上一篇文章《Kubernetes安装篇（上）：基于Minikube方式部署本地环境》介绍了基于本地环境下的 Kubernetes
安装，目的在于搭建本地开发环境。但在实际生产环境中，Kubernetes
环境就比这复杂的多，起码也是集群起步，因此，本文将从生产环境出发，为你带来基于生产环境下的 Kubernetes
集群部署，让你真正懂得该如何部署真正的 Kubernetes
集群环境。
1、环境准备
采用 VMware 虚拟机安装 Kubernetes 集群，准备环境情况如下：
1）2 台虚拟机：CentOS 7，配置越高越好！
2）Docker Version：19.03.13
3）kubeadm Version：V1.20.0
2、系统初始化
在安装之前，一些系统参数、配置需统一配置，确保后续安装的顺利进行。
系统初始化部分，均需在 Master、Node 节点上执行。
2.1 设置系统主机名
hostnamectl set-hostname <hostname>
执行过程：
1) Master 节点
[root@localhost xcbeyond]# hostnamectl set-hostname k8s-master
2) Node 节点：
[root@localhost xcbeyond]# hostnamectl set-hostname k8s-node01
2.2 修改 host 文件
为了方便集群间各节点间可以直接通过主机名互通，因此建议修改 host 文件。
在 Master、Node 节点上分别修改 host 文件 /etc/hosts
，添加以下内容：
192.168.11.100 k8s-master
192.168.11.101 k8s-node01
上述 IP 是对应节点的实际 IP。
2.3 安装依赖包
在接下来 Kubernetes 使用过程中，可能涉及一些工具，事先安装便于后期使用。
yum install -y conntrack ntpdate ntp ipvsadm ipset jq iptables curl sysstat libseccomp net-tools
2.4 设置防火墙为 Iptables 并设置空规则
systemctl stop firewalld && systemctl disable firewalld
yum -y install iptables-services && systemctl start iptables && systemctl enable iptables&& iptables -F && service iptables save
2.5 关闭 SELINUX
swapoff -a && sed -i '/ swap s/^\(.*\)$/#\1/g' etc/fstab
# 将SELinux禁用
setenforce 0 && sed -i 's/^SELINUX=.*/SELINUX=disabled/' etc/selinux/config
2.6 调整内核参数
cat > kubernetes.conf <<EOF
net.bridge.bridge-nf-call-iptables=1 # 节点上的iptables能够正确地查看桥接流量
net.bridge.bridge-nf-call-ip6tables=1 # 节点上的iptables能够正确地查看桥接流量
net.ipv4.ip_forward=1
net.ipv4.tcp_tw_recycle=0
vm.swappiness=0 # 禁止使用 swap 空间，只有当系统 OOM 时才允许使用它
vm.overcommit_memory=1 # 不检查物理内存是否够用
vm.panic_on_oom=0 # 开启 OOM
fs.inotify.max_user_instances=8192
fs.inotify.max_user_watches=1048576
fs.file-max=52706963
fs.nr_open=52706963
net.ipv6.conf.all.disable_ipv6=1
net.netfilter.nf_conntrack_max=2310720
EOF
cp kubernetes.conf etc/sysctl.d/kubernetes.conf
sysctl -p etc/sysctl.d/kubernetes.conf
2.7 调整时区
(如果时区正确，则无需调整)
# 设置系统时区为中国/上海
timedatectl set-timezone Asia/Shanghai
# 将当前的 UTC 时间写入硬件时钟
timedatectl set-local-rtc 0
# 重启依赖于系统时间的服务
systemctl restart rsyslog
systemctl restart crond
2.8 升级系统内核为 5.4
CentOS 7.x 系统自带的 3.10.x 内核存在一些Bugs，导致运行的 Docker、Kubernetes 不稳定，例如： rpm -Uvh http://www.elrepo.org/elrepo-release-7.0-3.el7.elrepo.noarch.rpm
rpm -Uvh http://www.elrepo.org/elrepo-release-7.0-3.el7.elrepo.noarch.rpm
# 安装完成后检查/boot/grub2/grub.cfg中对应内核menuentry中是否包含initrd16配置，如果没有，再安装一次！
yum --enablerepo=elrepo-kernel install -y kernel-lt
# 设置开机从新内核启动
grub2-set-default 'CentOS Linux (5.4.93-1.el7.elrepo.x86_64) 7 (Core)'
执行过程：
[root@k8s-master xcbeyond]# uname -r
3.10.0-1127.19.1.el7.x86_64
[root@k8s-master xcbeyond]# rpm -Uvh http://www.elrepo.org/elrepo-release-7.0-3.el7.elrepo.noarch.rpm
获取http://www.elrepo.org/elrepo-release-7.0-3.el7.elrepo.noarch.rpm
警告：/var/tmp/rpm-tmp.xF145X: 头V4 DSA/SHA1 Signature, 密钥 ID baadae52: NOKEY
准备中... ################################# [100%]
正在升级/安装...
