记一次Redis哨兵自动切换失败故障定位及处理

IT小Chen 2023-07-10

1828

环境说明：

redis实例:
192.168.126.128:6379  主
192.168.126.128:6380  从
192.168.126.128:6381  从

redis哨兵:
192.168.126.128:26379
192.168.126.128:26380
192.168.126.128:26381

redis版本：
测试4.x,5.x,6.x等版本都有类似问题。

问题现象1：

redis 哨兵架构下，关闭master主库后，主从没有自动切换，哨兵日志提示如下：

tail -100f sentinel_26379.log

......
9569:X 08 Jul 2023 18:57:09.888 # +sdown master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:09.956 # +odown master mymaster 192.168.126.128 6379 #quorum 2/2
9569:X 08 Jul 2023 18:57:09.956 # +new-epoch 1
9569:X 08 Jul 2023 18:57:09.956 # +try-failover master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:09.966 # +vote-for-leader d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.268 # b98812cd6e0b3e0a3a8527244cc09bb3a0c5f251 voted for d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.270 # c56a629c526c80483792ecae8d80eba98796583b voted for d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.343 # +elected-leader master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.343 # +failover-state-select-slave master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.410 # -failover-abort-no-good-slave master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.463 # Next failover delay: I will not start a failover before Sat Jul  8 19:03:10 2023

显示：-failover-abort-no-good-slave 没有可用的slave，故障转移终止，6分钟后再次尝试故障转移：

[redis@cjc-db-01 log]$ cat sentinel_26379.log |grep delay
9569:X 08 Jul 2023 18:57:10.463 # Next failover delay: I will not start a failover before Sat Jul  8 19:03:10 2023
9569:X 08 Jul 2023 19:03:10.337 # Next failover delay: I will not start a failover before Sat Jul  8 19:09:10 2023
9569:X 08 Jul 2023 19:09:10.515 # Next failover delay: I will not start a failover before Sat Jul  8 19:15:10 2023
9569:X 08 Jul 2023 19:15:10.697 # Next failover delay: I will not start a failover before Sat Jul  8 19:21:10 2023
9569:X 08 Jul 2023 19:21:11.081 # Next failover delay: I will not start a failover before Sat Jul  8 19:27:11 2023
9569:X 08 Jul 2023 19:27:11.709 # Next failover delay: I will not start a failover before Sat Jul  8 19:33:11 2023
......

最终故障转移一直失败，没有成功

问题现象2：

通过redis哨兵failover切换命令，执行报错：

127.0.0.1:26379> sentinel failover mymaster
(error) NOGOODSLAVE No suitable replica to promote

两个问题现象都表示主从无法正常切换。

问题原因：

通常情况下，Next failover delay: I will not start a failover before Sat Jul ..错误的可能原因有以下几种：

1：bind 参数

配置文件中 bind 参数没有配置或配置有问题，如无特殊要求， 可按如下方式配置：
bind 0.0.0.0

2.auth-pass参数

哨兵配置文件没有记录redis密码，或密码记录错误
添加参数，例如：
sentinel auth-pass mymaster 密码

3.protected-mode 参数

哨兵配置文件中启用了protected-mode，需要关闭，添加：
protected-mode no

4.rename-command CONFIG配置

redis.conf配置文件中，配置了rename-command CONFIG参数，例如：
rename-command CONFIG ""
将CONFIG命令禁用，防止人为修改
需要关闭此参数：
###rename-command CONFIG ""

经排查，并不是上述四种原因导致的。

既然切换时找不到可以提升为master的从库，还有一种可能：

从库的slave-priority或replica-priority参数配置为0，其中0表示不能提升为master。

查询从库slave-priority/replica-priority参数:

127.0.0.1:6379> config get slave-priority
1) "slave-priority"
2) "0"

127.0.0.1:6381> config get slave-priority
1) "slave-priority"
2) "0"

127.0.0.1:6380> config get slave-priority
1) "slave-priority"
2) "0"

