-zlrjn   0/1     Running             0               3s
  calico-node-5q8lq                         0/1     CrashLoopBackOff    11 (6s ago)     25m
  calico-node-62zd9                         0/1     CrashLoopBackOff    9 (5m6s ago)    25m
  calico-node-85b7k                         0/1     Running             11 (66s ago)    25m
  calico-node-8mt8q                         0/1     Running             3 (66s ago)     4m43s
  calico-node-cdkf8                         0/1     CrashLoopBackOff    9 (5m6s ago)    25m
  calico-node-jgm6q                         0/1     CrashLoopBackOff    9 (4m56s ago)   25m
  calico-node-x2b9q                         0/1     CrashLoopBackOff    9 (5m6s ago)    25m
  coredns-65c54cc984-7vt8m                  0/1     ContainerCreating   0               7m5s
  coredns-65c54cc984-hf774                  0/1     ContainerCreating   0               25m

操作步骤:
步骤 01.此处参考上面的文章进行更改etcd数据库证书链接字段。

# (1) Install Calico with etcd datastore (使用etcd数据存储安装Calico)
curl https://docs.projectcalico.org/manifests/calico-etcd.yaml -O


# calico-etcd 网络与etc集群连接修改(此处指定pod子网地址)
ETCD_CA=`cat etc/kubernetes/pki/etcd/ca.crt | base64 | tr -d '\n'`
ETCD_CERT=`cat etc/kubernetes/pki/etcd/server.crt | base64 | tr -d '\n'`
ETCD_KEY=`sudo cat etc/kubernetes/pki/etcd/server.key | base64 | tr -d '\n'`
POD_SUBNET=`sudo cat etc/kubernetes/manifests/kube-controller-manager.yaml | grep cluster-cidr= | awk -F= '{print $NF}'`
sed -i "s@# etcd-key: null@etcd-key: ${ETCD_KEY}@g; s@# etcd-cert: null@etcd-cert: ${ETCD_CERT}@g; s@# etcd-ca: null@etcd-ca: ${ETCD_CA}@g" calico-etcd.yaml


sed -i 's#etcd_ca: ""#etcd_ca: "/calico-secrets/etcd-ca"#g; s#etcd_cert: ""#etcd_cert: "/calico-secrets/etcd-cert"#g; s#etcd_key: "" #etcd_key: "/calico-secrets/etcd-key" #g' calico-etcd.yaml
sed -i 's#etcd_endpoints: "http://<ETCD_IP>:<ETCD_PORT>"#etcd_endpoints: "https://192.168.12.107:2379,https://192.168.12.108:2379,https://192.168.12.109:2379"#g' calico-etcd.yaml
sed -i 's@# - name: CALICO_IPV4POOL_CIDR@- name: CALICO_IPV4POOL_CIDR@g; s@#   value: "192.168.0.0/16"@  value: '"${POD_SUBNET}"'@g' calico-etcd.yaml