1:elrepo-release-7.0-3.el7.elrepo ################################# [100%]
[root@k8s-master xcbeyond]# yum --enablerepo=elrepo-kernel install -y kernel-lt
已加载插件：fastestmirror, langpacks
Loading mirror speeds from cached hostfile
……
警告：RPM 数据库已被非 yum 程序修改。
正在安装 : kernel-lt-5.4.93-1.el7.elrepo.x86_64 1/1
验证中 : kernel-lt-5.4.93-1.el7.elrepo.x86_64 1/1
已安装:
kernel-lt.x86_64 0:5.4.93-1.el7.elrepo
完毕！
[root@k8s-master xcbeyond]# grub2-set-default 'CentOS Linux (5.4.93-1.el7.elrepo.x86_64) 7 (Core)'
[root@k8s-master xcbeyond]# reboot
重启完成后，查看系统内核已升级成功：
[xcbeyond@k8s-master ~]$ uname -r
5.4.93-1.el7.elrepo.x86_64
别忘了在 node 节点上执行！
2.9 kube-proxy 开启 ipvs 的前置条件
modprobe br_netfilter
cat > etc/sysconfig/modules/ipvs.modules <<EOF
#!/bin/bash
modprobe -- ip_vs
modprobe -- ip_vs_rr
modprobe -- ip_vs_wrr
modprobe -- ip_vs_sh
modprobe -- nf_conntrack_ipv4
EOF
chmod 755 etc/sysconfig/modules/ipvs.modules && bash etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4
执行过程：
[root@k8s-master xcbeyond]# modprobe br_netfilter
[root@k8s-master xcbeyond]# cat > etc/sysconfig/modules/ipvs.modules <<EOF
> #!/bin/bash
> modprobe -- ip_vs
> modprobe -- ip_vs_rr
> modprobe -- ip_vs_wrr
> modprobe -- ip_vs_sh
> modprobe -- nf_conntrack_ipv4
> EOF
[root@k8s-master xcbeyond]# chmod 755 etc/sysconfig/modules/ipvs.modules && bash etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4
modprobe: FATAL: Module nf_conntrack_ipv4 not found.
别忘了在 Node 节点上执行！
3、Docker 安装
此处不再讲述 Docker 安装的过程，具体可参考之前写的文章。
4、安装 kubeadm
4.1 安装 kubeadm
、kubectl
和 kubelet
需要在每台机器上（Master、Node 节点）安装以下的软件包：
1)kubeadm
：用来初始化集群的指令。2) kubectl
：用来与集群通信的命令行工具。3) kubelet
：在集群中的每个节点上用来启动 Pod 和容器等。
（1）配置Kubernetes数据源
cat <<EOF > etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=http://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=0
repo_gpgcheck=0
gpgkey=http://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg
http://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
EOF
执行过程：
[root@k8s-master xcbeyond]# cat <<EOF > etc/yum.repos.d/kubernetes.repo
> [kubernetes]
> name=Kubernetes
> baseurl=http://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64
> enabled=1
> gpgcheck=0
> repo_gpgcheck=0
> gpgkey=http://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg
> http://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
> EOF
（2）安装 kubeadm
、kubectl
、kubelet
yum -y install kubeadm kubectl kubelet
执行过程：
[root@k8s-master xcbeyond]# yum -y install kubeadm kubectl kubelet
已加载插件：fastestmirror, langpacks
Loading mirror speeds from cached hostfile
* base: mirrors.neusoft.edu.cn
* elrepo: mirrors.neusoft.edu.cn
* extras: mirrors.neusoft.edu.cn
* updates: mirrors.neusoft.edu.cn
kubernetes | 1.4 kB 00:00:00
正在解决依赖关系
--> 正在检查事务