居然都是0，不允许提升为master主库，检查配置文件也都是0：

[redis@cjc-db-01 conf]$ cat redis_6379.conf |grep -i priority
replica-priority 0
[redis@cjc-db-01 conf]$ cat redis_6380.conf |grep -i priority
replica-priority 0
[redis@cjc-db-01 conf]$ cat redis_6381.conf |grep -i priority
replica-priority 0

很奇怪，slave-priority/replica-priority参数值默认值100，安装redis时replica-priority配置的值也是100。

为什么在没有手动调整redis.conf配置文件情况下，replica-priority值自动变成0了？

之前手动切换时，确实在redis内部修改过slave-priority参数，但是没有手动修改redis.conf配置文件，只是临时修改一次，用于切换。

redis-cli -p 6379
config set slave-priority 0

难道redis修改参数类似于oracle的scope=both方式吗，修改后内存和配置文件同时生效？

验证：

修改参数前：

127.0.0.1:6379> config get slave-priority
1) "slave-priority"
2) "100"

查看配置文件

[redis@cjc-db-01 conf]$ cat redis_6379.conf |grep -i priority
replica-priority 100

开始修改参数：

127.0.0.1:6379> config set slave-priority 0

查看配置文件，参数并没有发生改变

[redis@cjc-db-01 conf]$ cat redis_6379.conf |grep -i priority
replica-priority 100

此时执行一次redis切换

redis-cli -p 26379

查看

info Sentinel

切换

sentinel failover mymaster

查看，切换完成

info Sentinel

再次查看配置文件：

[redis@cjc-db-01 conf]$ cat redis_6379.conf |grep -i priority
replica-priority 0

此时redis_6379.conf配置文件中replica-priority参数自动发生了改变，从100自动变成了0。

如果重启此redis实例，重启后，值仍为0。

解决方案：

在redis哨兵架构下，为了实现自动故障转移，建议将slave-priority或replica-priority参数都调为100。

即：

当前运行参数应该为100

127.0.0.1:6379> config get slave-priority 100

如不是100，手动修改

127.0.0.1:6379> config set slave-priority 100

配置文件中replica-priority参数应为100：

cat redis_6379.conf |grep -i priority

如果不是，需要手动修改

replica-priority 100

如果要模拟切换，保障至少1个节点slave-priority/replica-priority参数不为0。

总结：

由于之前模拟过几次redis哨兵自动切换，为了实现将主库切换到指定节点，手动调整了redis实例的slave-priority，从100改成0，修改后主库故障就会将master切换到另一个没有修改slave-priority参数的节点上，然后将之前修改的参数改回原值100。

但是：

切换完成后，修改slave-priority参数节点的redis.conf配置文件中replica-priority参数会被自动更新为0，如果之后这个节点发生过重启，由于redis.conf配置文件记录的replica-priority是0，重启后redis当前运行值也是0。如果两个从节点都经历过类似的情况，最终就会出现两个从节点的slave-priority/replica-priority运行参数都是0，最终导致无法正常执行切换。

实验过程如下：

启动实例

redis-server redis/conf/redis_6379.conf
redis-server redis/conf/redis_6380.conf
redis-server redis/conf/redis_6381.conf

查看进程

ps -ef|grep redis|grep redis
redis      8984      1  0 17:56 ?        00:00:00 redis-server 0.0.0.0:6379
redis      8990      1  0 17:56 ?        00:00:00 redis-server 0.0.0.0:6380
redis      8998      1  0 17:56 ?        00:00:00 redis-server 0.0.0.0:6381

查看主从状态

redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK
127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6380,state=online,offset=112,lag=0
slave1:ip=192.168.126.128,port=6381,state=online,offset=112,lag=1
master_failover_state:no-failover
master_replid:009ba10699b6689dbce7d1919495ca5786fe9ba4
master_replid2:0000000000000000000000000000000000000000

写入测试数据

127.0.0.1:6379> get xxx
(nil)
127.0.0.1:6379> set xxx cjc
OK
127.0.0.1:6379> get xxx
"cjc"

检查数据同步

[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK
127.0.0.1:6380> get xxx
"cjc"


[redis@cjc-db-01 conf]$ redis-cli -p 6381
127.0.0.1:6381> auth 111
OK
127.0.0.1:6381> get xxx
"cjc"

先不启动哨兵，执行手动切换：

模拟主库故障

[redis@cjc-db-01 conf]$ ps -ef|grep 6379
[redis@cjc-db-01 conf]$ kill -9 8984

查看从库状态

[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK
127.0.0.1:6380> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6379
master_link_status:down
master_last_io_seconds_ago:-1
......