# (2) 覆盖部署calico到K8S集群中
kubectl apply -f calico-etcd.yaml


# (3) 此处对比两个配置清单文件即可发现证书的不同。
diff calico-etcd.yaml calico-etcd.yaml.bak
17,18c17,18

步骤 02.在master节点(weiyigeek-107)节点上执行如下命令，重启 calico 以及各节点中的 kube-proxy Pod 容器。

# calico-node
kubectl delete pod -n kube-system -l k8s-app=calico-node

# kube-proxy
kubectl delete pod -n kube-system -l k8s-app=calico-node

步骤 03.等待一段时间后，验证 calico-node 、kube-proxy服务启动情况

$ kubectl get pod -n kube-system  | egrep "calico|kube-proxy"
calico-kube-controllers-6cf9b574f-42jnz   1/1     Running   0               98m
calico-node-dvvxk                         1/1     Running   0               98m
calico-node-g9svc                         1/1     Running   0               98m
calico-node-ggxqp                         1/1     Running   0               98m
calico-node-jps97                         1/1     Running   0               98m
calico-node-qf7cj                         1/1     Running   0               92m
calico-node-vvw9f                         1/1     Running   0               98m
calico-node-zvz8r                         1/1     Running   0               98m
kube-proxy-25p5s                          1/1     Running   0               220d
kube-proxy-8bl7f                          1/1     Running   0               94m
kube-proxy-8jxvr                          1/1     Running   0               93m
kube-proxy-d79mp                          1/1     Running   0               381d
kube-proxy-dtdtm                          1/1     Running   0               108m
kube-proxy-l7jxp                          1/1     Running   0               93m
kube-proxy-nlgln                          1/1     Running   0               381d

步骤 04.访问通过nodePort暴露的业务系统验证是否可以从任意节点代理转发访问。

$ kubectl get svc,pod -n devops -l app=jenkins
  # NAME              TYPE       CLUSTER-IP       EXTERNAL-IP   PORT(S)                          AGE
  # service/jenkins   NodePort   10.109.163.223   <none>        8080:30001/TCP,50000:30634/TCP   380d

  # NAME                           READY   STATUS    RESTARTS   AGE
  # pod/jenkins-7fc6f4fcf6-glqxj   1/1     Running   0          118m


$ curl -sI 10.109.163.223:8080 | head -n 1
HTTP/1.1 200 OK


$ curl -s 10.109.163.223:8080  | grep -oP "<title>\S.+</title>"
$ curl -s 192.168.12.107:30001  | grep -oP "<title>\S.+</title>"
<title>Dashboard [Jenkins]</title>

好的，此问题也已经解决了。

下面继续来看，如何在更新证书后删除或者新增
控制面板节点以及工作节点。

5.控制平面(Master)节点的移除&&添加

描述: 有时在更新集群证书后，某一个控制平面的节点可能一致不正常，我们也找不到解决办法时，最终解决方案就是重置该master节点并重新加入到K8S集群中。

操作流程

步骤 01.将需要master节点，例如此处(weiyigeek-108)节点设置不可调度，温馨提示操作前请注意备份该节点上的相关数据。

# 在 weiyigeek-107 节点上执行如下命令，设置节点设置不可调度，此时节点状态变成：Ready,SchedulingDisabled
kubectl drain weiyigeek-108 --delete-local-data  --delete-emptydir-data --force --ignore-daemonsets
  # node/weiyigeek-108 cordoned
  # WARNING: ignoring DaemonSet-managed Pods: kube-system/calico-node-qf7cj, kube-system/kube-proxy-8jxvr
  # node/weiyigeek-108 drained


kubectl get node  weiyigeek-108
  NAME       STATUS                     ROLES                  AGE     VERSION
  weiyigeek-108   Ready,SchedulingDisabled   control-plane,master   3h50m   v1.23.1



# 从集群中移除 weiyigeek-108 节点
kubectl delete node weiyigeek-109

步骤 02.生成master节点以及工作节点加入到K8S集群的认证Token及其命令示例（值得学习借鉴）。

# (1) 查看token是否失效默认是24H，如果失效过期可以重新进行生成token并打印加入命令
kubeadm token list
kubeadm token create --print-join-command
  # kubeadm join slb-vip.k8s:16443 --token vkhqa1.t3gtrbowlalt8um5 --discovery-token-ca-cert-hash sha256:bfc86e13da79a1ec5f53cef99661e4e3f51adda59c525cb9377cfe59956b1e59 # 注意，配置清单中会使用到


# (2)从节点的 kubeadm 加入到k8s集群之中 (推荐)，使用此命令调用init工作流的单个阶段
kubeadm init phase upload-certs --upload-certs
  # [upload-certs] Using certificate key:
  # c6a084cb06aaae2f4581145dbbe6057ce111c88fdac4ff4405a0a2db58882d76     # 注意，配置清单中会使用到


