一文搞定 Apache SeaTunnel 2.3.1 全流程部署使用

# 解压到了/opt/module目录下
tar -zxvf apache-SeaTunnel-incubating-2.3.1-bin.tar.gz -C opt/module

connector-assert-2.3.1.jar
connector-cdc-mysql-2.3.1.jar
connector-console-2.3.1.jar # 自带的
connector-doris-2.3.1.jar
connector-elasticsearch-2.3.1.jar
connector-fake-2.3.1.jar # 自带的
connector-file-hadoop-2.3.1.jar
connector-file-local-2.3.1.jar
connector-hive-2.3.1.jar
connector-iceberg-2.3.1.jar
connector-jdbc-2.3.1.jar
connector-kafka-2.3.1.jar
connector-redis-2.3.1.jar

vim  SeaTunnel-2.3.1/config/plugin_config

--connectors-v2--
connector-assert
connector-cdc-mysql
connector-jdbc
connector-fake
connector-console
--end--

sh bin/install-plugin.sh 2.3.1

hive-exec-2.3.9.jar
# 下载链接
# https://repo.maven.apache.org/maven2/org/apache/hive/hive-exec/2.3.9/hive-exec-2.3.9.jar
# 注意这里是hive-exec-2.3.9.jar，不要从你的hive的lib目录下拷贝最新的jar包，就用这个




SeaTunnel-hadoop3-3.1.4-uber-2.3.1.jar
# 下载链接
# https://repo.maven.apache.org/maven2/org/apache/SeaTunnel/SeaTunnel-hadoop3-3.1.4-uber/2.3.1/SeaTunnel-hadoop3-3.1.4-uber-2.3.1.jar




SeaTunnel-hadoop3-3.1.4-uber-2.3.1-optional.jar
# 下载链接
# hhttps://repo.maven.apache.org/maven2/org/apache/SeaTunnel/SeaTunnel-hadoop3-3.1.4-uber/2.3.1/SeaTunnel-hadoop3-3.1.4-uber-2.3.1-optional.jar

env {
  execution.parallelism = 2
  job.mode = "BATCH"
  checkpoint.interval = 10000
}




source {
  FakeSource {
    parallelism = 2
    result_table_name = "fake"
    row.num = 16
    schema = {
      fields {
        name = "string"
        age = "int"
      }
    }
  }
}








sink {
  Console {
  }
}

cd opt/module/SeaTunnel-2.3.1
./bin/SeaTunnel.sh --config ./config/v2.batch.config.template -e lcoal

vim mysql_2console.conf




mysql_2console.conf




env {
  execution.parallelism = 2
  job.mode = "BATCH"
  checkpoint.interval = 10000
}
source{
    Jdbc {
        url = "jdbc:mysql://hadoop102/dim_db?useUnicode=true&characterEncoding=utf8&useSSL=false"
        driver = "com.mysql.cj.jdbc.Driver"
        connection_check_timeout_sec = 100
        user = "root"
        password = "xxxxxx"
        query = "select * from dim_basicdata_date_a_d where date < '2010-12-31'"
    }
}




sink {
    Console {
    }
}

CREATE DATABASE dim_db DEFAULT CHARACTER SET utf8 DEFAULT COLLATE utf8_general_ci;




drop table if exists  dim_db.dim_basicdata_date_a_d;
create table if not exists dim_db.dim_basicdata_date_a_d
(
    `date`          varchar(40) comment '日期',
    `year`          varchar(40) comment '年',
    `quarter`       varchar(40) comment '季度（1/2/3/4）',
    `season`        varchar(40) comment '季节（春季/夏季/秋季/冬季）',
    `month`         varchar(40) comment '月',
    `day`           varchar(40) comment '日',
    `week`          varchar(40) comment '年内第几周',
    `weekday`       varchar(40) comment '周几（1-周一/2-周二/3-周三/4-周四/5-周五/6-周六/7-周日）',
    `is_workday`    varchar(40) comment '是否是工作日（1-是,0-否）',
    `date_type`     varchar(40) comment '节假日类型（工作日/法定上班[调休]/周末/节假日）',
    `update_date`   varchar(40) comment '更新日期'
);

cd opt/module/SeaTunnel-2.3.1
./bin/SeaTunnel.sh --config ./job/mysql_2console.conf  -e local

CREATE database db_hive;




drop table if exists  db_hive.dim_basicdata_date_a_d;
create table if not exists db_hive.dim_basicdata_date_a_d
(
    `date`          string comment '日期',
    `year`          string comment '年',
    `quarter`       string comment '季度（1/2/3/4）',
    `season`        string comment '季节（春季/夏季/秋季/冬季）',
    `month`         string comment '月',
    `day`           string comment '日',
    `week`          string comment '年内第几周',
    `weekday`       string comment '周几（1-周一/2-周二/3-周三/4-周四/5-周五/6-周六/7-周日）',
    `is_workday`    string comment '是否是工作日（1-是,0-否）',
    `date_type`     string comment '节假日类型（工作日/法定上班[调休]/周末/节假日）',
    `update_date`   string comment '更新日期'
);

env {
  execution.parallelism = 2
  job.mode = "BATCH"
  checkpoint.interval = 10000
}
source{
  Hive {
    table_name = "db_hive.dim_basicdata_date_a_d"
    metastore_uri = "thrift://hadoop102:9083"
  }
}




sink {
    Console {
    }
}

    <!-- 为了方便连接，采用直连的方式连接到hive数据库，注释掉下面三条配置信息 -->
    <!-- 指定存储元数据要连接的地址 -->


        <property>
        <name>hive.metastore.uris</name>
        <value>thrift://hadoop102:9083</value>
    </property>




    <!-- 指定 hiveserver2 连接的 host -->
    <property>
        <name>hive.server2.thrift.bind.host</name>
        <value>hadoop102</value>
    </property>


    <!-- 指定 hiveserver2 连接的端口号 -->
    <property>
        <name>hive.server2.thrift.port</name>
        <value>10000</value>
    </property>

cd opt/module/SeaTunnel-2.3.1
./bin/SeaTunnel.sh --config ./job/hive_2console.conf -e local

dim_basicdate_mysql_2hive.conf




env {
  execution.parallelism = 2
  job.mode = "BATCH"
  checkpoint.interval = 10000
}
source{
    Jdbc {
        url = "jdbc:mysql://hadoop102/dim_db?useUnicode=true&characterEncoding=utf8&useSSL=false"
        driver = "com.mysql.cj.jdbc.Driver"
        connection_check_timeout_sec = 100
        user = "root"
        password = "111111"
        query = "select * from dim_basicdata_date_a_d"
    }
}




sink {
    Hive {
        table_name = "db_hive.dim_basicdata_date_a_d"
        metastore_uri = "thrift://hadoop102:9083"
    }
}

cd opt/module/SeaTunnel-2.3.1
./bin/SeaTunnel.sh --config ./job/dim_basicdate_mysql_2hive.conf-e local