---> 软件包 kubeadm.x86_64.0.1.20.2-0 将被 安装
--> 正在处理依赖关系 kubernetes-cni >= 0.8.6，它被软件包 kubeadm-1.20.2-0.x86_64 需要
--> 正在处理依赖关系 cri-tools >= 1.13.0，它被软件包 kubeadm-1.20.2-0.x86_64 需要
---> 软件包 kubectl.x86_64.0.1.20.2-0 将被 安装
---> 软件包 kubelet.x86_64.0.1.20.2-0 将被 安装
--> 正在处理依赖关系 socat，它被软件包 kubelet-1.20.2-0.x86_64 需要
--> 正在检查事务
---> 软件包 cri-tools.x86_64.0.1.13.0-0 将被 安装
---> 软件包 kubernetes-cni.x86_64.0.0.8.7-0 将被 安装
---> 软件包 socat.x86_64.0.1.7.3.2-2.el7 将被 安装
--> 解决依赖关系完成
依赖关系解决
=========================================================================================
Package 架构 版本 源 大小
=========================================================================================
正在安装:
kubeadm x86_64 1.20.2-0 kubernetes 8.3 M
kubectl x86_64 1.20.2-0 kubernetes 8.5 M
kubelet x86_64 1.20.2-0 kubernetes 20 M
为依赖而安装:
cri-tools x86_64 1.13.0-0 kubernetes 5.1 M
kubernetes-cni x86_64 0.8.7-0 kubernetes 19 M
socat x86_64 1.7.3.2-2.el7 base 290 k
事务概要
=========================================================================================
安装 3 软件包 (+3 依赖软件包)
总计：61 M
总下载量：52 M
安装大小：262 M
Downloading packages:
(1/5): 14bfe6e75a9efc8eca3f638eb22c7e2ce759c67f95b43b16fae4ebabde1549f3-cri-tools-1.13.0-0.x86_64.rpm | 5.1 MB 00:00:03
(2/5): b46459afb07aaf12937f7f310b876fab9f5f904eaa8f4a88a21547477eafba78-kubeadm-1.20.2-0.x86_64.rpm | 8.3 MB 00:00:06
(3/5): socat-1.7.3.2-2.el7.x86_64.rpm | 290 kB 00:00:02
(4/5): a79d632b1f8c40d2a00e2f98cba68b55c3928d70b97c32aad61c10e17965c2f1-kubelet-1.20.2-0.x86_64.rpm | 20 MB 00:00:14
(5/5): db7cb5cb0b3f6875f54d10f02e625573988e3e91fd4fc5eef0b1876bb18604ad-kubernetes-cni-0.8.7-0.x86_64.rpm | 19 MB 00:00:11
-----------------------------------------------------------------------------------------
总计 2.8 MB/s | 52 MB 00:00:18
Running transaction check
Running transaction test
Transaction test succeeded
Running transaction
正在安装 : socat-1.7.3.2-2.el7.x86_64 1/6
正在安装 : kubelet-1.20.2-0.x86_64 2/6
正在安装 : kubernetes-cni-0.8.7-0.x86_64 3/6
正在安装 : kubectl-1.20.2-0.x86_64 4/6
正在安装 : cri-tools-1.13.0-0.x86_64 5/6
正在安装 : kubeadm-1.20.2-0.x86_64 6/6
验证中 : kubernetes-cni-0.8.7-0.x86_64 1/6
验证中 : kubelet-1.20.2-0.x86_64 2/6
验证中 : kubeadm-1.20.2-0.x86_64 3/6
验证中 : cri-tools-1.13.0-0.x86_64 4/6
验证中 : kubectl-1.20.2-0.x86_64 5/6
验证中 : socat-1.7.3.2-2.el7.x86_64 6/6
已安装:
kubeadm.x86_64 0:1.20.2-0 kubectl.x86_64 0:1.20.2-0 kubelet.x86_64 0:1.20.2-0
作为依赖被安装:
cri-tools.x86_64 0:1.13.0-0 kubernetes-cni.x86_64 0:0.8.7-0 socat.x86_64 0:1.7.3.2-2.el7
完毕！
（3）设置开机启动 kubelet
systemctl enable kubelet.service
执行过程：
[root@k8s-master xcbeyond]# systemctl enable kubelet.service
Created symlink from etc/systemd/system/multi-user.target.wants/kubelet.service to usr/lib/systemd/system/kubelet.service.