# 3) 获取CA（证书）公钥哈希值
openssl x509 -pubkey -in etc/kubernetes/pki/ca.crt | openssl rsa -pubin -outform der 2>/dev/null | openssl dgst -sha256 -hex | sed 's/^ .* '
# (stdin)= bfc86e13da79a1ec5f53cef99661e4e3f51adda59c525cb9377cfe59956b1e59
# 此处是公钥哈希值(一台机器上ca证书不变就一直是该sha256的值)


# (4) 进行收到组合加入集群的 master 节点的 join 命令如下:
kubeadm join slb-vip.k8s:16443 --token ejwx62.vqwog6il5p83uk7y \
--discovery-token-ca-cert-hash sha256:bfc86e13da79a1ec5f53cef99661e4e3f51adda59c525cb9377cfe59956b1e59 \
--control-plane --certificate-key c6a084cb06aaae2f4581145dbbe6057ce111c88fdac4ff4405a0a2db58882d76

步骤 03.通过ssh远程登录weiyigeek-108
节点重置该节点。

systemctl stop kubelet


echo y | kubeadm reset
sudo rm -rf $HOME/.kube
sudo rm -rf var/lib/cni/ etc/cni/ var/lib/kubelet/*
ipvsadm --clear
iptables -F && iptables -t nat -F && iptables -t mangle -F && iptables -X


systemctl start kubelet; systemctl status kubelet

温馨提示: 如果主Master节点在初始化时候出错需要重新配置时候,请执行以上述命令进行重置;

步骤 04.准备控制平面节点加入到集群的JoinConfiguration资源配置清单

$ vim join-k8s.yaml
apiVersion: kubeadm.k8s.io/v1beta3
caCertPath: /etc/kubernetes/pki/ca.crt
discovery:
  bootstrapToken:
    apiServerEndpoint: slb-vip.k8s:16443   # 高可用的APIServer地址
    token: vkhqa1.t3gtrbowlalt8um5         # 上述步骤生成Token
    caCertHashes:
    - "sha256:bfc86e13da79a1ec5f53cef99661e4e3f51adda59c525cb9377cfe59956b1e59"   # 上述步骤获取到的CA（证书）公钥哈希值
  timeout: 5m0s
kind: JoinConfiguration
controlPlane:
  certificateKey: "c6a084cb06aaae2f4581145dbbe6057ce111c88fdac4ff4405a0a2db58882d76"  # 上述步骤获取到 certificate key
  localAPIEndpoint:
    advertiseAddress: 192.168.12.108      # 本地APIServer节点地址(即weiyigeek-108节点机器地址)
    bindPort: 6443                        # 本地APIServer节点端口
nodeRegistration:
  criSocket: /run/containerd/containerd.sock  # 重点，在1.24.x之前默认是使用docker-shim，此处我们指定使用containerd
  imagePullPolicy: IfNotPresent
  name: weiyigeek-108                              # 重点，节点名称
  taints:
  - effect: NoSchedule
    key: node-role.kubernetes.io/master

温馨提示: 在 bootstrapToken 字段中也可跳过 caCertHashes 认证，请键值为unsafeSkipCAVerification: true
。

步骤 05.证书更新后原有的master节点移除加入前，需要针对久的etcd数据库进行处理操作。

此处有个小插曲，由于各master节点组成了一个高可用集群，每个master节点上都运行了etcd服务，以实现etcd数据库的高可用，有

Kubernetes 与 Etcd 版本与证书关联说明:

ETCD 版本小于等于v1.9版本，etcd默认是不使用TLS连接，没有etcd相关证书，只需要更新master证书即可。
ETCD 版本大于等于v1.10版本，etcd默认开启TLS，需要更新etcd证书和master证书。