没有哨兵，不会自动切换

从库不支持写操作

127.0.0.1:6380> get xxx
"cjc"
127.0.0.1:6380> set yyy aaa
(error) READONLY You can't write against a read only replica.

[redis@cjc-db-01 conf]$ redis-cli -p 6381
127.0.0.1:6381> auth 111
OK
127.0.0.1:6381> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6379
master_link_status:down
......


127.0.0.1:6381> get xxx
"cjc"
127.0.0.1:6381> set yyy aaa
(error) READONLY You can't write against a read only replica.

手动切换

将6380提升为主

6380:

[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK

中断主从关系，角色变成master，原来同步所得的数据集不会被丢弃

127.0.0.1:6380> slaveof no one
OK
127.0.0.1:6380> info Replication
# Replication
role:master
connected_slaves:0
min_slaves_good_slaves:0
master_failover_state:no-failover
master_replid:43bb3d9953e3af5b34a8c83193043c55ad45fb09
master_replid2:009ba10699b6689dbce7d1919495ca5786fe9ba4
master_repl_offset:390
second_repl_offset:391
repl_backlog_active:1
repl_backlog_size:1048576
repl_backlog_first_byte_offset:1
repl_backlog_histlen:390

将6381节点对应主库改成6380

[redis@cjc-db-01 conf]$ redis-cli -p 6381
127.0.0.1:6381> auth 111
OK


127.0.0.1:6381> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6379
master_link_status:down
......


127.0.0.1:6381> slaveof 192.168.126.128 6380
OK


127.0.0.1:6381> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6380
master_link_status:up
master_last_io_seconds_ago:2
......

主从同步

redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK


127.0.0.1:6380> info Replication
# Replication
role:master
connected_slaves:1
min_slaves_good_slaves:1
slave0:ip=192.168.126.128,port=6381,state=online,offset=488,lag=0
master_failover_state:no-failover
master_replid:43bb3d9953e3af5b34a8c83193043c55ad45fb09
master_replid2:009ba10699b6689dbce7d1919495ca5786fe9ba4


127.0.0.1:6380> set zzz iii

启动6379，并加入到主从

redis-server redis/conf/redis_6379.conf
[redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK


127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:0
min_slaves_good_slaves:0


加入到主从
127.0.0.1:6379> get zzz
(nil)
127.0.0.1:6379> slaveof 192.168.126.128 6380
OK
127.0.0.1:6379> get zzz
"iii"


[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK
127.0.0.1:6380> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6381,state=online,offset=2068,lag=1
slave1:ip=192.168.126.128,port=6379,state=online,offset=2068,lag=0
master_failover_state:no-failover

手动切回原主库

[redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK
127.0.0.1:6379> SLAVEOF NO ONE


[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK
127.0.0.1:6380> slaveof 192.168.126.128 6379
OK


[redis@cjc-db-01 conf]$ redis-cli -p 6381
127.0.0.1:6381> auth 111
OK
127.0.0.1:6381> slaveof 192.168.126.128 6379
OK

查看

[redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK


127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6380,state=online,offset=2222,lag=0
slave1:ip=192.168.126.128,port=6381,state=online,offset=2222,lag=0
master_failover_state:no-failover