别忘了在 Node 节点上执行！
4.2 创建集群
4.2.1 安装镜像拉取
kubeadm
创建集群默认使用的 docker 镜像仓库为 k8s.gcr.io
，而国内无法直接访问，需要中转才能使用。
（已将所需镜像构建发布在 docker hub上，方便国内直接使用）
Master、Node 节点都需要执行！
安装镜像拉取脚本k8s-images-pull.sh如下：
#!/bin/bash
kubernetes_version="v1.20.0"
# 下载需要的镜像(docker hub)
kubeadm config images list --kubernetes-version=${kubernetes_version} |sed -e 's/^/docker pull g' -e 's#k8s.gcr.io#xcbeyond#g' |sh -x
# 重命名镜像
docker images |grep xcbeyond |awk '{print "docker tag ",$1":"$2,$1":"$2}' |sed -e 's#xcbeyond#k8s.gcr.io#2' |sh -x
# 删除xcbeyond镜像
docker images |grep xcbeyond |awk '{print "docker rmi ", $1":"$2}' |sh -x
查看需要哪些镜像：
kubeadm config images list
执行过程如下：
[root@k8s-master xcbeyond]# ./k8s-images-pull.sh
+ docker pull xcbeyond/kube-apiserver:v1.20.0
v1.20.0: Pulling from xcbeyond/kube-apiserver
f398b465657e: Pull complete
cbcdf8ef32b4: Pull complete
a9b56b1d4e55: Pull complete
Digest: sha256:c54e33e290aa1463eae80f6bd4440af3def87f01f86a37a12ec213eb205e538a
Status: Downloaded newer image for xcbeyond/kube-apiserver:v1.20.0
docker.io/xcbeyond/kube-apiserver:v1.20.0
+ docker pull xcbeyond/kube-controller-manager:v1.20.0
v1.20.0: Pulling from xcbeyond/kube-controller-manager
f398b465657e: Already exists
cbcdf8ef32b4: Already exists
2ffb969cde54: Pull complete
Digest: sha256:5f6321aaa0d9880bd3a96a0d589fc96e912e30f7f5f6d6f53c406eb2b4b20b68
Status: Downloaded newer image for xcbeyond/kube-controller-manager:v1.20.0
docker.io/xcbeyond/kube-controller-manager:v1.20.0
+ docker pull xcbeyond/kube-scheduler:v1.20.0
v1.20.0: Pulling from xcbeyond/kube-scheduler
f398b465657e: Already exists
cbcdf8ef32b4: Already exists
2f71710e6dc2: Pull complete
Digest: sha256:10f3ae3ed09f92b3be037e1dd465214046135eabd9879db43b3fe7159a1bae1c
Status: Downloaded newer image for xcbeyond/kube-scheduler:v1.20.0
docker.io/xcbeyond/kube-scheduler:v1.20.0
+ docker pull xcbeyond/kube-proxy:v1.20.0
v1.20.0: Pulling from xcbeyond/kube-proxy
e5a8c1ed6cf1: Pull complete
f275df365c13: Pull complete
6a2802bb94f4: Pull complete
cb3853c52da4: Pull complete
db342cbe4b1c: Pull complete
9a72dd095a53: Pull complete
6943e8f5bc84: Pull complete
Digest: sha256:d583d644b186519597dfdfe420710ab0888927e286ea43b2a6f54ba4329e93e4
Status: Downloaded newer image for xcbeyond/kube-proxy:v1.20.0
docker.io/xcbeyond/kube-proxy:v1.20.0
+ docker pull xcbeyond/pause:3.2
3.2: Pulling from xcbeyond/pause
c74f8866df09: Pull complete
Digest: sha256:4dcd2075946239537e21adcf4bb300f07eb5c2c8058d699480f2ae62a5cc5085
Status: Downloaded newer image for xcbeyond/pause:3.2
docker.io/xcbeyond/pause:3.2
+ docker pull xcbeyond/etcd:3.4.13-0
3.4.13-0: Pulling from xcbeyond/etcd
4000adbbc3eb: Already exists
d72167780652: Already exists
d60490a768b5: Already exists
4a4b5535d134: Pull complete
0dac37e8b31a: Pull complete
Digest: sha256:79d32edd429163b1ae404eeb078c75fc2f63fc3d606e0cd57285c832e8181ea3
Status: Downloaded newer image for xcbeyond/etcd:3.4.13-0
docker.io/xcbeyond/etcd:3.4.13-0
+ docker pull xcbeyond/coredns:1.7.0
1.7.0: Pulling from xcbeyond/coredns
c6568d217a00: Pull complete
6937ebe10f02: Pull complete
Digest: sha256:4310e3ed7a0a9b82cfb2d31c6a7c102b8d05fef2b0208072b87dc4ceca3c47bb
Status: Downloaded newer image for xcbeyond/coredns:1.7.0
docker.io/xcbeyond/coredns:1.7.0
+ docker tag xcbeyond/pause:3.2 k8s.gcr.io/pause:3.2