此处我们的etcd版本是v3.5.x是开启TLS的，前面我们重启在master节点的etcd的相关pod后将会自动使用最新的证书，而在将master节点移除重新加入需进行如下操作，否则将会报错（查看尾部的错误实例）:

kubectl exec -n kube-system -it etcd-weiyigeek-107 bin/sh
# etcd 集群成员列表
$ etcdctl --endpoints 127.0.0.1:2379 --cacert etc/kubernetes/pki/etcd/ca.crt --cert etc/kubernetes/pki/etcd/server.crt --key etc/kubernetes/pki/etcd/server.key member list
  # 2db31a5d67ec1034, started, weiyigeek-108, https://192.168.12.108:2380, https://192.168.12.108:2379, false
  # 42efe7cca897d765, started, weiyigeek-109, https://192.168.12.109:2380, https://192.168.12.109:2379, false
  # 471323846709334f, started, weiyigeek-107, https://192.168.12.107:2380, https://192.168.12.107:2379, false




# etcd 集群节点数据状态
$ etcdctl --endpoints https://192.168.12.107:2379,https://192.168.12.108:2379,https://192.168.12.109:2379 --cacert etc/kubernetes/pki/etcd/ca.crt --cert etc/kubernetes/pki/etcd/server.crt --key etc/kubernetes/pki/etcd/server.key endpoint status
  # https://192.168.12.107:2379, 471323846709334f, 3.5.1, 324 MB, true, false, 8, 109396908, 109396908,
  # https://192.168.12.108:2379, 2db31a5d67ec1034, 3.5.1, 324 MB, false, false, 8, 109396916, 109396916,
  # https://192.168.12.109:2379, 42efe7cca897d765, 3.5.1, 324 MB, false, false, 8, 109396922, 109396922,


#  移除 2db31a5d67ec1034 成员（weiyigeek-108 旧节点）
$ etcdctl --endpoints 127.0.0.1:2379 --cacert etc/kubernetes/pki/etcd/ca.crt --cert etc/kubernetes/pki/etcd/server.crt --key etc/kubernetes/pki/etcd/server.key member remove 7e66da9dd902d557
Member 2db31a5d67ec1034 removed from cluster 3a7f4f11f646b97b

步骤 06.在 weiyigeek-108 节点上执行加入集群命令, 若加入成果可以通过kubectl get nods
命令查看

# 停止该节点上所有 Pod 防止端口占用
crictl stop $(crictl ps -a -q)


# 按照 JoinConfiguration 资源配置清单加入到集群中，--v=5显示更完整的操作过程日志，排错必备。
kubeadm join --config=join-k8s.yaml --v=5
  # 若显示如下提示则加入成功，否则请排查异常情况。
  # This node has joined the cluster and a new control plane instance was created


# To start administering your cluster from this node, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config


$ kubectl get node weiyigeek-108
  # NAME       STATUS     ROLES                  AGE     VERSION
  # weiyigeek-108   Ready      control-plane,master   3m9s    v1.23.1

温馨提示: 如果加入主master节点时一直停留在 pre-flight 状态，请在第额外的几个节点上执行命令检查：curl -ik https://设置APISERVER地址:6443/version

$ curl -ik https://slb-vip.k8s:16443/version
# 正常状态下的输出
HTTP/2 200
audit-id: 77c614cb-0c27-42f5-a852-b5ef8415361f
cache-control: no-cache, private
content-type: application/json
x-kubernetes-pf-flowschema-uid: 41a01a35-c480-4cfd-8854-494261622406
x-kubernetes-pf-prioritylevel-uid: 4cfd380c-d39c-490f-96b0-dd4ed07be4e0
content-length: 263
date: Wed, 01 Feb 2023 07:34:01 GMT
{
  "major": "1",
  "minor": "23",
  "gitVersion": "v1.23.0",
  "gitCommit": "ab69524f795c42094a6630298ff53f3c3ebab7f4",
  "gitTreeState": "clean",
  "buildDate": "2021-12-07T18:09:57Z",
  "goVersion": "go1.17.3",
  "compiler": "gc",
  "platform": "linux/amd64"
}

至此，实践完毕!