以上就是手动故障转移过程，如果使用哨兵，会帮我们自动完成上述过程：

启动哨兵

redis-sentinel /redis/conf/redis_26379.conf

可以看到，启动26379哨兵后，对应配置文件新增# Generated by CONFIG REWRITE部分，自动发现了两个从节点：

原文件内容：

[redis@cjc-db-01 conf]$ cat redis_26379.conf
port 26379
logfile "/redis/log/sentinel_26379.log"
dir "/redis/26379/data"
pidfile "/redis/26379/pid/redis_26379.pid"
bind 0.0.0.0
protected-mode no
daemonize yes
sentinel monitor mymaster 192.168.126.128 6380 2
sentinel down-after-milliseconds mymaster 8000
sentinel auth-pass mymaster 111

启动后，文件内容：

[redis@cjc-db-01 conf]$ cat redis_26379.conf


port 26379
logfile "/redis/log/sentinel_26379.log"
dir "/redis/26379/data"
pidfile "/redis/26379/pid/redis_26379.pid"
bind 0.0.0.0
protected-mode no
daemonize yes
sentinel monitor mymaster 192.168.126.128 6379 2
sentinel down-after-milliseconds mymaster 8000
sentinel auth-pass mymaster 111
# Generated by CONFIG REWRITE
user default on nopass ~* &* +@all
sentinel myid d3c28e6d3315e1b63cefffc09de23131f67c9309
sentinel config-epoch mymaster 0
sentinel leader-epoch mymaster 0
sentinel current-epoch 0
sentinel known-replica mymaster 192.168.126.128 6381
sentinel known-replica mymaster 192.168.126.128 6380

启动其他哨兵

redis-sentinel /redis/conf/redis_26380.conf
redis-sentinel /redis/conf/redis_26381.conf

查看最终的哨兵配置文件

26379自动写入部分：

# Generated by CONFIG REWRITE
user default on nopass ~* &* +@all
sentinel myid d3c28e6d3315e1b63cefffc09de23131f67c9309
sentinel config-epoch mymaster 0
sentinel leader-epoch mymaster 0
sentinel current-epoch 0
sentinel known-replica mymaster 192.168.126.128 6381
sentinel known-replica mymaster 192.168.126.128 6380
sentinel known-sentinel mymaster 192.168.126.128 26380 b98812cd6e0b3e0a3a8527244cc09bb3a0c5f251
sentinel known-sentinel mymaster 192.168.126.128 26381 c56a629c526c80483792ecae8d80eba98796583b

26380自动写入部分：

# Generated by CONFIG REWRITE
user default on nopass ~* &* +@all
sentinel myid b98812cd6e0b3e0a3a8527244cc09bb3a0c5f251
sentinel config-epoch mymaster 0
sentinel leader-epoch mymaster 0
sentinel current-epoch 0
sentinel known-replica mymaster 192.168.126.128 6380
sentinel known-replica mymaster 192.168.126.128 6381
sentinel known-sentinel mymaster 192.168.126.128 26381 c56a629c526c80483792ecae8d80eba98796583b
sentinel known-sentinel mymaster 192.168.126.128 26379 d3c28e6d3315e1b63cefffc09de23131f67c9309

26381自动写入部分：

# Generated by CONFIG REWRITE
user default on nopass ~* &* +@all
sentinel myid c56a629c526c80483792ecae8d80eba98796583b
sentinel config-epoch mymaster 0
sentinel leader-epoch mymaster 0
sentinel current-epoch 0
sentinel known-replica mymaster 192.168.126.128 6380
sentinel known-replica mymaster 192.168.126.128 6381
sentinel known-sentinel mymaster 192.168.126.128 26380 b98812cd6e0b3e0a3a8527244cc09bb3a0c5f251
sentinel known-sentinel mymaster 192.168.126.128 26379 d3c28e6d3315e1b63cefffc09de23131f67c9309

可以看到，哨兵节点启动后，会在配置文件中自动写入从节点IP、端口信息，其他两个哨兵节点的IP、端口信息。

停止主库，查看哨兵变化

[redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK
127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6380,state=online,offset=317423,lag=1
slave1:ip=192.168.126.128,port=6381,state=online,offset=317423,lag=0
master_failover_state:no-failover
master_replid:fc7968519b15a9090407133791ea3551cdd67716
master_replid2:43bb3d9953e3af5b34a8c83193043c55ad45fb09
......
127.0.0.1:6379> shutdown save
not connected>