+ docker tag xcbeyond/kube-controller-manager:v1.20.0 k8s.gcr.io/kube-controller-manager:v1.20.0
+ docker tag xcbeyond/coredns:1.7.0 k8s.gcr.io/coredns:1.7.0
+ docker tag xcbeyond/etcd:3.4.13-0 k8s.gcr.io/etcd:3.4.13-0
+ docker tag xcbeyond/kube-proxy:v1.20.0 k8s.gcr.io/kube-proxy:v1.20.0
+ docker tag xcbeyond/kube-scheduler:v1.20.0 k8s.gcr.io/kube-scheduler:v1.20.0
+ docker tag xcbeyond/kube-apiserver:v1.20.0 k8s.gcr.io/kube-apiserver:v1.20.0
+ docker rmi xcbeyond/pause:3.2
Untagged: xcbeyond/pause:3.2
Untagged: xcbeyond/pause@sha256:4dcd2075946239537e21adcf4bb300f07eb5c2c8058d699480f2ae62a5cc5085
+ docker rmi xcbeyond/kube-controller-manager:v1.20.0
Untagged: xcbeyond/kube-controller-manager:v1.20.0
Untagged: xcbeyond/kube-controller-manager@sha256:5f6321aaa0d9880bd3a96a0d589fc96e912e30f7f5f6d6f53c406eb2b4b20b68
+ docker rmi xcbeyond/coredns:1.7.0
Untagged: xcbeyond/coredns:1.7.0
Untagged: xcbeyond/coredns@sha256:4310e3ed7a0a9b82cfb2d31c6a7c102b8d05fef2b0208072b87dc4ceca3c47bb
+ docker rmi xcbeyond/etcd:3.4.13-0
Untagged: xcbeyond/etcd:3.4.13-0
Untagged: xcbeyond/etcd@sha256:79d32edd429163b1ae404eeb078c75fc2f63fc3d606e0cd57285c832e8181ea3
+ docker rmi xcbeyond/kube-proxy:v1.20.0
Untagged: xcbeyond/kube-proxy:v1.20.0
Untagged: xcbeyond/kube-proxy@sha256:d583d644b186519597dfdfe420710ab0888927e286ea43b2a6f54ba4329e93e4
+ docker rmi xcbeyond/kube-scheduler:v1.20.0
Untagged: xcbeyond/kube-scheduler:v1.20.0
Untagged: xcbeyond/kube-scheduler@sha256:10f3ae3ed09f92b3be037e1dd465214046135eabd9879db43b3fe7159a1bae1c
+ docker rmi xcbeyond/kube-apiserver:v1.20.0
Untagged: xcbeyond/kube-apiserver:v1.20.0
Untagged: xcbeyond/kube-apiserver@sha256:c54e33e290aa1463eae80f6bd4440af3def87f01f86a37a12ec213eb205e538a
[root@k8s-master xcbeyond]# docker image ls
REPOSITORY TAG IMAGE ID CREATED SIZE
k8s.gcr.io/pause 3.2 b76329639608 16 hours ago 683kB
k8s.gcr.io/kube-controller-manager v1.20.0 630f45a9961f 16 hours ago 116MB
k8s.gcr.io/coredns 1.7.0 4e42ad8cda50 21 hours ago 45.2MB
k8s.gcr.io/etcd 3.4.13-0 999b6137af27 21 hours ago 253MB
k8s.gcr.io/kube-proxy v1.20.0 51912faaf3a3 21 hours ago 118MB
k8s.gcr.io/kube-scheduler v1.20.0 62181d1bf9a1 21 hours ago 46.4MB
k8s.gcr.io/kube-apiserver v1.20.0 0f7e1178e374 22 hours ago 122MB
别忘了在 Node 节点上执行！
4.2.2 初始化主节点
Master
节点是指 Kubernetes
集群中的控制节点，包括 etcd
（集群数据库）和 API Server
（集群控制的入口进程）。
初始化主节点，执行 kubeadm init <args>
。
（1）修改 kubeadm
初始化配置文件。
执行 kubeadm config print init-defaults
命令获取 kubeadm
初始配置文件模板，将其存放在 kubeadm-config.yml：
kubeadm config print init-defaults > kubeadm-config.yml
并修改以下参数：
localAPIEndpoint:
advertiseAddress: 192.168.66.10 # 主节点实际IP
kubernetesVersion: v1.20.0
networking:
podSubnet: "10.244.0.0/16" #
serviceSubnet: 10.96.0.0/12
# 新增如下内容：
---
apiVersion: kubeproxy.config.k8s.io/v1alpha1
kind: KubeProxyConfiguration
featureGates:
SupportIPVSProxyMode: true
mode: ipvs
kubeadm init --config=kubeadm-config.yml --upload-certs | tee kubeadm-init.log
（2）初始化。
kubeadm init --config=kubeadm-config.yml | tee kubeadm-init.log
方便初始化日志查看，将其留存在 kubeadm-init.log 文件。
如果说某次执行
kubeadm init
初始化失败，在下一次执行kubeadm init
初始化语句之前，先执行kubeadm reset
命令。这个命令的作用是重置节点，可以把这个命令理解为：上一次kubeadm init
初始化操作失败了，该命令清理了之前的失败环境。
执行过程：
[root@k8s-master xcbeyond]# kubeadm init --config=kubeadm-config.yml | tee kubeadm-init.log