6.工作平面(Work)节点的移除&&添加

描述: k8s集群中工作节点的添加与移除，和master节点移除添加方法基本一致，不同之处在于加入集群的配置清单，你可以对照一下master节点与node节点加入集群时的配置清单。

此处，也不在累述直接快速上脚本。

步骤 01.在master节点上执行，将设weiyigeek-226节点置不可调度,即不分配新的资源到该节点上，并且驱逐pod到其他工作节点上。

# 温馨提示: drain命令会自动把node设置为不可调度，所以可以省略上面执行的cordon命令
kubectl cordon weiyigeek-226
kubectl drain weiyigeek-226 --delete-emptydir-data --force --ignore-daemonsets

步骤 02.在weiyigeek-226工作节点上执行重置节点命令

systemctl stop kubelet
echo y | kubeadm reset
sudo rm -rf $HOME/.kube; sudo rm -rf var/lib/cni/ etc/cni/ var/lib/kubelet/*
ipvsadm --clear; iptables -F && iptables -t nat -F && iptables -t mangle -F && iptables -X
systemctl start kubelet; systemctl status kubelet

步骤 03.两种方式将工作节点加入K8S集群中。

# 1.命令行模式
kubeadm join 192.168.80.137:6443 --token 新生成的Token填写此处 --discovery-token-ca-cert-hash sha256:获取的公钥哈希值填写此处


# 2.配置清单模式
tee > join-k8s.yaml <<EOF
cat join-k8s.yaml
apiVersion: kubeadm.k8s.io/v1beta3
caCertPath: /etc/kubernetes/pki/ca.crt
discovery:
  bootstrapToken:
    apiServerEndpoint: slb-vip.k8s:16443
    token: vkhqa1.t3gtrbowlalt8um5
    unsafeSkipCAVerification: true
  timeout: 5m0s
  tlsBootstrapToken: vkhqa1.t3gtrbowlalt8um5
kind: JoinConfiguration
nodeRegistration:
  criSocket: /run/containerd/containerd.sock
  imagePullPolicy: IfNotPresent
  name: weiyigeek-226
  taints: null
EOF
kubeadm join --config=join-k8s.yaml --v=5

步骤 04.在master节点查看加入的工作的节点，此处设置其work标签。

kubectl label nodes weiyigeek-226 node-role.kubernetes.io/work=test
kubectl get nodes weiyigeek-226
  # NAME       STATUS   ROLES   AGE    VERSION
  # weiyigeek-226   Ready    work    10m   v1.23.1

至此，完毕!

n.实践所遇问题

问题1.在master节点上或者非master节点上执行kubectl命令报 `The connection to the server localhost:8080 was refused -`
错误

错误信息:

$ kubectl get cs
The connection to the server localhost:8080 was refused - did you specify the right host or port?

错误原因: 通常情况下是当前用户下没有~/.kube/config
或者不存在环境变量
解决办法:

# 方式1.复制 etc/kubernetes 目录下 admin.conf 文件到 当前用户家目录下 .kube/config
mkdir -p $HOME/.kube
echo 'yes' |  sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config


# 方式2.使用 KUBECONFIG 环境变量包含一个 kubeconfig 文件列表。
export  KUBECONFIG=/etc/kubernetes/admin.conf:~/.kube/devops.kubeconfig


# 方式3.在命令执行时使用--kubeconfig参数指定配置文件
kubectl config --kubeconfig=/etc/kubernetes/admin.conf

问题2.在某master节点上calico-node准备状态一直为0/1并提示 `connect: connection refusedcalico/node is not ready:`
错误

错误信息:

$ kubectl get pod -n kube-system calico-node-v52sv
  # NAME                READY   STATUS    RESTARTS   AGE
  # calico-node-v52sv   0/1     Running   0          31m