查看哨兵日志

tail -100f sentinel_26379.log
......
9569:X 08 Jul 2023 18:57:09.888 # +sdown master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:09.956 # +odown master mymaster 192.168.126.128 6379 #quorum 2/2
9569:X 08 Jul 2023 18:57:09.956 # +new-epoch 1
9569:X 08 Jul 2023 18:57:09.956 # +try-failover master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:09.966 # +vote-for-leader d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.268 # b98812cd6e0b3e0a3a8527244cc09bb3a0c5f251 voted for d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.270 # c56a629c526c80483792ecae8d80eba98796583b voted for d3c28e6d3315e1b63cefffc09de23131f67c9309 1
9569:X 08 Jul 2023 18:57:10.343 # +elected-leader master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.343 # +failover-state-select-slave master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.410 # -failover-abort-no-good-slave master mymaster 192.168.126.128 6379
9569:X 08 Jul 2023 18:57:10.463 # Next failover delay: I will not start a failover before Sat Jul  8 19:03:10 2023

从这里可以看到sentinel由于failover超时，导致切换延迟，并告知在几点之后进行下一次failover。

最新等待6分钟后仍然没有自动切换完成。

查看主从状态

[redis@cjc-db-01 conf]$ redis-cli -p 6380
127.0.0.1:6380> auth 111
OK
127.0.0.1:6380> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6379
master_link_status:down

[redis@cjc-db-01 conf]$ redis-cli -p 6381
127.0.0.1:6381> auth 111
OK
127.0.0.1:6381> info Replication
# Replication
role:slave
master_host:192.168.126.128
master_port:6379
master_link_status:down
master_last_io_seconds_ago:-1

查看哨兵状态

127.0.0.1:26379> info Sentinel
# Sentinel
sentinel_masters:1
sentinel_tilt:0
sentinel_running_scripts:0
sentinel_scripts_queue_length:0
sentinel_simulate_failure_flags:0
master0:name=mymaster,status=odown,address=192.168.126.128:6379,slaves=2,sentinels=3

启动原主库 6379

[redis@cjc-db-01 conf]$ redis-server redis_6379.conf
[redis@cjc-db-01 conf]$ redis-cli -p 6379
127.0.0.1:6379> auth 111
OK

启动后，master会自动加回原主库

127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6380,state=online,offset=6658,lag=1
slave1:ip=192.168.126.128,port=6381,state=online,offset=6658,lag=1
master_failover_state:no-failover
master_replid:361d438f4fae84a4c9501954f515d02cf31669ca
master_replid2:0000000000000000000000000000000000000000

调整权重

redis-cli -p 6379
redis-cli -p 6380
redis-cli -p 6381
config set slave-priority 100

再次关闭主库

查看，可以自动切换了

127.0.0.1:6379> info Replication
# Replication
role:master
connected_slaves:2
min_slaves_good_slaves:2
slave0:ip=192.168.126.128,port=6380,state=online,offset=63656,lag=0
slave1:ip=192.168.126.128,port=6381,state=online,offset=63510,lag=1

切换后，redis.conf配置文件会自动更新：

查看redis配置文件自动更新

cat redis_6381.conf

故障自动转移后，自动删除了：

slaveof 192.168.126.128 6379

自动添加了如下内容：

replicaof 192.168.126.128 6380


# Generated by CONFIG REWRITE
user default on #f6e0a1e2ac41945a9aa7ff8a8aaa0cebc12a3bcc981a929ad5cf810a090e11ae ~* &* +@all

查看6380节点

cat redis_6380.conf

自动删除了：

slaveof 192.168.126.128 6379

自动添加了

# Generated by CONFIG REWRITE
user default on #f6e0a1e2ac41945a9aa7ff8a8aaa0cebc12a3bcc981a929ad5cf810a090e11ae ~* &* +@all

###chenjuchao 20230708 17:00###

文章转载自IT小Chen，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

记一次Redis哨兵自动切换失败故障定位及处理

评论