[init] Using Kubernetes version: v1.20.0
[preflight] Running pre-flight checks
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [k8s-master kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local] and IPs [10.96.0.1 192.168.11.100]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [k8s-master localhost] and IPs [192.168.11.100 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [k8s-master localhost] and IPs [192.168.11.100 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 28.009413 seconds
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[kubelet] Creating a ConfigMap "kubelet-config-1.20" in namespace kube-system with the configuration for the kubelets in the cluster
[upload-certs] Skipping phase. Please see --upload-certs
[mark-control-plane] Marking the node k8s-master as control-plane by adding the labels "node-role.kubernetes.io/master=''" and "node-role.kubernetes.io/control-plane='' (deprecated)"
[mark-control-plane] Marking the node k8s-master as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
[bootstrap-token] Using token: abcdef.0123456789abcdef
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxy
Your Kubernetes control-plane has initialized successfully!
To start using your cluster, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Alternatively, if you are the root user, you can run:
export KUBECONFIG=/etc/kubernetes/admin.conf
You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
https://kubernetes.io/docs/concepts/cluster-administration/addons/
Then you can join any number of worker nodes by running the following on each as root:
kubeadm join 192.168.11.100:6443 --token abcdef.0123456789abcdef \
--discovery-token-ca-cert-hash sha256:79f34a5872b3df5817d29330ec055d14509a66c96c5de01bfa0d640fab671d90
4.2.3 加入主节点
在 Master 节点上 kubeadm init
执行成功后，注意日志末尾的提示，按要求在 Master、Node 节点上执行相关命令即可。
kubeadm init
初始化执行日志如下：
……
Your Kubernetes control-plane has initialized successfully!
To start using your cluster, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Alternatively, if you are the root user, you can run:
export KUBECONFIG=/etc/kubernetes/admin.conf
You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
https://kubernetes.io/docs/concepts/cluster-administration/addons/
Then you can join any number of worker nodes by running the following on each as root:
kubeadm join 192.168.11.100:6443 --token abcdef.0123456789abcdef \
--discovery-token-ca-cert-hash sha256:79f34a5872b3df5817d29330ec055d14509a66c96c5de01bfa0d640fab671d90
要使得非 root 用户可以运行 kubectl
，请运行以下命令（是 kubeadm init
输出日志的部分内容）：
mkdir -p $HOME/.kube
sudo cp -i etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
或者，如果你是 root
用户，则可以运行：
export KUBECONFIG=/etc/kubernetes/admin.conf
4.2.4 加入工作节点
工作节点是你的工作负载（容器和 Pod 等）运行的地方。要将新节点添加到集群，请对每台工作节点执行以下操作。
root 用户执行 kubeadm init
输出的命令：
kubeadm join 192.168.11.100:6443 --token abcdef.0123456789abcdef \
--discovery-token-ca-cert-hash sha256:79f34a5872b3df5817d29330ec055d14509a66c96c5de01bfa0d640fab671d90
执行过程：
[root@k8s-node01 xcbeyond]# kubeadm join 192.168.11.100:6443 --token abcdef.0123456789abcdef \
> --discovery-token-ca-cert-hash sha256:79f34a5872b3df5817d29330ec055d14509a66c96c5de01bfa0d640fab671d90
[preflight] Running pre-flight checks
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.