$ kubectl describe pod -n kube-system calico-node-v52sv | grep "not ready"
  # Warning  Unhealthy    33m (x2 over 33m)  kubelet  Readiness probe failed: calico/node is not ready: BIRD is not ready: Error querying BIRD: unable to connect to BIRDv4 socket: dial unix /var/run/calico/bird.ctl: connect: connection refused
  # calico/node is not ready: BIRD is not ready: BGP not established with 192.168.12.107,192.168.12.109,192.168.12.223,192.168.12.224,192.168.12.225,192.168.12.226


$ kubectl logs -f --tail 50  -n kube-system calico-node-v52sv | grep "interface"
  # 2023-02-01 08:40:57.583 [INFO][69] monitor-addresses/startup.go 714: Using autodetected IPv4 address on interface br-b92e9270f33c: 172.22.0.1/16
  # calico 对应的 Pod 启动失败，报错：
  # Number of node(s) with BGP peering established = 0

错误原因: 由于该节点上安装了docker并创建了容器，Calico 选择了有问题的br网卡，导致 calico-node 的 Pod 不能启动。

# Calico 提供了 IP 自动检测的方法，默认是使用第一个有效网卡上的第一个有效的 IP 地址：
IP_AUTODETECTION_METHOD=first-found

# 节点上应该是出现了有问题的网卡，可以使用以下命令查看：
ip link | grep br

知识扩展: calico-node daemonset 默认的策略是获取第一个取到的网卡的 ip 作为 calico node 的ip, 由于集群中网卡名称不统一所以可能导致calico获取的网卡IP不对, 所以出现此种情况下就只能 IP_AUTODETECTION_METHOD 字段指定通配符网卡名称或者IP地址。

解决办法:

# 方法1.修改 yaml 配置清单中 IP 自动检测方法，在 spec.containers.env 下添加以下两行。（推荐）
  - name: IP_AUTODETECTION_METHOD
    value: "interface=ens.*"  # ens 根据实际网卡开头配置


# 方法2.删除有问题的网卡（推荐），即指定网卡名称（br 开头的问题网卡）删除。
ifconfig br-b92e9270f33c down


# 方法3.假如环境不依赖docker情况下，可以卸载docker, 然后重启系统即可。
sudo apt-get autoremove docker docker-ce docker-engine docker.io

最后重新启动异常Pod即可:

kubectl delete pod -n kube-system calico-node-v52sv
kubectl get nodes weiyigeek-108
  # NAME       STATUS   ROLES                  AGE   VERSION
  # weiyigeek-108   Ready    control-plane,master   66m   v1.23.1

问题3.在节点加入集群时报 `bridge-nf-call-iptables does not exist`
错误问题解决

错误信息:

[preflight] Some fatal errors occurred:
  [ERROR FileContent--proc-sys-net-bridge-bridge-nf-call-iptables]: /proc/sys/net/bridge/bridge-nf-call-iptables does not exist
[preflight] If you know what you are doing, you can make a check non-fatal with `--ignore-preflight-errors=...`
error execution phase preflight

解决办法:

# 配置
$ cat <<EOF | sudo tee /etc/modules-load.d/k8s.conf
br_netfilter
EOF
$ cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
EOF
$ modprobe br_netfilter && sudo sysctl --system

问题4.在启动某个节点的kubelet报`Unable to read config path" err="path does not exist, ignoring`
错误解决办法

错误信息:

Jan 16 14:27:25 weiyigeek-226 kubelet[882231]: E0116 14:27:25.496423  882231 kubelet.go:2347] "Container runtime network not ready" networkReady="NetworkReady=false reason:NetworkPluginNotReady message:Network plugin returns e>
Jan 16 14:27:26 weiyigeek-226 kubelet[882231]: E0116 14:27:26.482369  882231 file_linux.go:61] "Unable to read config path" err="path does not exist, ignoring" path="/etc/kubernetes/manifests"

解决办法: 检查 /etc/kubernetes/manifests 目录是否存储及其权限

mkdir -vp /etc/kubernetes/manifests

问题5.在节点加入到集群中时报`the namespace "kube-system" error downloading the secret`
错误解决办法

错误信息:

I0116 04:39:41.428788  184219 checks.go:246] validating the existence and emptiness of directory /var/lib/etcd
[preflight] Would pull the required images (like 'kubeadm config images pull')
[download-certs] Downloading the certificates in Secret "kubeadm-certs" in the "kube-system" Namespace
secrets "kubeadm-certs" is forbidden: User "system:bootstrap:20w21w" cannot get resource "secrets" in API group "" in the namespace "kube-system"
error downloading the secret

解决办法: 将证书上载到kubeadm证书。

kubeadm init phase upload-certs --upload-certs
  # [upload-certs] Storing the certificates in Secret "kubeadm-certs" in the "kube-system" Namespace
  # [upload-certs] Using certificate key:
  # 3a3d7610038c9d14edf377d92b9c6b44e049566ddd25b0e69bf571af58227ae7

本文至此完毕，更多技术文章，尽情等待下篇好文！

文章书写不易，如果您觉得此篇文章还不错的朋友，请给这篇专栏 【点个赞、投个币、收个藏、关个注、转个发、留个言、赞个助】，这将对我的肯定，我将持续发布更多优质文章，谢谢！

原文地址: https://blog.weiyigeek.top/2022/12-28-691.html

学习书籍推荐 往期发布文章

网站首页被篡改? 看我使用PhantomJS利器实现网站自动监控修改并截图发送企业微信预警

运维实践 | 如何优雅将K8S资源清单中的元数据metadata，通过环境变量注入到Pod容器?

运维实践 | 使用K3S之快速搭建精简版本K8S集群环境，助力开发测试环境!

大神之路-起始篇 | 第1章.计算机科学导论之【基础绪论】学习笔记

更多企业运维实践、网络安全、系统运维、应用开发、物联网实战、全栈文章，尽在【 https://blog.weiyigeek.top 】站点，谢谢支持！

亲，文章都看完了，不关注一下吗？

点击 👆 卡片或者长按二维码即可关注我哟!

如果此篇文章对你有帮助，请你将它分享给更多的人！

温馨提示: 由于作者水平有限，本章错漏缺点在所难免，希望读者批评指正，并请在文章末尾留下您宝贵的经验知识，联系邮箱地址 master@weiyigeek.top 或者关注公众号 WeiyiGeek 联系我。

点击【"阅读原文"】获取更多有趣的知识!

文章转载自全栈工程师修炼指南，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

运维案例之记一次Kubernetes集群证书过期或延期操作处理实践指南（干货分享）

0x00 实操1.记一次 Kubernetes V1.23.x 集群证书过期或者延期处理操作实践案例

1.前言简述

3.实践证书续签

n.实践所遇问题

问题1.在master节点上或者非master节点上执行kubectl命令报 The connection to the server localhost:8080 was refused -错误

问题2.在某master节点上calico-node准备状态一直为0/1并提示 connect: connection refusedcalico/node is not ready: 错误

问题3.在节点加入集群时报 bridge-nf-call-iptables does not exist错误问题解决

问题4.在启动某个节点的kubelet报Unable to read config path" err="path does not exist, ignoring错误解决办法

问题5.在节点加入到集群中时报the namespace "kube-system" error downloading the secret 错误解决办法

评论

问题1.在master节点上或者非master节点上执行kubectl命令报 `The connection to the server localhost:8080 was refused -`
错误

问题2.在某master节点上calico-node准备状态一直为0/1并提示 `connect: connection refusedcalico/node is not ready:`
错误

问题3.在节点加入集群时报 `bridge-nf-call-iptables does not exist`
错误问题解决

问题4.在启动某个节点的kubelet报`Unable to read config path" err="path does not exist, ignoring`
错误解决办法

问题5.在节点加入到集群中时报`the namespace "kube-system" error downloading the secret`
错误解决办法