Run 'kubectl get nodes' on the control-plane to see this node join the cluster.
4.2.5 安装Pod网络附加插件
至此，在 Master 节点执行 kubectl get nodes
命令：
[root@k8s-master xcbeyond]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master NotReady control-plane,master 1m8s v1.20.2
k8s-node01 NotReady <none> 18s v1.20.2
发现是 NotReady
状态，因为 Kubernetes 要求必须要存在一个网络，即：目前还没有构建 Pod 网络附加插件，此时需要安装 Pod 网络附加插件。
可直接使用官方提供的 kube-flannel.yml
文件，进行创建。
（1）下载官方提供的 kube-flannel.yml 文件。
文件地址：https://github.com/coreos/flannel/blob/master/Documentation/kube-flannel.yml
（2）创建网络。
[root@k8s-master xcbeyond]# kubectl create -f kube-flannel.yml
podsecuritypolicy.policy/psp.flannel.unprivileged created
clusterrole.rbac.authorization.k8s.io/flannel created
clusterrolebinding.rbac.authorization.k8s.io/flannel created
serviceaccount/flannel created
configmap/kube-flannel-cfg created
daemonset.apps/kube-flannel-ds created
（3）查看 Pod。
如果 flannel 还未
Running
状态，可稍等一会儿，等待构建成功。
[root@k8s-master xcbeyond]# kubectl get pod -n kube-system
NAME READY STATUS RESTARTS AGE
coredns-74ff55c5b-fr4jj 0/1 ContainerCreating 0 6m3s
coredns-74ff55c5b-wcj2h 0/1 ContainerCreating 0 6m3s
etcd-k8s-master 1/1 Running 0 6m5s
kube-apiserver-k8s-master 1/1 Running 0 6m5s
kube-controller-manager-k8s-master 1/1 Running 0 6m5s
kube-flannel-ds-2nkcv 1/1 Running 0 13s
kube-flannel-ds-m8tf2 1/1 Running 0 13s
kube-proxy-mft9t 0/1 CrashLoopBackOff 6 6m3s
kube-proxy-n67px 0/1 CrashLoopBackOff 3 68s
kube-scheduler-k8s-master 1/1 Running 0 6m5s
（4）查看节点状态。
此时已经 Ready
状态。
[root@k8s-master xcbeyond]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
k8s-master Ready control-plane,master 6m30s v1.20.2
k8s-node01 Ready <none> 85s v1.20.2
4.3 集群环境验证
至此，基于 kubeadm
方式的集群搭建已完成，让我们一起在 Kubernetes 集群环境下开启 Kubernetes 的探索吧！
5、总结
安装过程中，可能会遇到各种形形色色的问题与障碍，大可不必担心，初次安装肯定会是这样的。
面对问题，有以下几点看法或建议：
1) 遇到问题，说明你亲自动手过，这本身就是一种乐趣。（坑就是这么被踩出来的）
2) 遇事不要慌，认真查看出错日志及提示。
3) 根据关键错误信息，各种搜索齐上阵，尤其是在官方网站或 github。
4) 解决问题后，要记录。
参考文章：
1. https://kubernetes.io/zh/docs/setup/production-environment/tools/kubeadm/install-kubeadm/
2. https://www.cnblogs.com/nb-blog/p/10636733.html
3. https://www.cnblogs.com/shoufu/p/13047723.html
感谢您的阅读，也欢迎您发表关于这篇文章的任何建议，关注我，技术不迷茫！
图解 Kubernetes Deployment 故障排查 | 推荐长期收藏 构建基于Spring Cloud向Service Mesh框架迁移的解决方案及思路 全方位解读服务网格（Service Mesh）的背景和概念 微服务架构下的核心话题 (三)：微服务架构的技术选型
喜欢就点个"在看"呗，留言、转发朋友圈
文章转载自程序猿技术大咖，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。
